Leckey squiggles User Instructions page 5

Check parts
Congratulations on purchasing your
Squiggles Seating System. When opening
the boxes, cut the straps, taking care not
to cut through the tape as you may damage
some of the parts contained inside. All of
the parts will be contained in polythene
bags with each one clearly labelled.
Carefully remove them from the boxes
and check you have all the parts you have
ordered.
Safety First
Keep polythene bags away from children.
Some of the accessories will need to be
assembled before you attach the seat to
the base you have purchased. If you are
fitting the seat to a mobility base please
ensure you fit the interface plate to the
mobility base first. Instructions on how to
attach the interface to specific bases will
be provided with the interface plate. Once
you have checked all the components you
are then ready to assemble the Squiggles
Seating System and attach it to its base.
Multi-tool
A number of adjustments will require the use
of the multi-tool, which is supplied with each
seat and can be found in the back pack.
7.1 Locating the
backrest
The backrest will be folded down for
shipping. Raise it into the vertical position
and, while doing so, slide the inner tube (A)
into the receiving backrest pivot lock (B).
Secure the backrest in an upright position
by tightening the ratchet handle (C). Check
that it is secure and does not move when
pressure is applied.
B
A
C
7.2 Attaching the
shoulder support
Attaching the shoulder support will increase
the size of the Squiggles seat. Remove
the headrest bracket. This is studlocked
into position for safety reasons and will
require force to break. Insert the shoulder
support between the backrest and headrest
bracket. Reattach the headrest bracket
using the 2 sets of screws (A & B) provided.
A
B
