IDM-Energiesysteme TERRA 5 S/W H Technical Documentation And Installation Instructions
  1. Manuals
  2. Brands
  3. IDM-Energiesysteme Manuals
  4. Heat Pump
  5. TERRA 5 S/W H
  6. Technical documentation and installation instructions
IDM-Energiesysteme TERRA 5 S/W H Technical Documentation And Installation Instructions

IDM-Energiesysteme TERRA 5 S/W H Technical Documentation And Installation Instructions

For brine and ground water systems with navigator 1.0 control
Hide thumbs
Table of Contents

Advertisement

Quick Links

T E R R A S / W BA ( H ) 0 5 - 45
for Brine and Ground Water Systems
with Navigator
Heat pumps with freshwater technology
w w w . i d m - e n e r g i e . c o m
Te c h n i c a l d o cu m e n t a t i o n
I n s t a l l a t i o n i n s t r u c t i o n s
1.0 Control
®
Aus g ab e 15/09/11
T H E P O WE R FA M I LY

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TERRA 5 S/W H and is the answer not in the manual?

Questions and answers

Related Manuals for IDM-Energiesysteme TERRA 5 S/W H

Summary of Contents for IDM-Energiesysteme TERRA 5 S/W H

  • Page 1 Te c h n i c a l d o cu m e n t a t i o n I n s t a l l a t i o n i n s t r u c t i o n s T E R R A S / W BA ( H ) 0 5 - 45 for Brine and Ground Water Systems with Navigator...

  • Page 2: Table Of Contents

    1. Allgemeine Informationen Contents H E P O W E R F A M I L Y 1. G ENERAL INFORMATION 1.2. General information 1.3. Safety Instructions 1.4. Transport 1.5. Sound Emission 1.6. Construction drying and screed heating 1.7. Servicing and Maintenance 1.8.
  • Page 3 Contents H E P O W E R F A M I L Y 5. H EAT SOURCE 5.1. Brine Surfaces Collector 5.1.1. Description 5.1.2. Application range 5.1.3. Scope of delivery 5.2. Connection diagram 5.2.1. Laying diagram 5.3. Brine depth probe 5.3.1.

  • Page 4: General Information

    Regular maintenance as well as checking and servic- cialist staff and commissioned by a customer service ing of all system components guarantee its safe and company trained to do so by IDM-Energiesysteme economical operation in the long term. To achieve GmbH.

  • Page 5: Installation Room

    General information H E P O W E R F A M I L Y 1 .1 0 . I n st a l l at io n R o o m 1 . 1 1. P rote cti on of the en vi r onm en t Heatpumps are electrical equipment - The TERRA heat pumps should be made from high valuable materials,...

  • Page 6: Description

    2. Description 2. Allgemeine Informationen H E P O W E R F A M I L Y 2 .1 . D e s c ri p tio n 2 . 3 . Scop e of d e l i ve r y Heat pump with suction gas cooled scroll compressor - Heat pump unit with suction gas cooled scroll com- with generously sized stainless steel heat exchangers...

  • Page 7: Dimensions

    Description H E P O W E R F A M I L Y 2 . 5 . Di m e ns io n s SW 05-30: Vorderseite Linke Seite Rückseite 7 7 62 5 S/W 7 S/W 8 S/W 10S/W 12S/W 15S/W...

  • Page 8: Technical Data

    2. Allgemeine Informationen Description H E P O W E R F A M I L Y 2 .6 . Te c h ni c al dat a Technical Data TERRA S/W with R407C Type TERRA (BA) (HGL) Unit 5 S/W 7 S/W 8 S/W 10 S/W...
  • Page 9 Description H E P O W E R F A M I L Y 15 S/W 17 S/W 19 S/W 22 S/W 26 S/W 30 S/W 37 S/W 45 S/W 116/62/76 116/62/76 116/62/76 126/75/76 126/75/76 126/75/76 130/62/110 130/62/110 164/148 172/154 178/160 248/230 262/244...
  • Page 10 2. Allgemeine Informationen Description H E P O W E R F A M I L Y Technical Data TERRA S/W for Brine Application with R407C Type TERRA (BA) (HGL) Unit 5 S/W 7 S/W 8 S/W 10 S/W 12 S/W Heating performance for S0°C/W35°C EN 255 12.0 Heating performance for A2°C/W35°C...
  • Page 11 Description H E P O W E R F A M I L Y 15 S/W 17 S/W 19 S/W 22 S/W 26 S/W 30 S/W 37 S/W 45 S/W 14.9 17.2 19.6 22.1 24.2 27.9 34.8 41.8 14.81 17.10 19.48 21.97 24.15...
  • Page 12 2. Allgemeine Informationen Description H E P O W E R F A M I L Y Technical Data TERRA S/W H with R134A Type TERRA (BA) (HGL) 5 S/W H 7 S/W H 8 S/W H 10 S/W H 12 S/W H Unit Dimensions (H x W x D)
  • Page 13 Description H E P O W E R F A M I L Y 15 S/W H 17 S/W H 19 S/W H 22 S/W H 26 S/W H 230 S/W H 37 S/W H 45 S/W H 116/62/76 116/62/76 116/62/76 126/75/76 126/75/76...
  • Page 14 2. Allgemeine Informationen Description H E P O W E R F A M I L Y Technical Data TERRA S/W H for Brine Application with R134A Type TERRA (BA) (HGL) Unit 5 S/W H 7 S/W H 8 S/W H 10 S/W H 12 S/W H Heating performance for S0°C/W35°C EN 255...
  • Page 15 Description H E P O W E R F A M I L Y 15 S/W H 17 S/W H 19 S/WH 22 S/W H 26 S/W H 30 S/W H 37 S/W H 45 S/W H 9.40 10.9 12.5 14.0 16.1 18.7...
  • Page 16 2. Allgemeine Informationen Description H E P O W E R F A M I L Y Technical Data TERRA S/W for Ground Water Application with R407C Type TERRA (BA) (HGL) Unit 5 S/W 7 S/W 8 S/W 10 S/W 12 S/W Heating performance for W10/W35 EN 255 6.90...
  • Page 17 Description H E P O W E R F A M I L Y 15 S/W 17 S/W 19 S/W 22 S/W 26 S/W 30 S/W 37 S/W 45 S/W 19.30 21.50 25.30 27.90 32.50 37.40 46.40 56.30 19.10 21.30 25.00 27.60 32.20...
  • Page 18 2. Allgemeine Informationen Description H E P O W E R F A M I L Y Technical Data TERRA S/W H for Ground Water Application with R134A Type TERRA (BA) (HGL) unit 5 S/W H 7 S/W H 8 S/W H 10 S/W H 12 S/W H Heating performance for W10/W35 EN 255...
  • Page 19 Description H E P O W E R F A M I L Y 15 S/W H 17 S/W H 19 S/W H 22 S/W H 26 S/W H 30 S/W H 37 S/W H 45 S/W H 11.97 13.85 15.89 17.82 22.40...

  • Page 20: Operating Limits

    2. Allgemeine Informationen Description H E P O W E R F A M I L Y 2 . 7 . Op e ra t in g L i m i ts Application range for ground water heat pumps TERRA-S/W heat pumps may only be used with heat conducting media, brine or ground water.

  • Page 21: Heating Side Installation

    3. Heating side installation H E P O W E R F A M I L Y 3 .1 . I n st a l l atio n The installation of the TERRA heat pump must be undertaken in a frost-proof room by an approved specialist company.
  • Page 22 3. Allgemeine Informationen Heating side installation H E P O W E R F A M I L Y Heat pump TERRA-BA with IDM Hygienik In the case of this diagram, the Hygienik is used ex- clusively for preparing tapwater. The heating is supplied directly from the heat pump.
  • Page 23 Heating side installation H E P O W E R F A M I L Y Terra heat pump with IDM Hygienik with layer isolating plate The upper storage tank area is charged via a priority valve in the case of priority charging. The lower storage tank area is used as a heating buffer.
  • Page 24 3. Allgemeine Informationen Heating side installation H E P O W E R F A M I L Y Heat pump TERRA-BA with Hygienik and heat- ing buffer In the hydraulic diagram shown below, the Hygienik is used exclusively for tapwater preparation. The Hygienik is loaded via the priority valve.

  • Page 25: Installation Heating Side

    Heating side installation H E P O W E R F A M I L Y 3 .2 . I n st a l l atio n He at in g S ide The relevant laws, regulations and standards for ma- Oxygen diffusion chine room piping and for heat pump systems must also be observed.

  • Page 26: Electrical Installation

    4. Electrical installation 4. 4. 4. Electrical installation Allgemeine Informationen Allgemeine Informatio Allgemeine Informatio H E P O W E R F A M I L Y 4 . 1 . P o w e r su ppl y Electrical connection must be registered with the The heat pump is operated via the Navigator Control.

  • Page 27: Connection Diagram Electrical Components

    Electrical installation H E P O W E R F A M I L Y 4.2. Connection Diagram Electrical Components The central unit of the control system is located under Upon delivery, the control unit is not connected to the the cover.

  • Page 28: Disassembly Cover

    4. Allgemeine Informationen Electrical installation H E P O W E R F A M I L Y 4 .3 . D i sa ss e m bl y C o v e r Prior to the electrical connection, the plastic cover The system must only be connected to the must be removed.

  • Page 29: Heat Source Pump Connection

    Electrical installation H E P O W E R F A M I L Y 4 .5 . He a t S o u rce P u m p C o n ne c ti o n The line cross section for the connection of the brine This interference affects all systems, both biological circuit or ground water pump must be sized according (us as living beings) as well as technical electrical...

  • Page 30: Layout Of The Inputs On The Central Unit

    4. Allgemeine Informationen Electrical installation H E P O W E R F A M I L Y 4 .7 . L a y o u t o f t h e I n pu ts o n t he C e n tral U n i t Connections shown as grey with a grey connection Connections shown as black must be put in place if...

  • Page 31: Sensor Design

    Electrical installation H E P O W E R F A M I L Y 4 .7 . 1 . S e n s o r d e si g n 4 . 7 .3 . F l ow te m pe ra ture se ns or Sensor lines have a cable cross section of 0.75 mm²...
  • Page 32 4. Allgemeine Informationen Electrical installation H E P O W E R F A M I L Y 100PE external control 102PE external switch heating (0) / cooling (1) 104PE power blocking contact 106PE failure heating source circuite (groundwater plants only) 108PE failure heating source pump 110PE...

  • Page 33: Layout Outputs

    Electrical installation H E P O W E R F A M I L Y 4 .9 . L a y o u t O u t pu t s 4 .9 .1 . Tri ac o u t pu t s ( 1 0 - 1 2 ) : 10PE Ladepumpe 11PE...

  • Page 34: Digital Outputs 230V Ac (20 - 38)

    4. Allgemeine Informationen Electrical installation H E P O W E R F A M I L Y 4 .9 . 2. D igi t al o u t pu t s 2 3 0 V A C ( 2 0 - 3 8 ) : control heating source pump activation compressor IN 1...

  • Page 35: Connection Of The Mixers

    Electrical installation H E P O W E R F A M I L Y 4 .1 0. Co nn e ct io n o f t h e m i xe r s 4 . 1 3. Com p os i te s ig na l zone va l v e s The ESBE mixers are connected as three-pole ac- The composite signal zone valve setting generates cording to the wiring diagram enclosed.

  • Page 36: Heat Source

    • Brine circulation pump Notes: Brine/groundwater inlet - Only antifreeze approved by IDM-Energiesysteme GmbH may be used. - Brine circuit lines must be provided with steam Brine/groundwater diffusion-tight insulation in the event of the forma- outlet tion of condensation and the accumulation of ice (e.g.

  • Page 37: Connection Diagram

    Heat source H E P O W E R F A M I L Y 5 . 2 . Co nn e c tio n di a g r am connection pipes to heat pump on site! manifold length L PE-pipe Ø...

  • Page 38: Laying Diagram

    5. Allgemeine Informationen Heat source H E P O W E R F A M I L Y 5 .2 .1 . L a yi ng d i agr a m As an example for a heat pump TERRA 8 S/W with 4 pipe circuits, distributor connection in the cellar loop 1 loop 2 loop 3 loop 4 - In the area of the pipe junction the pipes must be...

  • Page 39: Installation Diagram

    PE-pipe Ø 25 1 1/4” connection set Notes - Only antifreeze approved by IDM-Energiesysteme - The brine circuit expansion vessel must be con- GmbH may be used. nected from the brine line upwards. - Brine circuit lines must be provided with steam - When fi...

  • Page 40: Ground Water Use

    5. Allgemeine Informationen Heat source H E P O W E R F A M I L Y 5 .4 . G ro u nd w ate r u se 5 . 4 .2 . Ap p l ic ati on ran ge Water inlet temperature: at least + 7 °C 5 .4 .1 .

  • Page 41: Installation Diagram

    Heat source H E P O W E R F A M I L Y 5 . 4 . 3 . I n st a l l at i o n di ag r am 5 . 4 . 4 . Ac c e s so ri e s To be provided by the customer: - Well pump with suitable output - Motor protection switch for the well pump...

  • Page 42: Commissioning

    6. Allgemeine Informationen 6. Commissioning H E P O W E R F A M I L Y 6 .1 . C o m m is si o n i n g i n f o r m ati o n 6 .

  • Page 43: C) Idm Energiesysteme Gmbh Installation Terra S/W

    H E P O W E R F A M I L Y (C) IDM ENERGIESYSTEME GMBH Installation TERRA S/W...
  • Page 44 Always there for you. I DM HEADQUARTERS IN EASTERN TYROL , AUSTRIA I DM HEADQUARTERS IN EASTERN TYROL , AUSTRIA IDM ENERGIESYSTEME GMBH IDM ENERGIESYSTEME GMBH Se b l a s 16 – 18 Se b l a s 16 – 18 A-9971 M a trei in O s t tiro l, Aus t ria A-9971 M a trei in O s t tiro l, Aus t ria Te l e p h on e +43(0) 4875.6172 - 0...

This manual is also suitable for:
