Te c h n i c a l d o cu m e n t a t i o n
I n s t a l l a t i o n i n s t r u c t i o n s
T E R R A C L 0 8 - 33 - H G L / BA (4 0 0 V )
T E R R A C L 0 8 - 33 - H G L- P / BA - P (4 0 0 V )
reve r s i b l e f o r c o o l i n g
wi t h N a vi g a t o r
1 .0 C o n t ro l
®
Aus g ab e 23/0 4/10
Heat pumps with freshwater technology
T H E P O WE R FA M I LY
w w w . i d m - e n e r g i e . c o m
Advertisement
Table of Contents
Related Manuals for IDM-Energiesysteme Terra CL 08-HGL
Summary of Contents for IDM-Energiesysteme Terra CL 08-HGL
- Page 1 Te c h n i c a l d o cu m e n t a t i o n I n s t a l l a t i o n i n s t r u c t i o n s T E R R A C L 0 8 - 33 - H G L / BA (4 0 0 V ) T E R R A C L 0 8 - 33 - H G L- P / BA - P (4 0 0 V ) reve r s i b l e f o r c o o l i n g...
-
Page 2: Table Of Contents
2. Allgemeine Beschreibung Contents H E P O W E R F A M I L Y 1. D ESCRIPTION 1.1. General Information 1.2. Description 1.3. Application range 1.4. Scope of delivery 1.5. Protection of the environment 2. T ECHNICAL DATA 3. - Page 3 Contents H E P O W E R F A M I L Y 7. H EATING ONNECTION 7.1. Requirement heating side connection 7.2. Terra CL-HGL heat pump with IDM Hygienik with separation plate 7.3. Terra CL-HGL heat pump with IDM Hygienik and heating buffer 7.4.
-
Page 4: Description
No liability is accepted and the guarantee company trained to do so by IDM-Energiesysteme becomes void in the event of damage caused for this GmbH. When working on the heat pump, the system reason. -
Page 5: Description
Allgemeine Beschreibung H E P O W E R F A M I L Y 1 . 2 . D es c r iptio n - Refrigerant collector and dryer - Thermostatic expansion valve The TERRA CL is an air-water heat pump with suction - Refrigerant inspection glass gas cooled scroll compressor with large multi-row Al/ - Refrigerant heat exchanger... -
Page 6: Technical Data
2. Allgemeine Beschreibung 2. Technical data H E P O W E R F A M I L Y TERRA CL 08-33 to EN 14511 Type Unit Heat output for A2/W35 [kW] 10.4 12.5 15.2 20.8 24.6 30.4 32.6 Heat output for A7/W35 [kW] 11.1 13.6... -
Page 7: Design
3. Design H E P O W E R F A M I L Y The dimensioning of an air/water heat pump should Example: be such that the bivalence point is between -3 and Single-family house in Germany -10 °C. This will help ensure that more than 90° of 4 persons the annual heating requirement is covered by the heat pump. - Page 8 3. Allgemeine Beschreibung Design H E P O W E R F A M I L Y Performance charts CL 33 4511 4511 CL 30 CL 25 CL 20 CL 15 CL 12 CL 10 CL 08 Outside temperature [°C] W45 EN1 4511 4511...
- Page 9 Design H E P O W E R F A M I L Y W55 EN1 4511 4511 CL 33 CL 30 CL 25 CL 20 CL 15 CL 12 CL 10 CL 08 Outside temperature [°C] (C) IDM ENERGIESYSTEME GMBH Installation instructions Terra CL...
-
Page 10: Dimensions
4. Allgemeine Beschreibung 4. Dimensions H E P O W E R F A M I L Y 4 . 1 . H e at P u mp C L Conduit bushings in Terra CL HGL: Conduit bushings in Terra CL BA: ... -
Page 11: Control Cabinet
Dimensions H E P O W E R F A M I L Y 4 . 2 . C ontr o l ca b in e t The control cabinet contains the complete heat pump control system. It is separate from the heat pump, mounted on a suitable wall with the frame screws provided. -
Page 12: Interior Installation
5. Allgemeine Beschreibung 5. Interior installation H E P O W E R F A M I L Y 5 . 1 . I ns tal la tio n I n s t r u ct io n s 5. 4. A i r Ro uti n g Interior installation of the heat pump is recommended. -
Page 13: Noise
Interior installation H E P O W E R F A M I L Y 5 . 6 . N ois e 5. 7. In stal l a ti on sp ac e Noise level in the installation room depends on - The TERRA heat pumps should be various factors such as room size, absorption installed in a frost-proof room. -
Page 14: Corner Installation
5. Allgemeine Beschreibung Interior installation H E P O W E R F A M I L Y 5 . 8 . C or n er i n st a lla t i on The ideal position for the heat pump has proved to Front side (operation and maintenance side) = be in a corner. -
Page 15: Customer Preparation
Interior installation H E P O W E R F A M I L Y 5 . 8 .2 . C u s tome r p r e p a r a t i on Exhaust air opening to right Exhaust air opening to left An even, solid installation surface must be selected. -
Page 16: Accessories For Corner Installation
5. Allgemeine Beschreibung Interior installation H E P O W E R F A M I L Y 5 . 8 .3 . A c ce s sor i es f or cor n e r in st a l la ti o n Pos. -
Page 17: Installation - Standard Air Duct
Interior installation H E P O W E R F A M I L Y 5 . 9 . I ns tal la tio n – S t a n d a r d a ir d u ct If there are no two external walls directly available for Option 2 installation, the air fl... -
Page 18: Accessories - Standard Air Duct
5. Allgemeine Beschreibung Interior installation H E P O W E R F A M I L Y 5 . 9 .1 . A c ce s sor i es – S t a n d a r d a ir d u ct Pos. -
Page 19: Customer Preparation - Option
Interior installation H E P O W E R F A M I L Y 5 . 9 .2 . C u s tome r p r e p a r a t i on – O p t i on 1 TERRA CL 08-15 Standard duct - Version 1 (90°) Type... - Page 20 5. Allgemeine Beschreibung Interior installation H E P O W E R F A M I L Y 5 . 9 .3 . C u s tome r p r e p a r a t i on – O p t i on 2 TERRA CL 08-15 Standard duct - Version 2 (180°) Type...
-
Page 21: Assembly Instructions - Standard Duct
Interior installation H E P O W E R F A M I L Y 5 . 9 .4 . A ss e mb ly i ns t r u ct io n s - St a n d a rd d u c t Outlet Panel Air Inlet Side The outlet panel is mounted using the four clamps... -
Page 22: Installation - Flexible Air Hose
5. Allgemeine Beschreibung Interior installation H E P O W E R F A M I L Y 5 . 1 0 . I ns tal la tio n – F le x ib l e a ir h os e This option is suitable for connecting to air openings at varied heights. -
Page 23: Customer Preparation - Flexible Air Hose
Interior installation H E P O W E R F A M I L Y 5 . 1 0. 1 . C u s to me r p r e p a r a t ion – F l ex i b l e a i r h ose Option 1 Option 2 TERRA CL 08-15... -
Page 24: Accessories - Flexible Air Hose
5. Allgemeine Beschreibung Interior installation H E P O W E R F A M I L Y 5 . 1 0. 2 . Ac ces s or ie s – F le x ib le a ir h ose Option 1 Option 2 Pos. -
Page 25: Assembly Instructions - Flexible Air Hose
Interior installation H E P O W E R F A M I L Y 5 . 1 0. 3 . As s emb ly in s t r u ct io n s – F l ex ib l e a i r h ose Air Inlet Side Outlet panels: The inlet-side wall connection is supplied separately. -
Page 26: Flexible Air Hose With Air Intake Box
5. Allgemeine Beschreibung Interior installation H E P O W E R F A M I L Y 5 . 1 1. Fle xi bl e a i r h os e w it h a ir in t a k e b ox Pos. -
Page 27: Conversion From Left To Right-Side Connection
Interior installation H E P O W E R F A M I L Y 5 . 1 2. C onv er s i on f r om le f t t o r ig h t - s ide c on n e c ti on The TERRA CL HGL is pre-fi... -
Page 28: Exterior Installation
6. Allgemeine Beschreibung 6. Exterior installation H E P O W E R F A M I L Y 6 . 1 . C u s tome r p r e p a r a t ion Foundation: Frost protection: The foundation should be level and stable. -
Page 29: Distances
Exterior installation H E P O W E R F A M I L Y 6 . 2 . D i s tanc es min. 2 m min. 2 m min. 0,8 m alternativ connection heating side condensation run off min. -
Page 30: Heating Side Connection
7. Allgemeine Beschreibung 7. Heating Side Connection H E P O W E R F A M I L Y 7 . 1 . R e qu ir e men t h e a t in g sid e con n e ct i on The relevant laws, regulations and standards for ma- Heating water quality chine room piping and for heat pump systems must... -
Page 31: Terra Cl-Hgl Heat Pump With Idm Hygienik With Separation Plate
Heating Side Connection H E P O W E R F A M I L Y 7 . 2 . Te r r a CL- HG L h e a t p u m p wi t h I DM H yg i en i k w i th se p ara ti o n p l a te During the priority charging procedure, the top area of This keeps the Hygienik at the right temperature whilst the storage tank is charged with the speed-controlled... -
Page 32: Terra Cl-Hgl Heat Pump With Idm Hygienik And Heating Buffer
7. Allgemeine Beschreibung Heating Side Connection H E P O W E R F A M I L Y 7 . 3 . Te r r a CL- HG L h e a t p u m p wi t h I DM H yg i en i k a n d h e ati n g b uf fe r The Hygienik is only used to prepare tapwater and during the priority charging procedure is charged with a speed-controlled charging pump at the set HGL... -
Page 33: Terra Cl-Ba Heat Pump With Hygienik And Separation Plate
Heating Side Connection H E P O W E R F A M I L Y 7 . 4 . Te r r a CL- BA h e a t p u m p w it h H y g ie n i k a n d se pa ra ti on pl a te RE(B) RE(A) HC(B) -
Page 34: Terra Cl-Ba Heat Pump With Hygienik And Without Separation Plate And Heating Buffer
7. Allgemeine Beschreibung Heating Side Connection H E P O W E R F A M I L Y 7 . 5 . Te r r a CL- BA h e a t p u m p w it h H y g ie n i k a n d w i th o ut se pa rati on p l ate a n d hea ti ng b uf fe r For larger systems (over approx. -
Page 35: Terra Cl-Ba Oil/Gas Boiler, Hygienik With Separation Plate And Heating Buffer
Heating Side Connection H E P O W E R F A M I L Y 7 . 6 . Te r r a CL- BA o il/ g a s b oil er, H yg ie n i k w i th se p a ra ti on pl a te a n d h e ati n g bu f f e r RE(B) RE(A) HC(B) -
Page 36: Terra Cl-Hgl-P Heat Pump With Process Reversal For Cooling And Idm Hygienik With Separation Plate
7. Allgemeine Beschreibung Heating Side Connection H E P O W E R F A M I L Y 7 . 7 . Te rr a C L-HG L- P w it h p ro ce ss r e v e rsa l f or c ool i ng an d H yg i e n i k w i th se pa rati on p l ate RG (B) RG (A) HK (B) - Page 37 Heating Side Connection H E P O W E R F A M I L Y 7 . 8 . Ter r a C L- BA -P w it h p r oce s s r e v e r sa l f or c ool i ng an d H yg i e n i k w i th se pa rati on pl ate RG (B) RG (A) HK (B)
-
Page 38: Electrical Connection
8. Electrical connection 8. Allgemeine Beschreibung H E P O W E R F A M I L Y 8 . 1 . P o we r su p p ly Electrical connection must be registered with the All systems are equipped with a start-up current limiter. relevant power supply company. -
Page 39: Connection Diagram Electrical Components
Electrical connection H E P O W E R F A M I L Y 8 . 2 . C onn ec tio n D i a g r a m E l e ct r ica l Co mp on e n ts The central unit of the control system is located in the Additional modules such as the internal expansion control cabinet. -
Page 40: Power Supply Connection
8. Allgemeine Beschreibung Electrical connection H E P O W E R F A M I L Y 8 . 3 . P o we r Su p p ly Con n e c t ion The connection of the primary circuit for the heat pump and for the electric immersion heater, as well as for the control power connection, is executed directly on the control cabinet of the CL heat pump. -
Page 41: Emc 41
Electrical connection H E P O W E R F A M I L Y 8 . 5 . E MC Please take note of the following with regard to this is- As far as we are concerned, everything has been sue: Electro-Magnetic Compatibility (EMC) demands done to protect the Navigator Control from interfer- additional work and expertise from all manufacturers... -
Page 42: Layout Of The Inputs On The Central Unit
8. Allgemeine Beschreibung Electrical connection H E P O W E R F A M I L Y 8 . 6 . L ay ou t o f th e I n p u t s on t h e Ce n t r a l Un i t The sensor inputs on the central unit are described in In each heat pump a standard sensor the electrical wiring. -
Page 43: Layout Outputs
Electrical connection H E P O W E R F A M I L Y 8 . 1 0 . L ay ou t O u tp u t s 8. 11. S yste m E ar thi n g Max. -
Page 44: Commissioning
9. Commissioning 9. Allgemeine Beschreibung H E P O W E R F A M I L Y 9 . 1 . C om mi ss i on in g in f or m a t io n Annual inspection and maintenance of the system by customer services is recommended, in particular with Before start-up of the TERRA heat pump, the heating regard to the preserving warranty claims. - Page 45 Commissioning H E P O W E R F A M I L Y (C) IDM ENERGIESYSTEME GMBH Installation instructions Terra CL...
- Page 46 9. Allgemeine Beschreibung Commissioning H E P O W E R F A M I L Y (C) IDM ENERGIESYSTEME GMBH Installation instructions Terra CL...
-
Page 47: Declaration Of Conformity
UID-Nr.: ATU 433 604 02 Declaration of Conformity IDM-Energiesysteme GmbH, Seblas 16-18, A-9971 Matrei East Tyrol, confirms that the device(s) referred to below in the version put into circulation by us satisfies/satisfy the requirements of the harmonized EC Directives, EC Safety Standards and product-specific EC Standards. - Page 48 Always there for you. I DM HEADQUARTERS IN EASTERN TYROL , AUSTRIA I DM HEADQUARTERS IN EASTERN TYROL , AUSTRIA IDM ENERGIESYSTEME GMBH IDM ENERGIESYSTEME GMBH Se b l a s 16 – 18 Se b l a s 16 – 18 A-9971 M a trei in O s t tiro l, Aus t ria A-9971 M a trei in O s t tiro l, Aus t ria Te l e p h on e +43(0) 4875.6172 - 0...
