- Page 1 Swimming pool heat pump Instruction manual – ECO series (Type ZVWX4013, ZVWX4023, ZVWX4033, ZVWX4053) Imported by: Zwembad BVBA Industrieweg 9 3190 Boortmeerbeek België www.harmopool.eu...
-
Page 2: Table Of Contents
Table of contents Introduction ..........................3 Characteristics ........................3 Specifications ........................... 4 Performance data ........................ 4 Dimensions of the heat pump ..................... 5 Installation ..........................6 Installation items ......................... 6 Location ..........................6 Distance ..........................7 Installation of the valve ....................... 7 Configuration ........................ -
Page 3: Introduction
Introduction This manual includes all necessary information about installation, debugging, discharging and maintenance. Read the manual carefully before you open or maintain the unit. The manufacturer of this product will not be held responsible for injuries or damage to the unit, as a result of improper installation, debugging or unnecessary maintenance. -
Page 4: Specifications
Specifications Performance data Unit Model ZVWX4013 ZVWX4023 ZVWX4033 ZVWX4053 14,0 Heating Capacity* 13600 20500 30700 47800 BTU/h 0,73 0,98 1,63 Power Input Maximum Pool Volume m 3 12,0 Running Current Min air temperature DegC 220- 220- 220- 220- Power Supply... -
Page 5: Dimensions Of The Heat Pump
Dimensions of the heat pump ZVWX4013 213 ZVWX4023 280 ZVWX4033 280 ZVWX4053 301 370 1010 1050 83... -
Page 6: Installation
Installation Installation items The factory only provides the heat pump unit; the other items that are mentioned in the illustration are to be provided by the user or installer. Attention! ○ All feeding of chemicals to the pool water has to be done downstream of the heat pump. -
Page 7: Distance
Distance Install the heat pump as close to the swimming pool as possible to minimize the loss of heat through the piping. Put it on a solid base and place the rubber blocks under the heat pump to eliminate vibrations. Installation of the valve The placement of the chlorinator, water balance equipment, and the placement of injectors of chemicals, are very important aspects of the installation. -
Page 8: Installation Of The Bypass
Installation of the bypass With the bypass set correctly, your heat pump will deliver its best performance. The bypass has to be built as shown below: Setting the valves of the by-pass: ○ Install the bypass with all 3 valves entirely open ○... -
Page 9: Electrical Wiring
Earthing the heat pump is required to protect you against electrical shocks caused by an eventual short circuit inside the heat pump. Model Power supply (Volt) Circuit breaker (A) Running current (A) Cable diameter (mm2) for cable length max 15m ZVWX4013 220-240 ZVWX4023 220-240 ZVWX4033 220-240 ZVWX4053 220-240 Values in this table are only guidelines. -
Page 10: Start-Up Procedure
Start-up procedure Start-up Procedure - after the installation is completed, you should follow these steps: 1. Set the by-pass valve 1 entirely open. Turn on your filter pump. Check for water leaks and verify flow to and from the pool. 2. -
Page 11: Guidelines
Guidelines Water chemistry Special care should be taken to keep the chemical balance of your swimming pool within limits: 7,0 – 7,8 Free chlorine 0,5 – 1,2 mg/l 80 – 150 mg/l (10°F – 30°F) Salt max 8 g/l Attention! ○... -
Page 12: Spring Start-Up
Spring start-up If your heat pump has been winterized, perform the following steps when starting the system in the spring: Inspect the system for any debris or structural problems. Connect the water inlet and outlet unions firmly. Turn on the filter pump to supply water to the heat pump. Adjust the by-pass to allow water flow through the heat pump. -
Page 13: Maintenance And Inspection
Maintenance and inspection Maintenance o Check the water supply to the unit often. Low water flow and air entering into the system should be avoided, as this will diminish the units’ performance and reliability. You should clean the pool/spa filter regularly to avoid damage to the unit as a result of the dirty or clogged filter. -
Page 14: Problems And Solutions
Problems and solutions Problem Cause Solution Heat pump not running 1. No electricity 1. Switch on the electrical power 2. Heat pump not turned on 2. Switch on the heat pump 3. Water pump not running 3. Switch on the water pump 4. -
Page 15: Checklist
Checklist... -
Page 16: Warranty
Warranty...
