- Page 1 Swimming Pool Heat pump Instruction manual – Harmo POWERPACK series (Type ZVWX3103, ZVWX3113, ZVWX3123, ZVWX3128) Imported by : Zwembad BVBA Industrieweg 9 3190 Boortmeerbeek België www.harmopool.eu...
-
Page 2: Table Of Contents
Table of contents Introduction ................................... 3 Characteristics ................................3 Safety instructions ................................. 3 Specifications ................................. 4 Installation ..................................5 Accessories needed for the installation ........................5 Location ..................................5 Distance ..................................6 Installation of the pool system ..........................7 Installation of the bypass ............................7 Electrical wiring ................................. -
Page 3: Introduction
Introduction Read the manual carefully before you open or maintain the heat pump. The manufacturer of this product will not be held responsible for injuries or damage to the unit, as a result of improper installation, debugging or unnecessary maintenance. It is essential that the instructions of this manual are followed at all times. Qualified personnel must install the heat pump. -
Page 4: Specifications
Safety test Use the wiring diagram in the manual. Plug into the socket. Press the RESET button. The indicator "ON" is highlighted. Press the "TEST" button. The indicator "ON” will be turned off. Press the RESET button in order to use the device. Do not use if above test fails. Specifications Product code: ZVWX3103... -
Page 5: Installation
Installation Accessories needed for the installation The factory only provides the heat pump. Other necessary items that could be mentioned in the illustrations are to be provided by the user or installer. Attention! Please follow the following steps when installing the heat pump: ○... -
Page 6: Distance
Distance Install the heat pump as close to the swimming pool as possible to minimize the loss of heat through the piping. Put it on a solid base and place some rubber blocks under the heat pump to eliminate vibrations. Normally, the heat pump is installed within a 7,5 meter radius of the pool. -
Page 7: Installation Of The Pool System
Installation of the pool system Installation of the bypass With the bypass set correctly, your heat pump will deliver its best performance. The bypass has to be built as shown below: Setting the valves of the by-pass: ○ Install the bypass with all 3 valves entirely open ○... -
Page 8: Electrical Wiring
Electrical wiring Verify the local power supply and the operating voltage of the heat pump. It is recommended to use a separate circuit breaker (slow type – D curve) for the heat pump together with the proper wiring characteristics. The current to the heat pump should only be applied when the filter pump is running. -
Page 9: Winter-Ready
○ Failure to keep the swimming pool water between above limits will void the warranty ○ When the concentration of one or more products mentioned above becomes too high, irrevocable damage to your heat pump may occur. Make sure that you always install water treatment equipment after the heat pump. -
Page 10: Display Settings
The heat pump will produce condensation (water) operating. The heat pump base is designed to allow the condensation to exit through the bottom drain port. The condensation will increase as the outdoor air humidity level increases. Check the following at regular intervals to ensure proper condensate drainage: Visually inspect and clear the bottom drain port of any debris that could clog the port. -
Page 11: Clock Settings
Press "M" again "8" "1 " Press “SET” to enter Mode setting, press to alter. Press “SET” again to confirm. Press "M" again "9" "0 " Press “SET” to enter water pump setting, press to alter. Press “SET” again to confirm. Press "M" again "A" "40 " Press “SET” to enter return water temp. setting, press alter. -
Page 12: Functions Of The Display
Functions of the display o Under standby status, press M button 5s to enter Operation Parameter setting interface;" " o Press＂M＂again to start setting (parameter from 00-D,see the Operation Parameter Table); o Under parameter setting, press to set data; o Please note no motion on the display for 10s,the LCD will display water-in/water out temp.(under running)or ambient temp.(under standby status) o Under running status, you can press M"... -
Page 14: Current Status
Current status Ambient temp. Under running status, press “M” 5 seconds to check the status of the unit. You can check water- in/water out temp, condenser temp and ambient temp, please note no motion on the display for 10s, the LCD will display water-in/water out temp/ (under running) or1ambient temp. (unit stops). Maintenance o Check the water supply to the unit often. -
Page 15: Appendix
Appendix...
