Vendor: S000083
ASSEMBLY INSTRUCTIONS
SORRENTO 2 DOOR 1 DRAWER WARDROBE
IMPORTANT: READ THESE INSTRUCTIONS CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE OR USE YOUR
SORRENTO 2 DOOR 1 DRAWER WARDROBE
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.
HEALTH & SAFETY:
DO NOT use this item if any parts are missing, damaged or worn.
DO NOT use this item unless all fixings are secured.
Please keep small parts out of reach of children.
Always use on a level, even surface.
CARE & MAINTENANCE:
Assemble in the room of use.
Assembly should be carried out with this item laying flat, not standing upright.
Assemble on a soft, clean surface to prevent damages.
To remove the printed numbers on the pieces, use the eraser provided.
Periodically check all screws & fixings to ensure they are secure.
DO NOT push the item as this will damage the legs.
Always lift the item with two people to reposition.
Keep any sharp objects away from the item.
www.birlea.com
Page 1 of 9

Advertisement

loading
Need help?

Need help?

Do you have a question about the Sorrento and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Birlea Sorrento

Summary of Contents for Birlea Sorrento

  • Page 1 Vendor: S000083 ASSEMBLY INSTRUCTIONS SORRENTO 2 DOOR 1 DRAWER WARDROBE IMPORTANT: READ THESE INSTRUCTIONS CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE OR USE YOUR SORRENTO 2 DOOR 1 DRAWER WARDROBE PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE. HEALTH & SAFETY: DO NOT use this item if any parts are missing, damaged or worn.
  • Page 2 Vendor: S000083 Parts List 1 – Left Panel x 1 2 – Right Panel x 1 3 – Back Support Panel x 2 4 – Top Panel x 1 5 – Base Panel x 1 6 – Drawer x 1 7 –...
  • Page 3 Vendor: S000083 Hardware List Part Description 8 x 25 mm Plastic Dowel M6 x 60 mm JCBC M3.5 x 16 mm CSK M4 x 25 mm CSK 65 mm Allen Key Mini Fix Bolt Mini Fix Housing 22mm Handle Screw 38mm Handle Screw 20 mm CSK Screw Handle...
  • Page 4 Vendor: S000083 Step 1: Insert hardware parts A and F using a small mallet and a screwdriver (not provided). Attach the AC2 hardware part to the left panel (1) and right panel (2) using hardware part D and a screwdriver (not provided).
  • Page 5 Vendor: S000083 Step 2: Insert hardware part A to the back support panels (3) using a small mallet (not provided). Join the left panel (1) to the right panel (2) using the back support panels (3) and insert hardware part AB. You will need to use hardware parts F and G with a screwdriver (not provided).
  • Page 6 Vendor: S000083 Step 3: Attach the top panel (4) and bottom panel (5) using hardware parts A, B and E. DO NOT use any power tools as this may damage the frame and will invalidate any claim Page 6 of 9...
  • Page 7 Vendor: S000083 Step 4: Insert the drawer (6). DO NOT use any power tools as this may damage the frame and will invalidate any claim Step 5: Attach the large back panels (7) and small back panel (8) using hardware part C and a screwdriver (not provided).
  • Page 8 Vendor: S000083 Step 6: Secure the drawer (6) in place using hardware part D with a screwdriver (not provided). Attach hardware part AA using hardware part I and a screwdriver (not provided). DO NOT use any power tools as this may damage the frame and will invalidate any claim Step 7: Attach hardware part AC1 to the left door (9) and right door (10) using hardware part C, then attach hardware part AA using hardware part H and a screwdriver (not provided).

  • Page 9: Additional Information

    • If you have any issues with your item please contact the retailer directly you purchased it from who will be able to resolve any issues with Birlea. • Why don’t you send us photos of your assembled furniture to info@birlea.com...
