Schartec Porte 300 User Manual

Swing gate opener 24v dc
Hide thumbs Also See for Porte 300:
Table of Contents

Advertisement

Quick Links

Porte 300 Users Manual
Swing Gate Opener
24V DC
for residential use only
Signal Light
Push-button
Control Box
Gate 2
Gate 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Porte 300 and is the answer not in the manual?

Questions and answers

Related Manuals for Schartec Porte 300

Summary of Contents for Schartec Porte 300

  • Page 1 Porte 300 Users Manual Swing Gate Opener 24V DC for residential use only Signal Light Push-button Control Box Gate 2 Gate 1...

  • Page 2: Table Of Contents

    Electric Lock and Stopper-Plate Installation Notes on use of the operator Tools needed for the installation 3.1.1 3.1.2 Operator components and their installation Power Supply 3.2.1 Notes on Power Supply Installation 3.3.1 Preparation for motors 3.3.2 Motors installation Technical Data Porte 300...

  • Page 3: Important Safety Information

    1. Important Safety Information 1.1 Intended Use The Schartec Porte 300 swing gate opener is intended exclusively for the operation of smooth-running swinging gates in private, non-commercial areas. The maximum permissible gate size and maximum weight must not be exceeded. The gate must be easy to open and close by hand. Regional wind loads must be taken into account when using gate fillings/panels (EN 13241-1).
  • Page 4 1.7 Further important information 1. Please read and follow all safety instructions and installation recommendations. 2. The gate operator has been designed and manufactured according to local regulations. The installer must be familiar with local regulations regarding the installation of the swing gate operator. 3.

  • Page 5: Product Description And Application

    2. Product description and application 2.1 Application This gate operator is suitable for private entrance gates with 2-leafe swinging gates. The power supply for commissioning the system is 230 V. For manual operation of the swing gate, the two motors must be unlocked with the enclosed key.

  • Page 6: Electromechanical Gear Motors

    2.3.1 Electromechanical geared motors Figure 3 Porte 300 The swing gate operators consist of a 24 V DC motor and a worm gear. The motors are attached to the gate and pillar with front and rear brackets. The manual release keys are required for manual unlocking.

  • Page 7: Key Switch

    3.1 Notes on use of the operator The Porte 300 swing gate operator is designed for a maximum gate weight of 300 kg (per leaf) and a maximum gate width of 3 meters (per leaf). The opening angle is up to 110°. These maximum values must...

  • Page 8: Tools Needed For The Installation

    3.1.1 Tools needed for Installation Please make sure that the tools listed below are available for installation. Figure 11 3.1.2 Operator components and their installation Figure 12 shows an example installation with cable management including all possible components. Cables for accessories are not included. Figure 12 3.2 Mains Connection (Power Supply) The mains connection may only be carried out by a qualified person.
  • Page 9 7) Check the dimensions listed below. Figure 13 Porte 300 8) Make sure that there is enough space when opening the gate leaves. Figure 14 (Aerial View) 150 mm (max)
  • Page 10 9) If the gate opens to the outside, leave a distance of 70 mm between the motor pivot point and the mounting bracket. Figure 15 (Aerial View) Porte 300 70 mm 10) Use the opening angle of the gate to determine the correct installation dimensions (see also Figure 17)
  • Page 11 3.3.2 Installation of the Motors 1) Choose the correct mounting position of the motors. 2) Check that the mounting surfaces for the brackets are level. 3) Insert the cables for the power supply to the motors. 4) Install the motor mounts as shown in Figure 18. 5) Remove the two screws on the engine and remove the cover as shown in Figure 19.
  • Page 12 12) Lift the motor and insert the screw into the front motor mount. 13) Remove the motor cover, loosen the screw and remove the bolt. See Figure 25. Now lift the rear of the motor and move the gate until the motor can be locked to the rear bracket as shown in Figure 26. Slide the bolt through the hole provided in the motor and through the rear bracket.

  • Page 13: Power Supply

    4. Technical data Porte 300 Motor 24 V DC with mechanical unlocking release Gear Type Worm Gear Peak Force 3000 N Motor Travel Length 350 mm Power Supply 24 V DC Max. Working Current 4 A for max. 10 seconds Max.
