For the latest User Installation Guide please visit: www.ergotron.com
User's Guide - English
Guía del usuario - Español
Manuel de l'utilisateur - Français
Gebruikersgids - Deutsch
Benutzerhandbuch - Nederlands
Guida per l'utente - Italiano
Användarhandbok - svenska
ユーザーガイ ド : 日本語
用户指南 : 汉语
888-24-344-G-00 rev. C • 07/16
< 15lbs. (6.8kg)
CAUTION: DO NOT EXCEED
MAXIMUM LISTED WEIGHT
CAPACITY. SERIOUS INJURY
OR PROPERTY DAMAGE MAY
OCCUR!
16"
406mm
User's Guide
LearnFit ®
1 of 7
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Ergotron LearnFit 24-481-003
Summary of Contents for Ergotron LearnFit 24-481-003
- Page 1 MAXIMUM LISTED WEIGHT CAPACITY. SERIOUS INJURY OR PROPERTY DAMAGE MAY OCCUR! 16" 406mm For the latest User Installation Guide please visit: www.ergotron.com User's Guide - English Guía del usuario - Español Manuel de l’utilisateur - Français Gebruikersgids - Deutsch Benutzerhandbuch - Nederlands Guida per l’utente - Italiano...
-
Page 2: Tools Needed
Components Tools Needed 888-24-344-G-00 rev. C • 07/16 2 of 7... - Page 3 Remove base orientation indicator from base. Back Front Front Partially insert riser into base. < 10lbs. (4.5kg) 3°- 7° Rock riser from side to side while inserting. Indicator arrows will remain visible. Front 888-24-344-G-00 rev. C • 07/16 3 of 7...
- Page 4 Attach work surface and press down. Remove cap. Indicator arrows should be completely hidden. Lift up on the work surface to make sure it is securely attached to the base. 888-24-344-G-00 rev. C • 07/16 4 of 7...
- Page 5 Lift brake release lever to raise and lower riser. Loosen, but do not remove 2 screws to lift and lower hook to desired height. 180˚ 888-24-344-G-00 rev. C • 07/16 5 of 7...
-
Page 6: How To Disassemble
How to Disassemble To remove worksurface, push tab with a tool while removing. (Hex wrench suggested, max diameter 4mm) NOTE: Requires two people. Attach cap. 888-24-344-G-00 rev. C • 07/16 6 of 7... - Page 7 Blink - Blink often to avoid dry eyes. Break • 2 to 3 minutes every 20 minutes • 15 to 20 minutes every 2 hours. For local customer care phone numbers visit: http://contact.ergotron.com NOTE: When contacting customer service, reference the serial number.
