Before You Begin Assembly
Please read the following Instructions carefully before attempting to assemble these Ceiling
Hung rings.
Please note that under no circumstances should children be permitted to undertake assembly of
Ceiling Hung Rings. Only adults, coaches or other qualified persons should undertake the assembly
operation.
You have received One (1) shipping Carton containing the following components:
2 - Swivels
2 - Cable Thimbles
6 - Wire Rope Clips (Cable Clamps)
2 - Rings with straps and quick link attached
2 - Cables with thimble in fixed loop on one end for attachment to Ring Strap's quick link
Tools Required:
1 - Pliers for cotter pin assembly
2 - ¾" Wrenches
2 - ½" Wrenches
1 - Carpenters level
1 - Knife to strip plastic off Cable
1 - Wire rope cutter to cut excess cable
If your S/A Sport Beam Clamps have already been installed you are ready to begin assembly. If not,
Refer to 110 Beam Clamp Assembly instructions.
108 - Ceiling Hung Rings Instructions Rev1 8920071
SA Sport (Canada)
135 Forestview Road
P.O. Box 40
Orillia, Ontario
Canada L3V 6H9
Telephone: (705) 325-2274
Fax:
Toll Free: (800) 563-6479
108 - CEILING HUNG RINGS
Sales & Service
(705) 325-1485
SA Sport (U.S.A.)
7879 Will Rogers Blvd.
Fort Worth, Texas
USA 76140
Telephone: (817) 536-3366
Fax:
(817) 536-3006
Toll Free: (800) 331-8068
5
1/
Advertisement
Related Manuals for SA Sport 108 Ceiling Hung Rings
Summary of Contents for SA Sport 108 Ceiling Hung Rings
- Page 1 Sales & Service SA Sport (Canada) SA Sport (U.S.A.) 135 Forestview Road 7879 Will Rogers Blvd. P.O. Box 40 Fort Worth, Texas Orillia, Ontario USA 76140 Canada L3V 6H9 sasportonline.com Telephone: (705) 325-2274 Telephone: (817) 536-3366 Fax: (705) 325-1485 Fax:...
- Page 2 Swivel Attachment to Beam Clamps 1. Remove the bolts, washer, Cotter pin & Castle Nut from the underside of the Beam Clamps 2. Insert the top rounded end of the swivel between the two hanger brackets on the underside of the beam Clamp.
- Page 3 Cable Attachment to Swivel 1. Take one cable with plastic coating removed, as per figure D, and feed it around the Thimble which is inserted on the base of the Swivel as shown in figure B. Depending on height requirement, see figure C, it may be necessary to strip more plastic off. Note: When attaching wire rope clips, ensure the base is on the live end of the cable &...
- Page 4 Leveling & Height Adjustment 1. The official F.I.G. height spec. is 280 cm ± 5 mm. This measurement is taken from the floor to the inside bottom of the ring, Figure C. 2. Place a carpenters level through the rings & hang a weight from the centre to stretch cables. 3.
- Page 5 Warning Any activity involving motion or height creates the possibility of serious injury including permanent paralysis and even death, from landing or falling on the neck, head, or other parts of the body. You assume a risk of serious injury in using this equipment. However, this risk can be reduced by strictly following these rules at all times.
