5161 – Performance Series Competition Parallel Bars
"5161 - Performance Series Competition Parallel Bars" Instructions #8920002 Rev 1
September 21, 2009
Sales & Service
SA Sport (Canada)
135 Forestview Road
P.O. Box 40
Orillia, Ontario
Canada L3V 6H9
Telephone: (705) 325-2274
Fax:
(705) 325-1485
Toll Free: (800) 563-6479
SA Sport (U.S.A.)
4608 Fairlane Avenue
Fort Worth, Texas
USA 76119
Telephone: (817) 536-3366
Fax:
(817) 536-3006
Toll Free: (800) 331-8068
Advertisement
Related Manuals for SA Sport 5161
Summary of Contents for SA Sport 5161
- Page 1 Telephone: (705) 325-2274 Telephone: (817) 536-3366 Fax: (705) 325-1485 Fax: (817) 536-3006 Toll Free: (800) 563-6479 Toll Free: (800) 331-8068 5161 – Performance Series Competition Parallel Bars “5161 - Performance Series Competition Parallel Bars” Instructions #8920002 Rev 1 September 21, 2009...
- Page 2 Rails are guaranteed for one year from date of invoice. Damage or breakage, which in the opinion of SA Sport is caused by misuse or mishandling, is not covered by warranty Please read carefully the following instructions before assembling and using your new equipment.
- Page 3 2. Next, open the two upright base cartons. One of the cartons will be marked as containing the hardware Bag. Pg. 3 “5161 - Performance Series Competition Parallel Bars” Instructions #8920002 Rev 1...
- Page 4 If necessary, the upright angle can be adjusted (in the direction of the length) by using the installed Upright leveling screws. To do this, first loosen the 3 Flat head screws. Next, using the Pg. 4 “5161 - Performance Series Competition Parallel Bars” Instructions #8920002 Rev 1...
- Page 5 2. Ensure the locking T-handle is fully opened, V-notch spread apart, by turning T-Handle counter clockwise. WARNING: Be aware of the potential pinch hazard where the adjusting tube and upright tube meet when they are slid together. Pg. 5 “5161 - Performance Series Competition Parallel Bars” Instructions #8920002 Rev 1...
- Page 6 Note: You May have to rotate the Safety Lock until it lines up with the holes in the adjusting shaft in order for the Lock Pin to engage with a Hole in the Adjusting shaft. 10. Tighten the T-handle on each Upright! Pg. 6 “5161 - Performance Series Competition Parallel Bars” Instructions #8920002 Rev 1...
- Page 7 5. Lock the Adjusting Shaft by rotating the T-handle in a clockwise direction until tightened firmly. WARNING: Never attempt to use this apparatus without locking the T-Handles. Pg. 7 “5161 - Performance Series Competition Parallel Bars” Instructions #8920002 Rev 1...
- Page 8 1. Remove the Hex Head Cap Screws from each Pivot arm. 2. Slide the Carriers onto the Pivot Arm. 3. Replace the washers and screws and tighten securely. Pg. 8 “5161 - Performance Series Competition Parallel Bars” Instructions #8920002 Rev 1...
- Page 9 Bars in position. The other person will lift the Handle. Remember, it will move fast on the downside! Keep fingers well clear. As the Bars lower to the floor, keep feet well clear of the Base. Pg. 9 “5161 - Performance Series Competition Parallel Bars” Instructions #8920002 Rev 1...
- Page 10 6. Always inspect this equipment for loose fittings and parts. Replace any worn, defective or missing parts. 7. Always inspect this equipment for improper or unsafe installation. If in doubt, do not use this equipment. Pg. 10 “5161 - Performance Series Competition Parallel Bars” Instructions #8920002 Rev 1...
