ASSEMBLY AND CARE INSTRUCTIONS
PERFORMANCE SERIES SINGLE BAR TRAINER
VERSION: 8920019 (Revised 06/15)
SA Sport – Canada and International
135 Forestview Road, PO Box 40
Orillia, Ontario, Canada L3V 6H9
Toll-Free:
Telephone: (705) 325-2274
Fax:
info@spiethanderson.com
SALES AND SERVICE
sasportonline.com
(800) 563-6479
(705) 325-1485
228
SA Sport – USA
104 Nu Energy Drive, Suite 1
Aledo, Texas, USA 76008
Toll-Free:
Telephone: (817) 536-3366
Fax:
sales@sasportusa.com
(800) 331-8068
(817) 536-3006
Advertisement
Related Manuals for SA Sport 228
Summary of Contents for SA Sport 228
- Page 1 PERFORMANCE SERIES SINGLE BAR TRAINER VERSION: 8920019 (Revised 06/15) SALES AND SERVICE sasportonline.com SA Sport – Canada and International SA Sport – USA 135 Forestview Road, PO Box 40 104 Nu Energy Drive, Suite 1 Orillia, Ontario, Canada L3V 6H9...
- Page 2 228 PERFORMANCE SERIES SINGLE BAR TRAINER Assembly Instructions The Performance Series Single Bar Trainer requires 70% less anchor space than a conventional single bar and has platforms on the inside and outside of the uprights. The inside platform can be removed quickly and easily when needed.
-
Page 3: Assembly Instructions
228 PERFORMANCE SERIES SINGLE BAR TRAINER Assembly Instructions 1. Assembly Instructions 1.1. Single Bar Trainer pre-assembly Do not climb or stand on the bases until they are anchored to the floor. 1. Place the Upright Bases in the approximate location where they will be used. - Page 4 228 PERFORMANCE SERIES SINGLE BAR TRAINER Assembly Instructions 3. Slide the pre-assembled upright tubes into the base tubes. 4. Place bases where they will be permanently located. 5. Remove the Lock Pin on the carrier and lift off hold down bracket (See photos below).
- Page 5 228 PERFORMANCE SERIES SINGLE BAR TRAINER Assembly Instructions 1.2. Installing Concrete Anchors To determine anchor locations, please refer to the following section for your specific equipment to be anchored. Tools Required (customer supplied): • Tape measure • Anchor setting tool or punch with a ”...
- Page 6 228 PERFORMANCE SERIES SINGLE BAR TRAINER Assembly Instructions 1.3. Anchoring Bases FOR ONE BASE ONLY: a. Mark the center hole and the two corner holes (Use a Marker, a Pencil or Chalk). b. See floor anchor installation instructions on previous page.
- Page 7 228 PERFORMANCE SERIES SINGLE BAR TRAINER Assembly Instructions 1.4. Installing Cable Floor Anchors 1. Begin by marking out the locations for the cables anchors as shown in the diagram below. 48" 48" 48" 48" 2. Drill and install anchors as explained in the anchor instructions on page 5.
-
Page 8: Height Adjustment
228 PERFORMANCE SERIES SINGLE BAR TRAINER Assembly Instructions 1.5. Changing Rails Install the rail into the carriers as shown in the following photos. Step 1: Remove the locking Step 3: Replace hold down bracket Step 2: Place rail into pin and hold down bracket. - Page 9 228 PERFORMANCE SERIES SINGLE BAR TRAINER Assembly Instructions 2. SAFETY WARNING Any activity involving motion or height creates the possibility of serious injury including permanent paralysis and even death, from landing or falling on the neck, head, or other parts of the body.
