- Page 1 Camera Installation Guide Please read before carrying out any installations.
- Page 2 AUX CAMERA Smart Witness KP1s Standard Camera Kit LEAD CABLE RECORDER Power connector & optional aux camera connection TAPE ONCE FITTED STICK TO VEHICLE PLASTICS KP1s Camera unit with cable ties, windscreen adhesive & access key Note – The part of the camera that mounts to the windscreen (under the adhesive sticker) is also the GPS Antenna.
- Page 3 Smart Witness KP1s - Wiring Looms KP1-INT1-s -Advanced KP1-PKW - Standard power loom power loom. for 2 wire ignition live installs Allows for a defined run on period where power to the camera is maintained after ignition is turned off.
- Page 4 DO NOT CONNECT TO EARTH CABLE OR ANY OTHER SUPPOSED EARTH, MUST BE TO THE CORRECT EARTH Please ensure the live power supplies are not connected to CANBUS or auxiliary components (e.g. Hiab, tailgate) fitted to the vehicle.
- Page 5 Please ensure the live power supplies are not connected to CANBUS or auxiliary components (e.g. Hiab, tailgate) fitted to the vehicle.
- Page 6 Make & model of vehicle o Installation date / time o Vehicle mileage o Engineers full name KP1-Serial Number & DRID Labels Serial Number – KSYS71600889 DRID Number – KSMA71600283 This camera will show on platform as TDH600889 DRID number (TDH followed by last 6 digits of the serial number)
-
Page 7: Camera Positioning
Camera Positioning • Van / Car Camera should be positioned where it • meets the following criteria;- o Fix to windscreen, ideally to the Does not cause any obstruction to the driver. left of the rear view mirror, but Is within the arc of the wipers not on any part of the screen The lens is not obstructed by a wiper blade when wipers are not in use. - Page 8 Calibration] button for two seconds. This G-Sensor calibration is only needed the first time KP1 is used. All lights will go off. Turn the ignition off & back on to repower the camera. It will go through the boot up process, finishing with a solid blue &...
- Page 9 Commissioning Process Once camera has a solid blue & green LED log on to the following URL. http://www.telematicsserver.com/login.aspx Login Credentials. Company - DHINSTALL User Name – INSTALL Password – install...
- Page 10 Commissioning Process Once logged in the ‘latest location’ page will open. This window with show a map with the latest location of each camera that has been configured for installation. Any camera that has been active today will show in the left window, those that have not been active today will be visible on the right.
- Page 11 Commissioning Process The camera you’ve installed should now be visible on the left (active today) window. If this is not the case, check installation & contact the DataHub. See contacts page.
- Page 12 Commissioning Process The camera you’ve installed should now be visible on the left (active today) window. Click the icon next to the specific camera (TDH600011) This will load a new view.
- Page 13 Commissioning Process You will see in the activity detail the 1 min call ins from the camera since it was powered on. This will also show the GPS location. If it does not please check positioning of camera. Press the panic button on the camera & hold for 2 secs. This will generate a series of still images to be sent to the server.
- Page 14 Commissioning Process Within a few minutes you will see a camera icon appear in the activity detail window. Click on the camera & this will load a film reel at the bottom of the page...
- Page 15 Commissioning Process Ensure the still images provide a clear view ahead and are not obstructed, as shown above. If not reposition camera & repeat panic procedure. Commissioning complete – Power off vehicle, all LED’s should now turn off. Complete documentation as specified earlier & email to support@thedatahub.com...
- Page 16 The DataHub Contacts The DataHub 0121 713 4595 support@thedatahub.com Russell Ashford (Operations Director) 07738615985 r.ashford@thedatahub.com Harv Singh 07908544403 h.singh@thedatahub.com...
