OnvianTech IPC4300ADH User Manual

Ip camera tester
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Enlarged version
IP camera tester
USER MANUAL
（IPC1.03）

Advertisement

Table of Contents
loading

Summary of Contents for OnvianTech IPC4300ADH

  • Page 1 IP camera tester USER MANUAL （IPC1.03）...
  • Page 2 Thank you for purchasing the IP camera tester. Please read the manual before using the IP camera tester and use properly. For using the IP camera tester safely, please first read the「Safety Information」carefully in the manual. The manual should be kept well in case of reference. Keep the S/N label for after-sale service within warranty period.

  • Page 3: Table Of Contents

    Content Safety information ------------------------------------------ 1 IP Camera Tester Introduction ----------------------------- 2 2.1 General --------------------------------------------------- 2 2.2 Features -------------------------------------------------- 3 2.3 Function -------------------------------------------------- 5 2.4Packing list----------------------------------------------- 12 2.5 Function introduction： ----------------------------------- 13 Operation ---------------------------------------------------- 17 3.1 Installing the Battery ------------------------------------ 17 3.2 Instrument connection ------------------------------------- 18 3.2.1 IP camera connection ------------------------------- 18 3.2.2 Analog camera test --------------------------------- 19...
  • Page 4 3.3.14 Digital Multi-meter *（optional ） ----------------- 56 3.3.15 Video Player -------------------------------------- 61 3.3.16 Music player -------------------------------------- 62 3.3.17 LED lamp (Flashlight) ----------------------------- 63 3.3.18 PoE/PSE Voltage test ------------------------------ 63 3.3.19 TDR cable test *（optional） ---------------------- 64 3.3.20 Calculator ---------------------------------------- 67 3.3.21 Browser ------------------------------------------- 67 3.3.22 IP camera viewer ---------------------------------- 68 3.3.23 PoE power / DC12V 2A and DC 5V 2A USB power output 69...

  • Page 5: Safety Information

    1. Safety information The tester is intended to use in compliance with the local rules of the electrical usage and avoid to apply at the places which are inapplicable for the use of electrics such as hospital, gas station etc. ◆...

  • Page 6: Ip Camera Tester Introduction

    ◆Never connect the meter with any voltage source while the function switch is in the current, resistance, capacitance, diode, continuity, otherwise it will damage the meter. ◆Never perform capacitance measurements unless the capacitor to be measured has been discharged fully. ◆Never measure any of resistance, capacitance, diode or continuity measurements on live circuits.

  • Page 7: Features

    2.2 Features 4.3inch 800×600 touch screen, easy to operate. ONVIF IP camera test Test some customized brands’s H.264/MPEG4/MJPEG IP cameras, such as Dahua, HIKVISION,ACTI, etc. Customized service is available. Built in Wi-Fi ,can receive image from wireless camera, as well as ONVIF and customized IP cameras.
  • Page 8 connected IP camera or other network equipment’s Ethernet port is working normally and the IP address is correct. IP address scan, quickly search the connected IP camera or other network device’s IP address PoE voltage test,it can test the PoE voltage when the POE switch is supplying the POE power to IP camera ,wireless AP etc TDR cable test,test cable length and short-circuit* (Optional) Cable test , Test LAN cable or telephone cable,UTP cable etc ,cable type and the sequence of...

  • Page 9: Function

    Function 2.3.1 Touch screen and OSD menu The IP camera tester combines with capacitive touch screen and key buttons. It is great improving the working efficiency and simplifying the installation and maintenance.. The user can be freely to move the function icons from the tester’s main menu to APPS tool file or move them back, to make the main menu look simple and clear.
  • Page 10 Meanwhile, the HDMI output can be used as SDI-HDMI convertor to output the SDI video to the HD TV monitor. 2.3.6 Analog camera test Display analog camera image ,4.3 inch 800×480 LCD screen display ,larger viewing angle ,more intuitively and easily to display the camera image quality. Support PAL/NTSC format.LCD screen backlight brightness adjustable, and analog video image brightness/contrast/color Saturation adjustable.
  • Page 11 For NTSC format, the Chroma standard level is 40 IRE If the Chroma level is low or too low, the color will not bright, and some details on the iamge will lost or get dark or white when the monitor receives the iamge. If the Chroma level is too high, there will be spots on the image.
  • Page 12 power for the PoE network camera . 2.3.12 Audio testing Test the audio input from pickup devices. Connect the tester and pickup device with the audio cable. Supports audio recording and audio output. 2.3.13 Enhanced Color bar generator The tester sends out the color bar by its BNC output to the monitor at the monitoring center. If the monitor receive the color bar, it means the video transmit channel works normally.
  • Page 13 Capture the video frames as JPEG file, and save the current video in the SD card. 2.3.18 Playback Save video image and record files in the SD card. Storage file directory can be created according to the date 2.3.19 Cable tracer (optional) Send the specific signal, easy to find the connected cable from messy cables.
  • Page 14 camera or other network equipment’s Ethernet port is working normally and the IP address is correct. 2.3.26 Port Finder The tester will send special signals to make the connected POE port flicker at special frequency, which will enable the installers to easily and quickly find the connected ethernet cable. This function can prevent mistakenly insertion or disconnection non-corresponding cable to artificially interrupt network connection.
  • Page 15 security system maintenance. 2.3.31 LED lamp It is useful for the user to install and maintain security system at night. Press button LED On/Off, easy operation. 2.3.32 OSD menu rotates in 180 angle OSD menu can be rotated in 180 angle by manual setting. This function is very convenient for the user to upward the downside to connect the LAN cable and do the testing.

  • Page 16: Packing List

    2.4Packing list 1). Tester 2). Adaptor DC12V 2A 3) Network cable tester 4) Polymer lithium ion battery (7.4V DC 5000mAh) 5). BNC cable 6). RS485 cable 7).SC,ST connector（Only for optical power meter） 8).Multi-meter test leads one pair of red and black (only for the Multi-meter models) 9).

  • Page 17: Function Introduction

    Function introduction ： page 13...
  • Page 18 Press more than 2 seconds, turn on or off the device ,short press to turn on or off the menu display Set key. Menu key Near focus: Focus the image nearby Far focus: Focus the image faraway TELE: zoom in the image WIDE: zoom out the image Open/set ,Confirm the setting of parameters, open or enlarge the aperture Return/Close : Return or cancel while setting parameters of the menu, close or...
  • Page 19 The RS485/RS232 data transmission indicator: it lights red while the data is being transmitted The charge indicator: it lights red while the battery is being charged. As the charging is complete, the indicator turns off automatically Multimeter interface Top interface page 15...
  • Page 20 Left interface Right interface SDI input (BNC interface) LED lamp TDR cable test interface DC12V2A power output , for provisional DC power supply RS232 Interface: RS232 communication for the PTZ RS485 Interface: RS485communication for the PTZ Video image signal output（BNC interface）/cable scan interface Video image signal input（BNC interface）...

  • Page 21: Operation

    Audio output PoE power supply output/Lan test interface, PSE power supply input interface DC12V2A charging interface DC12V2A power output , for provisional DC power supply 3. Operation Installing the Battery The tester has built-in lithium ion polymer rechargeable battery. The battery cable inside battery cabin should be disconnected for safety during transportation! Usually it doesn’t need to disconnect the cable at the normal use Pressing the key...

  • Page 22: Instrument Connection

    Warnings：Instrument communication port is not permitted access circuit voltage over 6V, otherwise damage the tester. Warnings：Not allow insert multi-meter pen in the current terminal to measure voltag Instrument connection 3.2.1 IP camera connection Power the IP camera by outter power source, then connect the IP camera to the IPC tester’s LAN port, if the link indicator of the tester’s LAN port is green and the data indicator flickers, it means the IP camera and the IPC tester are well connected.

  • Page 23: Analog Camera Test

    Note：if the IP camera does not support external power supply, but only supports PoE power, then connect the IP camera to IP tester’s LAN port ,The tester will supply PoE Power for IP camera. Before connecting, the PoE switch and tester must be disconnected. It means tester’s PSE port cannot be connected to any network cable when its LAN port is supplying the PoE power to the IP camera.

  • Page 24: Sdi Camera Test

    (1) The camera or dome video output is connected to CCTV Tester VIDEO IN,the image display on the tester . (2) CCTV Tester “VIDEO OUT” interface connect to the Video input of monitor and optical video transmitter and receiver, the image display on the tester and monitor (3) Connect the camera or the speed dome RS485 controller cable to the tester RS485 interface ,(Note positive and negative connection of the cable).Support RS232 PTZ controller ,connect the RS232cable to RS232 interface of the tester...

  • Page 25: Osd Menu

    Connect the camera or the speed dome RS485 controller cable to the tester RS485 （2） interface ,(Note positive and negative connection of the cable).Support RS232 PTZ controller ,connect the RS232cable to RS232 interface of the tester OSD menu Press the key 2 seconds to turn on Press the key 2 seconds to turn off...
  • Page 26 Click SD card, install or remove SD card Press function Icons seconds, tip: whether move this icon to APPS file, if some function not be often used, can move these function icons to APPS. Click icon “APPS” tool, to show all collected function icons, Click , back to the tester’s main menu page 22...

  • Page 27: Video Monitor Test (Ptz Control)

    In APPS file, Select icon and press it for seconds, tip: whether move the file to the desktop? 3.3.1 Video monitor test (PTZ control) Analog camera test and PTZ control, click icon to enter page 23...
  • Page 28 Display the input video image, click the top menu bar icon to enter video level meter, (PEAK level, SYNC level, COLOR BURST measurement) Select relative function on the right side Toolbar to operate , functions including “Photos”, “Snapshot” , “Record” , “Playback” , “PTZ” , “Set” , Click to quit, or press back to menu.
  • Page 29 A. Protocol Use the up and down arrow keys to move the yellow cursor to the “protocol ”, set corresponding Protocol and support more than thirty PTZ protocols. Such as Pelco-D、Samsung、Yaan、LiLin、 CSR600、Panasonic、Sony-EVI etc. B. Port Click and move, to “port” Select the communication port for the PTZ camera controlling (RS232/485) C.
  • Page 30 Press the key control the PTZ direction of rotation to switch on or turn off the aperture. Press adjust the focus manually Press manually adjust the zoom Press (2) Video and storage setting Click icon “set”,to enter and set analog video image brightness , contrast, color saturation, screen snapshot, recording and storage,support Auto-storage and manual storage When select manual storage, user can name and store the files.
  • Page 31 when image input,press to enter “zoom”,press it again to quit. By two fingers move outward and inward on the touch screen to zoom in and out the image. When the image is enlarged, click left, right, upward and downward the image to view every detail. if not by touch screen to operate ,press the key to zoom out , press the key zoom in, press upward and downward key to move the image...
  • Page 32 (5) Video record Click icon “Record”, when video in, the tester starts to record, the red recording icon appear on the screen and begin to flash and count,, if click the icon “Record “ again, stop recording and save it in the SD card .
  • Page 33 (6)Photo Click the icon “photo” to enter,click the selected thumbnail photo to display it on the screen. Double-click the photo to make it full display. Double-click again the photo to return. Press the photo several seconds, rename or delete the files. Click to close and return to PTZ controller.
  • Page 34 (7) Record playback Click icon “playback”to enter Double –click the files to play,Click on the top right icon to close and return to PTZ controller. In the video "Playback” interface, Press the recording for several seconds, rename or delete the files. Video files also can play in the main menu “Video Player".
  • Page 35 (8) Video level meter（*optional） Click the icon to enter, the IP camera tester has adopted hardware high-speed sampling and processing technology, enable it to achieve more accurate measurements in the video signal PEAK, SYNC level, COLOR BURST chroma level. When the video signal is input, the tester auto test and display the measurement on the left bottom corner of the screen.
  • Page 36 Chroma level( COLOR BURST) 40±5IRE SYNC signal level 40±5IRE Video signal level 1000±200mV Chroma level( COLOR BURST) 300±35mV SYNC signal level 300±35mV Video signal PEAK level: For PAL format , the video signal level is 1000±200mV For NTSC format, the video signal level is 140±15IRE If the level is too low, it will cause the image to dim and reduce dynamic range, but if the level is too high, it will lead to virtual shadow and reduce the definition of the image .

  • Page 37: Color-Bar Generator (Tv Out)

    gradually dwindling photos on the desktop. 3.3.2 Color-bar generator (TV OUT) Click to enter,the tester send the color bars from the “Video out” port ,Click the icon “PAL”, select “PAL/NTSC” output formats Click the selected color-bars, testing image or single bar ( red, green, blue, white or black). Double click to full display on the screen and output, click to return main menu.

  • Page 38: Onvif

    3.3.3 ONVIF ONVIF tools support HD and LD two test modes .When IP camera stream is MPEG4, Please select LD mode display, HD mode cannot support MPEG4. While in LD mode, if the network camera resolution is 720P or higher720P, the image display may be delayed.while in HD mode, the network camera stream is H.264;...
  • Page 39 If some IP cameras cannot be auto scanned by the tester , click left bottom “Add”, users can add camera manually, but URL address should be identical to the ONVIF camera service address. Click the button “Refresh”, tester will scan the ONVIF camera again the new displayed ONVIF camera below “Device List“, the tester will show the IP camera relative information and setting.
  • Page 40 Live Video: click “Live Video” to enter, show the IP camera image. Double click showing area, can be full displayed on the screen. Double click on the image, By two fingers move outward on the touch screen to zoom in the image. When the image is enlarged, click left, right, upward and downward the image to view every detail.
  • Page 41 Video Streaming: Click “Video Set” to enter, set the IP camera decoding resolution, click “OK “to save. Image setting: Click “Image set”, adjust image brightness, saturation and contrast Profiles：Click"profiles"，can view video streaming current configuration files, as well as switch between Major stream and minor stream . page 37...
  • Page 42 Profiles：Click"profiles"，can view video streaming current configuration files, as well as switch between Major stream and minor stream . Network setting：Click “network set “to change the IP address. Some cameras cannot support change IP address, so there is no change after saving. page 38...
  • Page 43 Zoom in image :press the key to enter, press it again to quit. By two fingers move outward and inward on the touch screen to zoom in and out the image. When the image is enlarged, click left, right, upward and downward the image to view every detail. When the image is enlarged, if not operate on touch screen, it can operate by the keyboard ,press the to zoon in , press the key to zoom out ,press upward and downward key to move...
  • Page 44 If it is network video input to the tester, as the tester supports resolution up to 1080p, the input image will be very clear after it is enlarged. This is greatly helpful to help the installers to ensure the IP camera’s video coverage and decide the IP camera’s install site.
  • Page 45 Set：Click icon “Set”, Photo and record function can select, if Auto-name, Photos and recording files Auto-storage, if manual, user define files name. Playback：Click icon “Playback” to display video files, double click to play, click to return page 41...

  • Page 46: Ip Camera Test

    Press the video files seconds to delete or rename. Video files can play in the Video player of the main menu 3.3.4 IP camera test Click icons to enter IP camera test Display high-definition images, support snapshot, video record and playback. Currently, the IPC tester only support some brands’...
  • Page 47 version. APK files) for our engineers to try to add the protocol to the IPC tester. Note： This function can only be used for the specified IP cameras, for example Dahua, Hikvision, etc, but please be noticed if the IP cameras come from the same brand but have different network communication, will result in incompatible with the tester.
  • Page 48 2. when IP camera type is "Auto"，the tester auto- match the camera type. IPC Camera's address: Enter IP camera’s IP address , click “deploy”to add IP address of the Different network segments, support multi- network segments’ IP camera test . Click “Search”...

  • Page 49: Sdi Camera Test(*Optional)

    IPC Password: Enter IP camera’s login password, if default enter password, not show relevant letters, click “display” to show the passord IPC Port No.：Select IP camera type, it default relative camera port number, and not need change. After setting, click “Enter” to enter image interface. If IP address setting has error or IP camera is not connected..
  • Page 50 When tester received SDI camera image, it will display the image data .by two fingers quickly double click the screen, the image display on the full screen. The tester support resolution as follows: 1280x720P 25Hz 1280x720P 30Hz 1280x720P 50Hz 1280x720P 60Hz 1920x1080P 25Hz 1920x1080P 30Hz 1920x1080I 50Hz...

  • Page 51: Ip Address Scan

    If no SDI camera image input, the tester’s screen display “NO video signal input!”: The HDMI output can be used as SDI-HDMI convertor to output the SDI video to the HD TV monitor. Select relative function on the right side Toolbar to operate , “Snapshot“ , “Recording”, “Photos ”, “Video playback”, “PTZ control”, “Brightness and Storage set”,its operating as the same as the video monitor function, Please refer to the relevant instructions “3.3.1”...

  • Page 52: Ping Test

    3.3.7 PING Test Connect the cable to the LAN port, click icon to enter, select set local IP, Remote Host IP, Packet Size, Packet time Timeout etc, press “Start “to test. If IP camera or other network equipment is not connected to the tester, show sending and receiving packet ‘s quantity inconsistency,Error rate 100%,if connect well, to start Ping test ,if the tested device’s IP address is correct, sending and receiving packet ‘s quantity consistencies Application：...

  • Page 53: Cable Test

    It’s normal that the first data packet will be lost when test start. 3.3.8 Cable test Click icon to enter Test LAN cable or telephone cable. Connect LAN cable or telephone cable with the CCTV testerPRO and cable tester. And then the connecting status, cable type and the sequence of wires as well as the serial number of the cable tester kit will be displayed.
  • Page 54 Turn on the cable scan; use the copper pin to search, the cable with loudest voice means it is connected with the tester. Four Audio types can choose. LED lamp is convenient to work in dark or at night. Press the button (+ - ) to adjust the volume, use two batteries (size AAA) Application...

  • Page 55: Port Finder

    3.3.10 Port finder Connect the cable to the tester “LAN” port,click icon to enter. Click “Start” to test, tester send signal to make the connected LAN port flicker at special frequency. If the tester and PoE switch are connected well, the LAN port of POE switch flash at special frequency, If not, no any changes on the LAN port Application：...

  • Page 56: Data Monitor

    prevent mistakenly insertion or disconnection non-corresponding cable to artificially interrupt network connection. 3.3.11 Data monitor Pls click icon to enter Click “Setting” to choose the baud rate of RS485/RS232; it must be the same as the DVR or the Control keyboard The DVR or Control keyboard send the code to the tester, if it can be read, the protocol will shown on the upper right, like Pelco D, if not, like P:---...
  • Page 57 Note：Please keep the fiber connector and the dust cap be clean, and clean the detector with the special alcohol. Data hold While testing, click “Hold” to data hold, the data will not change. It’s convenient to read. Press again to quit. Relative power value (optical link loss) measurement While testing, set the wavelength for measurement.

  • Page 58: Visual Fault Locator（Optional

    Data hold and Relative measuring use together, the data is yellow while the function is effect. 3.3.13 Visual Fault Locator（optional） Click icon to enter VFL four status can select——“Steady mode”, “Evasive 1Hz”,“Evasive 2Hz”and“Time off”. Click button “Steady mode” to enter steady status, click button “Evasive 1Hz” and “Evasive 2Hz, to enter pulse mode, click button “Time off”, VFL be turned off.
  • Page 59 Click” Steady mode”, red laser sources emit steady, click again to quit. Click icons “Evasive 1Hz”or“Evasive 2Hz”to enter pulse mode, the red laser sources emitted by a certain frequency, press it again to quit page 55...

  • Page 60: Digital Multi-Meter *（Optional

    3.3.14 Digital Multi-meter * （optional ） 1.Click icon to enter 2) SYMBOLS： U：DC Voltage Measuring A：DC Current Measuring Ω：Resistance Measuring ：Diode Testing ：AC Voltage Measuring ：AC Current Measuring ：Continuity Testing ：Capacitance Measuring AC/DC Voltage and current measurement state display Auto- range The Multimeter auto adjust the range by input signal or tested components Data hold Hold data...
  • Page 61 000.0V 660.0V range 000.0mV 660.0mV rang AC Voltage Measuring a. Connect the black test lead to the “COM” jack and the red test lead to the “V/Ω” jack. b. select U ~ , enter the AC voltage measurement. C.the tester default Auto range status, by click “AC auto range” d.
  • Page 62 Note： When only the figure “OL” is displayed, it indicates over range situation and the higher range has to be selected. When the value scale to be measured is unknown beforehand, set the range selector at the highest position. The maximum current of mA socket is 660mA; over-current will destroy the fuse, and will damage the meter.
  • Page 63 Continuity Testing Ω a. Connect the black test lead to the “COM” jack and the red test lead to the “V/ ” jack. b.to select , enter the continuity test, Connect test leads across two point of the circuit under testing. c.
  • Page 64 d. Before connect test leads across two sides of the capacitor under measurement, be sure that the capacitor has been discharged fully. Note: The capacitance of a capacitor should be tested separately, should not test in the installation of circuit. To avoid electric shock, be sure the capacitors have been discharged fully before measuring the ca pacitance of a capacitor.

  • Page 65: Video Player

    Relative value measurement Click “Relative “to enter ,the tester Auto-save the data, the displayed new measurement and relative value is red color. Press it again to quit The hold function and the relative value be combined use, the display value is yellow The meter protection Voltage protection You can’t input the voltage which more than 660V AC, it’s possible to show higher voltage, but...

  • Page 66: Music Player

    Video file player, can browse image files, also supports play formats MP4, H. 264, MPEG4, MKV,etc ONVIF tool, IP camera Test and video monitoring test’s video recording can play directly via video player. Video player auto-search the video files on SD card,click the display list to play directly,and click RETURN to quit Click the files for several seconds,delete or rename the files 3.3.16 Music player...

  • Page 67: Led Lamp (Flashlight)

    3.3.17 LED lamp (Flashlight) It is convenient for the installation or maintenance in the evening or in the dark. Click icon enter While in flashlight interface, click the red button, to turn on the LED lamp. Press again to turn off. if not turn off the light and click icon to quit, the LED lamp is still on Lighting model or Time setting can be selected.

  • Page 68: Tdr Cable Test *（Optional

    Connect the cable to the power supply equipment’s POE port and the tester’s PSE IN port. Connect IP camera or wireless AP equipment connect to tester’s LAN port, the POE voltage and the cable’s pin connection status show on the screen. Note : the Poe power supply equipment( POE Switch, PSE power supply equipment) must be connected to the PSE IN port, the powered device such as IP camera or wireless AP must be connected to the LAN port, then it measure the voltage correctly.
  • Page 69 cable type for testing, click “+” and“-” to adjust cable’s wave speed . User-defined calibration：Choose the cable 100 meters to 200 meters (more than 50 meters) ,click“Cable” , “Type”to select user-defined 1 for calibration, 11 groups user-defined can be set. 1.Select user-defined and click “Calibration “to enter test , click “user-defined 1”can define cable name,such as：AiPu BNC-5.
  • Page 70 3.Click “+”or“-” to adjust wave speed ,while display length is the same with the actual Length ,click “Save“to save calibration data ,It can be used for the same cable testing next time. Application：TDR test is the use of pulse reflection method, to transmit pulse signal for tested cable, when cable is disconnected or short-circuit, reflected pulse is generated, the tester receives and deals with the reflected wave, measurement results displayed on the screen.

  • Page 71: Calculator

    3.3.20 Calculator Click icon to enter 3.3.21 Browser Click icon to enter Input the IP camera’s IP address, or click “Scan IP” to scan, browser can be used to log IP camera and change IP camera’s address. The IP camera and IP tester must be in the same network segment so that the browser can login IP camera successfully,if they are not in the same segment after revise the IP camera address ,click or press “RETRUN”...

  • Page 72: Ip Camera Viewer

    3.3.22 IP camera viewer If the IP camera neither Non- customized nor support ONVIF,but IP camera manufacturers can offer Video Management Software that compatible with mobile phone or tablet PC, intall the Video Management Software in the tester enable the tester to display IP camera image by IP camera viewer. . Click icon “IP camera viewer”...

  • Page 73: Poe Power / Dc12V 2A And Dc 5V 2A Usb Power Output

    Click icon “update “ in the IPC viewer interface,to update Video Management Software. 3.3.23 PoE power / DC12V 2A and DC 5V 2A USB power output When the tester turns on, DC12V output power function Auto-turn on 5V USB power output,use of ultra-low standby power design, when the tester turns off ,also can be as a power bank ,to supply power for the external USB device To turn on and turn off PoE power function must by click the switch power output, to choose...
  • Page 74 the tester’s 1236 pins of the tester output power for IP camera . The top menu bar display icon“48V ON”, the icon can be moved. 1 .Don’t input any power into the “DC12/2A OUTPUT” port of the IPcamera tester to avoid destroy.

  • Page 75: Application Tools

    5. When PoE power output, UTP cable must be Straight-through, and cannot short-circuited, or it will damage the tester . 6. Make sure the tester is full charged or more than 80%, otherwise the tester will shows “low power ” , “not able to supply power” . 3.3.24 Application tools It contains Audio record, Network Bandwidth test ,DHCP, Notepad, Link Monitor, etc.
  • Page 76 Net work test (Ethernet bandwidth test) Built in Ethernet bandwidth test tools, two devices mutual –testing, one as a Server, the other as a Client,then test Network bandwidth, also can upload test software on a computer ,combine with a tester to test .
  • Page 77 b).Start send packet test：Input Server's IP address in other tester , used as a Client, to send packet test ,click button “start test” Network bandwidth testing,can be tested by a tester and a computer, Install network bandwidth testing software on a computer,as a test Client or Server,with testera mutual -testing If computer as the server,the computer IP address is :192.168.0.89 page 73...
  • Page 78 Tester as Client, tester’s IP address is:192.168.0.230. The Server and the Client are at the same network segment, but with different IP address. Input Server’s IP address 192.168.0.89 in the tester and click “Start” to test network bandwidth. Or tester as a Server, computer as test Client（select Client,input tester’s IP address to test） page 74...
  • Page 79 when tester as Server,shows results： DHCP server： Start “DHCP” Server, dynamic assign IP address for the IP camera, not need to set IP camera’s static IP address before start the testing . Select “Start” , set assigned addresses segment, click “save”to assign dynamic IP addresses. Click “Refresh”...
  • Page 80 Notepad： Notepad can be used to record the important testing results, click the key “Save” to save the contents. Notepad can auto record the storage date and time. pls click to view the notepad , all saving contents display. Click each record bar to show the details.

  • Page 81: Apps Tools

    Link monitor ： Click icon to enter, check and the new IP address whether has been occupied by other network device. Avoid the new address conflict with other network devices. Click “Add” to display the testing IP addresses, can add multiple IP addresses, For different network segments’...
  • Page 82 to APPS tool . Click icons “APPS” to show all icon, if tap on the screen outside the APPS interface, return to main menu Click icon for several seconds, prompt whether move the icon to the main menu. page 78...

  • Page 83: System Set

    3.3.26 System Set Click icon to enter Language：Simplified Chinese, Traditional Chinese, English and others Date/Time：Set the Date/time IP setting： Set the IP address, Subnet Mask, Default Gateway, DNS address Test multiple network segments’IP, click “Advance”, to display IP setting interface, then click “Add” to add new IP address as tester’s address to test .
  • Page 84 WLAN：Turn on /off WIFI. After connecting WIFI, double click WIFI to check the connected IP address. Brightness：Set brightness、sleep time Volume：Set volume SD Card：Show SD Card Capacity, remove SD card FTP server：IP camera tester connect to network by WIFI or network port ,PC can read SD card files by network.

  • Page 85: Update

    Power display: Display the battery level information Version information：Check version information for each application PTZ address scan: Turn on/ off Screen rotation：The LAN slot, PSE IN slot, UTP/SCAN slot etc, are on the downside of the IPC tester.Image 180 degree rotation, is very convenient for the user to upward the downside to connect the LAN cable and do the testing.

  • Page 86: Hdmi Output

    If there are applications for updating, the applications will be displayed on the interface. Click the relevant applications to update to the latest version. 3.4 HDMI output Built in HDMI output port, output recording files, media files and image to HD TV monitors, support resolution up to 1080p.

  • Page 87: Dc12V 2A Power Output

    Notice a. Please make sure the cable connected to the tester’s Lan port is straight-line cable and has no short circuit, otherwise will damage the tester b. Before using PoE power output, pls check the IP camera whether supports POE powered. Otherwise it will damage the IP camera.

  • Page 88: Usb 5V 2A Power Output

    Notice: Don’t input any power into the “DC12/2A OUTPUT” port of the IP camera tester to avoid destroy. man-made damage is not within the Company’s warranty Don’t output this DC12V/2A power to DC12V/ IN port to avoid destroy. otherwise the tester will damage, and man-made damage is not within the Company’s warranty.

  • Page 89: Audio Test

    3.8 Audio test Test the audio input from pickup devices. Connect the tester and pickup device with the audio cable.Support audio record and storage page 85...

  • Page 90: Specifications

    4. Specifications General Specifications IPC-4300【*】models optional Model Display 4.3 inch Capacitive touch screen , resolution 800（RGB）x 480 Network port 10/100M auto adapt,RJ45 WIFI Built in WIFI,speeds150M,display wireless camera image ONVIF,ACTi 、 Dahua IPC-HFW2100P 、 Hikvision,DS-2CD864-E13 、 Samsung SNZ-5200、Tiandy TD-NC9200S2、Kodak IPC120L、Honeywell HICC-2300T、 IP camera type Aipu-waton IP5000-BC-13MP/IRS06-13MP 、...
  • Page 91 Output one channel PAL/NTSC color bar video signal for testing monitor or video color bar generator cable.(red, green ,blue, white and black color ) Test UTP cable connection status and display on the screen. Read the number on UTP Cable tester the screen Captures and analyzes the command data from controlling device,also can send Data monitor...

  • Page 92: Multi-Meter Specifications

    General Working Temperature -10℃---+50℃ Working Humidity 30%-90% Dimension/Weight 215mm x 127mm x 53mm / 0.82kg Note: * means optional Multi-meter specifications Counts：-6600～+6600 Conversion rate: 3times/s Current modes for clamp meter with ZERO function Isolation: the Multi-meter connector must be isolated with the other connector. DC voltage Range Accuracy...
  • Page 93 DC current Range Accuracy Resolution 6.600mA 66.00mA 10uA ±（0.5%+3） 660.0mA 100uA 10.00A ±（1%+5） 10mA AC current Range Accuracy Resolution 6.600mA 66.00mA ±（0.5%+3） 10uA 660.0mA 100uA 10.00A ±（1%+5） 10mA Resistance Range Accuracy Resolution 660.0Ω ±（0.8%+5） 0.1Ω 6.600KΩ 1Ω 66.00KΩ 10Ω ±（0.8%+2） 660.0KΩ...

  • Page 94: Optical Power Meter Specifications

    Diode Range Resolution Function Schottky diode：0.15~0.25V 2.0V rectifier diode：0.6~1.0V triode PN junction:0.5~0.8V Capacitance Range Accuracy Resolution 6.600nF ±（0.5%+20） 66.00nF 10pF 660.0nF 100pF ±（3.5%+8） 6.600µF 66.00µF 10nF 660.0µF 100nF 6.600mF 1µF ±（5%+8） 66.00mF 10µF Optical power meter specifications -70～+10dBm Measure Range(dBm) Wavelength(nm) 850nm、1300nm、1310nm、1490nm、1550nm、1625nm Detector...

  • Page 95: Visual Fault Locator Specifications

    Operating Temperature(℃) -10～+50 Storage Temperature (℃) -20～+70 Connector type FC/PC Visual fault locator specifications Laser type Wavelength Calibration 650nm Output power 5mW（optional 10mW,20mW） Modulation mode CW/1Hz/2Hz Measurement Range 5KM（optional 10-20KM） Connector FC/PC exchangeable Working Temperature －10℃～+50℃ Operating Temperature -20℃～+70℃ The data above is only for reference and any change of them will not be informed in advance. For more detailed technical inquiries, please feel free to call the Technical Department of our company.
