Technology SPX5 User Manual page 10

The SPX5 Browser (Shown in figure 10) is a simple to use software that allows you to detect SPX5
devices present on the network, change or assign a temporary IP to them, and allow upgrading the
firmware version of the devices.
In order to detect an SPX5 on the network go to the menu "Tools" (1) and choose "Firmware
Download" to upgrade a gateway firmware or "View Device Web Page" to configure a gateway on
the network. After choosing any of these options a dialog will present that will show all the detected
SPX5 devices on the network. When presented, the IP Address of the PC interface at which the SPX5
is connected to will be shown (2). This allows the user to determine what is the optimal IP that can
be assigned to the SPX5 in order to access it through the network.
For each detected SPX5 on the network, the SPX5 Browser, will show: Gateway Name, Serial Number
or MAC Address (3) SPX5 Configured IP Address (4), Temporary IP Address (7) and Firmware Version
(5).
If the IP Address is shown in red, it means the IP Address of the gateway is not reachable from the
computer you are connected from. In that case you need either to change your computer IP Address
or assign a temporary IP address to the SPX5 gateway. To assign a temporary IP address to the SPX5,
right click over the gateway and select "Change Temporary IP Address". After that, the temporary
IP change window (6) will be displayed. A new IP Address and network mask must be entered in this
window. If the new IP Address is on the same subnet as the PC, it will be possible to access the SPX5
Gateway for configuration or for firmware upgrade.
Once the SPX5 has an IP Address that is reachable from the PC, double clicking the shown gateway
will start the configuration or firmware upgrade process. In Figure 11 the main configuration web
page of the SPX5 is shown.
