IEI Technology Mustang-200 User Manual

10 gbps network based pcle computing accelerator card with two intel core i5/i7 processors, 32 gb ram, 1 tb ssd, qts-lite, sdk, rohs
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Mustang-200 Computing Accelerator
Mustang-200 CPU Card
MODEL:
Mustang-200
10 Gbps Network Based PCIe Computing Accelerator Card with
Two Intel® Core™ i5/i7 Processors, 32 GB RAM,
1 TB SSD, QTS-Lite, SDK, RoHS
User Manual
Page I
Rev. 1.00 - October 27, 2017

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Mustang-200 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for IEI Technology Mustang-200

Summary of Contents for IEI Technology Mustang-200

  • Page 1 Mustang-200 Computing Accelerator Mustang-200 CPU Card MODEL: Mustang-200 10 Gbps Network Based PCIe Computing Accelerator Card with Two Intel® Core™ i5/i7 Processors, 32 GB RAM, 1 TB SSD, QTS-Lite, SDK, RoHS User Manual Page I Rev. 1.00 - October 27, 2017...
  • Page 2 Mustang-200 Computing Accelerator Revision Date Version Changes October 27, 2017 1.00 Initial release Page II...
  • Page 3 Mustang-200 Computing Accelerator Copyright COPYRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.
  • Page 4 Mustang-200 Computing Accelerator Manual Conventions WARNING Warnings appear where overlooked details may cause damage to the equipment or result in personal injury. Warnings should be taken seriously. CAUTION Cautionary messages should be heeded to help reduce the chance of losing data or damaging the product.

  • Page 5: Table Of Contents

    Mustang-200 Computing Accelerator Table of Contents 1 INTRODUCTION......................1 1.1 I ......................2 NTRODUCTION 1.2 M ....................3 ODEL ARIATIONS 1.3 F ........................3 EATURES 1.4 C ......................4 ONNECTORS 1.5 D ....................... 5 IMENSIONS 1.6 D ........................ 6 1.7 T ..................
  • Page 6 Mustang-200 Computing Accelerator 5.4.3 Cards Info ......................26 5.4.3.1 Port Settings ....................27 5.4.3.2 Add Task ....................28 5.5 T ................29 RANSCODING PECIFICATIONS 5.6 E ........................ 30 XAMPLES 5.6.1 VOD Transcoding..................... 30 5.6.2 File Transcoding ....................35 A REGULATORY COMPLIANCE ................40 B PRODUCT DISPOSAL ....................
  • Page 7 Figure 1-4: Dimensions (mm) ......................5 Figure 1-5: Data Flow Diagram......................6 Figure 3-1: Remove Two Blank Brackets...................15 Figure 3-1: Install and Secure Mustang-200 ................16 Figure 3-1: Power Cable Connection..................16 Figure 3-1: Assign a Card ID .......................17 Figure 3-1: Multiple Mustang-200 Installed ................17 Figure 3-1: IEI Resource Download Page ..................19...
  • Page 8 Mustang-200 Computing Accelerator List of Tables Table 1-1: Mustang-200 Model Variations ..................3 Table 1-2: Technical Specifications....................7 Table 5-1: Transcoding Specifications..................29 Page VIII...

  • Page 9: Introduction

    Mustang-200 Computing Accelerator Chapter Introduction Page 1...

  • Page 10: Ntroduction

    (P2V) and assign it to one of the nodes on the Mustang-200. SDK and a Web Application are also come with the Mustang-200. The Web Application is capable of VOD (file to live), Live (live to live) and File (file to file) transcoding scenarios.

  • Page 11: Model Variations

    Mustang-200 Computing Accelerator 1.2 Model Variations The model variations of the Mustang-200 series are listed below. Model No. Processor Intel® Core™ i5-7267U Mustang-200-i5-1T/32G (3.5 GHz, dual-core, 4 MB cache, TDP=28 W) Intel® Core™ i7-7567U Mustang-200-i7-1T/32G (4.0 GHz, dual-core, 4 MB cache, TDP=28 W) Table 1-1: Mustang-200 Model Variations 1.3 Features...

  • Page 12: Connectors

    Mustang-200 Computing Accelerator 1.4 Connectors The connectors on the Mustang-200 are shown in the figures below. Figure 1-2: Connectors (Front Side) Figure 1-3: Connectors (Rear Side) Page 4...

  • Page 13: Dimensions

    Mustang-200 Computing Accelerator 1.5 Dimensions The dimensions of the board are listed below: Figure 1-4: Dimensions (mm) Page 5...

  • Page 14: Data Flow

    1.6 Data Flow Figure 1-5 shows the data flow between the CPU and other components installed on the Mustang-200. Figure 1-5: Data Flow Diagram 1.7 Technical Specifications Mustang-200 technical specifications are listed below. Specification Mustang-200 Processor Intel® Core™ i5-7267U (up to 3.5 GHz, dual-core, 4 MB cache, TDP=28 W) Intel®...

  • Page 15: Table 1-2: Technical Specifications

    210 mm x 111 mm x 40 mm There is no support for UPnP (Universal Plug and Play). This Remark is because Mustang-200 is not connected to router directly, and its connection to external network can only be established via the host server.

  • Page 16: Unpacking

    Mustang-200 Computing Accelerator Chapter Unpacking Page 8...

  • Page 17: Anti-Static Precautions

    Only handle the edges of the PCB: Don't touch the surface of the motherboard. Hold the motherboard by the edges when handling. 2.2 Unpacking Precautions When the Mustang-200 is unpacked, please do the following:  Follow the antistatic guidelines above.

  • Page 18: Packing List

    If any of the components listed in the checklist below are missing, do not proceed with the installation. Contact the IEI reseller or vendor the Mustang-200 was purchased from or contact an IEI sales representative directly by sending an email to sales@ieiworld.com.

  • Page 19: Optional Item

    Mustang-200 Computing Accelerator 2.4 Optional Item The following is optional component which may be separately purchased: Item Image Dual-port USB cable kit for debug (includes two cables) (P/N: 19B00-000396-00-RS) Page 11...

  • Page 20: Hardware Installation

    Mustang-200 Computing Accelerator Chapter Hardware Installation Page 12...

  • Page 21: Anti-Static Precautions

    Electrostatic discharge (ESD) can cause serious damage to electronic components, including the Mustang-200. Dry climates are especially susceptible to ESD. It is therefore critical that whenever the Mustang-200 or any other electrical component is handled, the following anti-static precautions are strictly adhered to.

  • Page 22: Hardware Installation

    ESD from the body and helps prevent ESD damage.  Turn all power to the system off: When installing the Mustang-200, make sure that the system to be connected is disconnected from all power supplies and that no electricity is being fed into the system.

  • Page 23: Figure 3-1: Remove Two Blank Brackets

    Step 4: Install and secure the Mustang-200 to the system. Align the Mustang-200 to the PCIe slot. Press down gently, but firmly, to seat the Mustang-200 correctly in the slot. Install two bracket screws to secure the Mustang-200 to the system’s chassis.

  • Page 24: Figure 3-1: Install And Secure Mustang-200

    Figure 3-2: Install and Secure Mustang-200 Step 5: Connect a power cable to the Mustang-200. The Mustang-200 requires 12V 10A DC power. Use a power cable with 6-pin connector from the system, if applicable, or add the 4-pin to 6-pin PCIe power adapter to connect to the power connector of the Mustang-200.

  • Page 25: Figure 3-1: Assign A Card Id

    Mustang-200 Computing Accelerator Step 6: Assign a card ID to the Mustang-200 by adjusting the rotary switch. The card ID number assigned here will be shown on the LED display of the card after power-up. Figure 3-4: Assign a Card ID...

  • Page 26: Software Installation

    Mustang-200 Computing Accelerator Chapter Software Installation Page 18...

  • Page 27: System Requirements

     Linux Ubuntu 16.04 4.2 Prerequisites  Make sure the system installed with the Mustang-200 is connected to the network  Please run all the following installation steps as the root user. 4.3 Host SDK Installation To install the Mustang-200 host SDK in Linux, follow the steps below.
  • Page 28 Inside the MVT Host root directory, run the following command to execute the MVT Host: Step 0: sudo node mvt_host.js NOTE: If, by any chance, the Linux kernel has been re-installed, the Mustang-200 driver must be installed again. Page 20...

  • Page 29: Web Application

    Mustang-200 Computing Accelerator Chapter Web Application Page 21...

  • Page 30: Web Application Introduction

    It is released under open source license, allowing users to modify it to meet their requirements. The Web Application is capable of handling multiple Mustang-200 cards. The user can manage and monitor all of the cards using this application. Also you can navigate to the Mustang-200 operating system named QTS Lite by clicking the QTS icon in the application.
  • Page 31 Mustang-200 Computing Accelerator Step 4: Run in host sever 1) Set file: "/src/js/config/appConfig.js" parameter  "const DebugUse=false;" 2) Modify DebugUse and host IP npm run build_dev 4) Copy the application’s "/mustang-web-application-master/public" folder to replace the "/mvt_host/public" folder of Host SDK.

  • Page 32: How To Access

    To access IEI web application without changing its function, follow the guide below. Prerequisites: Install Mustang-200 Host SDK as described in Chapter 4. How to: Open a web page in Google Chrome browser and type the URL which is hostIP:hostPort (e.g.

  • Page 33: Log

    Mustang-200 Computing Accelerator NOTE: Users can login to QTS Lite OS by clicking the IP address link. The default username and password for QTS login are:  Username: admin  Password: admin 5.4.2 Log The Log page shows the log of the tasks. The user can search a log by using the filter and clicking on the page.

  • Page 34: Cards Info

    Mustang-200 Computing Accelerator 5.4.3 Cards Info The Cards Info pages show information about individual cards. The user can also assign task in this page. It card page gives the following information:  Card ID  CPU and GPU usage ...

  • Page 35: Port Settings

    Mustang-200 Computing Accelerator 5.4.3.1 Port Settings This is a sub page from the card page. After clicking the Port Settings button, the Port Settings page will appear with the network information regarding how this card is connected to host system. The Port Settings page contains the following information: ...

  • Page 36: Add Task

    Mustang-200 Computing Accelerator 5.4.3.2 Add Task This is a sub page from the card page. After clicking the Add Task button to add new task, this wizard page will appear. A sequence of wizard steps will guide the user to setup transcoding tasks.

  • Page 37: Transcoding Specifications

    Mustang-200 Computing Accelerator 5.5 Transcoding Specifications The table below lists the transcoding specifications supported by the web application of the Mustang-200. Video File Format H.264/MPEG-4/AVC H.265/HEVC /UHD/4K MPEC2 Audio File Format Vorbis Copy Disable Streaming Format RTMP MPEG-DASH ICECAST Resolutions...

  • Page 38: Examples

    Mustang-200 Computing Accelerator 5.6 Examples The following sections give step-by-step examples to help users learn to use the web application to assign transcoding tasks. 5.6.1 VOD Transcoding The following example will teach you how to transcoding 4K HEVC to 4K H.264 codec for VOD RTMP streaming.
  • Page 39 Mustang-200 Computing Accelerator Step 3: Output Format Setting: 1) Choose output streaming RTMP 2) Video Codec: H.264 3) Profile: Main 4) Level: 4 5) Audio Codec: AAC 6) Audio Bitrate: 128 Kbps Click Next to continue. Page 31...
  • Page 40 Mustang-200 Computing Accelerator Step 4: Output Quality Settings: 1) Select quality as QP Select the number of outputs by adding the following settings: 2) Resolution: 3840x2160 (4K) 3) Frame Rate: 30 4) QP Value: 23 Page 32...
  • Page 41 Mustang-200 Computing Accelerator Step 5: The Summary page displays all the selected information. Transcoding will begin after clicking the Start button. Page 33...
  • Page 42 Mustang-200 Computing Accelerator Step 6: The transcoding task is added to the list. Step 7: Click on the card page. The following page with task information appears. Click the icon to preview the video in media player. Step 8: Click on the card page to view the transcoding summary.

  • Page 43: File Transcoding

    Mustang-200 Computing Accelerator 5.6.2 File Transcoding The following example will teach you how to transcoding H.264 4K to 4K H.265 (HEVC) codec. Step 1: Click Add Task on Card Page. Step 2: 1) Select "File" as the Task Type. 2) Enable "Quick Transcode" to complete transcoding process quicker. Quick Transcode uses maximum GPU resources to transcode faster.
  • Page 44 Mustang-200 Computing Accelerator be displayed. Click Next to continue. Step 3: Output Format Setting: 1) Choose output file format: MKV 2) Video Codec: H.265 3) Profile: Main 4) Level: 6.2 5) Audio Codec: AAC 6) Audio Bitrate: 128 Kbps Click Next to continue.
  • Page 45 Mustang-200 Computing Accelerator Step 4: Output Quality Setting: 1) Select quality as QP Select the number of outputs by adding the following settings: 2) Resolution: 3840x2160 (4K) 3) Frame Rate: 30 4) QP Value: 23 Page 37...
  • Page 46 Mustang-200 Computing Accelerator Step 5: The Summary page displays all the selected information. Transcoding will begin after clicking the Start button. Page 38...
  • Page 47 Mustang-200 Computing Accelerator Step 6: The transcoding task is added to the list. Step 7: Click on the card page to view the transcoding summary. Step 0: Page 39...

  • Page 48: A Regulatory Compliance

    Mustang-200 Computing Accelerator Appendix Regulatory Compliance Page 40...

  • Page 49: Declaration Of Conformity

    Mustang-200 Computing Accelerator DECLARATION OF CONFORMITY This equipment has been tested and found to comply with specifications for CE marking. If the user modifies and/or installs other devices in the equipment, the CE conformity declaration may no longer apply. FCC WARNING This equipment complies with Part 15 of the FCC Rules.

  • Page 50: B Product Disposal

    Mustang-200 Computing Accelerator Appendix Product Disposal Page 42...
  • Page 51 Mustang-200 Computing Accelerator CAUTION: Risk of explosion if battery is replaced by an incorrect type. Only certified engineers should replace the on-board battery. Dispose of used batteries according to instructions and local regulations.  Outside the European Union–If you wish to dispose of used electrical and electronic products outside the European Union, please contact your local authority so as to comply with the correct disposal method.

  • Page 52: C Hazardous Materials Disclosure

    Mustang-200 Computing Accelerator Appendix Hazardous Materials Disclosure Page 44...
  • Page 53 Mustang-200 Computing Accelerator The details provided in this appendix are to ensure that the product is compliant with the Peoples Republic of China (China) RoHS standards. The table below acknowledges the presences of small quantities of certain materials in the product, and is applicable to China RoHS only.
  • Page 54 Mustang-200 Computing Accelerator 此附件旨在确保本产品符合中国 RoHS 标准。以下表格标示此产品中某有毒物质的含量符 合中国 RoHS 标准规定的限量要求。 本产品上会附有”环境友好使用期限”的标签，此期限是估算这些物质”不会有泄漏或突变”的 年限。本产品可能包含有较短的环境友好使用期限的可替换元件，像是电池或灯管，这些元 件将会单独标示出来。 部件名称 有毒有害物质或元素 铅 汞 镉 六价铬 多溴联苯 多溴二苯 醚 (Pb) (Hg) (Cd) (CR(VI)) (PBB) (PBDE) 壳体 显示 印刷电路板 金属螺帽 电缆组装 风扇组装 电力供应组装 电池 O: 表示该有毒有害物质在该部件所有物质材料中的含量均在 SJ/T 11363-2006 (现由 GB/T 26572-2011 取代) 标准规定的限量要求以下。...
