- Page 1 Web GUI iRIS-2600/iRIS2-2600 Web GUI IEI iMAN V2 Web-based Graphics User Interface (GUI) User Manual Page i Rev. 1.02 – September 13, 2023...
-
Page 2: Revision
Web GUI Revision Date Version Changes September 13, 2023 1.02 Updated screenshots to the latest version Updated Section 1.1 July 11, 2023 1.01 Added pinouts of iRIS2 connector and DP connector in Section 1.1 September 1, 2022 1.00 Initial release... -
Page 3: Copyright
Web GUI Copyright COPYRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages. -
Page 4: Table Of Contents
Web GUI Table of Contents REVISION ........................II COPYRIGHT ........................III TABLE OF CONTENTS ....................IV LIST OF FIGURES ......................VI 1 INTRODUCTION ......................1 RIS-2600/ RIS2-2600 O ................2 VERVIEW 1.1.1 Model Variations ....................2 1.1.2 Hardware Installation ..................3 1.1.3 IEI iRIS2 Connector ................... - Page 5 Web GUI 4.7 V ....................... 25 IRTUAL EDIA 4.8 C BMC T PC ............26 HECKING TATUS IN EMOTE 5 SETTINGS ........................27 5.1 O ........................ 28 VERVIEW 5.2 D ......................28 ATE AND 5.3 N ........................ 30 ETWORK 6 SECURITY AND ACCESS ..................
-
Page 6: List Of Figures
Web GUI List of Figures Figure 1-1: IEI iMAN V2 Web Address Sample ................9 Figure 1-2: IEI iMAN V2 Web GUI Login Page ................10 Figure 1-3: IEI iMAN V2 GUI Interface ..................11 Figure 2-1: Overview Page ......................13 Figure 3-1: Sensor Page ...................... -
Page 7: Introduction
Web GUI Chapter Introduction Page 1... -
Page 8: Iris-2600/Iris2-2600 Overview
SMBus system interface provides low-pin count connection for low-cost management controllers Firmware Firewall supports partitioning and protection of management between blades in modular system implementations 1.1.1 Model Variations The model variations of the iRIS-2600/iRIS2-2600 series are listed below. Model Name Slot Interface KVM Support Display Output iRIS-2600... -
Page 9: Hardware Installation
The iRIS module can be installed into the iRIS module slot on IEI motherboard that supports IPMI 2.0. The iRIS-2600 is for the IEI iRIS slot, and the iRIS2-2600 module is for the IEI iRIS2 slot. Please refer to the motherboard manual for the hardware installation instruction. -
Page 10: Iei Iris2 Connector
Web GUI iRIS-2600 Installation (180° Slot) iRIS2-2600 Installation 1.1.3 IEI iRIS2 Connector The IEI iRIS2 connector pinouts are listed below. Description Pin No. Pin No. Description 3.3 V 3.3 V 3.3 V BMC_Tx (Uart) ESPI_LPC BMC_Rx (Uart) LPC_AD3/ESPID3 LPC_SERIRQ/ESPIALT_N... - Page 11 Web GUI LPC_AD1/ESPID1 LPC_FRAME_N/ESPICS_N LPC_AD0/ESPID0 LPC_RST_N/ESPIRST_N SPI_MISO PCIE_WAKE# DIF_PCIE_EP_CLK_P CLKREQ# DIF_PCIE_EP_CLK_N PCIE_RST# SPI_MOSI DIF_PCIE_EP_RX_P SPI_CLK DIF_PCIE_EP_RX_N SPI_CS0 SMBUSDAT1_EC(1.8V) DIF_PCIE_EP_TX_P SMBUSCLK1_EC(1.8V) DIF_PCIE_EP_TX_N GBE_LED_100M MDI0_P MDI0_N MDI1_P MDI1_N MDI2_P MDI2_N MDI3_P MDI3_N GBE_LED_LINK_ACT# USB2.0- GBE_LED_1G USB2.0+ 3.3 V 3.3 V Page 5...
-
Page 12: Dp Connector (Iris2-2600 Only)
Web GUI 1.1.4 DP Connector (iRIS2-2600 Only) The DP connector pinouts are listed below. Pin No. Description CONFIG 1 CONFIG 2 DP_HPD-R DIF_DP_AUX-N-C DIF_DP_AUX-P-C DIF_DP_CONN_TX1-N DIF_DP_CONN_TX1-P DIF_DP_CONN_TX0-N DIF_DP_CONN_TX1-N Page 6... -
Page 13: Dp Cable Connector (Iris2-2600 Only)
Web GUI 1.1.5 DP Cable Connector (iRIS2-2600 Only) The DP connector pinouts of the DP cable are listed below. IMP. Signal Data CONFIG 1 CONFIG 2 DP_HPD-R DIF_DP_AUX-N-C 100Ω +/-15% DIF_DP_AUX-P-C DIF_DP_CONN_TX1-N 100Ω +/-15% DIF_DP_CONN_TX1-P DIF_DP_CONN_TX0-N 100Ω +/-15% DIF_DP_CONN_TX1-N... -
Page 14: Iei Iman V2 Gui Overview
Web GUI 1.2 IEI iMAN V2 GUI Overview The IEI iMAN V2 Graphics User Interface (GUI) is designed to manage a client system from a remote console using standard Internet browsers. 1.2.1 System Requirements Minimum software requirements for using IEI iMAN V2 GUI are listed below. -
Page 15: Access The Iei Iman V2 Web Gui
Web GUI 1.2.2 Access the IEI iMAN V2 Web GUI To initial access to the IEI iMAN V2 Web GUI, follow the steps below. Step 1: Obtain the IP address of the managed system. It is recommended to use BIOS or the IPMI Tool to obtain the IP address of the managed system. -
Page 16: Figure 1-2: Iei Iman V2 Web Gui Login Page
Web GUI Figure 1-2: IEI iMAN V2 Web GUI Login Page Step 4: Enter the user name and password to login the system. The default login information is Username: root Password: IRIS + last 6 digit number of MAC (for example: IRIS421316) Step 5: Press the Log in button to login the system. -
Page 17: Iei Iman V2 Gui Interface
Web GUI 1.2.3 IEI iMAN V2 GUI Interface Figure 1-3 shows a screenshot of the IEI iMAN V2 GUI after login. The menu bars contain general function buttons, quick buttons and logged-in user information. Figure 1-3: IEI iMAN V2 GUI Interface The logged-in user information shows the logged-in user and his/her privilege. -
Page 18: Overview Page
Web GUI Chapter Overview Page Page 12... -
Page 19: Overview Page
Web GUI 2.1 Overview Page The Overview page gives the overall information about the status of a device. To open the Overview page, click Overview from the side menu bar. Figure 2-1: Overview Page A brief description about the information displayed in the Overview page is given below. -
Page 20: Hardware Status
Web GUI Chapter Hardware Status Page 14... -
Page 21: Overview
Web GUI 3.1 Overview The Hardware Status page contains one subpage – Sensors, which is described in detail in the following section. 3.2 Sensor The Sensor page displays all the sensor related information (Figure 3-1). To open the Sensor page, click Hardware status Sensor from the side menu. A list of sensors with sensor name, status critical and current value is displayed. -
Page 22: Operations
Web GUI Chapter Operations Page 16... -
Page 23: Overview
Web GUI 4.1 Overview The Remote Control consists of the following. Factory reset Firmware update Reboot BMC SOL console Server power operations Virtual media A detailed description of each submenu is given below. -
Page 24: Figure 4-1: Factory Page
Web GUI Figure 4-1: Factory Page To restore default configuration of the device, click the Reset button. Page 18... -
Page 25: Kvm
Web GUI 4.3 KVM NOTE: The KVM function is only supported by the iRIS-2600 and iRIS2-2600 modules, which contain AST2600 BMC. The KVM page is used to configure virtual media configuration settings for the next redirection session. To open the KVM page, click Operations KVM from the side menu bar. -
Page 26: Firmware Update
Web GUI 4.4 Firmware Update The Firmware Update page allows the user to update BMC image and BIOS image files. To load the Firmware page, click Operations Firmware from the side menu bar. WARNING: Please note that after firmware update, other web pages and services will not work. -
Page 27: Figure 4-3: Firmware Page
Web GUI Figure 4-3: Firmware Page To update BMC/BIOS image file, click Upload File button to select the image file and then click Update button to update it. Page 21... -
Page 28: Sol
Web GUI 4.5 SOL The SOL page allows the user to launch the SOL. The SOL is used to view the host screen using the SOL Redirection. To open SOL page, click Operations Sol Console from the side menu bar. -
Page 29: Figure 4-5: Bmc Console Redirection Bios Option
Web GUI Figure 4-5: BMC Console Redirection BIOS Option Step 2: Enter the BMC Console Redirection Settings BIOS menu (Figure 4-6). Configure the BIOS options if necessary. Figure 4-6: BMC Console Redirection Settings BIOS Menu Page 23... -
Page 30: Server Power Operations
Web GUI 4.6 Server Power Operations The Server Power Operations page allows the user to view and control the power of the server. To open the Server Power Operations page, click Operations Server Power from the side menu bar. -
Page 31: Virtual Media
Web GUI 4.7 Virtual Media The Virtual Media screen can be accessed by clicking Operations Virtual Media button. The user can enter the Virtual media for media redirection. Figure 4-8: Virtual Media Page To add, remove or modify images, follow the steps below. -
Page 32: Checking Bmc Test Status In Remote Pc
Web GUI 4.8 Checking BMC Test Status in Remote PC This section describes how to check BMC test pass/fail status of a remote PC. This instruction can be applied to a remote PC where the iRIS module is installed on the IEI board. -
Page 33: Settings
Web GUI Chapter Settings Page 27... -
Page 34: Overview
Web GUI 5.1 Overview The Settings page consists of the following. Date and time Network A detailed description of each submenu is given below. 5.2 Date and Time The Date and Time page displays the device current date and time settings. It can be used to configure Date, Time or NTP server settings for the device. - Page 35 Web GUI The fields of Date and Time page are explained below. Manual Date: To specify the current date of the device Time: Specify the current Time for the device. Note: As Year 2038 Problem exists, Date and Time should be configured within the range.
-
Page 36: Network
Web GUI 5.3 Network The Network page is used to configure the network settings for the available LAN channels. To open the Network page, click Settings Network from the side menu bar. Figure 5-2: Network Page The fields of Network Settings page are explained below. - Page 37 Web GUI Static: These fields are for specifying the static IPv4 address and Subnet Mask to be configured to the device. - IP Address made of 4 numbers separated by dots as in "xxx.xxx.xxx.xxx". - Each Number ranges from 0 to 255.
-
Page 38: Security And Access
Web GUI Chapter Security and Access Page 32... -
Page 39: Overview
Web GUI 6.1 Overview The Security and Access allows users to access various configuration settings. Each configuration setting is described in detail in the following sections. 6.2 Sessions The Sessions page allows users to manage session server settings. To open Sessions page, click Security and access ... -
Page 40: Ldap
Web GUI 6.3 LDAP The Lightweight Directory Access Protocol (LDAP)/E-Directory Settings is an application protocol for querying and modifying data of directory services implemented in Internet Protocol (IP) networks. In IEI iMAN V2 GUI, LDAP is an Internet protocol that the iRIS module can use to authenticate users. -
Page 41: Figure 6-3: Ldap Authentication
Web GUI To input information in the LDAP page, follow the steps below: Step 1: Click LDAP on the side menu bar to open the LDAP setting page. Figure 6-3: LDAP Authentication Step 2: Click to select Enable to enable the LDAP authentication settings. -
Page 42: Ldap Settings
Web GUI 6.3.1 LDAP Settings To enter the details in the LDAP page, follow the steps below. Step 1: In the LDAP page, select OpenLDAP. Figure 6-4: OpenLDAP Settings page Step 2: Follow the rules below to enter the IP address of LDAP server in the Server URI field. -
Page 43: User Management
Web GUI Step 5: Enter the Base DN. The Search base tells the LDAP server which part of the external directory tree to search. The search base may be something equivalent to the organization, group of external directory. ... -
Page 44: Add User
Web GUI Privilege: Displays the network access privilege of the user. Status: User status NOTE: The Free slots are denoted by "~" in all columns for the slot. 6.4.1 Add User To add a new user, follow the steps below. -
Page 45: Certificates
Web GUI Step 2: Follow the rules below to enter the name of the user in the Username field. - Username is a string of 4 to 16 alpha-numeric characters. - It must start with an alphabetical character. - It is case-sensitive. -
Page 46: Add New Certificate
Web GUI 6.5.1 Add new certificate Figure 6-7: Certificate – Add Certificate The fields in Certificate – Add Certificate window are explained below. Certificate type: Support LDAP Certificate and CA Certificate. Upload File: Click to browse a certificate file which should be of pem type ... -
Page 47: Generate Csr
Web GUI 6.5.2 Generate CSR Figure 6-8: Certificate – Generate CSR The fields in Certificate – Generate CSR window are explained below. Certificate type: select HTTPS Certificate or LDAP Certificate. Country/Region: Country or Region of the organization - Maximum length of 64 characters. - Page 48 Web GUI State: State or Province of the organization - Maximum length of 64 characters. - Special characters '#' and '$' are not allowed. City: City or Locality of the organization - Maximum length of 64 characters.
-
Page 49: View Ssl
Web GUI 6.5.3 View SSL Figure 6-9: Certificate – View SSL The fields in the Certificate Configuration page are explained below. Certificate: Displays the basic information about the uploaded SSL certificate. It displays the field of certificate type.
