- Page 1 Mustang-V100-MX8 Mustang-V100-MX8 CPU Ca MODEL: Mustang-V100-MX8 ® ® Intel Vision Accelerator Design with Intel Movidius™ VPU Powered by Open Visual Inference & Neural Network Optimization (OpenVINO™) toolkit User Manual Page I Rev. 1.00 - October 5, 2018...
- Page 2 Mustang-V100-MX8 Revision Date Version Changes October 5, 2018 1.00 Initial release Page II...
- Page 3 Mustang-V100-MX8 Copyright COPYRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.
- Page 4 Mustang-V100-MX8 Manual Conventions WARNING Warnings appear where overlooked details may cause damage to the equipment or result in personal injury. Warnings should be taken seriously. CAUTION Cautionary messages should be heeded to help reduce the chance of losing data or damaging the product.
-
Page 5: Table Of Contents
Mustang-V100-MX8 Table of Contents 1 INTRODUCTION ......................1 1.1 I ......................2 NTRODUCTION 1.2 F ........................3 EATURES 1.3 B ....................... 3 LOCK IAGRAM 1.4 I/O ....................4 IMENSIONS 1.5 T ..................5 ECHNICAL PECIFICATIONS 2 UNPACKING ......................... 6 2.1 A .................. - Page 6 Mustang-V100-MX8 List of Figures Figure 1-1: Mustang-V100-MX8 ..................... 2 Figure 1-2: Block Diagram ......................3 Figure 1-3: Dimensions (mm) ......................4 Figure 3-1: Remove One Blank Bracket ..................12 Figure 3-2: Change to Full-height Bracket ................. 13 Figure 3-3: Change to Full-height Bracket ................. 13 Figure 3-4: Power Connector Location ..................
-
Page 7: Introduction
Mustang-V100-MX8 Chapter Introduction Page 1... -
Page 8: Introduction
The Mustang-V100-MX8 is a deep learning convolutional neural network acceleration card for speeding up AI inference, in a flexible and scalable way. Equipped with Intel® Movidius™ Myriad™ X Vision Processing Unit (VPU), the Mustang-V100-MX8 PCIe card can be used with the existing system, enabling high-performance computing without costing a fortune. -
Page 9: Features
Low power consumption, approximate 2.5W for each Intel® Movidius™ Myriad™ X 12V external power Equipped with rotary switch and LED indicator for card number identification 1.3 Block Diagram Figure 1-2 shows the block diagram of the Mustang-V100-MX8. Figure 1-2: Block Diagram Page 3... -
Page 10: I/Oand Dimensions
Mustang-V100-MX8 1.4 I/O and Dimensions The I/O interfaces and dimensions of the board are listed below: Figure 1-3: Dimensions (mm) Page 4... -
Page 11: Technical Specifications
Mustang-V100-MX8 1.5 Technical Specifications Mustang-V100-MX8 technical specifications are listed below. Specification Mustang-V100-MX8 Main Chip Intel® Movidius™ Myriad™ X Ubuntu* 16.04.3 (LTS), 64-bit Operating Systems CentOS 65-bit PCI Express x4 Physical PCIe Interface Compliant with PCI Express Specification v2.0 7-segment LED display for card ID... -
Page 12: Unpacking
Mustang-V100-MX8 Chapter Unpacking Page 6... -
Page 13: Anti-Static Precautions
Only handle the edges of the PCB: Don't touch the surface of the motherboard. Hold the motherboard by the edges when handling. 2.2 Unpacking Precautions When the Mustang-V100-MX8 is unpacked, please do the following: Follow the antistatic guidelines above. -
Page 14: Packing List
If any of the components listed in the checklist below are missing, do not proceed with the installation. Contact the IEI reseller or vendor the Mustang-V100-MX8 was purchased from or contact an IEI sales representative directly by sending an email to sales@ieiworld.com. -
Page 15: Hardware Installation
Mustang-V100-MX8 Chapter Hardware Installation Page 9... -
Page 16: Anti-Static Precautions
Mustang-V100-MX8 and severe injury to the user. Electrostatic discharge (ESD) can cause serious damage to electronic components, including the Mustang-V100-MX8. Dry climates are especially susceptible to ESD. It is therefore critical that whenever the Mustang-V100-MX8 or any other electrical component is handled, the following anti-static precautions are strictly adhered to. - Page 17 ESD from the body and helps prevent ESD damage. Turn off system: When installing the Mustang-V100-MX8, make sure that the system to be connected is disconnected from all power supplies and that no electricity is being fed into the system.
-
Page 18: Hardware Installation
Step 3: Locate available PCIe slots and remove the blank brackets. The Mustang-V100-MX8 is compatible with PCIe x4 slots, and only needs one PCIe slot for installation. Remove a blank bracket panel on the back of the computer that aligns with the PCIe slot for installing the Mustang-V100-MX8. Save the bracket screw. -
Page 19: Figure 3-2: Change To Full-Height Bracket
Step 5: Install and secure the Mustang-V100-MX8 to the system. Align the Mustang-V100-MX8 to the PCIe slot. Press down gently, but firmly, to seat the Mustang-V100-MX8 correctly in the slot. Install the bracket screw to secure the Mustang-V100-MX8 to the system’s chassis. -
Page 20: Figure 3-4: Power Connector Location
Mustang-V100-MX8. Figure 3-4: Power Connector Location Step 7: Assign a card ID to the Mustang-V100-MX8 by adjusting the rotary switch. The card ID number assigned here will be shown on the LED display of the card after power-up. - Page 21 Mustang-V100-MX8 Step 8: Repeat Step 3 ~ Step 7 to install multiple Mustang-V100-MX8 into the system if available. Step 9: Re-install the cover of the chassis. Step 10: Reconnect any power cords and any network cables to the system. Power up the system.
-
Page 22: Software Installation (Openvino™ Toolkit )
Mustang-V100-MX8 Chapter Software Installation (OpenVINO™ Toolkit ) Page 16... -
Page 23: System Requirements
Mustang-V100-MX8 4.1 System Requirements Linux Ubuntu 16.04.3 LTS 64bit CentOS 65-bit OpenVINO™ Toolkit was pre-installed in TANK-870AI. 4.2 Installation Go to https://software.intel.com/en-us/openvino-toolkit. Click “Get Started” then choose your configuration from “Development Environment Installation Guides & Videos”. Follow the instruction to complete the installation procedure. -
Page 24: A Regulatory Compliance
Mustang-V100-MX8 Appendix Regulatory Compliance Page 18... - Page 25 Mustang-V100-MX8 DECLARATION OF CONFORMITY This equipment has been tested and found to comply with specifications for CE marking. If the user modifies and/or installs other devices in the equipment, the CE conformity declaration may no longer apply. FCC WARNING This equipment complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: ...
-
Page 26: B Product Disposal
Mustang-V100-MX8 Appendix Product Disposal Page 20... - Page 27 Mustang-V100-MX8 CAUTION: Risk of explosion if battery is replaced by an incorrect type. Only certified engineers should replace the on-board battery. Dispose of used batteries according to instructions and local regulations. Outside the European Union–If you wish to dispose of used electrical and electronic products outside the European Union, please contact your local authority so as to comply with the correct disposal method.
-
Page 28: C Hazardous Materials Disclosure
Mustang-V100-MX8 Appendix Hazardous Materials Disclosure Page 22... - Page 29 Mustang-V100-MX8 The details provided in this appendix are to ensure that the product is compliant with the Peoples Republic of China (China) RoHS standards. The table below acknowledges the presences of small quantities of certain materials in the product, and is applicable to China RoHS only.
- Page 30 Mustang-V100-MX8 此附件旨在确保本产品符合中国 RoHS 标准。以下表格标示此产品中某有毒物质的含量符 合中国 RoHS 标准规定的限量要求。 本产品上会附有”环境友好使用期限”的标签，此期限是估算这些物质”不会有泄漏或突变”的 年限。本产品可能包含有较短的环境友好使用期限的可替换元件，像是电池或灯管，这些元 件将会单独标示出来。 部件名称 有毒有害物质或元素 铅 汞 镉 六价铬 多溴联苯 多溴二苯 醚 (Pb) (Hg) (Cd) (CR(VI)) (PBB) (PBDE) 壳体 显示 印刷电路板 金属螺帽 电缆组装 风扇组装 电力供应组装 电池 O: 表示该有毒有害物质在该部件所有物质材料中的含量均在 SJ/T 11363-2006 (现由 GB/T 26572-2011 取代) 标准规定的限量要求以下。...
