5 Sensing Labs SenlabA 4MA-LAB-xxNS – User guide – Version 2 – REV D
Application features (datalog mode)
This chapter describes the SenlabA application features available in datalog mode
(accessible via SLgateway or SLcodec – refer respective User Guide for more details)
Measure data
ID
current
battery_current_level
Event data
ID
start_event Happens when device is restarted on the field
Configuration requests
Parameter ID
log_period
log_tx_period
log_tx_random_activation
(optional)
NO PARAMETERS
NO PARAMETERS
Description
Measured current of 4-20mA connected
sensor
Battery level of the device
Description
Description
Datalog configuration
(ID = request_write_datalog_cfg)
Device will measure every X minutes
Device will send logged measure every X
minutes (must be a multiple of log_period)
Maximize device datalog reliability
Reset battery level
(ID = request_reset_battery_level)
Must be used after battery replacement only
Stop application
(ID = request_stop_application)
Warning: activation with magnet will be
mandatory to reactivate the device
Type Unit
FLOAT mA
UINT8 %
Type Unit
BOOL -
Type Unit
UINT16 Minute
UINT16 Minute
BOOL -
©2018 Sensing-labs
Range
0...25
1...100
Range
-
Range
1...1440
(1440=
24h)
3...1440
-
