User Guide CONTENT Product Features-----------------------------------------------2 Video Recording-------------------------------------------11 Before Use--------------------------------------------------------4 Viewing photos/videos----------------------------------12 System Modes---------------------------------------------------5 Setting Time/Date-----------------------------------------12 Multi-function keys-----------------------------------------6 Setting Time Display-------------------------------------13 Manual On Screen----------------------------------------- 7 Viewing on a TV monitor-------------------------------13 DELETE ALL--------------------------------------------------7 Setting video format-------------------------------------14 VIDEO OUTPUT--------------------------------------------- 7 Deleting a specific photo (Browse mode only)-14 DATE/TIME SETUP-----------------------------------------8 Deleting all photos---------------------------------------15 LANGUAGE---------------------------------------------------8... -
Page 2: Product Features
User Guide User Guide Product Features CONSOLE Handle/Controller (10) 1 – Handle 2 – Console (6) OK/MENU RECORD (1) Insert Tube (7) ESC SNAP (2) On/Off Switch & Light (8) SD Port POWER Source Adjustment (9) Video Output PREVIOUS (3) Camera Lens (10) AC Jack NEXT (4) Insert Tube Connector... -
Page 3: Before Use
“click” followed by illumination of the » Wireless Mode – DCS1800 also has a built-in wireless transmission function. It will adjust to Wireless adjacent green light. Mode automatically once the console and insertion tube controller are separated. -
Page 4: Multi-Function Keys
User Guide User Guide Manual On Screen Multi-function keys The user may press the OK/MENU button in Manual Mode to execute desired commands as indicated Each console button performs a unique function depending upon the Mode in which the system is being below. -
Page 5: Date/Time Setup
Channel Adjusting DATE/TIME SETUP MANUAL MENU TIME SETUP The DCS1800’s handle and console must be on the same channel during wireless transmission. Adjust Use the arrow buttons to select Year/Month/Day or DELDTE ALL 2000/01/101 VIDEO OUTPUT the channel by using a small slotted screw driver following the direction of the arrow sign as shown below. -
Page 6: Operating Instructions
User Guide User Guide Operating Instructions Control Handle Indicator Lights Light Indication Status Description Power On/Off Green In use Working under full battery Dark Red Low battery Please recharge the battery when the dark red light STEP1: To turn the console on, press the power button for 3~5 seconds until you see the sign below appears during usage appear on your monitor. -
Page 7: Viewing Photos/Videos
User Guide User Guide Note: User may return to Preview mode anytime by pressing button regardless of working under Browse mode 5.Press for next adjustment. MANUAL MENU TIME SET TIME SET DELDTE ALL 2000/02/14 or Manual mode. 6.Repeat step 4 and 5 until the correct time/date are set. VIDEO OUTPUT 17:30:51 DATE/TIME SETUP... -
Page 8: Setting Video Format
User Guide User Guide 2.Press OK/MENU 3. To select your option, press 3.Press to move to “Video output” option. Image Status: .The selected option flashes. 4.Press OK/MENU 4. Press OK/MENU to execute your selected option or press ESC to cancel. Image Status: image will be transmitted to the external monitor. -
Page 9: Re-Charging The Battery
User Guide User Guide Creation of Memory Card Folder 4.Press to select desired time length or choose “Disable”. The following information applies to the included SD card only. All photos and videos are stored in the 5.Press OK/MENU [100MEDIA] folder under the [DCIM] folder. All files will be named according to the time/date setup. The console will automatically turn off if it has not been used for this preset length of time. -
Page 10: Specifications
User Guide User Guide Specifications System Camera System and Insertion Tube System Dimension 146.9 * 105.4 * 71 mm Insertion tubes diameter 5.5 mm System Weight 335g Rescolution 325(H)*250(V) Power Battery rechargeable Li-Polymer battery 3.7V power supply Housing Steel AC 100-240V 50-60Hz power consumption DC5.5 1.8A Light Source White LED Display... -
Page 11: Troubleshooting
2.The insertion tube contains a series of small wires that control the optics and electronics of - Do not use the DCS1800 in a fuel tank or other dangerous environment such as a gasoline the camera tip. To ensure long-term reliability, do not bend the insertion tube more than or alcohol storage tank. - Page 12 - Please use only recommended components or accessories.Unapproved accessories and components may cause damage. - Please do not use the DCS1800 in a medical facility or on an airplane, as the wireless signal may interfere with other critical equipment nearby.
- Page 13 User Guide...
