Adjusting primary and secondary air inlets
You have purchased an insert model that offers maximum efficiency and performance. Therefore, control of the
primary air inlet, located in the ashtray, and the secondary air inlet, located on the left of the front of the appliance,
are essential to achieve optimum combustion levels.
Adjustable
secondary air inlet
Adjustable primary
air inlet
- Primary air inlet
It is essential to open to maximum position when lighting the fire and to leave the door ajar to avoid the
condensation of fumes on the glass, closing it again once the appliance has warmed up.
In order to avoid burns, always use the glove supplied with the
appliance when adjusting the primary air inlet and opening the door.
- Secondary air inlet
It must always be in open position when lighting the fire.
CLOSE OPEN
You can adjust the secondary air inlet when the appliance is warm enough and there is a sufficient amount of
flames.
