Adjusting the steel baffle

If there is no draught, you can adjust the steel deflector to evacuate fumes.

Note: opening the deflector will reduce the performance of the insert.

Baffle C-70 Plus, C-80 Plus, C-100 Plus

Pre-cut for adjustment

Lift the tab for the

draught

C-60 Plus Baffle
