This manual covers both uSwitch™ and uSwitchPro™. All exclusive features to the uSwitchPro will be, as this text is, on a
light blue background, differentiating its advanced features.
Additionally, this manual covers the most popular adapters to the uSwitch including the A-plug™ a universal 110VAC
uSwitch adapter.

uSwitch and uSwitchPro Features

•
Plug-and-Play
•
Two dry contact relays (5A@120Vac, 3A@250VAC), (5A@120VDC, 3A@ 250VDC) for direct connection to load.
(Not designed for devices with large inrush current)
•
No programming required
•
Auto Discovery mode user configurable
•
Connect from computers, smart phones, iPads and other web and network devices
•
May be used as a standalone device
•
Built-in web pages provide simple user interface for configuration and control.
•
Customizable user interface (customize controls, colors, text and buttons).
•
Removable terminal connectors (included) simplify wiring and service
•
Custom applications can control uSwitch with standard CGI interface.
•
Multiple levels of password protection
•
Supports fixed IP, DHCP, and Dynamic IP with port forwarding and virtual port addressing.
•
Selectable TCP ports for proxy server and NAT applications
•
10/100 Ethernet connectivity.
•
Built-in automatic watchdog mode on each relay; with three independent user assignable ping-able URL options
•
Watchdog Cloak™ mode for ultra-secure applications
•
Watchdog mode timers and counters user configurable
•
Latched, Momentary and Pulse timing modes for relays
•
Relay power up state user configurable (Closed, Open, Previous)
•
Minimal footprint
•
Low power consumption
•
Manual relay control mode
•
All inputs and outputs have user customizable state colors and state text
•
All inputs and outputs have user customizable displayed names
•
On board relays can be linked directly to onboard GPIOs
•
GPIO(s) and virtual buttons can drive relays on other uSwitch devices (Each Pro can drive up to 8 uSwitches and
16 relays which can be daisy chained to unlimited number of relays)
•
Input Counters for tracking events
•
Universal Voltage input 12-16VDC
•
Great documentation, Great support
•
Manufactured and all Software from USA
