Control Center (Relay1 Watchdog Mode, Startup Delay phase)
The image below shows the Control Center with relay1 configured in Watchdog Mode (a relay is placed in watchdog
mode from the Relay Configuraton page)..A greyed out relay button indicates manual control is disabled when watchdog
mode has been turned on. Whenever a relay is in watchdog mode it cannot be manually controlled by a push button. The
screen below shows relay1 in Watchdog mode. On the screen below thewatchdog feature has started the initial startup
countdown specified by the startup delay entry before testing for connectivity, currently 261 seconds remain before
watchdog mode becomes fully active. A minimum recommended startup countdown time of five minutes (300 seconds) is
recommended.
uSwitch and uSwitchPro Installation and Operating Manual
Page 13
