Page 1 MDR-8000 Microwave Digital Radios Users Manual Alcatel Part Number 3EM11931AA Issue 9, December, 2007 3400 West Plano Parkway Plano, Texas 75075-5813 U.S.A.
Page 3 From “MyAlcatel” go to “Alcatel Support Documentation” – Register for access to Documentation and e-mail Update notifications For Product Change Notices (PCN), Product Documentations, etc. – Software and Hardware upgrade documentation • Customized and Comprehensive Service Agreements ALCATEL-LUCENT’S PRIMARY MISSION IS SATISFYING OUR CUSTOMERS' QUALITY EXPECTATIONS.
Page 4 Technical Assistance Center Telephone Assistance, Normal Working Hours (CST 8am 5pm M-F) TAC supports all Alcatel North America Microwave products. This includes routine questions and emergency service. Telephone Assistance, Emergency After-Hours • Defined as loss of traffic, standby equipment, or network visibility on traffic-bearing systems. •...
Page 5 Table of Contents Page Section 1 General INTRODUCTION ..................... 1 - 1 CONTENT....................... 1 - 1 Section 2 Operation GENERAL ......................2 - 1 TURN-ON......................2 - 1 USER SYSTEM INTERFACE (USI) PROVISIONING FUNCTION/OPERATION ..2 - 2 OPERATING PROCEDURES ................2 - 2 2.4.1 Radio Receiver Manual Switching ..............
Page 6 High Capacity DS3 Radios ................3 - 7 3.5.3 High Capacity OC3 Radios................3 - 7 3.5.4 MDR-8000 Synchronous Repeater Compatibility Matrix ........3 - 8 3.5.5 MDR-8000 Synchronous Repeater Cables ............3 - 8 DS1 CONNECTIONS (J303 IN AND J304 OUT) ..........3 - 9 DS1 REPEATER (J314 ON ONE SHELF TO J314 ON SECOND SHELF) ....
Page 7: Table Of Contents
SECTION INTRODUCTION ................4 - 1 RECOMMENDED SEQUENCE ................. 4 - 1 SECURITY MANAGEMENT ................4 - 2 LOAD MDR-8000 SOFTWARE ON PC.............. 4 - 2 TURN-ON PROCEDURE ................... 4 - 4 ESTABLISH COM PORT ..................4 - 4 TEST PROCEDURES ..................4 - 7 PROVISIONING RADIO ...................
Page 8 RECOMMENDED TEST EQUIPMENT ..............5 - 4 OPTIONAL TEST EQUIPMENT ................5 - 4 PERSONAL COMPUTER (PC)/LAPTOP .............. 5 - 5 MDR-8000 ALARMS ..................5 - 7 ALARM MONITORING AND INSPECTION ............5 - 7 RECOMMENDED PERIODIC CHECKS .............. 5 - 8 RADIO TROUBLESHOOTING ................
Page 9 Section 6 User Guide INTRODUCTION ..................... 6 - 1 ANALOG SCREEN ..................6 - 1 6.2.1 PA (DC MON) ....................6 - 1 6.2.2 TX (PWR MON) ....................6 - 1 6.2.3 ATPC Voltage ....................6 - 1 6.2.4 RX (RSL 1) dBm ....................6 - 1 6.2.5 RX (EYE MON) ....................
Page 10 6.5.8 Radio Error Seconds ..................6 - 8 6.5.9 Radio Severe Error ................... 6 - 8 6.5.10 Radio BER ....................... 6 - 8 ETHERNET RADIO PERFORMANCE MONITORING SCREEN ......6 - 8 6.6.1 RF Receive ....................... 6 - 8 6.6.2 GPF Receive ....................
Page 11: Section Introduction
This provisioning part of the section describes provisioning options available with the MDR-8000 software application. Provisioning allows for the deﬁnition, editing, and storing of speciﬁc functions. The MDR-8000 provides the ability to provision equipment and facili- ties through a series of Windows™-based screens and messages. The Provisioning menu lists equipment and functions which may be provisioned.
Page 12: Security Management
SECURITY MANAGEMENT Note A password is not required to operate the MDR-8000. The radio is shipped without a password and if a password is desired, it must be entered using the Change Password screen. Once entered initially, the password must be entered each time the user wants to access the provi- sioning screens (level 1 password required) or download software (level 2 password required).
Page 13 2 CLICK HERE Exit Setup MDR-8000 Universal USI Setup Begin the installation by clicking the button below. CLICK HERE Click this button to install MDR-8000 Universal USI software to the specified destination directory. COPYING FILES Directory: Change Directory...
Page 14: Turn-On Procedure
TURN-ON PROCEDURE Note For user safety, user should become familiar with locations of power distribution units and circuit breakers associated with the MDR-8000 radio. Perform the following procedure to turn on the radio. On power supply module, set switch to .
Page 15 AE–37( ) CNTLR MDR–8000 SHELF TO CONNECTOR J301 (CONNECTS TO RS–232C AE–37 CONTROLLER) INTERFACE CABLE TERMINAL MW211–0066–1 101598 RS–232C PORT Figure 4-2 USI Computer Hookup...
Page 16 On Program menu, click on Win USI program. Win USI screen displays with message COMMUNICATING to indicate PC is communicating with the radio controller. If COMMUNICATION DOWN message is displayed, perform procedure shown on Figure 4 - 3 to change COM port. STOP .
Page 17: Test Procedures
TEST PROCEDURES The radio has been properly aligned and tested at the factory before shipment eliminating the need for testing after initial turn-up. The only time testing and/or adjustment is required is after a maintenance action such as removal and replacement procedure and/or constant alarms requiring corrective maintenance action.
Page 18 START FIG 4-5 DS1/E1, DS3, OC3/STM-1, ETH RADIO CONFIG PROVISIONING DS1/E1 OC3/STM-1 FIG 4-6 FIG 4-8 FIG 4-11 FIG 4-14 DS1/E1 RADIO DS3 RADIO OC3/STM-1 RADIO ETH RADIO CONFIG CONFIG CONFIG CONFIG PROVISIONING PROVISIONING PROVISIONING PROVISIONING FIG 4-7 FIG 4-9 FIG 4-12 FIG 4-15 DS1/E1...
Page 19 Not provisionable. of X/Y data) are being transported between J314 of both shelves. SYSTEM ID: ELMC: RADIO LINK ID: Disable R112 RADIO TYPE: MDR-8000 OC3 OC-3 128 TCM 10-11 GHz RADIO CONFIG: Hot-Standby Tx Hot-Standby Rx TERMINAL ATPC Disable NO PA...
Page 20 HOUR, ATPC GOES HIGH FOR 10 SECONDS AND THEN GOES TO LOW POWER. THIS CONTINUES UNTIL THE CMD PATH IS RESTORED. SELECT DISABLE TO DISABLE ATPC FUNCTION. SYSTEM ID: ELMC: RADIO LINK ID: TEST1 Disable RADIO TYPE: MDR-8000 DS1 16 LINES 128 TCM 6-8 GHz RADIO CONFIG: HS Tx/HS Rx TERMINAL ATPC Enabled A&B PA Present...
Page 21 Radio Configuration Service Channel DS1 Facilities ELMC: DS105 RADIO LINK ID: Disable SYSTEM ID: MDR-8000 DS1 16 LINES 128 TCM RADIO TYPE: 6GHz RADIO CONFIG: Non-Standby Tx Hot-Standby Rx TERMINAL ATPC Enabled A&B PA Present Relay Card Present SYSTEM ALARM:...
Page 22 Radio Configuration Service Channel DS3 Facilities ELMC: DS105 RADIO LINK ID: Disable SYSTEM ID: MDR-8000 DS1 16 LINES 128 TCM RADIO TYPE: U6-8GHz RADIO CONFIG: Hot-Standby Tx Hot-Standby Tx Hot-Standby Rx Hot-Standby Rx Repeater ATPC Disable A&B PA Present Relay Card Present...
Page 23 Radio Configuration Service Channel DS1 Facilities ELMC: DS105 RADIO LINK ID: Disable SYSTEM ID: MDR-8000 DS1 16 LINES 128 TCM RADIO TYPE: U6-8GHz RADIO CONFIG: Hot-Standby Tx Hot-Standby Tx Space Diversity Rx Space Diversity Rx Repeater ATPC Disable A&B PA Present...
Page 24 WITH AN AIS SIGNAL PRIOR TO TRANSMISSION). SELECT ON TO DROP USING THE REPEATER CABLE TO PASS DS1 DATA ON CHANNELS LINE OR OFF TO 5-16 IS NOT RECOMMENDED ON MDR-8000 RADIOS. PASSING THE DISABLE LINE AND DATA THROUGH ON THESE CHANNELS WILL PREVENT ALARMS.
Page 25 Radio Configuration Service Channel DS3 Facilities WaySide DS1 Facilities ELMC: DS305 RADIO LINK ID: Disable SYSTEM ID: MDR-8000 DS3 3 LINES 64 QAM RADIO TYPE: 6GHz RADIO CONFIG: Non-Standby Tx Hot-Standby Rx TERMINAL ATPC Enabled A&B PA Present Relay Card Present...
Page 26 Radio Configuration Service Channel DS3 Facilities WaySide DS1 Facilities ELMC: DS305 RADIO LINK ID: Disable SYSTEM ID: MDR-8000 DS3 3 LINES 64 QAM RADIO TYPE: U6-8GHz RADIO CONFIG: Hot-Standby Tx Hot-Standby Tx Hot-Standby Rx Hot-Standby Rx Repeater ATPC Disable A&B PA Present...
Page 27 Radio Configuration Service Channel DS1 Facilities ELMC: DS105 RADIO LINK ID: Disable SYSTEM ID: MDR-8000 DS1 16 LINES 128 TCM RADIO TYPE: U6-8GHz RADIO CONFIG: Hot-Standby Tx Hot-Standby Tx Space Diversity Rx Space Diversity Rx Repeater ATPC Disable A&B PA Present...
Page 28 Note If installation at both ends of a hop are complete except for connecting to customer inputs/outputs and it is desirable to have an alarm-free system, alarm reporting on the incomplete connections can be disabled temporarily through provisioning. You can communicate over the hop even if you do not have the radio connected to customer DS3 and wayside DS1 inputs;...
Page 29 SELECT AMI OR B8ZS CODING FOR WAYSIDE DS1 LINE. SELECT ON TO DISABLE ALARM REPORTING FOR WAYSIDE DS1 LINE. SELECT OFF TO REPORT ALL ALARMS FOR THAT LINE. DS1 CARD A DS1 CARD B DS1 LINES Select All ALARM LOCK OUT DS1 LINE CODING AIS INHIBIT AIS INSERT...
Page 30 SYSTEM ID: ELMC: TEST 1 RADIO LINK ID: Disable RADIO TYPE: MDR-8000 OC3 OC3-3 128 TCM RADIO CONFIG: HS Tx TERMINAL HS Rx ATPC Enabled A&B PA Present Visual/Audible SYSTEM ALARM RELAYS ON/NO Station Alarm 13-16 RSL Alarm Enable RCV SWITCHING:...
Page 31 1X10-6 1X10-6 1X10-6 Alarm Disable Tuesday, June 3, 2003 5:20:04 AM USI Version R1.04 MDR-8000 OC3 Controller Version R1.4 SELECT ERROR RATE (1x10-5, SELECT ERROR RATE (1x10-5, 1x10-6, 1x10-6, 1x10-7, OR 1x10-8) 1x10-7, OR 1x10-8) WHICH CAUSES WHICH CAUSES OC3 INPUT...
Page 32 Fiber Configuration 4 Fiber Switched 2 Fiber Frame & B1 Section OH Insertion 2 Fiber Switched 4 Fiber MDR-8000 OC3 Controller Version R1.00 Tuessday, March 7, 2000 1:27:15 PM USI Version R1.00 4 Fiber Switched 4 Fiber Switched TRANSMITTER RECEIVER...
Page 33 2 Fiber Switched 2 Fiber Frame & B1 Section OH Insertion 2 Fiber Switched 2 Fiber Switched 4 Fiber MDR-8000 OC3 Controller Version R1.00 Tuessday, March 7, 2000 1:27:15 PM USI Version R1.00 4 Fiber Switched TRANSMITTER RECEIVER Select All...
Page 34 Figure 4 - 13 OC3/STM-1 Radio Wayside DS1 Facilities Provisioning Note A password is not required to operate the MDR-8000. The radio is shipped without a password and if a password is desired, it must be entered using the Change Password screen. Once entered initially, the...
Page 35 Displays modulation scheme. Displays radio type. Not provisionable. Not provisionable. SYSTEM ID: ELMC: RADIO LINK ID: Disable R112 RADIO TYPE: MDR-8000 ETH 150 Mbs 128 TCM 5-8 GHz RADIO CONFIG: Non-Standby Tx Non-Standby Rx TERMINAL Relay Card Present ATPC Disable...
Page 36 A & B Switched A Only Frame & B1 Section OH Insertion A & B Switched A & B Separate MDR-8000 OC3 Controller Version R1.00 Tuessday, March 7, 2000 1:27:15 PM USI Version R1.00 A & B Summed TRANSMITTER RECEIVER...
Page 37 A & B Summed A Only Frame & B1 Section OH Insertion A & B Switched A & B Separate MDR-8000 OC3 Controller Version R1.00 Tuessday, March 7, 2000 1:27:15 PM USI Version R1.00 A & B Summed TRANSMITTER RECEIVER...
Page 38 A & B Summed Allow 10 Mb Half Duplex Tuessday, March 7, 2000 1:27:15 PM USI Version R1.00 MDR-8000 OC3 Controller Version R1.00 Allow 10 Mb Full Duplex Allow 100 Mb Half Duplex Allow 100 Mb Full Duplex DIPLEXER Allow 1000 Mb Full Duplex...
Page 39: Provision Ethernet Facility
PROVISION ETHERNET FACILITY See Figure 4 - 15 to provision the Ethernet radio. Alcatel User Interface – [Universal USI – Provisioning ] File View Setup Options Prov. Save Alarm Status Analog Monitor Performance Station Alarm User Control Provisioning Password ELMC Address: 201R2 LOCAL ETHERNET PROVISIONING (RS-232) Communicating*...
Page 40: Auto-Negotiation
Auto-Negotiation 4.9.1 MDR-8000E auto-negotiation is not a stand-alone function, and proper operation and use of all available functions depends on the capabilities of the external customer equipment that is connected to the radio. Just because an autonegotiation function is checked for pro- visioning does not automatically mean that function is fully operable.
Page 41 Input Pause Feature 4.9.1.4 See Figure 4 - 16. Checking the box next to Allow Input Pause makes the auto-negotiation function willing to stop receiving trafﬁc. When the radio input buffers approach overﬂow, the function sends a pause message to the ink partner that is transmitting data to the radio, telling the device to temporarily stop sending data.
Page 42: Provision Ds1 Facility
Allow Output Pause 4.9.1.5 Checking the box next to Allow Output Pause makes the radio auto-negotiation function willing to stop sending trafﬁc. When the input buffers on the link partner approach over- ﬂow, the link partner sends a pause message to the radio, telling the radio to temporarily stop sending data.
Page 43 Change Password -- Change Level 1 Password Enter the New Level 1 Password: Confirm the New Level 1 Password: Change Level 2 Password Enter the New Level 2 Password: Confirm the New Level 2 Password: Cancel Save Password Forgot Password MDR-1033 09/02/04 Level One Password --...
Page 44 Alcatel User Interface – [System, DS3, and DS1 Provisioning -- MDR-8000 DS3] File View Setup Options Prov. Save Alarm Status Analog Monitor Performance Station Alarm User Control Provisioning LOCAL DS3 PROVISIONING ELMC Address: J7914 ELMC Description: DURANGO Communicating*** Radio Configuration...
Page 45 1 J316 or Alcatel User Interface – [System, DS3, and DS1 Provisioning -- MDR-8000 DS3] audio port 2 J317 on the radio backplane. These provisionable 4-wire audio functions should File View Setup Options not be confused with the 2-wire audio handset.
Page 46 HANDSET IS PARTY-LINE. DTMF ADDRESSING IS A LOCAL FUNCTION NOT A NETWORK FUNCTION, THEREFORE, IF ONE OR MORE RADIOS ARE ASSIGNED THE SAME DTMF ADDRESS, THEY WILL ALL RING WHEN THAT ADDRESS IS Alcatel User Interface – [System, DS3, and DS1 Provisioning -- MDR-8000 DS3] DIALED. File View Setup Options TO BE ABLE TO USE THE DTMF FUNCTION: 1.
Page 47 Alcatel User Interface – [System, DS3, and DS1 Provisioning -- MDR-8000 DS3] File View Setup Options Prov. Save Alarm Status Analog Monitor Performance Station Alarm User Control Provisioning LOCAL DS3 PROVISIONING ELMC Address: J7914 ELMC Description: DURANGO Communicating*** 1:, 2: OR 3: – THE 64 kb/s SERVICE CHANNEL TO BE INSERTED INTO RADIO...
Page 48 Channel 1 Channel 2 Repeater D/1 RS-232 SELECT FOR TERMINAL (ONE DIRECTION) AE-37( ) CONTROLLER SC MULDEM J343 J314 RCV SC DATA E TO/FROM DROP XMT SC I/O INTFC DATA W INSERT RS-232 RXD1 RS-232 TXD1 J312 DATA PATH NOT USED Channel 1 Channel 2 Repeater D/1...
Page 49 Select ports on I/O INTFC module that will be used to insert and drop service channel data. Channel MCS Transport RF/Rptr PPP Transport RF/Rptr None None Rptr Rptr Select channel 1, 2, or 3 as RF/Rptr RF/Rptr service channel to be used for MCS transport and/or PPP transport.
Page 50 4) MCS-11 = Non TMN compatible MCS-11 + PPP = TMN compatible 5) TMN compatibility is determined by the radio controller software and radio provisioning. MCS-11 PROTOCOL RF PORT RF PORT MDR-8000 MDR-8000 ANY PROTOCOL DISABLED RPTR PORT RPTR PORT MCS TRANSPORT...
Page 51 3) RPTR at both ends must be provisioned for the same PPP Transport selection. 4) MCS-11 = Non TMN compatible MCS-11 + PPP = TMN compatible 5) TMN compatibility is determined by the radio controller software and radio provisioning. MCS-11 MCS-11 MDR-8000 MDR-8000 RF PORT RF PORT DISABLED DISABLED...
Page 52 2) RPTR at both ends must be provisioned for the same PPP Transport selection. 3) MCS-11 = Non TMN compatible MCS-11 + PPP = TMN compatible 4) TMN compatibility is determined by the radio controller software and radio provisioning. DISABLED MCS-11 MDR-8000 MDR-8000 RF PORT RF PORT MCS-11 MCS-11...
Page 53 RPTR at both ends must be provisioned for the same PPP Transport selection. MCS-11 = Non TMN compatible MCS-11 + PPP = TMN compatible TMN compatibility is determined by the radio controller software and radio provisioning. MCS-11 MCS-11 MDR-8000 MDR-8000 RF PORT RF PORT MCS-11 MCS-11...
Page 54 Alcatel User Interface – [System, DS3, and DS1 Provisioning -- MDR-8000 DS3] File View Setup Options Note Prov. Save Alarm Status Analog Monitor Performance Station Alarm User Control Provisioning A default MCS-11 address (A1A) is assigned automatically. A different unique address must be entered for each radio...
Page 55 7. CLICK HERE DESCRIPTION ELMC ADDRESS. EXACTLY. TO ENTER NEW (IF DESIRED). 4. OPEN ELMC ADDRESS ADDRESS AND SETUP SCREEN. DESCRIPTION Setup ELMC Address -- MDR-8000 Extended Link Monitor Channel (Elmc) Address J7914 DURANGO ELMC: J7914 Description: DURANGO Add Elmc=> Save...
Page 56 Current time-out is 3 secs 4 secs 5 secs 6 secs 7 secs 8 secs 9 secs 10 secs Cancel Alcatel User Interface - [Alarm Status -- MDR-8000 OC3] File View Setup Options ✓ Acknowledge Alarm Status Analog Monitor Performance Station Alarm User Control...
Page 57 NOTE: DEFAULT CONTROL NAMES ARE USER CONTROL 1-6 1. OPEN USER CONTROL NAMES SETUP SCREEN 2. SELECT RADIO User Control Names Setup -- MDR-8000 CONTROL NAMES ELMC List GEN START RACK1 DURANGO RACK2 DURANGO TWR LIGHT OVRD RACK3 RED MTH PASS...
Page 58 1. SELECT RADIO CLICK HERE TO SAVE Alcatel User Interface – [Provisioning MDR-8000 OC3] File View Setup Options Prov. Save Alarm Status Station Alarm User Control Password Analog Monitor Performance ELMC ADDRESS: S302 LOCAL DS3 PROVISIONING Communicating*** ELMC ADDRESS: DS301 -- MDR-8000 DS3...
Page 59: Introduction
This section contains information and procedures to aid in restoring the equipment to its proper operating condition after it has been determined that a problem exists. The following warnings and cautions apply while operating, performance testing, trouble- shooting, or repairing the MDR-8000 series radios. DANGER Possibility of...
Page 60: Maintenance Philosophy
CAUTION Possibility of Service Interruption RF ﬂex coaxial cable requires special consideration. The electrical char- acteristics of the coax can be affected if it is accidentally twisted or bent. Provide mechanical support to prevent any weight or strain to the coax and connector when connecting or disconnecting equipment.
Page 61 Alarm Periodic Check Performance Indication Failure* Screen Errors Para. 5.6 Para. 5.8 Para. 5.9.3 Perform Trouble Analysis Para. 5.9 Checks and Adjustments Cause Required Alarm Module Replacement Required Refer to Module Replacement Table Table 5 - 6 Module Adjustment Required Perform Applicable Checks and Adjustments Per Module Replacement Table...
Page 62: Recommended Test Equipment
RECOMMENDED TEST EQUIPMENT Refer to Table 5 - 1 for the list of recommended test equipment. Alcatel recommends this test equipment to properly maintain the radio. Table 5 - 1 Recommended Test Equipment Test Equipment/Function Essential Characteristics Used On Digital Volt Meter (DVM) Out-of-Service Carrier Null Adjustment Fluke 75 Using DVM (Refer to CD).
Page 63: Personal Computer (Pc)/Laptop
Table 5 - 2 Optional Test Equipment (Cont.) Test Equipment/Function Essential Characteristics Used On Communications Ana- Over-The-Hop DS1 BER Threshold Test lyzer w/DS1 Package Acterna TB 2310-P4 D1 Data Rate 1.544 Mb/s, DS1 Modulation B8ZS or AMI Scheme Communications Ana- Over-The-Hop DS3 BER Threshold Test lyzer w/DS3 Package Acterna TB 2310-P5...
Page 64 AE–37( ) CNTLR MDR–8000 SHELF TO CONNECTOR J301 (CONNECTS TO RS–232C AE–37 CONTROLLER) INTERFACE CABLE TERMINAL MW211–0066–1 101598 RS–232C PORT Figure 5 - 2 USI Computer to Controller Interconnection...
Page 65: Mdr-8000 Alarms
MDR-8000 ALARMS MDR-8000 Alarms are displayed on: USI Alarm and Status screen Alcatel MCS-11 Monitor and Control System SNMP MIB browser TBOS foreign alarm system External relay interface Module front panel indicators Alarm names are radio/alarm equipment dependent. The Alarm List found under NOC Alarm Troubleshooting on the enclosed CD, identiﬁes every alarm name indicated by the...
Page 66: Recommended Periodic Checks
RECOMMENDED PERIODIC CHECKS Perform XMTR local oscillator frequency veriﬁcation (Para. 5.18) and XMTR output check (Para. 5.19) 1 year after initial setting and at 5-year intervals thereafter to correct possible drift caused by aging. RADIO TROUBLESHOOTING The digital radio system is equipped with alarm circuitry and automatic switching (in hot- standby, frequency diversity, and space diversity conﬁgurations) to provide protection against loss of trafﬁc.
Page 67: Troubleshooting Performance Screen Errors
Troubleshooting Performance Screen Errors 5.9.3 Path and intermod problems can occur that cause errors to be indicated on the Perfor- mance monitor screens that are not severe enough to generate an alarm on the USI Alarm and Status screen. Errors of this type fall into two categories: burst and dribbling errors. The performance screens can be a useful tool in troubleshooting a radio with and without alarms being indicated on the Status Alarm screen.
Page 68 Loss of XMT signal detected at output of PA. If any other alarms are red, go to 1. If not, go to 2. If Off Normal alarm is lit, check 10.5 V switch on power supply is on. If not, remove/replace PA module.
Page 69 Both RCVRs at the other end have a problem and have switched the TRANSMITTER XMTRs to try and clear it. If the RCVRs clear within a defined time frame STATUS (which we will hereafter call the CLA window) after switching, the CLA appears.
Page 70 DS3 I/O INTFC cannot recover framing from incoming DS3 signal or there is no TRANSMITTER input signal. Is DS3 AIS Detect Alarm on? STATUS Yes, troubleshoot upstream radios and external MUX equipment. No, check input signal. If input signal is OK, replace DS3 I/O INTFC.
Page 71 Note Always troubleshoot and clear the most severe alarm first. Channel Fail is the most severe, followed by Radio Frame Loss and Eye Closure. The Eye Closure alarm, Radio Frame Loss alarm, and Channel Fail alarm all work together to form effective 3-level troubleshooting tools. If RECEIVER the radio is provsioned correctly, Eye Closure STATUS...
Page 72: Rx (Afc Mon)
A Channel Fail alarm occurs when RCVR(s) have lost lock and are not locked on the signal from the farend XMTR(s). Loss of signal also means loss of CMD path. The most effective method of troubleshooting this type RECEIVER alarm is to have a technician at both ends of the hop. Farend status STATUS viewing and controls must be performed at the farend site.
Page 73 Note Always troubleshoot and clear the most severe alarm first. Channel Fail is the most severe, followed by Radio Frame Loss and Eye Closure. Loss of radio frame from RCVR in I/O Interface RCVR circuits. Before starting, check USI for receiver Channel Fail alarms and Common...
Page 74 Errors are being received by the RCVR at a rate exceeding the Eye RECEIVER BER threshold error rate provisioned on the radio configuration STATUS screen. This alarm could be caused by a faulty XMTR (farend), radio Receiver Fault interference on the RF path (RFI), antenna/waveguide problem, or a Receiver On Line faulty antenna/waveguide problem, or a faulty RCVR/RCVR local Channel Fail...
Page 75 Note is displayed on DS1 USI Status and Alarm Radio Dade screen only. Low RSL on alarmed RCVR. Alarm only functions if AGC switching threshold is provisioned active. RECEIVER 1. Check for path fading. STATUS 2. Check upstream XMTR. Receiver Fault Receiver On Line Channel Fail High level of distortion in TDE due...
Page 76 I/O Interface cannot recover framing from signal from RCVR module. 1. Is DS3 AIS Detect alarm on? Yes, check for upstream XMTR DS3 AIS Detect alarm. If XMTR DS3 AIS Detect alarm is on, troubleshoot external MUX equipment at XMT end. If not, troubleshoot upstream XMTR.
Page 77 Future use AIS (blue signal), inserted at MUX (external to the radio) has been detected by OC3/STM-1 I/O INTFC RCV circuits. I/O conditioner cannot recover framing Troubleshoot external MUX equipment from signal from RCVR module. OC3 Output Online (fault is not in radio). 1.
Page 78 Module is present, but cannot communicate with Controller on I C Bus. Voltage regulation failure or 1. Remove and replace module indicating read fail on Inventory screen. excessive load. 2. Remove and replace Controller. 1. Cycle power 2. Check fuse COMMON 3.
Page 79 MESSAGE MEANING ACTIONS A Tx Override Override function is enabled Disable override function on on controller module locking A- controller module front panel. side XMTR/PA in-service. Switching is disabled regard- less of alarms. B Tx Override Override function is enabled Disable override function on on controller module locking B- controller module front panel.
Page 80 MESSAGE MEANING ACTIONS B Side PA OFF switch on B-side switch on B- PA ON/OFF PA ON/OFF power supply is set to side power supply to Prov. Mismatch Provisioning on the controller Provision to match system does not match the provision- requirements.
Page 81 LOS has been detected at RCV Input of I/O interface and AIS (All Ones or Zeros) is being inserted. Check for LOS at XMT end of HOP. If not, 1. Check for upstream XMTR alarms. Any XMTR alarms? Yes, troubleshoot XMTR. No, go to 2.
Page 82: Ethernet-Specific Troubleshooting
The LEDs on the front panel of the Ethernet I/O Interface module and the alarms on the radio USI status and alarm screen are the ﬁrst indication of a fault. Troubleshoot radio XMT and RCV alarms using the procedures in the MDR-8000 Instruction Book/Users Manual. Troubleshoot Ethernet alarms as follows: Troubleshooting Using Ethernet I/O Interface Module Front Panel Indicators 5.10.1...
Page 83 Table 5-3 Troubleshoot Using Ethernet I/O Interface Module Indicators (Cont.) Indication Probable Cause Corrective Action ETH IN Green LED Loss of Ethernet RCV/radio XMT Not Lit signal in. Most probable causes: 1. Cable between link partner and Connect/repair cable. radio is disconnected/broken. 2.
Page 84: Tmn-Specific Troubleshooting
TMN-SPECIFIC TROUBLESHOOTING 5.11 Refer to Table 5 - 4. The red ALM LED on the front panel of the TMN Interface module and the alarm on the radio USI status and alarm screen are the ﬁrst indication of a fault. The ALM LED on the front panel of the TMN Interface module lights for any module fault.
Page 85 Table 5-5 TMN Network Troubleshooting Problem Possible Cause Possible Solution 1. Normal network management 1. There may be too many radios Unusually slow communi- trafﬁc is saturating the communi- being managed within a single cation in radio network cations channel. region.
Page 86 Table 5 - 5 TMN Network Troubleshooting (Cont.) Problem Possible Cause Possible Solution 1. Manager not registered in NE to 1. Register Manager with NE. No traps being received receive traps from NE 2. Communication failure in net- 2. Check network connectivity. work Check redundant network paths and routing.
Page 87: Module Replacement
MODULE REPLACEMENT 5.12 WARNING Possibility of Damage to Equipment Modules screwed to heat sink must be screwed securely before power is turned on. WARNING Possibility of Damage to Equipment Units with the electrostatic-sensitive (ESS) symbol contain ESS devices. Store these units in an antistatic container when not in use, and anyone handling a unit should observe antistatic precautions.
Page 88 CAUTION Possibility of Service Interruption XMTR Crystals are soldered and tuned up in an oscillator assembly board at the factory. CAUTION Possibility of Service Interruption Modules may be removed or installed with shelf power applied. However, exercise reasonable care to prevent contact- ing adjacent modules.
Page 89 Table 5-6 Module Replacement Matrix MODULE/UNIT REMOVAL/REPLACEMENT CHECKS/ADJUSTMENTS PROCEDURE PROCEDURE AE-27AF Relay Interface No Special Procedure Required None Required AE-37Y Controller Para. 5.14 None Required CE-16BB Power Supply Para. 5.13 None Required Fuse No Special Procedure Required. Refer to Operations Section for Location.
Page 90: Power Supply Removal And Replacement
POWER SUPPLY REMOVAL AND REPLACEMENT 5.13 See Figure 5 - 13 and follow the procedure to remove and replace CE-16BB Power Supply. CAUTION Possibility of Service Interruption This is an out-of-service procedure when on a nonstandby (unprotected) system. On a hot-standby or frequency diversity system, switch traffic on the channel under test to protect.
Page 91: Controller Removal And Replacement
CONTROLLER REMOVAL AND REPLACEMENT 5.14 See Figure 5 - 14 and follow the procedure to remove and replace AE-37Y Controller. CAUTION Possibility of Service Interruption This is an in service procedure, however protection switching is disabled. If another failure occurs during the performance of the procedure, service will be interrupted.
Page 92 Note A replacement controller that is loaded with the same firmware load as the controller that is being replaced (i.e.: controller for DS3 radio is replacing a DS3 radio controller) is automatically rebooted and provisioned to match the module it is replacing. If the replacement controller is for a different type of radio (i.e.;...
Page 93: User Controls
Provisioning hold Click here. Click here. message displays. Alcatel User Interface File View Setup Options Communication Options New Controller Provisioning Alarm Status Performance Station Alarm User Control Firmware Upgrade LOCAL MAIN ELMC Address Prov. Hold Diagnostics Communicating*** ELMC Descriptions TDE Chip Receive Provisioning Note Provisioning hold message is displayed...
Page 94: User Controls
CLICK HERE CLICK HERE CLICK HERE Alcatel User Interface File View Setup Options Communication Options New Controller Provisioning Alarm Status Performance Station Alarm User Control Download Firmware Upgrade LOCAL MAIN ELMC Address Prov. Hold Diagnostics ELMC Descriptions Communicating*** TDE Chip Receive Provisioning 11-DS1 21 = R2.01 = Release Version...
Page 95: Ds3 I/O Interface Removal And Replacement
DS3 I/O INTERFACE REMOVAL AND REPLACEMENT 5.15 Follow procedure to remove and replace DX-35N DS3 I/O Interface module. Refer to Table 5 - 7 and Table 5 - 8 for conﬁguration functions. Table 5 - 7 1- or 3-Line I/O Interface Module PN 3DH03169XX System Front Panel...
Page 96 Table 5 - 9 1- or 3-Line Matrix, Valid Combinations/Procedures I/O Interface Module Radio Radio Line DADE PN 3DH03169AAXX DADE Conﬁguration in Shelf Position Conﬁguration (Refer to CD) ( Refer to CD ) A3, B3, Variant XX = HS, FD, SD HS, FD, SD HS, FD, SD HS, FD, SD...
Page 97: Oc3/Stm-1/Eth I/O Interface Removal And Replacement
OC3/STM-1/ETH I/O INTERFACE REMOVAL AND REPLACEMENT 5.16 Use this procedure to remove and replace DX-35P OC3/STM-1 or DX-35R/S ETH I/O Interface module. If radio is protected (hot-standby, space diversity, or frequency diversity, use front panel controls on AE-37( ) Controller to lock on-line OVRD XMTR, RCVR, and I/O (opposite side from failed I/O) on line.
Page 98: Xmtr Removal And Replacement
XMTR REMOVAL AND REPLACEMENT 5.17 Use this procedure to remove and replace the UD-35( ) XMTR and/or Capacity Key and Crystal Oscillator Subboards on the XMTR. Note Spare XMTRs and XMTRs repaired at the factory normally do not con- tain Crystal Oscillator Subboards or Capacity Keys. The user must retain the crystal Oscillator Subboard and the Capacity Key from the module being replaced before sending the module back to the factory for repair.
Page 99 Perform XMT Crystal Oscillator Frequency Checks and Adjustment procedure. Refer to Para. 5.18. On power supply, set PA ON/OFF switch to ON (if turned off in Step a). Note Output level calibration is required for the last ampliﬁcation stage in the chain of XMT ampliﬁers leading to the antenna, only.
Page 100 Remove: Remove transmitter from card cage. Remove 8 screws from Crystal Ocsillator Subboard cover, and remove cover. XMTR–RIGHT SIDE VIEW Disconnect ribbon Remove 3 mounting screws, cable from J8. and remove Crystal Oscillator Subboard. Install: Place Crystal Oscillator Subboard in mounting cavity. Install 3 mounting screws.
Page 101 CAUTION Possibility of Service Interruption This is an out-of-service procedure when on a nonstandby (unprotected) system. On a hot-standby or frequency diversity system, switch traffic on the Remove: channel under test to protect. Remove transmitter from card cage. Remove 13 screws from Capacity Key and remove Capacity Key.
Page 102 NTFC Connect power meter with 50 OHM power sensor to RF MON connector on PA. Measure RF monitor level on power meter. XMT LVL While monitoring power meter, adjust PWR ALM control on XMTR for READ XMT LVL ADJ PWR MON X.X dBm level on PA label.
Page 103 Connect DVM to DC MON (+) test point and GND on PA. DC MON Measure DC monitor level on DVM. XMT LVL PWR ALM While monitoring voltage on DVM, adjust XMT TEMP ALM LVL ADJ control on XMTR for READ (X.X Vdc) PWR MON DC MONITOR CALIBRATION voltage on PA label.
Page 104: Xmt Crystal Oscillator Frequency Correction
XMT CRYSTAL OSCILLATOR FREQUENCY CORRECTION 5.18 PURPOSE See Figure 5 - 19 and follow the procedure to correct the transmit frequency of the crystal oscillator on the UD-35() Transmitter module. Allow a 1-hour warm-up period for radio and test equipment before starting applicable tests or improper frequency adjustment can result.
Page 105: Xmtr Output Level Check (No Pa)
XMTR OUTPUT LEVEL CHECK (NO PA) 5.19 See Figure 5 - 20 and follow the procedure to check the RF output of the UD-35( ) Transmit- ter in radio conﬁguration that is not equipped with the optional PA. CAUTION Possibility of Service Interruption This is an out-of-service procedure when on a nonstandby...
Page 106: In-Service Xmtr Carrier Null Adjustment Using Spectrum Analyzer
Transmitter, in service. For out-of-service carrier null procedures, refer to CD. Note Carrier leakage can be nulled in the MDR-8000 using any one of three methods. Method 1 (the preferred method) uses a spectrum analyzer to determine if carrier leakage is present while a modulated signal is being transmitted (in service) and then nulling any carrier present.
Page 107 PO SHELF CONNECT SPECTRUM ANALYZER TO RF MON CONNECTOR. XMT LVL b. SET SPECTRUM ANALYZER CONTROLS. CONTROL SETTING PWR MON INPUT ATTEN (dB) 10 dB FREQ CONT CENTER FREQ CHAN FREQ XMT PWR (SEE FREQ LABEL ON LINE ON XMTR OR PA). I CARR NULL FREQ SPAN VALUE APPROXIMATELY...
Page 108 Reduce the frequency span on the spectrum analyzer display while keeping the spectrum centered on the spectrum analyzer display. Continue to reduce the spectrum analyzer span while observing the ﬁeld in the bottom left corner of the spectrum analyzer display. Continue reducing the frequency span until the correct Res BW measuring carrier for the Radio Capacity/Modulation is displayed.
Page 109 CAUTION Possibility of Service Interruption Adjustment of the carrier signal for minimum amplitude is critical. Do not attempt to null the carrier signal until the correct Res BW is reached. Incorrect adjustment can result in loss of trafﬁc due to slow RCVR lock. Observe the display at the correct for measuring carrier for a Res BW...
Page 110 a. Center carrier on screen. Note It is extremely important to keep the carrier signal centered in the display so that the carrier will become visible as the span is reduced. b. Reduce Span to 30 mHz. 10 dB above c.
Page 111 e. Center carrier on screen. f. Reduce Span to 1 mHz. g. Center carrier on screen. i. Reduce Span h. Observe to 500 kHz. Res BW MDR-1217 09/20/05 5-53...
Page 112 Note You must watch the trace carefully on the spectrum analyzer when adjusting the I and Q carrier controls on the XMTR module. the I and Q carrier controls are interactive and the slightest change on one control causes a change on the other.
Page 113 5-55...
Page 114: Xmtr Output Level Calibration
XMTR OUTPUT LEVEL CALIBRATION 5.21 See Figure 5 - 21 and follow the procedure to check, and if necessary adjust, the RF output of the UD-35() Transmitter in radio conﬁguration that is not equipped with the optional CAUTION Possibility of Service Interruption This is an out-of-service procedure when on a nonstandby...
Page 115 ELMC Address: RACK6 Communicating* 10-May-99 high and low output level: Description: MDR-8000 XMTR nominal high output level = level at top of stack + insertion loss of diplexer filter/XMT filter CLICK CALIBRATE A OR B SIDE (marked on label on filter.
Page 116 Note Ensure ATPC is disabled. Save the calibrated values. Click next Storing calibration data, please wait... Abort Back Next Abort Back Next Click Next. Click Next. Successfully stored calibration data Back Finish Click Finish. Calibration is complete. Disconnect power meter and sensor Observe RF MON label on XMTR from connector.
Page 117 Connect Power Meter with 50 OHM Power Sensor to RF MON connector. Measure RF Monitor Level on Power Meter. XMT LVL Make new label for RF MON. MEASURED LEVEL PWR MON (STEP b). FREQ CONT XMT PWR READ [X.X dBm] FOR [XX.X dBm] ON LINE AT TOP OF RACK...
Page 118 Connect DVM to PWR MON test point. XMT LVL Measure voltage on DVM. Make new label. PWR MON FREQ CONT XMT PWR DC MONITOR CALIBRATION MEASURED LEVEL READ [X.X Vdc] (STEP b). ON LINE FOR [XX.X dBm] I CARR NULL Q CARR NULL EXPECTED OUTPUT LEVEL DC MONITOR CALIBRATION...
Page 119: Rcvr Removal And Replacement
RCVR REMOVAL AND REPLACEMENT 5.22 Use this procedure to remove and replace UD-36() RCVR. CAUTION Possibility of Service Interruption This is an out-of-service procedure when on a nonstandby (unprotected) system. On a hot-standby, space diversity, or fre- quency diversity system, switch trafﬁc on the channel under test to protect.
Page 120 Remove: a Remove Receiver from card cage. b Remove 8 screws from Crystal OSC Subboard cover, and remove cover. RCVR–RIGHT SIDE VIEW c Disconnect ribbon cable from J8. d Remove 3 mounting screws, and remove Crystal OSC Subboard. Install: e Place Crystal OSC Subboard in mounting cavity.
Page 121 REMOVE: (Remove steps are prefixed by the letter "R". Remove Receiver from card cage. Remove 13 screws from Capacity Key, and remove Capacity Key. INSTALL: (Install steps are prefixed by the letter "I". Install Capacity Key on 3 connectors. Install 13 screws. RCVR –...
Page 122: Rcv Crystal Oscillator Frequency Correction
RCV CRYSTAL OSCILLATOR FREQUENCY CORRECTION 5.23 See Figure 5 - 24 and follow the procedure to correct the receive frequency of the crystal oscillator on older versions of the UD-36 ( ) receiver module. Allow a 1-hour warm-up period for radio and test equipment before starting procedure or improper frequency adjustment can result.
Page 123: Pa Removal And Replacement
PA REMOVAL AND REPLACEMENT 5.24 See Figure 5 - 25 and follow the procedure to remove and replace UD-51() PA. CAUTION Possibility of Service Interruption This is an out-of-service procedure when on a nonstandby (unprotected) system. On a hot-standby or frequency diversity system, switch trafﬁc on the channel under test to protect.
Page 124 FRONT PANEL P/O SHELF REMOVE: INSTALL: (Remove steps are prefixed (Install steps are prefixed DC MON by the letter "R"). by the letter "I". PWR ALM TEMP ALM Install replacement PA in shelf and tighten DC MON ADJ mounting screws (torque to 19 in.
Page 125: Pa Output Level Calibration
PA OUTPUT LEVEL CALIBRATION 5.25 See Figure 5 - 26 and follow procedure to check, and if necessary, adjust the UD-51( ) Power Ampliﬁer (PA) output in radio conﬁguration that is equipped with the optional PA. CAUTION Possibility of Service Interruption This is an out-of-service procedure when on a nonstandby (unprotected) system.
Page 126 ELMC Address: RACK6 Communicating* 10-May-99 and low output level: Description: MDR-8000 PA nominal high output level = level at top of stack + insertion loss of diplexer filter/XMT filter CLICK CALIBRATE A OR B SIDE (marked on label on filter).
Page 127 Save your calibrated values. Click next Abort Back Next Storing calibration data, please wait... CLICK NEXT . Abort Back Next Click Finish. Calibration is complete. Successfully stored calibration data Reconnect cable to RF OUT connector. Observe RF MON label on PA front panel.
Page 128 Connect Power Meter with 50 Ohm Power Sensor to RF MON connector. Measure RF MON level on Power Meter. Make new label for RF MON: PWR ALM MEASURED LEVEL (STEP b). TEMP ALM DC MON ADJ READ X.X dBm FOR XX.X dBm PWR ALM ADJ AT TOP OF RACK 10.5V DC...
Page 129 Connect DVM to test point and DC MON (+) Using DC on PA front panel, adjust for MON ADJ voltage on DVM equaling expected level at top of DC MON stack multiplied by 0.1. PWR ALM EXAMPLE: TEMP ALM EXPECTED LEVEL AT TOP OF STACK = 29 dBm 29 dBm X 0.1 (VOLTS DC/dBm) = 2.9 VOLTS DC DC MONITOR CALIBRATION READ [X.X Vdc]...
Page 130: Changing Frequency
CHANGING FREQUENCY 5.26 CAUTION Possibility of Service Interruption Crystals are soldered and tuned up in a crystal oscillator sub- board at the factory. Changing frequencies requires changing the crystal on the crystal oscillator subboard in the transmitter and receiver modules. Changing out the crystal requires tuning the crystal oscillator subboard.
