Page 1 MDR-8000 Microwave Digital Radios Users Manual Alcatel Part Number 3EM11931AA Issue 9, December, 2007 3400 West Plano Parkway Plano, Texas 75075-5813 U.S.A.
Page 3 From “MyAlcatel” go to “Alcatel Support Documentation” – Register for access to Documentation and e-mail Update notifications For Product Change Notices (PCN), Product Documentations, etc. – Software and Hardware upgrade documentation • Customized and Comprehensive Service Agreements ALCATEL-LUCENT’S PRIMARY MISSION IS SATISFYING OUR CUSTOMERS' QUALITY EXPECTATIONS.
Page 4 Technical Assistance Center Telephone Assistance, Normal Working Hours (CST 8am 5pm M-F) TAC supports all Alcatel North America Microwave products. This includes routine questions and emergency service. Telephone Assistance, Emergency After-Hours • Defined as loss of traffic, standby equipment, or network visibility on traffic-bearing systems. •...
Page 5: Table Of Contents
Table of Contents Page Section 1 General INTRODUCTION ..................... 1 - 1 CONTENT....................... 1 - 1 Section 2 Operation GENERAL ......................2 - 1 TURN-ON......................2 - 1 USER SYSTEM INTERFACE (USI) PROVISIONING FUNCTION/OPERATION ..2 - 2 OPERATING PROCEDURES ................2 - 2 2.4.1 Radio Receiver Manual Switching ..............
Page 6 High Capacity DS3 Radios ................3 - 7 3.5.3 High Capacity OC3 Radios................3 - 7 3.5.4 MDR-8000 Synchronous Repeater Compatibility Matrix ........3 - 8 3.5.5 MDR-8000 Synchronous Repeater Cables ............3 - 8 DS1 CONNECTIONS (J303 IN AND J304 OUT) ..........3 - 9 DS1 REPEATER (J314 ON ONE SHELF TO J314 ON SECOND SHELF) ....
Page 7 SECTION INTRODUCTION ................4 - 1 RECOMMENDED SEQUENCE ................. 4 - 1 SECURITY MANAGEMENT ................4 - 2 LOAD MDR-8000 SOFTWARE ON PC.............. 4 - 2 TURN-ON PROCEDURE ................... 4 - 4 ESTABLISH COM PORT ..................4 - 4 TEST PROCEDURES ..................4 - 7 PROVISIONING RADIO ...................
Page 8 RECOMMENDED TEST EQUIPMENT ..............5 - 4 OPTIONAL TEST EQUIPMENT ................5 - 4 PERSONAL COMPUTER (PC)/LAPTOP .............. 5 - 5 MDR-8000 ALARMS ..................5 - 7 ALARM MONITORING AND INSPECTION ............5 - 7 RECOMMENDED PERIODIC CHECKS .............. 5 - 8 RADIO TROUBLESHOOTING ................
Page 9 Section 6 User Guide INTRODUCTION ..................... 6 - 1 ANALOG SCREEN ..................6 - 1 6.2.1 PA (DC MON) ....................6 - 1 6.2.2 TX (PWR MON) ....................6 - 1 6.2.3 ATPC Voltage ....................6 - 1 6.2.4 RX (RSL 1) dBm ....................6 - 1 6.2.5 RX (EYE MON) ....................
Page 10 6.5.8 Radio Error Seconds ..................6 - 8 6.5.9 Radio Severe Error ................... 6 - 8 6.5.10 Radio BER ....................... 6 - 8 ETHERNET RADIO PERFORMANCE MONITORING SCREEN ......6 - 8 6.6.1 RF Receive ....................... 6 - 8 6.6.2 GPF Receive ....................
Page 11: Safety Precautions
SAFETY PRECAUTIONS While the manufacturer has attempted to detail in this manual all areas of possible danger to personnel in connection with the use of this equipment, personnel should use caution when installing, checking out, operating, and servicing this equipment. As with all electronic equipment, care should be taken to avoid electrical shock in all cir- cuits where substantial currents or voltages may be present, either through design or short circuit.
Page 12 FM-ii This page intentionally left blank.
Page 13: General
MDR-8000 equipment. CONTENT Refer to Table 1 - 1. The Attached CD column lists the parts of the MDR-8000 Radio Family Operation and Maintenance Manual, PN 3EM20188AAAA. A check mark under the Users Manual column or the Attached CD column indicates where the information is located.
Page 14 Table 1 - 1 (Cont.) Information Location Location Section/Appendix Users Manual Attached CD Maintenance √ √ Troubleshooting USI Alarms √ √ Troubleshooting Using Performance Screens √ √ Troubleshooting TMN Alarms √ √ Module Replacement Procedures √ √ Post-Replacement Test procedures √...
Page 15 TO MATCH I/O INTFC (DATA RATE) DS1/E1 LBO DS3 LBO DX-35P OC3/STM-1 DX-35N OC3/STM-1 AUX INTFC (ALSO USED ON ETHERNET) DX-35M DS1/EI DX-35R/S Ethernet ETH/T1 LINE INTFC MDR-1305 07/21/07 Figure 1-1 Typical MDR-8000 Hot-Standby Shelf Component Locations and Options (Sheet 1 of 3)
Page 16 D S1 / E1 SELECT DS1/E1 CAPACITY KEY BY CAPACITY AND MODULATION SCHEME MDR-1310 2, 4, 8, 12, 16 DS1/E1 AND 32 OR 128 TCM. 08/21/07 Figure 1 - 1 Typical MDR-8000 Hot-Standby Shelf Component Locations and Options (Sheet 2 of 3)
Page 17 Location of A and B RCV ports on diplexer filter varies, depending on RF frequency. For some frequencies, A and LMW-7211-SM B ports reverse location. 06/08/04 Figure 1-1 Typical MDR-8000 Hot-Standby Shelf Component Locations, and Options (Sheet 3 of 3 )
Page 18 This page intentionally left blank.
Page 19: Operation
Until all radios in the transmission link are interconnected, turned on, and operating properly, alarm conditions may exist. Perform the following procedure to turn on the MDR-8000 series radios: On all power supply modules, set power ON/OFF switches to ON.
Page 20: User System Interface (Usi) Provisioning Function/Operation
Verify that power distribution unit rack alarm indicator (if any) is not lighted. If indicator is lighted, troubleshoot as described in the Maintenance section. Verify that no red indicators are lighted. If a red indicator is lit, troubleshoot as described in the Maintenance section. Perform lamp test by momentarily holding OVRD-ACO/LT switch on control- ler to ACO/LT.
Page 21 TOGGLE SWITCH LEFT TO SWITCH A XMTR, RCVR, OR I/O MODULE IN-SERVICE AND TOGGLE SWITCH RIGHT TO SWITCH B XMTR, RCVR, OR I/O MODULE IN-SERVICE. NOTE OVERRIDE (OVRD) LOCKS XMTR, RCVR, OR I/O MODULE, SELECTED ABOVE IN-SERVICE, REGARDLESS OF ALARMS. TO ENABLE OVERRIDE: 1.
Page 22 1. OPEN USI CONTROLS SCREEN. Controls -- MDR-8000 DS3 File View Setup Options Alarm Status Analog Monitor Performance Station Alarm User Control Provisioning LOCAL CONTROLS ELMC Address: J7915 Communicating* Description: SILVERTON IN-SERVICE DS1 LINE LOOP-BACK RCV to XMT A Transmitter On Line Line 1 loopback 2.
Page 23: Radio Transmitter Manual Switching
Radio Transmitter Manual Switching 2.4.2 CAUTION Possibility of Service Interruption Switching the radio transmitter may momentarily interrupt trafﬁc. Before switching the transmitter, obtain permission from the proper authority. Note When used in conjunction with a XMTR manual switch, press the OVRD switch to lock the XMTR on line regardless of alarms.
Page 24 Controls -- MDR-8000 DS3 File View Setup Options Alarm Status Analog Monitor Performance Station Alarm User Control Provisioning LOCAL CONTROLS ELMC Address: J7915 Communicating* Description: SILVERTON 1. SELECT XMTR TO PUT IN-SERVICE. IN-SERVICE SYSTEM LOOP-BACK DS1 LINE LOOP-BACK RCV to XMT 2.
Page 25: Mcs-11 Operation
An Operational Support System (OSS) provides a means to remotely monitor and control an MDR-8000 radio via an MCS-11 Monitor and Control System polling master. A Remote Station Summary (RSS), a Remote Detail Scanner (RDS), a Remote Analog Scanner (RAS), and a Remote Control Decoder (RCD) are available at the polling master for each radio network element.
Page 26: Lamp Tests
Lamp Tests 2.4.5 Perform lamp tests by pressing and holding ACO/LT OVRD switch on controller front panel in ACO/LT position. All indicators on controller and indicators on all equipped modules should light. Release ACO/LT OVRD switch. Alarm Checks 2.4.6 The USI Alarm and Status screens provide alarms and status for the radio. Refer to description of alarms and status in the maintenance section.
Page 27: Turn-Off Procedure
It is recom- mended that turn-off be performed only in an emergency. EMERGENCY OPERATION If an emergency occurs, such as a short circuit or a ﬁre, turn off all MDR-8000 Microwave Digital Radio power supplies as quickly as possible. MODEM OPERATION Refer to the attached CD for modem connection and setup procedures.
Page 28 Red LED indicates module fault or reboot in progress. 9-Pin D-type connector for interface with computer. Dual-color LED (green/yellow) lights green to indicate link is active. Blinks green when receiving data packets on port. Lights yellow to indicate port is misconfigured. Blinks yellow to indicate collisions.
Page 29 Ethernet 1 RJ-45 connector for uplink connection to Ethernet hub, switch, or router Ethernet 2 and 3 RJ-45 connectors for normal/bridged connection toj other SNMP ports of other NEs (radio, MUX, computers) Point-to-Point (PPP) RJ-45 connector for connection to other radio TMN INTFC PPP ports.
Page 30 9-Pin D-Type connector for interface with computer Red LED indicates module fault or reboot in progress. Green LEDs On – Linked Off – No Link Green LED blinks on activity. Blinking – Activity Green ETH 1 RJ45 Connector On – Linked Off –...
Page 31 Ethernet 3 and 4 RJ-45 connectors for normal/bridged connection to other SNMP ports Point-to-Point (PPP) RJ-45 connector for connection to other radio TMN INTFC PPP ports. Can support backhaul connection over PQ/ECRC channel bank or synchronous Subboard modem with appropriate cable. Flash Card MDR-1326...
Page 32 RED LED INDICATES CONTROLLER FAILED. YELLOW LED INDICATES ONE OR MORE FLASHING LED INDICATES INCORRECT SOFTWARE OVERRIDES IN PROCESS OR FIRMWARE LOAD. ONE OR MORE SWITCHES ACTIVATED. RED LED INDICATES ANY MODULE IN SHELF FAILED. RED LED INDICATES XMTR A FAILED. RED LED INDICATES XMTR B FAILED.
Page 33 ELMC OPTION KEY EPLD PROGRAMMING CONNECTOR (FACTORY TEST PURPOSES ONLY) LMW-7047P 07/18/02 Figure 2-7 AE-37( ) Controller Controls, Indicators, and Connectors (Sheet 2 of 2) 2-15...
Page 34 RED LED INDICATES INTERNAL FAILURE OR BLOWN FUSE. YELLOW LED INDICATES PA ON/OFF SWITCH IS SET TO OFF (LED IS LABELED OFF NORM ON OLDER VERSIONS OF POWER SUPPLIES). 2-POSITION TOGGLE SWITCH APPLIES POWER TO POWER SUPPLY (ON 1) OR REMOVES POWER (OFF 0). FACTORY TEST POINTS FOR POWER SUPPLY VOLTAGES.
Page 35 SPARES 15A FAST BLO PN 264-0928-130 F1 F2 SIDE VIEW OF POWER SUPPLY LMW-3160P 08/15/02 Figure 2-8 CE-16BB Power Supply Controls, Indicators, Test Points, and Connectors (Sheet 2 of 2) 2-17...
Page 36 RED LED INDICATES LOSS OF SIGNAL, DETECTION OF BIPOLAR VIOLATION, OR FAILURE OF ACTIVE DS1/E1 LINE(S). GREEN LED INDICATES I/O IN SERVICE. RED LED INDICATES XMT SYNC FAILURE BETWEEN I/O INTERFACE MODULES. RED LED INDICATES LOSS OF RCV FRAME SYNC. GREEN LED INDICATES RCVR IN SERVICE.
Page 37 GREEN LED INDICATES AUXILIARY XMT CIR- CUITS ARE ENABLED. ALLOWS TRANSFER OF DATA TO DS1/E1 INTFC CIRCUITS. RED LED INDICATES SERVICE CHANNEL FRAME LOSS DETECTED IN RCV CIRCUITS. GREEN LED INDICATES RCV CIRCUITS ARE ENABLED. ALLOWS TRANSFER OF DATA TO ENCODER/DECODER CIRCUITS.
Page 38 RED LED INDICATES MODULE FAILURE. GREEN LED INDICATES XMT AND/OR RCV CIRCUITS ARE PASSING DATA. GREEN LED INDICATES WAYSIDE DS1 IN SERVICE. YELLOW LED INDICATES WAYSIDE DS1 SIGNAL FAILURE. GREEN LED INDICATES OC3 DATA ON INPUT TO OPTICAL RCV/RADIO XMT CIRCUITS. YELLOW LED INDICATES OPTICAL RCV CIRCUIT FAILURE.
Page 39 DX-35R-2 (DX-35R-1 is not shown). Note Both the Ethernet and optical ports can be connected for backup protection. Only one port is active. When both are connected, the optical port has priority over the Ethernet port and will remain the active port unless a failure occurs. Red LED indicates module failure.
Page 40 ADJUSTS RF OUTPUT POWER AT OUTPUT OF XMTR (AND PA, IF EQUIPPED). ADJUSTS FUNDAMENTAL FREQ OF CRYSTAL OSCILLATOR. MONITORS RF OUTPUT DETECTED DC RED LED INDICATES XMTR POWER LOSS. GREEN LED INDICATES XMTR IN SERVICE. ADJUSTS I–CHANNEL CARRIER SUPPRESSION. NULLS RF CARRIER ADJUSTS Q–CHANNEL CARRIER SUPPRESSION.
Page 41 RED LED INDICATES LOSS OF LOCK FROM RECEIVE SIGNAL. YELLOW LED INDICATES DEGRADED RECEIVE SIGNAL. GREEN LED INDICATES RCVR IN SERVICE. MONITOR POINT TO MEASURE DC CONTROL VOLTAGE USED TO CONTROL LO FREQ. SAME VOLTAGE IS DISPLAYED ON RX (AFC MON) FIELD ON ANALOG MONITOR SCREEN.
Page 42 RED LED INDICATES LOSS OF RED LED INDICATES LOSS OF LOCK LOCK ON MAIN RECEIVE SIGNAL. ON DIVERSITY RECEIVE SIGNAL. YELLOW LED INDICATES YELLOW LED INDICATES DEGRADED DEGRADED MAIN RECEIVE SIGNAL. DIVERSITY RECEIVE SIGNAL. GREEN LED INDICATES MAIN RCVR GREEN LED INDICATES DIVERSITY IN SERVICE.
Page 43 MONITOR POINT TO MEASURE DC VOLTAGE REP- RESENTATIVE OF OUPUT POWER (0.1V DC PER DB OF RF OUTPUT SIGNAL FOR NOMINAL POWER ONLY) RED LED INDICATES RF PWR IS ABOVE OR BELOW ALARM THRESHOLD SET BY PWR ALM ADJ. YELLOW LED INDICATES HIGH TEMP ON PA (MAY BE CAUSED BY IMPROPER MOUNTING TO HEATSINK).
Page 44 FRONT VIEW FV/DC SWITCH SET TO FV FOR MDR-8000 APPLICATION NOT USED BIS BUTTON - PRESS NOT USED TO CALL LAST NUMBER DIALED ON-HOOK/OFF-HOOK SWITCH - PUSH FROM LEFT TO RIGHT TO TALK AND LISTEN REAR VIEW RJ11 CONNECTOR RJ11 CONNECTOR...
Page 45: Interconnect
Refer to CD for similar installation information for the Compact radios. POWER CABLE CONNECTION See Figure 3 - 1 for power cable assembly installation procedures. The MDR-8000 is inter- nally wired to accept 20.5 to 60 V dc input power with positive or negative ground. To pro- tect maintenance personnel from lightning strikes, the ground system must be integrated by bonding station ground and dc battery return together.
Page 46 WARNING Possibility of Damage to Equipment Do not apply battery power until it is determined that A and B battery cables with isolated returns and power cables are wired correctly. With power applied, reverse polarity on wir- ing (+batt wired to -batt pin on connector) can cause power supply fuse to blow.
Page 47 1. DETERMINE IF INSTALLATION PIN 1 PIN 2 PIN 3 REQUIRES POS OR NEG GND. 2. INSTALL BATT, GND, AND JUMPER WIRES ON PWR CABLE ASSEMBLY. 3. CONNECT PWR CABLE ASSEMBLY TO J1 (AND J2 IF HOT-STBY). 4. CONNECT RACK GND AND CHASSIS GND.
Page 48: Pdu Strapping And Connections
PDU STRAPPING AND CONNECTIONS See Figure 3 - 2 for strapping and connections for PDU PN 3EM13317AA. For strapping and connections for PDU PN 695-6200, Refer to CD. BATTERY INPUT WIRE SIZE NO. 4 (MAX) POWER DISTRIBUTION UNIT ISOMETRIC VIEW – CIRCUIT BOARD AND FRONT PANEL REMOVED A+ A- B+ B-...
Page 49: Shelf/Rack Alarm Connection
MDR-8000 SYNCHRONOUS REPEATER CONNECTIONS The following paragraphs describe the cabling and limitations involved with carrying MDR-8000 service channel information across two (2) back-to-back radio terminals at a repeater site. In this document, the term synchronous indicates that the clocks of the two radios are locked together.
Page 50 OUTPUTS MAJOR 3 MINOR 3 MAJOR 4/AUX MINOR 4/AUX UNUSED FUSE ALM NC COM NO PIN 1 J305 MDR-8000 SHELF WIRE WRAP ADAPTER PIN 1 FAN ASSY HEAT DEFLECTOR J305 MDR-8000 SHELF FAN ASSY LMW-8057F 04/23/03 Figure 3 - 3 Shelf Alarm Wiring PDU (3EM13317AA...
Page 51: Low Capacity Ds1 Radios
Low Capacity DS1 Radios 3.5.1 The MDR-8000 synchronous repeater connection J314 in a low capacity DS1 radio is used to pass orderwire, fault alarm, ELMC, trafﬁc between two (2) back-to-back low capac- and DS1 ity terminals over a common cable. The framing structure of the X/Y rail pairs being passed over the synchronous repeater cable are the same for radios equipped to transport 4, 8, 12, or 16 DS1s but unique for 2 DS1.
Page 52: Mdr-8000 Synchronous Repeater Compatibility Matrix
MDR-8000s OC3 radio and part will be SONET ﬁber equipment. MDR-8000 Synchronous Repeater Compatibility Matrix 3.5.4 Table 3 - 1 lists the combinations of MDR-8000 capacities that support the use of the syn- chronous repeater cable. Table 3 - 1 Synchronous Repeater Compatibility Radio #2 Capacity...
Page 53: Ds1 Connections (J303 In And J304 Out)
The MDR-8000 Synchronous repeater Cable for the OC3 version of the radio uses the same part number as the ELMC cable. Table 3 - 2 Synchronous Repeater Cables Capacity Part Number Designation No. of Pins 695-7836-001/005 J314 695-7836-001/005 J401 695-4125-007/013...
Page 54: Wire Color
Table 3 - 3 DS1 IN J303 and DS1 OUT J304 Mating Cable CONNECTOR CABLE WIRE COLOR SIGNAL NAME PIN NUMBER PAIR NUMBER WHITE–BLUE CHAN 1 TIP BLUE–WHITE CHAN 1 RING WHITE–ORANGE CHAN 2 TIP ORANGE–WHITE CHAN 2 RING WHITE–GREEN CHAN 3 TIP GREEN–WHITE CHAN 3 RING...
Page 55: Ds1 Repeater (J314 On One Shelf To J314 On Second Shelf)
DS1 REPEATER (J314 ON ONE SHELF TO J314 ON SECOND SHELF) Note The DS1 repeater cable carries clocks, DS1 data, and overhead for two directions. If the 314 cable is not used, the embedded data in the over- head must be cabled individually. In this case, individual cables must be run for MCS–11, audio, RS-232, and ELMC.
Page 56: Ds3 Lbo Strapping And Connections
DS3 LBO STRAPPING AND CONNECTIONS The DS3 LBO compensates for the distance to the cross-connect for DS3 and wayside DS1 outputs. See Figure 3 - 6 for strap locations. Refer to Table 3 - 4 for strapping requirements. IN/OUT STRAPPING IN/OUT STRAPPING WAYSIDE DS1 LINES DS3 LINES...
Page 57: Ds3 Lbo Ds3 Bnc Connections (J21 Through J26)
DS3 LBO DS3 BNC CONNECTIONS (J21 THROUGH J26) BNC removal tool (PN 359-0092-010) is required for installing and removing BNC cables. Recommended connectorized cable assembly for all applications except repeaters, PN 632- 4429-096/180 (8/15 ft RG-59B/U coax cable with straight male BNC connector on one end and right angle male BNC connector on other end).
Page 58: Ds3 Lbo Wayside Ds1 Connections (J201 In And J202 Out)
DS3 LBO WAYSIDE DS1 CONNECTIONS (J201 IN AND J202 OUT) 3.10 Wayside DS1 is an option in the MDR-8000 DS3 radios. This option provides 1 DS1 for each equipped DS3. To activate the wayside channels requires a small circuit board, called ELMC option key, that plugs onto the controller module.
Page 59 J307 J308 J309 J310 J312 J315 J305 J313 J318 J316 J317 J302 LINE 3 OUT TIP LINE 3 IN TIP J201 J202 LINE 2 IN TIP LINE 2 OUT TIP INPUT OUTPUT LINE 1 IN TIP LINE 1 OUT TIP LINE 1 OUT RING LINE 1 IN RING LINE 2 IN RING...
Page 60: Ds3 Repeater (J401 On One Shelf To J401 On Second Shelf)
Table 3 - 7 Wayside DS1 Mating Cable – DS3 LBO J201 (INPUTS) 202 (OUTPUTS) FUNCTION END 1 WIRE COLOR WIRE COLOR END 2 FUNCTION LINE 1 TIP IN BLACK BLACK LINE 1 TIP OUT LINE 1 RING IN LINE 1 RING OUT LINE 2 TIP IN BLACK BLACK...
Page 61 J307 J308 J309 J310 J312 J315 J305 J313 J318 J316 J317 J302 J401 PIN 1 FRONT VIEW LMW-7066F 07/23/02 Figure 3 - 10 Connector J401 Location – DS3 LBO 3-17...
Page 62: Fiber Optic Cable Connections
FIBER OPTIC CABLE CONNECTIONS 3.12 DANGER Possibility of Injury to Personnel This system normally operates as a Class I Laser Product (no hazard), however during servicing operations, when optical connectors are being connected, disconnected, or handled without dust covers, it is possible to be exposed to Class IIIB laser radiation which can cause eye damage.
Page 63: Or 4 Fiber Management Panel
Table 3 - 8 Fiber Optic Jumpers JUMPER TYPE PART NO. APPLICATION FC to LC 3EM07651AA-AK TERMINAL SC TO LC 3EM07646AA-AK TERMINAL LC TO LC 3EM07641AA-AK REPEATER 2 or 4 Fiber Management Panel 3.12.1 The 2 or 4 ﬁber management panel provides a direct interface with customers 2 or 4 ﬁber equipment.
Page 64 VIEW OF CONNECTOR WITH FIBER OPTIC CABLES REMOVED OT-1 OR-1 CONNECT OPTICAL RCV (OR) CABLE TO IN CONNECTOR CONNECT OPTICAL XMT (OT) CABLE TO OUT CONNECTOR INPUTS OUTPUTS CUSTOMER INTFC SIDE VIEW I/O INTFC MODULE SIDE VIEW OT-3 OUT OT-1 OUT OT-2 OUT OT-4 OUT OT-4 OUT...
Page 65 VIEW OF CONNECTOR WITH FIBER OPTIC CABLES OT-1 OR-1 REMOVED CONNECT OPTICAL RCV (OR) CABLE TO IN CONNECTOR CONNECT OPTICAL XMT (OT) CABLE TO OUT CONNECTOR FRONT VIEW COMBINER SPLITTER OT-1 OT-2 OR-1 OR-2 FROM RADIO I/O TO RADIO I/O INTFC MODULES INTFC MODULES OUTPUT TO...
Page 66: Oc3/Stm-1 Aux Interface Board Wayside Ds1 Connections (J201 In And J202 Out)
OC3/STM-1 AUX INTERFACE BOARD WAYSIDE DS1 CONNECTIONS (J201 IN AND J202 OUT) 3.13 Wayside DS1 is an option in the MDR-8000 OC3/STM-1 radios that prevents having to add a SONET add/drop MUX to access payload trafﬁc. This option provides 1 DS1 for each STS-1 within the OC3/STM-1.
Page 67: Oc3/Stm-1 Repeater (J203 On One Shelf To J203 On Second Shelf)
OC3/STM-1 REPEATER (J203 ON ONE SHELF TO J203 ON SECOND SHELF) 3.14 Note The OC3/STM-1 radio repeater cable carries clocks, data, and over- head for two directions. It does not carry OC3/STM-1 or Wayside DS1 trafﬁc. OC3/STM-1 ﬁber optic cables and Wayside DS1 cables must be run separately.
Page 68: Ethernet Cable Connections
Table 3 - 9 Repeater Mating Cable – OC3/STM-1 AUX Interface J203/J203 MDR-8000 OC3/STM-1 J203/J203 J203/J203 MDR-8000 OC3/STM-1 FUNCTION END 1 WIRE COLOR PAIR WIRE COLOR END 2 FUNCTION DS1 IN TIP BLACK BLACK DS1 OUT TIP DS1 IN RING...
Page 69: Crossover Cable Option
Crossover Cable Option 3.15.2 Crossover type cables with pin 1 wired to pin 3 and pin 2 wired to pin 6 can be used, but are not necessary. Crossover is automatically performed by the Ethernet PHY, resulting in a straight-through interface to the link partner. Table 3 - 10 10/100BASE-T Ethernet Connector Pinout FUNCTION PORT...
Page 70 PAIR A PAIR B CONN 1 CONN 2 WHITE-GREEN GREEN WHITE-ORANGE ORANGE WHITE-BLUE BLUE WHITE-BROWN BROWN PAIR C LMW-9053F PAIR D 05/24/05 Figure 3 - 15 Straight-Through Mating Cable MDI Mode MDI-X Mode Ethernet Ethernet I/O INTFC I/O INTFC Active Active Active Active...
Page 71 Shelf 1 Shelf 2 Ethernet Ethernet I/O INTFC I/O INTFC TRDA+ TRDA- TRDB+ TRDB- TRDC+ TRDC- TRDD+ TRDD- MDR-1170F Cancel. Cancels XMT data in RCV output. 05/24/05 Figure 3-17 1000BASE-T Interconnect Note Transmit data (TRD) is both directions, simultaneously. Unwanted data is cancelled.
Page 72 WARNING Possibility of Damage to Equipment Follow carefully the following do’s and don’ts to prevent future loss of trafﬁc. MAINTAIN A MAXIMUM BEND RADIUS OF 4 TIMES DON’T EXCEED A 90 DEGREE BEND. CABLE DIAMETER (4–PAIR CABLES). CABLE BEND RADIUS CABLE DIA.=0.20”...
Page 73: Terminal Connections
Terminal Connections 3.15.3 See Figure 3 - 18. Radio terminal connections consist of Ethernet connections (refer to Para 3.6), DS1 connections, and service channel connections. The radio provisioned as a termi- nal can transport up to 32 DS1 lines in one direction. Radio Terminal Eth Card...
Page 74: Front View
Terminal DS1 Lines 1-32 Connections (J303/J323 In and J304/J324 Out) 3.15.3.1 Recommended connectorized cable assembly – PN 695-7806-001 through 005 (22 AWG 16- pair shielded, jacketed cable with 37-pin D-type connector on one end). See Figure 3-19 for location and pinout. Refer to Table 3-12 and Table 3-13 for mating cable pinout. T1 1-16 T1 17-32 J323...
Page 75 Table 3-12 DS1 IN J303 and DS1 OUT J304 Pinout Assignments CONNECTOR PIN WIRE COLOR SIGNAL NAME CABLE PAIR NUMBER NUMBER WHITE–BLUE CHAN 1 TIP BLUE–WHITE CHAN 1 RING WHITE–ORANGE CHAN 2 TIP ORANGE–WHITE CHAN 2 RING WHITE–GREEN CHAN 3 TIP GREEN–WHITE CHAN 3 RING WHITE–BROWN...
Page 76 Table 3 - 13 DS1 IN J323 and DS1 OUT J324 Pinout Assignments CONNECTOR PIN WIRE COLOR SIGNAL NAME CABLE PAIR NUMBER NUMBER WHITE–BLUE CHAN 17 TIP BLUE–WHITE CHAN 17 RING WHITE–ORANGE CHAN 18 TIP ORANGE–WHITE CHAN 18 RING WHITE–GREEN CHAN 19 TIP GREEN–WHITE CHAN 19 RING...
Page 77: Repeater Connections
Repeater Connections 3.15.4 See Figure 3-20. Radio repeater connections consist of Ethernet connections (refer to Para. 3.15), DS1 connections, and service channel connections. When the radio is provisioned as a repeater, service channel overhead is transported between shelves at the DS1 data rate using the RPTR IN/OUT connector J203 on the ETH/T1 line interface board.
Page 78 Table 3 - 14 Repeater Mating Cable – ETH/T1 Line J203/ J203/J203 MDR-8000 J203/J203 MDR-8000 J203 WIRE WIRE FUNCTION END 1 PAIR END 2 FUNCTION COLOR COLOR DS1 IN TIP BLACK BLACK DS1 OUT TIP DS1 IN RING DS1 OUT RING...
Page 79: Usi/Controller Cable Connection To Laptop (J301)
USI/CONTROLLER CABLE CONNECTION TO LAPTOP (J301) 3.16 Recommended connectorized cable assembly – PN 695-7848-001 through 004 (24 AWG 6 pair shielded, jacketed cable with DEMM-9P connector on each end). See Figure 3 - 21 for Figure 3 - 22 for controller connector location and pinout. Refer to Table 3 - 17 for mating cable pinout and color code.
Page 80 J307 J308 J309 J310 J312 J315 J305 J313 J318 J316 J317 J302 J301 FRONT VIEW LMW-7059F 02/04/03 Figure 3 - 22 Controller USI Connector Location and Pinout 3-36...
Page 81: Service Channel Connections
The MDR-8000 provides a 256 kb/s auxiliary channel for servicing the radio. This is an over- head channel and is independent of the trafﬁc channels. The 256 kb/s service channel con- tains four 64 kb/s service channels.
Page 82 J316 J316 RADIO RADIO AUDIO AUDIO TELEPHONE TELEPHONE (4-WIRE) (4-WIRE) CONTROLLER CONTROLLER J317 J317 AUDIO AUDIO MULDEM MULDEM J307, J310 J307, J310 (BRIDGED) (BRIDGED) TSM–2500 TSM–2500 OVERHEAD OVERHEAD CHANNELS CHANNELS J315, J318 J315, J318 (BRIDGED) (BRIDGED) ELMC ELMC J312 J312 HANDSET RS232–1 RS232–1...
Page 83: Service Channels Provisioning Options
Service Channels Provisioning Options 3.17.2 Note Service channels at both ends of a hop (and end-to-end in a link) must be provisioned the same. Service channel provisioning is interactive. When an option is selected for any service channel, that option is excluded from selections on the other applicable service channels. Provisioning options for Service Channels 1, 2, and 3 are listed: •...
Page 84 Audio 1 3.17.3.1 Audio 1 (J316) is a 4-wire function port on the backplane that provides off-hook detection, level control, E and M-lead signaling, and DTMF and 2-wire handset capabilities. 3.17.3.2 Audio 2 Audio 2 (J317) is a 4-wire function port on the backplane that provides off-hook detection, level control, and E and M-lead signaling.
Page 85 J307 J308 J309 J310 J312 J308 J309 J312 J315 J305 J313 J318 J316 J316 J317 J317 J302 CALL DETECT AUDIO TIP OUT M LEAD J316/J317 AUDIO TIP IN AUDIO RING IN E LEAD AUDIO RING OUT CALL COMMON FRONT VIEW LMW-7238F 02/23/04 Figure 3 - 24 Audio Connectors Location and Pinout...
Page 86 J308 J309 J310 J312 J315 J305 J313 J318 J316 J316 J317 J317 J302 J316 J317 WIRE WRAP ADAPTER (PN 3DH04178 AB) P316 P317 P101 P102 P101 P316 P102 P317 AUDIO TIP IN AUDIO TIP IN AUDIO RING IN AUDIO RING IN AUDIO M LEAD AUDIO M LEAD AUDIO TIP OUT...
Page 87: Rs-232-1, Rs-232-2 (J312, J313)
RS-232-1, RS-232-2 (J312, J313) 3.17.4 Recommended connectorized cable assembly – PN 695-4125-021 through 025 (26 AWG 5 pair shielded, jacketed cable with 9-pin D-type connector on each end). See Figure 3 - 26 for shelf connector locations and pinout. Refer to Table 3 - 17 for mating cable wiring and color code.
Page 88: Mcs-11 Connections
Table 3 - 17 RS-232 Mating Cable Wiring and Color Codes J312/ J312/J313 MDR-8000 J312/J313 MDR-8000 J313 WIRE WIRE FUNCTION PAIR FUNCTION COLOR COLOR NOT USED BLACK BLACK NOT USED NOT USED NOT USED RS-232 OUT/RS-232-1 OUT* BLACK BLACK RS-232 IN/RS-232-1 IN*...
Page 89: Master (J307)
MCS-11 Master (J307) 3.18.1 Note If the radio is provisioned , port 2 on the controller, that con- Repeater nects to J307, is disabled. At a repeater, you can use J310 in lieu of J307 for connecting the TSM polling engine to the radio. MCS-11 connector J307 is used to connect to a TSM (-2500, -3500, or -8000) polling engine at a master terminal.
Page 90 Table 3 - 18 MCS-11 Master Connector J307 Mating Cable Wiring and Color Codes J307 MDR-8000 POLLING ENGINE FUNCTION END 1 WIRE COLOR PAIR WIRE COLOR END 2 FUNCTION RCV CLK + BLACK BLACK RCV CLK + RCV CLK- RCV CLK-...
Page 91 CABLE 372-0546-020/050/070 RPTR TERM J314 S7341 T7341 MDR-6000 MDR-6000 SITE A LEGEND: MDR-8000 J308/J309 MCS-11 ADDRESS XXXX PROVISIONING NOTES YYYY CONFIGURATION 1. PROVISION RPTR DS309 (FIRST RADIO IN CHAIN) J308 OUTPUT CLOCK ZZZZ ELMC ADDRESS DS3ZZ = RADIO CAPACITY (DS3) 2.
Page 92: Repeater-To-Spur Daisy Chain Connection (J308/J309)
MCS-11 Repeater-to-Spur Daisy Chain Connection (J308/J309) 3.18.2 Note MCS-11 must be provisioned to enable MCS-11 J310 Master/Junction XMT, RCV, and OUTPUT clocks. If an external modem is being used, provision MCS-11 for MCS-11 J310 Modem . This selection disables XMT, RCV,OUTPUT clocks and all MCS-11 clocks must now be pro- vided by the external modem.
Page 93 Master Mode (CLKS OUT) 3.18.2.2 See Figure 3 - 30 for a simpliﬁed block diagram of the master mode. The master mode sends RCV and XMT clocks out to other equipment. Typically one radio at a repeater/junction is provisioned J308 Output clock and this master radio provides the clocks on which other radios at the site can sync.
Page 94 Figure 3 - 29 Typical MCS-11 Interconnect 3-50...
Page 95 MDR-1009 02/02/07 Typical Interconnect 3-51...
Page 96 EPLD CLK DIR CTRL MASTER/SLAVE µ PROCESSOR SWITCH CONTROL CLK E DET LOGIC XCVR DRIVER 64 CLK W W SC RCV CLK + MULDEM INTFC RCV CLK - RCVR CLK 7 TO µ PROCESSOR CLK 8 XCVR 64 CLK E E SC MODEM DRIVER...
Page 97 EPLD CLK DIR CTRL MASTER/SLAVE µ PROCESSOR SWITCH CONTROL CLK E DET LOGIC XCVR DRIVER W SC 64 CLK W RCV CLK + MULDEM INTFC RCV CLK - RCVR CLK 7 TO µ PROCESSOR CLK 8 XCVR E SC 64 CLK E MODEM DRIVER TX CLK OUT...
Page 98 J307 J308 J308 J309 J310 J312 J312 J315 J305 J313 J318 J316 J317 J302 OFF HOOK + OFF HOOK + XMT DATA + XMT DATA + CLK OUT + XMT CLK + XMT CLK + RCV DATA + RCV DATA + RCV CLK + RCV CLK + J308...
Page 99 Table 3 - 19 J308-to-J308 Mating Cable Wiring and Pinout J308 MDR-8000 J308/J308 J308 MDR-8000 FUNCTION END 1 WIRE COLOR PAIR WIRE COLOR END 2 FUNCTION RCV CLK + BLACK BLACK XMT CLK + RCV CLK- XMT CLK- RCV DATA +...
Page 100: Spur Connection (J310)
Table 3 - 20 J309-to-J308 Mating Cable Wiring and Pinout 309 MDR-8000 J309/J308 J308 MDR-8000 FUNCTION END 1 WIRE COLOR PAIR WIRE COLOR END 2 FUNCTION RCV CLK + BLACK BLACK RCV CLK + RCV CLK- RCV CLK- RCV DATA +...
Page 101 J307 J307 J308 J309 J310 J310 J312 J312 J315 J305 J313 J318 J316 J317 J302 XMT DATA + RTN CLK + XMT CLK + RCV DATA + J310 RCV CLK + RCV CLK – RCV DATA – XMT CLK – RTN CLK –...
Page 102: Tmn Connections
3.19.1 Installing Module Connect mating cables to applicable connectors J1-J4. Install TMN Interface module loosely in slot C3 in MDR-8000 shelf. Route cables through slot in module front panel, leaving a service loop in the space below. Limit the number of cable ties to prevent having to use large service loops.
Page 103 ETH 1 UPLINK ETH 2 ETH 3 LMW-9006F 06/13/03 Figure 3-34 TMN Interface Module Signal Connections 3-59...
Page 104: Typical Interconnect Scenarios
Typical Interconnect Scenarios 3.19.2 Note Refer to CD, Connecting MDR-8000 Radio TMN Interface in an Ether- net LAN, for limitations on interconnecting radios and equipment at a site. Scenario 1 – Daisy Chain, Bridged Connection 3.19.2.1 See Figure 3 - 35. In this scenario, four TMN interface modules are connected to the LAN.
Page 105 INTF SHELF INTF SHELF INTF SHELF NOTE ALL CABLES ARE STANDARD CAT 5 STRAIGHT-THROUGH CABLES. INTF SHELF LMW-9009 06/19/03 Figure 3-35 Daisy Chain, Using Internal Repeating Hub 3-61...
Page 106 SWITCH INTF SHELF INTF SHELF INTF SHELF NOTE ALL CABLES ARE STANDARD CAT 5 STRAIGHT-THROUGH CABLES. INTF SHELF LMW-9008F 06/19/03 Figure 3 - 36 Switched Connection Using External Switch/Hub Standard Cat 5 Cable Interface Interface Normal Crossover (DCE) (DTE) Loopback MDR-1279 12/15/06 Figure 3 - 37 Front PPP Port TMN to TMN Connection...
Page 107 USER EQUIPMENT MDR-8000 9400 AWY CO-DIRECTIONAL TMN INTERFACE MODE CROSSOVER MODE GENERIC DB-15 RJ-45 Data + TXD+ 3 RXD+ Data - TXD- 6 RXD- Clock + TXC+ 7 RXC+ Clock - TXC- 8 RXC- Data + RXD+ 1 TXD+ Data -...
Page 108: Front Access Connectors
MDR-8000 RS-422 CHANNEL BANK TMN INTERFACE DCE INTERNAL CLOCK CROSSOVER MODE DB-37 RJ-45 SEND DATA A RXC + SEND DATA B RXC - RXD + RX DATA A RXD - RX DATA B TXC + RX CLK A TXC -...
Page 109 PIN 1 PIN 8 LMW-8053F 06/30/03 Figure 3-39 Typical RJ-45 Connector Pinout Ethernet (ETH) 1 Uplink Connector J1 3.19.3.1 Uplink connector J1 is crosswired internally. Use a straight-through cable for connecting to hub or other equipment. Refer to Table 3-22 for module connector pinout. Table 3-22 ETH1 Uplink Connector J1 Pinout FUNCTION GND (via 75 ohm resistor)
Page 110 Ethernet Connectors J2 and J3 3.19.3.2 ETH2 and ETH3 connectors require straight-through cables to connect to external equip- ment. Refer to Table 3-23 for pinout/function. Table 3-23 ETH2 and ETH3 Connectors J2 and J3 Pinout FUNCTION GND (via 75 ohm resistor) GND (via 75 ohm resistor) PPP Connector J4 3.19.3.3...
Page 111: Mating Cables
MATING CABLES 3.19.4 See Figure 3-40 and Figure 3-41. Part numbers are assigned for CAT5 UTP straight and crossover unshielded and shielded cables as follows: PN 3AL48960AAAAAADSZZA straight-through, unshielded PN 3AL48956AAAAAADSZZA straight-through, shielded PN 3AL48961AAAAAADSZZA crossover, unshielded PN 3AL48962AAAAAADSZZA crossover, shielded PAIR A PAIR B CONN 1...
Page 112: Front Panel Craft Interface Connector J5
Front Panel Craft Interface Connector J5 3.19.5 The CRAFT J5 connector on the front panel is used to interface the TMN interface module with a PC. The CRAFT interface is an RS-232-compatible DCE interface, DB9 male to DB9 female cable, PN 695-7848. Refer to Table 3-25 for connector pinout/function. Refer to Table 3-26 for mating cable pinout/function.
Page 113: Wire Color
Table 3-26 J5 Straight-Through Mating Cable FUNCTION END 1 WIRE COLOR END 2 FUNCTION BLACK BLACK WHITE BLACK GREEN BLACK BLUE BLACK ELMC (J315, J318) 3.20 As a standard feature, the Extended Link Monitor Channel (ELMC) function allows local provisioning, alarms, status information, and control commands for the local radio and, (with the exception of wayside DS1), alarms, status information, control for addressable remote radios.
Page 114 Table 3-28 ELMC Connector J315/J318 Mating Cable Wiring and Pinout J315/J318 MDR-8000 J315/J318 MDR-8000 FUNCTION END 1 WIRE COLOR PAIR WIRE COLOR END 2 FUNCTION RCV+ BLACK BLACK XMT+ RCV- XMT- XMT+ BLACK BLACK RCV+ XMT- WHITE WHITE RCV- NOT USED...
Page 115 MDR-6000 Note When connecting MDR-8000 radios with Windows USI to radios with DOS USI, check the DOS USI ELMC address for space, dash, slash, asterisk, or underscore. The Windows USI cannot recognize a space, dash, slash, asterisk, or underscore. Change the DOS ELMC address to a 5-character alphanumeric address without the prohibited characters.
Page 116: Foreign Alarm Interface (J305)
FOREIGN ALARM INTERFACE (J305) 3.21 Recommended connectorized cable assembly – PN 695-4121-001/003 (24 AWG 25 pair cable). See Figure 3-45 for shelf connector location and pinout. Refer to Table 3-29 for mating cable pinout and color code. Recommended wirewrap cable – PN 424-0429-020 (22 AWG 30-pair twisted cable) for use with wirewrap adapter PN 695-4171-002.
Page 117 Table 3-29 Alarm/Status Connector J305 Mating Cable Wiring and Pinout WIRE ALM/STATUS/CONTROL REMARKS COLOR A XMT ALM OUT WHT/BLU ALARM OUTPUT FROM RELAY INTFC B XMT ALM OUT BLU/WHT ALARM OUTPUT FROM RELAY INTFC A RCV ALM OUT WHT/ORN ALARM OUTPUT FROM RELAY INTFC B RCV ALM OUT ORN/WHT ALARM OUTPUT FROM RELAY INTFC...
Page 118 Table 3-29 Alarm/Status Connector J305 Mating Cable Wiring and Pinout (Cont.) WIRE ALM/STATUS/CONTROL REMARKS COLOR TBOS XMT- DATA IN OR BLK/GRN SERIAL DATA INPUT TO RADIO CON- STATION ALM 13 IN TROLLER OR RELAY INPUT FROM CUS- TOMER EQUIPMENT TO RELAY INTFC CARD (PROVISIONABLE) STATION ALM 5 IN GRN/BLK...
Page 119: Alarm, Status, And Controls Interconnect
Table 3-29 Alarm/Status Connector J305 Mating Cable Wiring and Pinout (Cont.) WIRE ALM/STATUS/CONTROL REMARKS COLOR CONTROL 5 OUT VIO/BLU OUTPUT TO CUSTOMER EQUIPMENT CONTROL STATUS 5 IN BLU/VIO INPUT FROM CUSTOMER EQUIPMENT IN RESPONSE TO CONTROL 5 OUTPUT CONTROL 6 OUT VIO/ORN OUTPUT TO CUSTOMER EQUIPMENT CONTROL STATUS 6 IN...
Page 120 J305 RELAY SWITCH XMTR J305 INTERFACE SWITCH RCVR PATH ALM SWITCH I/O LOSS OF INPUT ALM A XMT ALM STATION ALM 1 STATION ALM 2 B XMT ALM STATION ALM 3 A RCV ALM STATION ALM 4 B RCV ALM STATION ALM 5 POWER SUPPLY ALM STATION ALM 6...
Page 121: Controller Bus
Controller Bus 3.22.1 The Relay Interface communicates with the AE-37( ) Controller card via the processor bus and the data bus. The processor bus, consisting of three address lines, two control lines, and a clock, is applied to a XCVR. The data bus contains the eight data lines (D0-D7) and is applied to a separate transceiver.
Page 122: Station Alarm Wiring
1) is connected by software. The station alarms for MCS-11 address A1B and A1C are assigned to MCS-11 Alarm points 2 and 3, respectively. WIRE WRAP ADAPTER (PN 695-4171-002) #1 STATION PIN 1 (SEE NOTE) RACK ALM J305 MDR-8000 SHELF MCS-11 ADDRESS #2 STATION FAN ASSY HEAT DEFLECTOR J305 MDR-8000 SHELF MCS-11...
Page 123: Relay Alarm/Status Outputs
Relay Alarm/Status Outputs 3.22.5 Eight alarm relay outputs and seven status relay outputs provide relay closure to ground (provisioned NO) or open (provisioned NC) when activated. All relays default to open if card power is lost, except the Power Supply alarms, which default to ground. The maxi- mum contact rating for each relay is 0.5 A, 100 Vdc.
Page 124: Relay Control Outputs
Channel Alarm RCV Frame Loss Eye Closure RSL Alarm • PWR Supply Alarm – This summary alarm is activated by any A or B power supply failure. • Controller Fail – relay is activated if a card select has not been detected in the pre- vious approximately 200 msec.
Page 125: Initial Turnup
This provisioning part of the section describes provisioning options available with the MDR-8000 software application. Provisioning allows for the deﬁnition, editing, and storing of speciﬁc functions. The MDR-8000 provides the ability to provision equipment and facili- ties through a series of Windows™-based screens and messages. The Provisioning menu lists equipment and functions which may be provisioned.
Page 126: Security Management
SECURITY MANAGEMENT Note A password is not required to operate the MDR-8000. The radio is shipped without a password and if a password is desired, it must be entered using the Change Password screen. Once entered initially, the password must be entered each time the user wants to access the provi- sioning screens (level 1 password required) or download software (level 2 password required).
Page 127 2 CLICK HERE Exit Setup MDR-8000 Universal USI Setup Begin the installation by clicking the button below. CLICK HERE Click this button to install MDR-8000 Universal USI software to the specified destination directory. COPYING FILES Directory: Change Directory...
Page 128: Turn-On Procedure
TURN-ON PROCEDURE Note For user safety, user should become familiar with locations of power distribution units and circuit breakers associated with the MDR-8000 radio. Perform the following procedure to turn on the radio. On power supply module, set switch to .
Page 129 AE–37( ) CNTLR MDR–8000 SHELF TO CONNECTOR J301 (CONNECTS TO RS–232C AE–37 CONTROLLER) INTERFACE CABLE TERMINAL MW211–0066–1 101598 RS–232C PORT Figure 4-2 USI Computer Hookup...
Page 130 On Program menu, click on Win USI program. Win USI screen displays with message COMMUNICATING to indicate PC is communicating with the radio controller. If COMMUNICATION DOWN message is displayed, perform procedure shown on Figure 4 - 3 to change COM port. STOP .
Page 131: Test Procedures
TEST PROCEDURES The radio has been properly aligned and tested at the factory before shipment eliminating the need for testing after initial turn-up. The only time testing and/or adjustment is required is after a maintenance action such as removal and replacement procedure and/or constant alarms requiring corrective maintenance action.
Page 132 START FIG 4-5 DS1/E1, DS3, OC3/STM-1, ETH RADIO CONFIG PROVISIONING DS1/E1 OC3/STM-1 FIG 4-6 FIG 4-8 FIG 4-11 FIG 4-14 DS1/E1 RADIO DS3 RADIO OC3/STM-1 RADIO ETH RADIO CONFIG CONFIG CONFIG CONFIG PROVISIONING PROVISIONING PROVISIONING PROVISIONING FIG 4-7 FIG 4-9 FIG 4-12 FIG 4-15 DS1/E1...
Page 133 Not provisionable. of X/Y data) are being transported between J314 of both shelves. SYSTEM ID: ELMC: RADIO LINK ID: Disable R112 RADIO TYPE: MDR-8000 OC3 OC-3 128 TCM 10-11 GHz RADIO CONFIG: Hot-Standby Tx Hot-Standby Rx TERMINAL ATPC Disable NO PA...
Page 134 HOUR, ATPC GOES HIGH FOR 10 SECONDS AND THEN GOES TO LOW POWER. THIS CONTINUES UNTIL THE CMD PATH IS RESTORED. SELECT DISABLE TO DISABLE ATPC FUNCTION. SYSTEM ID: ELMC: RADIO LINK ID: TEST1 Disable RADIO TYPE: MDR-8000 DS1 16 LINES 128 TCM 6-8 GHz RADIO CONFIG: HS Tx/HS Rx TERMINAL ATPC Enabled A&B PA Present...
Page 135 Radio Configuration Service Channel DS1 Facilities ELMC: DS105 RADIO LINK ID: Disable SYSTEM ID: MDR-8000 DS1 16 LINES 128 TCM RADIO TYPE: 6GHz RADIO CONFIG: Non-Standby Tx Hot-Standby Rx TERMINAL ATPC Enabled A&B PA Present Relay Card Present SYSTEM ALARM:...
Page 136: Ds1/E1 Provisioning Example 1: Hs Tx/Hs Rx
Radio Configuration Service Channel DS3 Facilities ELMC: DS105 RADIO LINK ID: Disable SYSTEM ID: MDR-8000 DS1 16 LINES 128 TCM RADIO TYPE: U6-8GHz RADIO CONFIG: Hot-Standby Tx Hot-Standby Tx Hot-Standby Rx Hot-Standby Rx Repeater ATPC Disable A&B PA Present Relay Card Present...
Page 137: Ds1/E1 Provisioning Example 2: Hs Tx/Sd Rx
Radio Configuration Service Channel DS1 Facilities ELMC: DS105 RADIO LINK ID: Disable SYSTEM ID: MDR-8000 DS1 16 LINES 128 TCM RADIO TYPE: U6-8GHz RADIO CONFIG: Hot-Standby Tx Hot-Standby Tx Space Diversity Rx Space Diversity Rx Repeater ATPC Disable A&B PA Present...
Page 138 WITH AN AIS SIGNAL PRIOR TO TRANSMISSION). SELECT ON TO DROP USING THE REPEATER CABLE TO PASS DS1 DATA ON CHANNELS LINE OR OFF TO 5-16 IS NOT RECOMMENDED ON MDR-8000 RADIOS. PASSING THE DISABLE LINE AND DATA THROUGH ON THESE CHANNELS WILL PREVENT ALARMS.
Page 139 Radio Configuration Service Channel DS3 Facilities WaySide DS1 Facilities ELMC: DS305 RADIO LINK ID: Disable SYSTEM ID: MDR-8000 DS3 3 LINES 64 QAM RADIO TYPE: 6GHz RADIO CONFIG: Non-Standby Tx Hot-Standby Rx TERMINAL ATPC Enabled A&B PA Present Relay Card Present...
Page 140: Ds3 Provisioning Example 1: Hs Tx/Hs Rx
Radio Configuration Service Channel DS3 Facilities WaySide DS1 Facilities ELMC: DS305 RADIO LINK ID: Disable SYSTEM ID: MDR-8000 DS3 3 LINES 64 QAM RADIO TYPE: U6-8GHz RADIO CONFIG: Hot-Standby Tx Hot-Standby Tx Hot-Standby Rx Hot-Standby Rx Repeater ATPC Disable A&B PA Present...
Page 141: Ds3 Provisioning Example 2: Hs Tx/Sd Rx
Radio Configuration Service Channel DS1 Facilities ELMC: DS105 RADIO LINK ID: Disable SYSTEM ID: MDR-8000 DS1 16 LINES 128 TCM RADIO TYPE: U6-8GHz RADIO CONFIG: Hot-Standby Tx Hot-Standby Tx Space Diversity Rx Space Diversity Rx Repeater ATPC Disable A&B PA Present...
Page 142 Note If installation at both ends of a hop are complete except for connecting to customer inputs/outputs and it is desirable to have an alarm-free system, alarm reporting on the incomplete connections can be disabled temporarily through provisioning. You can communicate over the hop even if you do not have the radio connected to customer DS3 and wayside DS1 inputs;...
Page 143 SELECT AMI OR B8ZS CODING FOR WAYSIDE DS1 LINE. SELECT ON TO DISABLE ALARM REPORTING FOR WAYSIDE DS1 LINE. SELECT OFF TO REPORT ALL ALARMS FOR THAT LINE. DS1 CARD A DS1 CARD B DS1 LINES Select All ALARM LOCK OUT DS1 LINE CODING AIS INHIBIT AIS INSERT...
Page 144 SYSTEM ID: ELMC: TEST 1 RADIO LINK ID: Disable RADIO TYPE: MDR-8000 OC3 OC3-3 128 TCM RADIO CONFIG: HS Tx TERMINAL HS Rx ATPC Enabled A&B PA Present Visual/Audible SYSTEM ALARM RELAYS ON/NO Station Alarm 13-16 RSL Alarm Enable RCV SWITCHING:...
Page 145 1X10-6 1X10-6 1X10-6 Alarm Disable Tuesday, June 3, 2003 5:20:04 AM USI Version R1.04 MDR-8000 OC3 Controller Version R1.4 SELECT ERROR RATE (1x10-5, SELECT ERROR RATE (1x10-5, 1x10-6, 1x10-6, 1x10-7, OR 1x10-8) 1x10-7, OR 1x10-8) WHICH CAUSES WHICH CAUSES OC3 INPUT...
Page 146: Oc3 Provisioning Example 1: Hs Tx/Hs Rx/4 Fiber Switched
Fiber Configuration 4 Fiber Switched 2 Fiber Frame & B1 Section OH Insertion 2 Fiber Switched 4 Fiber MDR-8000 OC3 Controller Version R1.00 Tuessday, March 7, 2000 1:27:15 PM USI Version R1.00 4 Fiber Switched 4 Fiber Switched TRANSMITTER RECEIVER...
Page 147: Oc3 Provisioning Example 2: Hs Tx/Sd Rx/2 Fiber Switched
2 Fiber Switched 2 Fiber Frame & B1 Section OH Insertion 2 Fiber Switched 2 Fiber Switched 4 Fiber MDR-8000 OC3 Controller Version R1.00 Tuessday, March 7, 2000 1:27:15 PM USI Version R1.00 4 Fiber Switched TRANSMITTER RECEIVER Select All...
Page 148 Figure 4 - 13 OC3/STM-1 Radio Wayside DS1 Facilities Provisioning Note A password is not required to operate the MDR-8000. The radio is shipped without a password and if a password is desired, it must be entered using the Change Password screen. Once entered initially, the...
Page 149 Displays modulation scheme. Displays radio type. Not provisionable. Not provisionable. SYSTEM ID: ELMC: RADIO LINK ID: Disable R112 RADIO TYPE: MDR-8000 ETH 150 Mbs 128 TCM 5-8 GHz RADIO CONFIG: Non-Standby Tx Non-Standby Rx TERMINAL Relay Card Present ATPC Disable...
Page 150 A & B Switched A Only Frame & B1 Section OH Insertion A & B Switched A & B Separate MDR-8000 OC3 Controller Version R1.00 Tuessday, March 7, 2000 1:27:15 PM USI Version R1.00 A & B Summed TRANSMITTER RECEIVER...
Page 151 A & B Summed A Only Frame & B1 Section OH Insertion A & B Switched A & B Separate MDR-8000 OC3 Controller Version R1.00 Tuessday, March 7, 2000 1:27:15 PM USI Version R1.00 A & B Summed TRANSMITTER RECEIVER...
Page 152 A & B Summed Allow 10 Mb Half Duplex Tuessday, March 7, 2000 1:27:15 PM USI Version R1.00 MDR-8000 OC3 Controller Version R1.00 Allow 10 Mb Full Duplex Allow 100 Mb Half Duplex Allow 100 Mb Full Duplex DIPLEXER Allow 1000 Mb Full Duplex...
Page 153: Provision Ethernet Facility
PROVISION ETHERNET FACILITY See Figure 4 - 15 to provision the Ethernet radio. Alcatel User Interface – [Universal USI – Provisioning ] File View Setup Options Prov. Save Alarm Status Analog Monitor Performance Station Alarm User Control Provisioning Password ELMC Address: 201R2 LOCAL ETHERNET PROVISIONING (RS-232) Communicating*...
Page 154: Auto-Negotiation
Auto-Negotiation 4.9.1 MDR-8000E auto-negotiation is not a stand-alone function, and proper operation and use of all available functions depends on the capabilities of the external customer equipment that is connected to the radio. Just because an autonegotiation function is checked for pro- visioning does not automatically mean that function is fully operable.
Page 155 Input Pause Feature 4.9.1.4 See Figure 4 - 16. Checking the box next to Allow Input Pause makes the auto-negotiation function willing to stop receiving trafﬁc. When the radio input buffers approach overﬂow, the function sends a pause message to the ink partner that is transmitting data to the radio, telling the device to temporarily stop sending data.
Page 156: Provision Ds1 Facility
Allow Output Pause 4.9.1.5 Checking the box next to Allow Output Pause makes the radio auto-negotiation function willing to stop sending trafﬁc. When the input buffers on the link partner approach over- ﬂow, the link partner sends a pause message to the radio, telling the radio to temporarily stop sending data.
Page 157 Change Password -- Change Level 1 Password Enter the New Level 1 Password: Confirm the New Level 1 Password: Change Level 2 Password Enter the New Level 2 Password: Confirm the New Level 2 Password: Cancel Save Password Forgot Password MDR-1033 09/02/04 Level One Password --...
Page 158 Alcatel User Interface – [System, DS3, and DS1 Provisioning -- MDR-8000 DS3] File View Setup Options Prov. Save Alarm Status Analog Monitor Performance Station Alarm User Control Provisioning LOCAL DS3 PROVISIONING ELMC Address: J7914 ELMC Description: DURANGO Communicating*** Radio Configuration...
Page 159 1 J316 or Alcatel User Interface – [System, DS3, and DS1 Provisioning -- MDR-8000 DS3] audio port 2 J317 on the radio backplane. These provisionable 4-wire audio functions should File View Setup Options not be confused with the 2-wire audio handset.
Page 160 HANDSET IS PARTY-LINE. DTMF ADDRESSING IS A LOCAL FUNCTION NOT A NETWORK FUNCTION, THEREFORE, IF ONE OR MORE RADIOS ARE ASSIGNED THE SAME DTMF ADDRESS, THEY WILL ALL RING WHEN THAT ADDRESS IS Alcatel User Interface – [System, DS3, and DS1 Provisioning -- MDR-8000 DS3] DIALED. File View Setup Options TO BE ABLE TO USE THE DTMF FUNCTION: 1.
Page 161 Alcatel User Interface – [System, DS3, and DS1 Provisioning -- MDR-8000 DS3] File View Setup Options Prov. Save Alarm Status Analog Monitor Performance Station Alarm User Control Provisioning LOCAL DS3 PROVISIONING ELMC Address: J7914 ELMC Description: DURANGO Communicating*** 1:, 2: OR 3: – THE 64 kb/s SERVICE CHANNEL TO BE INSERTED INTO RADIO...
Page 162 Channel 1 Channel 2 Repeater D/1 RS-232 SELECT FOR TERMINAL (ONE DIRECTION) AE-37( ) CONTROLLER SC MULDEM J343 J314 RCV SC DATA E TO/FROM DROP XMT SC I/O INTFC DATA W INSERT RS-232 RXD1 RS-232 TXD1 J312 DATA PATH NOT USED Channel 1 Channel 2 Repeater D/1...
Page 163 Select ports on I/O INTFC module that will be used to insert and drop service channel data. Channel MCS Transport RF/Rptr PPP Transport RF/Rptr None None Rptr Rptr Select channel 1, 2, or 3 as RF/Rptr RF/Rptr service channel to be used for MCS transport and/or PPP transport.
Page 164 4) MCS-11 = Non TMN compatible MCS-11 + PPP = TMN compatible 5) TMN compatibility is determined by the radio controller software and radio provisioning. MCS-11 PROTOCOL RF PORT RF PORT MDR-8000 MDR-8000 ANY PROTOCOL DISABLED RPTR PORT RPTR PORT MCS TRANSPORT...
Page 165 3) RPTR at both ends must be provisioned for the same PPP Transport selection. 4) MCS-11 = Non TMN compatible MCS-11 + PPP = TMN compatible 5) TMN compatibility is determined by the radio controller software and radio provisioning. MCS-11 MCS-11 MDR-8000 MDR-8000 RF PORT RF PORT DISABLED DISABLED...
Page 166 2) RPTR at both ends must be provisioned for the same PPP Transport selection. 3) MCS-11 = Non TMN compatible MCS-11 + PPP = TMN compatible 4) TMN compatibility is determined by the radio controller software and radio provisioning. DISABLED MCS-11 MDR-8000 MDR-8000 RF PORT RF PORT MCS-11 MCS-11...
Page 167 RPTR at both ends must be provisioned for the same PPP Transport selection. MCS-11 = Non TMN compatible MCS-11 + PPP = TMN compatible TMN compatibility is determined by the radio controller software and radio provisioning. MCS-11 MCS-11 MDR-8000 MDR-8000 RF PORT RF PORT MCS-11 MCS-11...
Page 168 Alcatel User Interface – [System, DS3, and DS1 Provisioning -- MDR-8000 DS3] File View Setup Options Note Prov. Save Alarm Status Analog Monitor Performance Station Alarm User Control Provisioning A default MCS-11 address (A1A) is assigned automatically. A different unique address must be entered for each radio...
Page 169 7. CLICK HERE DESCRIPTION ELMC ADDRESS. EXACTLY. TO ENTER NEW (IF DESIRED). 4. OPEN ELMC ADDRESS ADDRESS AND SETUP SCREEN. DESCRIPTION Setup ELMC Address -- MDR-8000 Extended Link Monitor Channel (Elmc) Address J7914 DURANGO ELMC: J7914 Description: DURANGO Add Elmc=> Save...
Page 170 Current time-out is 3 secs 4 secs 5 secs 6 secs 7 secs 8 secs 9 secs 10 secs Cancel Alcatel User Interface - [Alarm Status -- MDR-8000 OC3] File View Setup Options ✓ Acknowledge Alarm Status Analog Monitor Performance Station Alarm User Control...
Page 171 NOTE: DEFAULT CONTROL NAMES ARE USER CONTROL 1-6 1. OPEN USER CONTROL NAMES SETUP SCREEN 2. SELECT RADIO User Control Names Setup -- MDR-8000 CONTROL NAMES ELMC List GEN START RACK1 DURANGO RACK2 DURANGO TWR LIGHT OVRD RACK3 RED MTH PASS...
Page 172 1. SELECT RADIO CLICK HERE TO SAVE Alcatel User Interface – [Provisioning MDR-8000 OC3] File View Setup Options Prov. Save Alarm Status Station Alarm User Control Password Analog Monitor Performance ELMC ADDRESS: S302 LOCAL DS3 PROVISIONING Communicating*** ELMC ADDRESS: DS301 -- MDR-8000 DS3...
Page 173: Introduction
This section contains information and procedures to aid in restoring the equipment to its proper operating condition after it has been determined that a problem exists. The following warnings and cautions apply while operating, performance testing, trouble- shooting, or repairing the MDR-8000 series radios. DANGER Possibility of...
Page 174: Maintenance Philosophy
CAUTION Possibility of Service Interruption RF ﬂex coaxial cable requires special consideration. The electrical char- acteristics of the coax can be affected if it is accidentally twisted or bent. Provide mechanical support to prevent any weight or strain to the coax and connector when connecting or disconnecting equipment.
Page 175 Alarm Periodic Check Performance Indication Failure* Screen Errors Para. 5.6 Para. 5.8 Para. 5.9.3 Perform Trouble Analysis Para. 5.9 Checks and Adjustments Cause Required Alarm Module Replacement Required Refer to Module Replacement Table Table 5 - 6 Module Adjustment Required Perform Applicable Checks and Adjustments Per Module Replacement Table...
Page 176: Recommended Test Equipment
RECOMMENDED TEST EQUIPMENT Refer to Table 5 - 1 for the list of recommended test equipment. Alcatel recommends this test equipment to properly maintain the radio. Table 5 - 1 Recommended Test Equipment Test Equipment/Function Essential Characteristics Used On Digital Volt Meter (DVM) Out-of-Service Carrier Null Adjustment Fluke 75 Using DVM (Refer to CD).
Page 177: Personal Computer (Pc)/Laptop
Table 5 - 2 Optional Test Equipment (Cont.) Test Equipment/Function Essential Characteristics Used On Communications Ana- Over-The-Hop DS1 BER Threshold Test lyzer w/DS1 Package Acterna TB 2310-P4 D1 Data Rate 1.544 Mb/s, DS1 Modulation B8ZS or AMI Scheme Communications Ana- Over-The-Hop DS3 BER Threshold Test lyzer w/DS3 Package Acterna TB 2310-P5...
Page 178 AE–37( ) CNTLR MDR–8000 SHELF TO CONNECTOR J301 (CONNECTS TO RS–232C AE–37 CONTROLLER) INTERFACE CABLE TERMINAL MW211–0066–1 101598 RS–232C PORT Figure 5 - 2 USI Computer to Controller Interconnection...
Page 179: Mdr-8000 Alarms
MDR-8000 ALARMS MDR-8000 Alarms are displayed on: USI Alarm and Status screen Alcatel MCS-11 Monitor and Control System SNMP MIB browser TBOS foreign alarm system External relay interface Module front panel indicators Alarm names are radio/alarm equipment dependent. The Alarm List found under NOC Alarm Troubleshooting on the enclosed CD, identiﬁes every alarm name indicated by the...
Page 180: Recommended Periodic Checks
RECOMMENDED PERIODIC CHECKS Perform XMTR local oscillator frequency veriﬁcation (Para. 5.18) and XMTR output check (Para. 5.19) 1 year after initial setting and at 5-year intervals thereafter to correct possible drift caused by aging. RADIO TROUBLESHOOTING The digital radio system is equipped with alarm circuitry and automatic switching (in hot- standby, frequency diversity, and space diversity conﬁgurations) to provide protection against loss of trafﬁc.
Page 181: Troubleshooting Performance Screen Errors
Troubleshooting Performance Screen Errors 5.9.3 Path and intermod problems can occur that cause errors to be indicated on the Perfor- mance monitor screens that are not severe enough to generate an alarm on the USI Alarm and Status screen. Errors of this type fall into two categories: burst and dribbling errors. The performance screens can be a useful tool in troubleshooting a radio with and without alarms being indicated on the Status Alarm screen.
Page 182 Loss of XMT signal detected at output of PA. If any other alarms are red, go to 1. If not, go to 2. If Off Normal alarm is lit, check 10.5 V switch on power supply is on. If not, remove/replace PA module.
Page 183 Both RCVRs at the other end have a problem and have switched the TRANSMITTER XMTRs to try and clear it. If the RCVRs clear within a defined time frame STATUS (which we will hereafter call the CLA window) after switching, the CLA appears.
Page 184 DS3 I/O INTFC cannot recover framing from incoming DS3 signal or there is no TRANSMITTER input signal. Is DS3 AIS Detect Alarm on? STATUS Yes, troubleshoot upstream radios and external MUX equipment. No, check input signal. If input signal is OK, replace DS3 I/O INTFC.
Page 185 Note Always troubleshoot and clear the most severe alarm first. Channel Fail is the most severe, followed by Radio Frame Loss and Eye Closure. The Eye Closure alarm, Radio Frame Loss alarm, and Channel Fail alarm all work together to form effective 3-level troubleshooting tools. If RECEIVER the radio is provsioned correctly, Eye Closure STATUS...
Page 186 A Channel Fail alarm occurs when RCVR(s) have lost lock and are not locked on the signal from the farend XMTR(s). Loss of signal also means loss of CMD path. The most effective method of troubleshooting this type RECEIVER alarm is to have a technician at both ends of the hop. Farend status STATUS viewing and controls must be performed at the farend site.
Page 187 Note Always troubleshoot and clear the most severe alarm first. Channel Fail is the most severe, followed by Radio Frame Loss and Eye Closure. Loss of radio frame from RCVR in I/O Interface RCVR circuits. Before starting, check USI for receiver Channel Fail alarms and Common...
Page 188 Errors are being received by the RCVR at a rate exceeding the Eye RECEIVER BER threshold error rate provisioned on the radio configuration STATUS screen. This alarm could be caused by a faulty XMTR (farend), radio Receiver Fault interference on the RF path (RFI), antenna/waveguide problem, or a Receiver On Line faulty antenna/waveguide problem, or a faulty RCVR/RCVR local Channel Fail...
Page 189 Note is displayed on DS1 USI Status and Alarm Radio Dade screen only. Low RSL on alarmed RCVR. Alarm only functions if AGC switching threshold is provisioned active. RECEIVER 1. Check for path fading. STATUS 2. Check upstream XMTR. Receiver Fault Receiver On Line Channel Fail High level of distortion in TDE due...
Page 190 I/O Interface cannot recover framing from signal from RCVR module. 1. Is DS3 AIS Detect alarm on? Yes, check for upstream XMTR DS3 AIS Detect alarm. If XMTR DS3 AIS Detect alarm is on, troubleshoot external MUX equipment at XMT end. If not, troubleshoot upstream XMTR.
Page 191 Future use AIS (blue signal), inserted at MUX (external to the radio) has been detected by OC3/STM-1 I/O INTFC RCV circuits. I/O conditioner cannot recover framing Troubleshoot external MUX equipment from signal from RCVR module. OC3 Output Online (fault is not in radio). 1.
Page 192 Module is present, but cannot communicate with Controller on I C Bus. Voltage regulation failure or 1. Remove and replace module indicating read fail on Inventory screen. excessive load. 2. Remove and replace Controller. 1. Cycle power 2. Check fuse COMMON 3.
Page 193 MESSAGE MEANING ACTIONS A Tx Override Override function is enabled Disable override function on on controller module locking A- controller module front panel. side XMTR/PA in-service. Switching is disabled regard- less of alarms. B Tx Override Override function is enabled Disable override function on on controller module locking B- controller module front panel.
Page 194 MESSAGE MEANING ACTIONS B Side PA OFF switch on B-side switch on B- PA ON/OFF PA ON/OFF power supply is set to side power supply to Prov. Mismatch Provisioning on the controller Provision to match system does not match the provision- requirements.
Page 195 LOS has been detected at RCV Input of I/O interface and AIS (All Ones or Zeros) is being inserted. Check for LOS at XMT end of HOP. If not, 1. Check for upstream XMTR alarms. Any XMTR alarms? Yes, troubleshoot XMTR. No, go to 2.
Page 196: Ethernet-Specific Troubleshooting
The LEDs on the front panel of the Ethernet I/O Interface module and the alarms on the radio USI status and alarm screen are the ﬁrst indication of a fault. Troubleshoot radio XMT and RCV alarms using the procedures in the MDR-8000 Instruction Book/Users Manual. Troubleshoot Ethernet alarms as follows: Troubleshooting Using Ethernet I/O Interface Module Front Panel Indicators 5.10.1...
Page 197 Table 5-3 Troubleshoot Using Ethernet I/O Interface Module Indicators (Cont.) Indication Probable Cause Corrective Action ETH IN Green LED Loss of Ethernet RCV/radio XMT Not Lit signal in. Most probable causes: 1. Cable between link partner and Connect/repair cable. radio is disconnected/broken. 2.
Page 198: Tmn-Specific Troubleshooting
TMN-SPECIFIC TROUBLESHOOTING 5.11 Refer to Table 5 - 4. The red ALM LED on the front panel of the TMN Interface module and the alarm on the radio USI status and alarm screen are the ﬁrst indication of a fault. The ALM LED on the front panel of the TMN Interface module lights for any module fault.
Page 199 Table 5-5 TMN Network Troubleshooting Problem Possible Cause Possible Solution 1. Normal network management 1. There may be too many radios Unusually slow communi- trafﬁc is saturating the communi- being managed within a single cation in radio network cations channel. region.
Page 200 Table 5 - 5 TMN Network Troubleshooting (Cont.) Problem Possible Cause Possible Solution 1. Manager not registered in NE to 1. Register Manager with NE. No traps being received receive traps from NE 2. Communication failure in net- 2. Check network connectivity. work Check redundant network paths and routing.
Page 201: Module Replacement
MODULE REPLACEMENT 5.12 WARNING Possibility of Damage to Equipment Modules screwed to heat sink must be screwed securely before power is turned on. WARNING Possibility of Damage to Equipment Units with the electrostatic-sensitive (ESS) symbol contain ESS devices. Store these units in an antistatic container when not in use, and anyone handling a unit should observe antistatic precautions.
Page 202 CAUTION Possibility of Service Interruption XMTR Crystals are soldered and tuned up in an oscillator assembly board at the factory. CAUTION Possibility of Service Interruption Modules may be removed or installed with shelf power applied. However, exercise reasonable care to prevent contact- ing adjacent modules.
Page 203 Table 5-6 Module Replacement Matrix MODULE/UNIT REMOVAL/REPLACEMENT CHECKS/ADJUSTMENTS PROCEDURE PROCEDURE AE-27AF Relay Interface No Special Procedure Required None Required AE-37Y Controller Para. 5.14 None Required CE-16BB Power Supply Para. 5.13 None Required Fuse No Special Procedure Required. Refer to Operations Section for Location.
Page 204: Power Supply Removal And Replacement
POWER SUPPLY REMOVAL AND REPLACEMENT 5.13 See Figure 5 - 13 and follow the procedure to remove and replace CE-16BB Power Supply. CAUTION Possibility of Service Interruption This is an out-of-service procedure when on a nonstandby (unprotected) system. On a hot-standby or frequency diversity system, switch traffic on the channel under test to protect.
Page 205: Controller Removal And Replacement
CONTROLLER REMOVAL AND REPLACEMENT 5.14 See Figure 5 - 14 and follow the procedure to remove and replace AE-37Y Controller. CAUTION Possibility of Service Interruption This is an in service procedure, however protection switching is disabled. If another failure occurs during the performance of the procedure, service will be interrupted.
Page 206 Note A replacement controller that is loaded with the same firmware load as the controller that is being replaced (i.e.: controller for DS3 radio is replacing a DS3 radio controller) is automatically rebooted and provisioned to match the module it is replacing. If the replacement controller is for a different type of radio (i.e.;...
Page 207 Provisioning hold Click here. Click here. message displays. Alcatel User Interface File View Setup Options Communication Options New Controller Provisioning Alarm Status Performance Station Alarm User Control Firmware Upgrade LOCAL MAIN ELMC Address Prov. Hold Diagnostics Communicating*** ELMC Descriptions TDE Chip Receive Provisioning Note Provisioning hold message is displayed...
Page 208 CLICK HERE CLICK HERE CLICK HERE Alcatel User Interface File View Setup Options Communication Options New Controller Provisioning Alarm Status Performance Station Alarm User Control Download Firmware Upgrade LOCAL MAIN ELMC Address Prov. Hold Diagnostics ELMC Descriptions Communicating*** TDE Chip Receive Provisioning 11-DS1 21 = R2.01 = Release Version...
Page 209: Ds3 I/O Interface Removal And Replacement
DS3 I/O INTERFACE REMOVAL AND REPLACEMENT 5.15 Follow procedure to remove and replace DX-35N DS3 I/O Interface module. Refer to Table 5 - 7 and Table 5 - 8 for conﬁguration functions. Table 5 - 7 1- or 3-Line I/O Interface Module PN 3DH03169XX System Front Panel...
Page 210 Table 5 - 9 1- or 3-Line Matrix, Valid Combinations/Procedures I/O Interface Module Radio Radio Line DADE PN 3DH03169AAXX DADE Conﬁguration in Shelf Position Conﬁguration (Refer to CD) ( Refer to CD ) A3, B3, Variant XX = HS, FD, SD HS, FD, SD HS, FD, SD HS, FD, SD...
Page 211: Oc3/Stm-1/Eth I/O Interface Removal And Replacement
OC3/STM-1/ETH I/O INTERFACE REMOVAL AND REPLACEMENT 5.16 Use this procedure to remove and replace DX-35P OC3/STM-1 or DX-35R/S ETH I/O Interface module. If radio is protected (hot-standby, space diversity, or frequency diversity, use front panel controls on AE-37( ) Controller to lock on-line OVRD XMTR, RCVR, and I/O (opposite side from failed I/O) on line.
Page 212: Xmtr Removal And Replacement
XMTR REMOVAL AND REPLACEMENT 5.17 Use this procedure to remove and replace the UD-35( ) XMTR and/or Capacity Key and Crystal Oscillator Subboards on the XMTR. Note Spare XMTRs and XMTRs repaired at the factory normally do not con- tain Crystal Oscillator Subboards or Capacity Keys. The user must retain the crystal Oscillator Subboard and the Capacity Key from the module being replaced before sending the module back to the factory for repair.
Page 213 Perform XMT Crystal Oscillator Frequency Checks and Adjustment procedure. Refer to Para. 5.18. On power supply, set PA ON/OFF switch to ON (if turned off in Step a). Note Output level calibration is required for the last ampliﬁcation stage in the chain of XMT ampliﬁers leading to the antenna, only.
Page 214 Remove: Remove transmitter from card cage. Remove 8 screws from Crystal Ocsillator Subboard cover, and remove cover. XMTR–RIGHT SIDE VIEW Disconnect ribbon Remove 3 mounting screws, cable from J8. and remove Crystal Oscillator Subboard. Install: Place Crystal Oscillator Subboard in mounting cavity. Install 3 mounting screws.
Page 215 CAUTION Possibility of Service Interruption This is an out-of-service procedure when on a nonstandby (unprotected) system. On a hot-standby or frequency diversity system, switch traffic on the Remove: channel under test to protect. Remove transmitter from card cage. Remove 13 screws from Capacity Key and remove Capacity Key.
Page 216 NTFC Connect power meter with 50 OHM power sensor to RF MON connector on PA. Measure RF monitor level on power meter. XMT LVL While monitoring power meter, adjust PWR ALM control on XMTR for READ XMT LVL ADJ PWR MON X.X dBm level on PA label.
Page 217 Connect DVM to DC MON (+) test point and GND on PA. DC MON Measure DC monitor level on DVM. XMT LVL PWR ALM While monitoring voltage on DVM, adjust XMT TEMP ALM LVL ADJ control on XMTR for READ (X.X Vdc) PWR MON DC MONITOR CALIBRATION voltage on PA label.
Page 218: Xmt Crystal Oscillator Frequency Correction
XMT CRYSTAL OSCILLATOR FREQUENCY CORRECTION 5.18 PURPOSE See Figure 5 - 19 and follow the procedure to correct the transmit frequency of the crystal oscillator on the UD-35() Transmitter module. Allow a 1-hour warm-up period for radio and test equipment before starting applicable tests or improper frequency adjustment can result.
Page 219: Xmtr Output Level Check (No Pa)
XMTR OUTPUT LEVEL CHECK (NO PA) 5.19 See Figure 5 - 20 and follow the procedure to check the RF output of the UD-35( ) Transmit- ter in radio conﬁguration that is not equipped with the optional PA. CAUTION Possibility of Service Interruption This is an out-of-service procedure when on a nonstandby...
Page 220: In-Service Xmtr Carrier Null Adjustment Using Spectrum Analyzer
Transmitter, in service. For out-of-service carrier null procedures, refer to CD. Note Carrier leakage can be nulled in the MDR-8000 using any one of three methods. Method 1 (the preferred method) uses a spectrum analyzer to determine if carrier leakage is present while a modulated signal is being transmitted (in service) and then nulling any carrier present.
Page 221 PO SHELF CONNECT SPECTRUM ANALYZER TO RF MON CONNECTOR. XMT LVL b. SET SPECTRUM ANALYZER CONTROLS. CONTROL SETTING PWR MON INPUT ATTEN (dB) 10 dB FREQ CONT CENTER FREQ CHAN FREQ XMT PWR (SEE FREQ LABEL ON LINE ON XMTR OR PA). I CARR NULL FREQ SPAN VALUE APPROXIMATELY...
Page 222 Reduce the frequency span on the spectrum analyzer display while keeping the spectrum centered on the spectrum analyzer display. Continue to reduce the spectrum analyzer span while observing the ﬁeld in the bottom left corner of the spectrum analyzer display. Continue reducing the frequency span until the correct Res BW measuring carrier for the Radio Capacity/Modulation is displayed.
Page 223 CAUTION Possibility of Service Interruption Adjustment of the carrier signal for minimum amplitude is critical. Do not attempt to null the carrier signal until the correct Res BW is reached. Incorrect adjustment can result in loss of trafﬁc due to slow RCVR lock. Observe the display at the correct for measuring carrier for a Res BW...
Page 224 a. Center carrier on screen. Note It is extremely important to keep the carrier signal centered in the display so that the carrier will become visible as the span is reduced. b. Reduce Span to 30 mHz. 10 dB above c.
Page 225 e. Center carrier on screen. f. Reduce Span to 1 mHz. g. Center carrier on screen. i. Reduce Span h. Observe to 500 kHz. Res BW MDR-1217 09/20/05 5-53...
Page 226 Note You must watch the trace carefully on the spectrum analyzer when adjusting the I and Q carrier controls on the XMTR module. the I and Q carrier controls are interactive and the slightest change on one control causes a change on the other.
Page 227 5-55...
Page 228: Xmtr Output Level Calibration
XMTR OUTPUT LEVEL CALIBRATION 5.21 See Figure 5 - 21 and follow the procedure to check, and if necessary adjust, the RF output of the UD-35() Transmitter in radio conﬁguration that is not equipped with the optional CAUTION Possibility of Service Interruption This is an out-of-service procedure when on a nonstandby...
Page 229 ELMC Address: RACK6 Communicating* 10-May-99 high and low output level: Description: MDR-8000 XMTR nominal high output level = level at top of stack + insertion loss of diplexer filter/XMT filter CLICK CALIBRATE A OR B SIDE (marked on label on filter.
Page 230 Note Ensure ATPC is disabled. Save the calibrated values. Click next Storing calibration data, please wait... Abort Back Next Abort Back Next Click Next. Click Next. Successfully stored calibration data Back Finish Click Finish. Calibration is complete. Disconnect power meter and sensor Observe RF MON label on XMTR from connector.
Page 231 Connect Power Meter with 50 OHM Power Sensor to RF MON connector. Measure RF Monitor Level on Power Meter. XMT LVL Make new label for RF MON. MEASURED LEVEL PWR MON (STEP b). FREQ CONT XMT PWR READ [X.X dBm] FOR [XX.X dBm] ON LINE AT TOP OF RACK...
Page 232 Connect DVM to PWR MON test point. XMT LVL Measure voltage on DVM. Make new label. PWR MON FREQ CONT XMT PWR DC MONITOR CALIBRATION MEASURED LEVEL READ [X.X Vdc] (STEP b). ON LINE FOR [XX.X dBm] I CARR NULL Q CARR NULL EXPECTED OUTPUT LEVEL DC MONITOR CALIBRATION...
Page 233: Rcvr Removal And Replacement
RCVR REMOVAL AND REPLACEMENT 5.22 Use this procedure to remove and replace UD-36() RCVR. CAUTION Possibility of Service Interruption This is an out-of-service procedure when on a nonstandby (unprotected) system. On a hot-standby, space diversity, or fre- quency diversity system, switch trafﬁc on the channel under test to protect.
Page 234 Remove: a Remove Receiver from card cage. b Remove 8 screws from Crystal OSC Subboard cover, and remove cover. RCVR–RIGHT SIDE VIEW c Disconnect ribbon cable from J8. d Remove 3 mounting screws, and remove Crystal OSC Subboard. Install: e Place Crystal OSC Subboard in mounting cavity.
Page 235 REMOVE: (Remove steps are prefixed by the letter "R". Remove Receiver from card cage. Remove 13 screws from Capacity Key, and remove Capacity Key. INSTALL: (Install steps are prefixed by the letter "I". Install Capacity Key on 3 connectors. Install 13 screws. RCVR –...
Page 236: Rcv Crystal Oscillator Frequency Correction
RCV CRYSTAL OSCILLATOR FREQUENCY CORRECTION 5.23 See Figure 5 - 24 and follow the procedure to correct the receive frequency of the crystal oscillator on older versions of the UD-36 ( ) receiver module. Allow a 1-hour warm-up period for radio and test equipment before starting procedure or improper frequency adjustment can result.
Page 237: Pa Removal And Replacement
PA REMOVAL AND REPLACEMENT 5.24 See Figure 5 - 25 and follow the procedure to remove and replace UD-51() PA. CAUTION Possibility of Service Interruption This is an out-of-service procedure when on a nonstandby (unprotected) system. On a hot-standby or frequency diversity system, switch trafﬁc on the channel under test to protect.
Page 238 FRONT PANEL P/O SHELF REMOVE: INSTALL: (Remove steps are prefixed (Install steps are prefixed DC MON by the letter "R"). by the letter "I". PWR ALM TEMP ALM Install replacement PA in shelf and tighten DC MON ADJ mounting screws (torque to 19 in.
Page 239: Pa Output Level Calibration
PA OUTPUT LEVEL CALIBRATION 5.25 See Figure 5 - 26 and follow procedure to check, and if necessary, adjust the UD-51( ) Power Ampliﬁer (PA) output in radio conﬁguration that is equipped with the optional PA. CAUTION Possibility of Service Interruption This is an out-of-service procedure when on a nonstandby (unprotected) system.
Page 240 ELMC Address: RACK6 Communicating* 10-May-99 and low output level: Description: MDR-8000 PA nominal high output level = level at top of stack + insertion loss of diplexer filter/XMT filter CLICK CALIBRATE A OR B SIDE (marked on label on filter).
Page 241 Save your calibrated values. Click next Abort Back Next Storing calibration data, please wait... CLICK NEXT . Abort Back Next Click Finish. Calibration is complete. Successfully stored calibration data Reconnect cable to RF OUT connector. Observe RF MON label on PA front panel.
Page 242 Connect Power Meter with 50 Ohm Power Sensor to RF MON connector. Measure RF MON level on Power Meter. Make new label for RF MON: PWR ALM MEASURED LEVEL (STEP b). TEMP ALM DC MON ADJ READ X.X dBm FOR XX.X dBm PWR ALM ADJ AT TOP OF RACK 10.5V DC...
Page 243 Connect DVM to test point and DC MON (+) Using DC on PA front panel, adjust for MON ADJ voltage on DVM equaling expected level at top of DC MON stack multiplied by 0.1. PWR ALM EXAMPLE: TEMP ALM EXPECTED LEVEL AT TOP OF STACK = 29 dBm 29 dBm X 0.1 (VOLTS DC/dBm) = 2.9 VOLTS DC DC MONITOR CALIBRATION READ [X.X Vdc]...
Page 244: Changing Frequency
CHANGING FREQUENCY 5.26 CAUTION Possibility of Service Interruption Crystals are soldered and tuned up in a crystal oscillator sub- board at the factory. Changing frequencies requires changing the crystal on the crystal oscillator subboard in the transmitter and receiver modules. Changing out the crystal requires tuning the crystal oscillator subboard.
Page 245 Note The information contained in this section is a summary of the sec- tion with the same title, but not the same section number, on the enclosed CD. “Refer to CD” is used throughout this section to refer the reader to the detail information on the CD. Go to this section on the CD for interactive links to the detail information referred to in this section.
Page 246 Alarm Status Analog Monitor Station Alarm User Control Provisioning Performance LOCAL ANALOG ELMC Address [F8]: J7915 ELMC Description: SILVERTON Communicating* TRANSMIT Voltages RECEIVE Voltages PA (DC MON) RX (RSL 1) dbm 3.13 3.03 -45 dBm -53 dBm TX (PWR MON) RX (EYE MON) 1.91 1.95...
Page 247: Ds1/E1 Radio Performance Screen
DS1/E1 RADIO PERFORMANCE SCREEN See Figure 6 - 3. The Analog Monitor screen is used to display real-time analog voltages and radio performance monitors for the ELMC address. Analog voltages are updated automatically every second. Reset performance parameters to zero using the Error Reset button (or hotkey F3) on the toolbar.
Page 248 3 WAYS TO OPEN ANALOG MONITOR SCREEN Analog and Performance Monitoring -- MDR-8000 File View Setup Options Alarm Status Performance Error Reset [F3] Alarm Status [F4] Perf Monitor [F5] Station Alarm [F6] Control [F7] Provisioning [F9] Station Alarm Control 2. CLICK HERE...
Page 249: Ds3 Radio Performance Monitoring Screen
DS3 RADIO PERFORMANCE MONITORING SCREEN See Figure 6 - 4. Reset performance parameters to zero using the Error Reset button (or hotkey F3) on the toolbar. TIME SINCE LAST RESET displays the time in days, hours, minutes, and seconds since the last error reset. Line 1-3 DS3 Errors 6.4.1 Indicates total number of coding violations, slips, or frame losses in the DS3 line data.
Page 250: Oc3/Stm-1 Radio Performance Monitoring Screens
5.2 E-7 1.0 E-14 Time Since Errors Reset: 0 Days, 00:00:00 LMW-5072 01/29/04 Monday, July 28, 2003 3:30:05 PM USI Version R1.04 MDR-8000 OC3 Controller Version R1.04 Figure 6 - 5 OC3/STM-1 Radio, OC3/STM-1 Facilities Performance Screen 6 - 6...
Page 251 Time Since Errors Reset: 0 Days, 00:00:00 LMW-5073 01/29/04 Monday, August 20, 2001 3:30:05 PM USI Version R1.01 MDR-8000 OC3 Controller Version R1.01 Figure 6-6 OC3/STM-1 Radio, Wayside DS1 Facilities Performance Screen Error Reset Alarm Status Analog Monitor Performance Station Alarm...
Page 252: Radio Error Seconds
Radio Error Seconds 6.5.8 Any second during which a code violation was detected. Count is initiated during any second that qualiﬁes as Unavailable Second. 6.5.9 Radio Severe Error Any second during which the code violation count exceeds the number of errors that could occur in one second at 1 X 10 error rate.
Page 253: Gpf Receive
Communicating* Radio Ethernet RF RECEIVE GFP RECEIVE Errors Errors Error Seconds Error seconds Severe Error Seconds Severe Error Seconds Severe Error Frame Seconds Severe Error Frame Seconds 1.0 E-14 1.1 E-14 2.9 E-12 1.5 E-12 Radio Outage Sec Radio A and B Outage Sec MDR-1202 08/15/05 Figure 6-8 Ethernet Radio, Radio Performance Screen...
Page 254: Out (From Rf Receive)
Total Frames 6.7.1.2 Indicates number of valid Ethernet frames in the Ethernet RCV/radio XMT data. Error Frames 6.7.1.3 Frame Check Sequence (FCS) error count indicates the number of Ethernet frames with errors in the Ethernet RCV/radio XMT data. Dropped Frames 6.7.1.4 Indicates number of Ethernet frames dropped due to errors in the Ethernet RCV/radio XMT data or lack of buffer space.
Page 255: Ds1/E1 Radio Control Screen
Total Frames 6.7.2.2 Indicates number of valid Ethernet frames in the Ethernet XMT/radio RCV data. Error Frames 6.7.2.3 Frame Check Sequence (FCS) error count indicates the number of Ethernet frames with errors in the Ethernet XMT/radio RCV data. Dropped Frames 6.7.2.4 Indicates number of Ethernet frames dropped due to errors in the Ethernet XMT/radio RCV data, or lack of buffer space.
Page 256 3 WAYS TO OPEN CONTROL SCREEN Controls -- MDR-8000 DS1 File View Setup Options Alarm Status Performance Alarm Status [F4] Perf Monitor [F5] Station Alarm [F6] Control [F7] Provisioning [F9] Station Alarm Control 2. CLICK HERE Provisioning Inventory 3. PRESS F7 ON KEYBOARD...
Page 257: Ds3 Radio Control Screen
I/O INTFC XMTR MODULE MODULE DS1 LINE ( ) LOOPBACK I/O LOOPBACK (PER DS1) (ALL DS1s) RCVR MODULE I/O INTFC MODULE DEMUX LMW-6072 07/05/04 Figure 6-11 DS1/E1 Loopback DS3 RADIO CONTROL SCREEN See Figure 6 - 12. The Control screen is used to enable or disable and display the status of manual controls.
Page 258: User Controls
User Controls 6.9.3 USER CONTROLS , deﬁned by the customer and named on the User Control Names Setup screen, are displayed and can be enabled or disabled if the optional AE-27() Relay Interface module is installed. Wayside DS1 Line Loopback Controls 6.9.4 See Figure 6 - 13.
Page 259 UNI XMT DS3 LINE 1-3 ENFEC XMTR ASIC TO/FROM DS3 LBO LOOPBACK (ALL DS3s) DEFEC UNI RCV DS3 LINE 1-3 FROM ASIC RCVR SW SWITCH LOOPBACK I/O CONTROL ENABLED LOOPBACK ENABLE FROM CONTROLLER DS3 I/O INTFC LMW-5056 07/05/04 Figure 6-13 DS3 System Loopback 6 - 15...
Page 260: Oc3/Stm-1 Radio Control Screen
OC3/STM-1 RADIO CONTROL SCREEN 6.10 See Figure 6 - 14 . and Figure 6 - 15 The Control screen is used to enable or disable and dis- play the status of manual controls. Manual controls include equipment and function in- service controls, system loopback controls, user controls, and DS1/E1 loopback controls.
Page 261 B OC3 Output FORCED SWITCHING A Main A Diversity B Main B Diversity LMW-9075 01/29/04 Monday, July 28, 2003 1:06:08 PM USI Version R1.04 MDR-8000 OC3 Controller Version R1.04 Figure 6-15 OC3/STM-1 Radio Control Screen (Dual RCVR) 6 - 17...
Page 262: Ethernet Radio Control Screen
I/O INTFC XMTR 4 x 39 SMCRA Translator OR/RT Equipment LPBK Switch Facility Equipment RCVR LPBK LPBK OT/RR MDR-1094 Switch Switch 12/14/04 Figure 6 - 16 OC3/STM-1 Loopbacks ETHERNET RADIO CONTROL SCREEN 6.11 See Figure 6 - 17. The Control screen is used to enable or disable and display the status of manual controls.
Page 263 System Loopback 6.11.3 See Figure 6 - 18 for the system loopback functions. There are three system loopback functions available on the Ethernet radio; Eth facility loopback, RC3 equipment loop- back, and Eth equipment loopback. All loopbacks occur on the Ethernet I/O interface module.
Page 264: System Loopback
ETHRA FPGA ETH RC3 LPBK (DATA + OH + WSDS1) ETH TX RADIO FIFO FRAME MULDEM ETH RX EQUIP FACILITY LPBK LPBK DS1 LINE INTFC WS DS1 LINE 1 TI/DS1 FRAMING WS DS1 LINE 1 ETH-1046 01/25/06 Figure 6 - 18 Ethernet Loopbacks RC3 Equipment Loopback 6.11.3.2 RC3 equipment loopback is a local loopback function that can be used to test the per-...
Page 265: Ds1 Line Loopback
Eth Equipment Loopback 6.11.3.3 Eth equipment Loopback is a farend loopback function that can be used to test the over-the-hop performance of radios. Eth Equipment loopback is enabled by selecting A Eth Equipment under SYSTEM LOOPBACK on the USI Control screen. This function loops the radio RCV (RR) input into the radio XMT output.
Page 266 CAUTION Possibility of Service Interruption Loopbacks cause loss of traffic on DS1 outputs to X-connect. Quad Falc DS1 RX 1 T/R DS1 RX 2 T/R DS1 RX 3 T/R DS1 RX 4 T/R DS1 TX 1 T/R Switch DS1 TX 2 T/R ETHRA INTFC FPGA...
Page 267 CAUTION Possibility of Service Interruption Loopbacks cause loss of traffic on DS1 inputs to ETHRA FPGA. Quad Falc DS1 RX 1 T/R Switch DS1 RX 2 T/R Switch DS1 RX 3 T/R ETHRA INTFC FPGA Board Switch DS1 RX 4 T/R DS1 TX 1 T/R Switch DS1 TX 2 T/R...
Page 268: Inventory Screen
Field Not Applicable Item Change Status - identifies source of part Tuesday, November 30, 2004 3:31:44 PM Universal USI Version P2.00q MDR-8000 OC3 Controller Version P3.13 Realization Variant - identifies Manufacturing Revision - differences in design within identifies enhancement-type MDR-1162...

Alcatel-Lucent MDR-8000 User Manual

Quick Links

Troubleshooting

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Alcatel-Lucent MDR-8000

Summary of Contents for Alcatel-Lucent MDR-8000

Table of Contents
