OneControl® Control Panel
NoTe: Password protection will only be on tablets manufactured on or after 7-13-15.
• If the tablet is outside of the dock and connected to the system via WiFi, clicking on "OneControl® Control
Panel" from the main OneControl® screen will show the attached password screen (Fig. 10A). The default PIN is
1234.
• The PIN is not required if the tablet is inside the dock and connected to the USB cable.
• The OneControl® Control Panel screen includes a settings button in the upper-right hand corner (Fig. 11A).
• Clicking the settings button will open the attached settings screen, where the PIN can be changed (Fig. 12).
Fig. 10
Rev: 12.11.2017
A
Fig. 12
Page 6
Fig. 11
A
OneControl Tablet Owner's Manual
