Summary of Contents for Atid AT911N
- Page 1 AT911N Guide for Customer...
- Page 2 ATID web site (www.atid1.com) or provided on appropriate media. If you visit our web site and would like to make comments or suggestions about this or other ATID publications, please let us know via the “Contact ATID ” page.
-
Page 3: Table Of Contents
Contents Page Contents Before using manual for AT911N Chapter 1. Caution when using AT911N 1. How to use battery correctly 2. Caution when using AT911N Chapter 2. Product composition 1. Product composition 2. Name of each part 3. Function of each part Chapter 3. - Page 4 Page Contents Chapter 4. Optional module 1. Using 1D or 2D barcode scanner 2. Barcode emulator setting 3. Barcode scanning 4. WIFI connection and termination 5. Bluetooth connection and termination 6. GPS demo program execution 7. Use of camera 8. NFC execution 9.
-
Page 5: Before Using Manual For At911N
Before using manual for AT911N User guide inclusive of text, images, logos, product names is either the property of, or used with permission by ATID CO.LTD. The information may not be distributed, modi ed, displayed, reproduced (in whole or in part) without the prior written permission of ATID CO.LTD. -
Page 6: Caution When Using At911N
Caution when using AT911N Please aware of the manual contents in advance before you handle and operate your AT911N and other ATID Products. How to use the battery correctly In case that you dropped the main body or battery in water, please do not put into the stove or heater for drying. Just keep it in natural drying or contact purchase •... -
Page 7: Product Composition
Product Composition AT911N is based upon Android 4.2. As the state of the art product, it is equipped with barcode scanner, RFID Tag reader, MODEM, Camera and so on and it can be applied to Industry, Enterprise, Logistics and so on, can be used extensively in many elds due to this kind of various functions Product composition Open the packing box and con rm the items as below. -
Page 8: Name Of Each Part
Name of each part Camera ash 1D/2D Scanner Sync cable connector/ (option) (option) DC Power Port Camera (Option) Speaker Charge LED Internal NFC WLAN LED/3G LED (option) Power key Earphone jack Side key Side key Touch Screen Keypad Reset button Scan key Microphone Gun handle... -
Page 9: Function Of Each Part
Function of each part NAME FUNCTION Please be careful not to get the damage or the foreign substances at the Window emitted the laser beam 1D/2D Scanner (option) Warning Do not look at the laser beam directly. UHF Connecting port It is connector to equip the UHF 900MHz tag reader module. -
Page 10: Attaching And Detaching The Battery
Basic Function PDA is composed of battery. The battery supplies the power to the system and RAM which can save and conserve the data. Battery: 3.7V 2,200mAh Lithium-Ion Attach the battery to the back battery compartment of the PDA. Push the batter lever inside so that the battery is rmly attached to the PDA. “Refer to 1.1 Battery attaching and detaching”... - Page 11 ▶ Battery attachment Put the top part of battery into the upward groove, and then press down the bottom of battery into the battery compartment, slide battery latch to the left (LOCK side) to attach battery rmly Above gap for attachment/ top of battery Chapter 3.
-
Page 12: Charging Battery
Charging battery You have to charge the battery via dedicated adapter, which provided from the factory. “Power LED” is while charging or is Green when charged completely. When fully charged, the LED light will be turned o . ▶ Connecting Adapter 1. - Page 13 ▶ Automatic Power OFF If the user doesn’t use the device for a set period of time, system enters into the low power mode (sleep mode) automatically. You can change the setting time in control panel and power management as shown below. Using proper time-out setting prevents the system is on a long time without the user and extends hours of battery use.
-
Page 14: Hard Reset
Hard reset If the system is not responding or application program doesn’t work, restart the system by using reset function. System reset is used to reboot and initialize the hardware completely. The installed programs copied les, and registry values will be preserved even after the system reset [Process of hard reset] Push and release the reset button. -
Page 15: Attaching Micro Sd Card
The image below shows the back side of the PDA when the battery is removed. There are 1 SIM card slot, 1 Micro SD memory card slot as shown below. Micro SD card slot SIM card slot Attaching Micro SD card Slide the cover of Micro SD Lift up the top of the slot Place the SD memory card... -
Page 16: Attaching Sim Card
When the SD memory is selected from the File Manager after installing Micro SD memory card, it is shown as below. Attaching SIM card Below is the screenshot after installing the SIM card. Place and insert the SIM card so that it ts the slot shape. Chapter 3. -
Page 17: Set Screen Brightness
Set screen brightness Brightness of the screen a ects the power consumption the most, so it is recommended to be set as required by the user. [Setting the screen brightness] 1. [Menu] -> [Settings] -> [Display] -> [Brightness] Brightness: Adjust the screen brightness. Wallpaper: Choose the wallpaper. -
Page 18: Using Keypad
Keypad is an input method editor that inputs numbers or alphabetic characters easily. Using keypad To change the current input language, follow the steps below. [Menu] -> [Settings] -> [Language & input] Keypad button execution Describe the Keypad Function. Keypad Function description Menu key Home button. -
Page 19: Chapter 4. Optional Module
This chapter describes various option modules for use with AT911N.Please refer to description of necessary option modules and use them. Option module for AT911N AT911N device provides the options as below according to the purpose of use. The Option Modules below are other speci cations outside AT911N, so when buying the device, you should con rm it to buy. -
Page 20: Using 1D Or 2D Barcode Scanner
The barcode scanner which can recognize 1D, 2D barcode can be installed on this device. Using 1D or 2D barcode scanner [Menu] -> [Application] -> ATID Barcode demo [ATID Barcode] Chapter 4. Optional module... -
Page 21: Barcode Emulator Setting
Barcode emulator setting Can input the read barcode values (Notes, Internet Explorer…) where the cursors are located. Sets the barcode value input method, scan button, scan sound etc. using Barcode Emulator program. When opening the Barcode Emulator, if other Barcode programs are being run, please close the program rst to run the Barcode Emulator. [Menu] ->... - Page 22 1) Emulator execution Cursor is on the screen and user can use this program when barcode soft keyboard is created. Read barcode value by using SCAN Key and Side key. Chapter 4. Optional module...
-
Page 23: Barcode Scanning
Barcode scanning 1. Remove protection lm on barcode scanner 2. Run the scanning application 3. Place beam in the middle of the barcode to read • Adjust distance ts to the barcode • Scanning stops automatically after 5 seconds from getting out of readable distance [Correct barcode reading] The small barcode should be closer to the device. -
Page 24: Wifi Connection And Termination
This device can communicates wireless data by 802.11a/b/g/n radio, and describes access pointer and the contents related to wireless communication. AT 911N device supports TCP/IP network protocol and directly use host computer and TCP/IP in TCP/IP network. When shipping goods, wireless LAN is always set to o WIFI connection and termination [Menu] ->... -
Page 25: Bluetooth Connection And Termination
The below contents are related to “AP6330 COMBO” Module which is used in AT911N. Bluetooth connection and termination [Menu] -> [Applications] -> [Settings] -> [Bluetooth] 1. Start Bluetooth function Chapter 4. Optional module... -
Page 26: Gps Demo Program Execution
The device can be installed with GPS system as option, and GPS Module will be installed on top of AT911N into Built-in shape. GPS demo program execution [Menu] -> [Applications] -> [GPS Test] GPS Test Start the program Con rm GPS reception Data: 1. -
Page 27: Use Of Camera
The products are installed with 5.0 mega pixel cameras and have the functions of screen brightness, resolution adjustment and screen captures Use of camera [Menu] -> [Applications] -> [Camera] Start Camera program Camera screen Chapter 4. Optional module... -
Page 28: Nfc Execution
AT911N can internally install the NFC module as an option and it can read the tag in range of 3~8.5cm in accordance with ISO standard. In case of Mifare tag, it can read in range of 1~3.5cm. NFC tag can be also read. -
Page 29: Uhf 900Mhz Rfid Program
UHF 900MHz RFID program [Menu] -> [Applications] -> [Settings] -> [ATUHF Demo] Start ATUHF Demo program ATUHF Demo screen Chapter 4. Optional module... -
Page 30: Chapter 5. Appendix
Appendix Product speci cation PHYSICAL CHARACTERISTICS Dimensions (L x W x H) 145 x 75 x 27 (31.5) mm Weight 270g (PDA only, without battery) Operating Temp. -10℃ ~ 60℃ Storage Temp. -30℃ ~ 70℃ Charging Temp. -0℃ ~ 45℃ Humidity 95% non-condensing Drop Spec. - Page 31 NETWORK CHARACTERISTICS WLAN IEEE 802.11 a/b/g/n Compliant Bluetooth Bluetooth Class II, 2.1 + EDR Radio MODEM 3G (GSM / GPRS / EDGE / WCDMA / HSPA+) Internal Antenna (GPS + Glonass) DATA CAPTURE & DATA PROCESSING DEVICE Barcode Engine 1D Laser or 2D Imager Barcode Scanner Camera CMOS 5 MEGA Pixel Auto Focus with Flash Sensor...
