EXPLODED VIEW PARTS LIST

[PART]
No. PART CODE PART NAME
1 02905789 PANEL SHEET
2 02905745 TOP CASE
3 02905767 REAR PANEL
4 02905790 RUBBER SW
4 02905790 RUBBER SW
4 02905790 RUBBER SW
5 72016578 MAIN BOARD ASSY
6 02905756 BOTTOM COVER
7 02905734 X R-KNOB
8 01346112 KNOB
9 01343101 D C-ESCT
10 12359137 RUBBER FOOT
10 12359137 RUBBER FOOT
10 12359137 RUBBER FOOT
10 12359137 RUBBER FOOT
[SCREW]
No. PART CODE PART NAME
A 40011490 SCREW M3X6
B 40011090 SCREW 3X6
C 40011301 SCREW M3X6
DESCRIPTION
MF GLD
MOLD KNOB BLK
D C-ESCT BX1H BLK
SJ-5012 BLK
SJ-5012 BLK
SJ-5012 BLK
SJ-5012 BLK
DESCRIPTION
PAN MACHINE W/SW BZC
BINDING TAPTITE B BZC
BINDING P-TITE FE BZC
MC-09
