May 2002
SPECIFICATIONS................................................................. 2
LOCATION OF CONTROLS............................................... 4
LOCATION OF CONTROLS PARTS LIST ....................... 5
EXPLODED VIEW ................................................................ 6
EXPLODED VIEW PARTS LIST ......................................... 7
PARTS LIST............................................................................ 8
CHECKING THE VERSION NUMBER ........................... 12
USERS DATA SAVE AND LOAD(BULK DUMP) ......... 12
RESTORING THE FACTORY SETTINGS ....................... 13
Copyright © 2002 ROLAND CORPORATION
All rights reserved. No part of this publication may be reproduced in any form without the written permission
of ROLAND CORPORATION.
SYSTEM SOFTWARE UPDATE PROCEDURE ..............13
TEST MODE.......................................................................... 14
BLOCK DIAGRAM ............................................................. 16
CIRCUIT BOARD(MAIN BOARD 1/2) ........................... 18
CIRCUIT BOARD(MAIN BOARD 2/2) ........................... 20
CIRCUIT DIAGRAM(MAIN BOARD 1/2)......................22
CIRCUIT DIAGRAM(MAIN BOARD 2/2)......................24
ERROR MESSAGES............................................................. 26
17058085EO
SERVICE NOTES
Issued by RJA
Printed in Japan ( 0800 ) (AS)
MC-09
Advertisement
Table of Contents
Related Manuals for Roland Phase Lab MC-09
Summary of Contents for Roland Phase Lab MC-09
-
Page 1: Table Of Contents
USERS DATA SAVE AND LOAD(BULK DUMP) ..12 RESTORING THE FACTORY SETTINGS ....... 13 Copyright © 2002 ROLAND CORPORATION All rights reserved. No part of this publication may be reproduced in any form without the written permission of ROLAND CORPORATION. -
Page 2: Specifications
May 2002 SPECIFICATIONS Input Impedance INPUT: 42 k ohm MC-09: Phrase Lab Nominal Output Level DSP Synthesizer OUTPUT: -10 dBu Number of Parts Output Impedance OUTPUT: 600 ohm Maximum Polyphony PHONES: 100 ohm LEAD, BASS: 1 Residual Noise Level RHYTHM: 3 Preset Tones (LINE IN: OFF, input terminated with 150 , IHF-A, typ.) •... - Page 3 MC-09...
-
Page 4: Location Of Controls
May 2002 LOCATION OF CONTROLS fig.top... -
Page 5: Location Of Controls Parts List
MC-09 LOCATION OF CONTROLS PARTS LIST PART CODE Part name Description Q’TY 02905734 X R-KNOB MF GLD 02455223 EVUF2KFK4B14 9M/M ROTARY POTENTIOMETER 02905734 X R-KNOB MF GLD 02905412 RK12L12C0A0E 12M/M ROTARY POTENTIOMETER 01346112 KNOB MOLD KNOB BLK 02239523 EWAN1AC15B14 30M/M SLIDE POTENTIOMETER 02126912 PTR LED SLR-342VR-TG7 01342534... -
Page 6: Exploded View
May 2002 EXPLODED VIEW fig.explo... -
Page 7: Exploded View Parts List
MC-09 EXPLODED VIEW PARTS LIST [PART] PART CODE PART NAME DESCRIPTION 02905789 PANEL SHEET 02905745 TOP CASE 02905767 REAR PANEL 02905790 RUBBER SW 02905790 RUBBER SW 02905790 RUBBER SW 72016578 MAIN BOARD ASSY 02905756 BOTTOM COVER 02905734 X R-KNOB MF GLD 01346112 KNOB MOLD KNOB BLK... -
Page 8: Parts List
May 2002 PARTS LIST fig.part1e CONSIDERATION ON PARTS ORDRING SAFETY PRECAUTIONS: When ordering any parts listed in the parts list, please specify the following items in the order sheet. The parts marked have PART NUMBER DESCRIPTION MODEL NUMBER safety-related characteristics. Use 22575241 Sharp Key C-20/50... - Page 9 MC-09 TRANSISTOR 15319102 2SC2882-Y(TE12L.C) TRANSISTOR Q11 on Main Board 15319116 2SC4154-T11-F TRANSISTOR Q34,Q6,Q5 on Main Board 02670989 DTB113ZK-146T TRANSISTOR Q17,Q16,Q18,Q19,Q20,Q21,Q22,Q15 on Main Board 02905856 UNR5211-(TX) TRANSISTOR Q29,Q30,Q32,Q35,Q33,Q1,Q28,Q27,Q26,Q2 5,Q24,Q23,Q31 on Main Board 15329536 RN1442-A(TE85L) TRANSISTOR Q8,Q7 on Main Board DIODE 15339412 U1BC44(TE12L) DIODE D1 on Main Board...
- Page 10 May 2002 CAPACITOR 01674701 ECJ1VF1E104Z 0.1UF/16VK CERAMIC CAPACITOR(CHIP) C178,C138,C139,C141,C144,C145,C151,C19 0,C158,C41,C179,C180,C186,C132,C154,C10 ,C81,C107,C9,C11,C15,C18,C27,C102,C37,C 39,C75,C82,C99,C32,C8,C106 on Main Board 01674712 ECJ1VF1A105Z CERAMIC CAPACITOR C5,C4,C3,C2,C24,C22,C6,C167,C25,C12,C13 ,C20,C21,C26,C40,C131,C169,C170,C130 on Main Board 01346889 ECHU1H151JX5 POLYEST. CAPACITOR C103,C86 on Main Board 01784145 ECHU1H152JX5 POLYEST. CAPACITOR C92,C108 on Main Board 13639546M0 ECEA1CKA100B 10UF/16V CHEMICAL CAPACITOR...
- Page 11 MC-09...
-
Page 12: Checking The Version Number
May 2002 CHECKING THE VERSION Saving all settings of the MC-09 to a memory card NUMBER The following settings stored in the audio looper will be Turn off the main power. saved together on the memory card. · All loops and user patterns While holding down [SHIFT] and STEP [4], turn on the main power. -
Page 13: Restoring The Factory Settings
MC-09 Saving MC-09 data on an Press the [INC] or [DEC] button until the display indicates “Fct”. external MIDI sequencer Press the [ENTER] button. The display will show “Sur”. To execute the factory reset, press the [WRITE] button. While the factory Use a MIDI cable to connect the MC-09’s MIDI OUT tothe MIDI IN of settings are being restored, “BSY”... -
Page 14: Test Mode
May 2002 Er2:Message Error Connect MIDI OUT of the sequencer and MIDI IN of the MC-09 with the MIDI cable. Displayed when a problem exists in received MIDI message. (SumCheck, etc.) Beyond these steps, proceed according to the updating mode. Er3:FIFO Over Flow Procedure for ALL Updating Displayed when the MC-09 cannot process a large amount of MIDI messages... - Page 15 MC-09 7: Initialize Error number and error content Reset the user memory built into the main unit to factory shipment setting. Checksum error in Flash ROM. After “ini” appears for a few seconds on the display, “Sur” appears and blinks. Access error in Work RAM.
-
Page 16: Block Diagram
May 2002 MC-09 BLOCK DIAGRAM fig.block Smart Media Switch Matrix Rotary Volume DRAM & (1024k x 16bit) OSCILLATOR LED Matrix Slide Fader 67.7376MHz GM71C18163CJ-6 JK2B INPUT IC11 ESP4 LINE signal processor bus transceiver X'TAL 24bit IC33 2ch codec HD74LV245ATELL TC223C080AF 20.000MHz OUTPUT JK2A... -
Page 17: Circuit Board(Main Board 1/2)
May 2002 MC-09 CIRCUIT BOARD(MAIN BOARD 1/2) fig.block View from component side... -
Page 18: Circuit Board(Main Board 2/2)
May 2002 MC-09 CIRCUIT BOARD(MAIN BOARD 2/2) fig.block View from foil side... -
Page 19: Circuit Diagram(Main Board 1/2)
May 2002 MC-09 CIRCUIT DIAGRAM(MAIN BOARD 1/2) fig.main1 MIDI C167 RA10 IN/OUT 3. 3 RCE9A@JA C169 C170 P_SCAN0 XCS4 YKF51-5048 P_SCAN1 P_SCAN2 mode4 SM SW P_SCAN0 SM WP PA4/A23/TIOCA1* C180 3. 3 P_SCAN1 PA5/A22/TIOCB1* CA13 TRR5 P_SCAN2 R173 PA6/A21/TIOCA2* I/O16 CA12 TRR4 PA7/A20/TIOCB2*... -
Page 20: Circuit Diagram(Main Board 2/2)
May 2002 MC-09 CIRCUIT DIAGRAM(MAIN BOARD 2/2) fig.main2 VR6A C154 EVUF2K@ IC22 CBN-C-1 10KB DA11 DA12 DA13 TC74VHC138FT PTN1A MA142WK-(TX) MA142WK-(TX) MA142WK-(TX) PTN1B CBN-E-2 CBN-C-1 CBN-C-1 CBN-E-2 CBN-E-2 CBN-E-2 SCAN2 IC23 PTN9A PTN16A PTN23A PTN30A PTN37A PTN45A R121 SCAN1 HD74LV4051ATELL PTN9B PTN16B PTN23B... -
Page 21: Error Messages
May 2002 ERROR MESSAGES Message Cause A large number of MIDI messages were received all atonce, and processing could not be completed. There is a problem with the MIDI cable connection. The checksum value of a received exclusive message is incorrect. The format of a received exclusive message is incorrect.
