General Information and Setup
3. See Figure 2-3. Install gun hook (A) on
right (back) side of handle. Secure with
tree clip (B).
B
A
Figure 2-3. Install Gun Hook
4. See Figure 2-4. Insert and snap nozzles
into spaces provided in handle.
Figure 2-4. Insert Nozzles
5. See Figure 2-5 to install battery.
Figure 2-5. Install Battery

Add Engine Oil

Unit is shipped with no oil in the engine.
Add engine oil before starting. See
Recommendations.
1. Place power washer on a level surface.
2. Verify oil fill area is clean.
3. Remove oil fill cap and wipe dipstick clean.
4
4. Add recommended engine oil.
006459
NOTE: Some units have more than one oil fill
location. It is only necessary to use one oil fill
point.
5. Thread dipstick into oil filler neck. Oil level
is checked with dipstick fully inserted.
6. See
oil level is within safe operating range.
001621 001621
7. Install oil fill cap/dipstick and hand-tighten.

Fuel

Fuel requirements are as follows:
• Clean, fresh, unleaded gasoline.
• Minimum rating of 87 octane/87 AKI (91
RON).
006214
• Up to 10% ethanol (gasohol) is acceptable.
• DO NOT use E85.
• DO NOT use a gas oil mix.
• DO NOT modify engine to run on alternate
fuels.
• Add a fuel stabilizer prior to storing.
Engine Oil
1. Verify unit is OFF and cooled for a
minimum of two minutes prior to fueling.
2. Place unit on level ground in a well
ventilated area.
3. See
cap and remove cap slowly.
Figure 2-6. Remove Dipstick
Figure 2-7. Remove dipstick and verify
Figure 2-7. Safe Operating Range
DANGER
Explosion and Fire. Fuel and vapors are
extremely flammable and explosive. Add fuel
in a well ventilated area. Keep fire and spark
away. Failure to do so will result in death
or serious injury.
Figure 2-8. Clean area around fuel
Owner's Manual for Power Washer
