Vehicle Hardware Installation
Vehicle Mount Device (VMD)
The Qualifier X-Ray system requires installation of the Qualifier Vehicle Mounted
Device (VMD) and a Dual Band Antenna.
Installation Precautions
Please observe the following during installation.
• Wear eye protection when installing the system.
• The vehicle must have a 12-volt negative ground electrical system.
• Insure that no mounting hardware makes contact with any wiring, fuel/brake
lines or other components.
• Insure the mounting position of the VMD is clear of obstacles.
• Protect the system from metal debris.
• Do not route cabling or wiring through sharp edged openings or potential
pinch points to prevent future failures and safety hazards.
• Maintain at least one inch of clearance around the VMD for proper cooling.
