TECNO Star Dual Power
INDEX
1
HOW TO USE THE MANUAL
2
DESCRIPTION OF THE CENTRAL VACUUM CLEANER
2.1 Distinctive product features
3
TECHNICAL FEATURES
4
CONSTRUCTION FEATURES
5
SAFETY FEATURES
5.1 IP protection degree
5.2 Electric insulation degree
5.3 Declaration of absence of dangerous substances
5.4 Fixed closure safety guards
5.5 Movable closure safety guards
5.6 Identifi cation plate
6
AUTHORIZED USE OF THE VACUUM CLEANER
7
UNAUTHORIZED USE OF THE VACUUM CLEANER
8
EQUIPMENT AND ACCESSORIES
9
INSTALLATION
9.1 Recommended Installation
9.2 Transport and unpacking
9.3 Positioning of the vacuum cleaner
9.4 Transforming DX version (outlet pipes fi tted on the right) into SX version
(outlet pipes fi tted on the left)
9.5 Fixing the system to the wall
9.5.1 Connection to the piping network
10 STARTING THE VACUUM CLEANER
10.1 Control board
10.2 Electric connection
10.2.1 Auxiliary connection signal
11 USE OF THE VACUUM CLEANER
11.1 Switching on the vacuum cleaner
11.2 Using the vacuum cleaner
11.3 Programming and use of the computer for controlling the central unit
05/07/11 Rev:1.0.0
INSTRUCTION MANUAL
• Type: domestic vacuum cleaner
• Model: Tecno Star Dual Power
• Revision 1.0.0
4
4
5
6
8
9
10
10
10
10
11
11
12
12
13
14
14
15
17
17
19
19
19
19
20
21
22
22
22
23
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SISTEM AIR Tecno Star Dual Power
Summary of Contents for SISTEM AIR Tecno Star Dual Power
- Page 1 INSTRUCTION MANUAL • Type: domestic vacuum cleaner Line • Model: Tecno Star Dual Power TECNO Star Dual Power • Revision 1.0.0 INDEX HOW TO USE THE MANUAL DESCRIPTION OF THE CENTRAL VACUUM CLEANER 2.1 Distinctive product features TECHNICAL FEATURES CONSTRUCTION FEATURES SAFETY FEATURES 5.1 IP protection degree...
-
Page 2: Table Of Contents
INSTRUCTION MANUAL Line • Type: domestic vacuum cleaner • Model: Tecno Star Dual Power TECNO Star Dual Power • Revision 1.0.0 INDEX 11.3.1 Programming the start up 11.3.2 Main Menu 11.3.3 Turbo function Menu setting 11.3.4 Menu for date and time 11.3.5 Information and alarms Menu / Alarms coding... - Page 3 TECNOPLUS S.r.l., owner of the SISTEM AIR Trademark would fi rst of all like to thank you for having chosen to buy the new vacuum cleaner of the TECNO Star Dual Power. We are sure that the characte- ristics described in this manual will satisfy your needs.
-
Page 4: How To Use The Manual
PVC trace pipes, housed in walls or in false ceilings running through the various rooms; at the end of the pipes are positioned the suction sockets. The SISTEM AIR vacuum cleaner is usually placed in a utility room, garage or other storeroom and connected to the suction pipes network. -
Page 5: Distinctive Product Features
- Possibility of contemporary use by two operators either with two separate micro lines or with one single micro line. - The Tecno Star Dual Power vacuum cleaner by Sistem Air adopts an innovative control and mainte- nance system based on an electronic control board with microchip connected to pressure sensors and programmed to easily and immediately interact with the user. -
Page 6: Technical Features
TECNO Star Dual Power instruction manual 3- TECHNICAL FEATURES H (recommended) Tecno Star Dual Power Model Pressure transducer Electronic board On-board computer Cover Bin release handle Motors group Air exhaust Main switch Thermal Sensor Filter protection Micro lines and contact... - Page 7 TECNO Star Dual Power Line TECNO Star Dual Power Model Item 3116.2TS Maintenance Computer Dust inlet Ø mm Air exhaust Ø mm Protection degree Power supply V ac 220/240 Frequency 50/60 Motor power 1,3x2 Absorption Socket power supply V dc...
-
Page 8: Construction Features
(*) for two separate micro lines. (**) for one single micro line. The vacuum systems of the Tecno Star Dual Power Line have been designed and manufactured in com- pliance with all the criteria imposed by the current regulations and European directives while carefully paying attention to crucial elements like performance, power and operating capacity. -
Page 9: Safety Features
Italian Legislation by Decree Law 17/10), in the Low Voltage Directive 2006/95/CE, and in the Elec- tromagnetic Compatibility Directive 2004/108/CE, the Tecno Star Dual Power vacuum cleaner complies with the standard established for electrical appliances for household and similar purposes EN 60335-1 (2008) and with the Regulation C EN 60335-2-2 (2011), specially conceived for vacuum cleaners for household and similar purposes with rated voltage not exceeding 250 V. -
Page 10: Ip Protection Degree
TECNO Star Dual Power instruction manual WARNING: TECNOPLUS S.R.L. declines any form of responsibility or guarantee if the purchaser, or anyone in his stead, makes even the slightest modifi cation or adjustment to the purchased product. The unit has been designed to satisfy at best the present needs of the domestic central vacuum cleners market, both in terms of quality and operating capacity. -
Page 11: Identifi Cation Plate
5.5 Movable closure guards safety There are no movable closure guards assembled on the appliance. Every guard assembled is conside- red a fi xed guard and is fastened with special screws. TECNOPLUS s.r.l. reminds you that it is absolu- tely forbidden to replace the screws used to design and manufacture the appliances with screws that feature different characteristics. -
Page 12: Authorized Use Of The Vacuum Cleaner
PVC wall traced piping network and to a standard home electric wiring. The Tecno Star Dual Power vacuum cleaner is the ideal choice to work out and meet the most demanding needs; it is recommended for residential dwelling units with the characteristics detailed... -
Page 13: Equipment And Accessories
8 - EQUIPMENT AND ACCESSORIES The packaging of the vacuum cleaner also includes a series of accessories as detailed below: N°1 TECNO Star Dual Power vacuum cleaner N°2 rubber sleeves for the connection to the suction pipe network N°4 metal clamps to fi x the sleeves N°1 adhesive label detailing the system model... -
Page 14: Installation
BY QUALIFIED STAFF 9.1 RECOMMENDED INSTALLATION The Tecno Star Dual Power vacuum cleaner must be connected to an exhaust air pipe, crucial for discharging outside the micropowders that the fi lter cartridge cannot retain. The vacuum cleaner must be installed in service rooms (e.g. garage, store room etc) protected from bad weather, dampness and excessive temperature variations. -
Page 15: Transport And Unpacking
9.2 Transport and unpacking Use a transpallet or a fork-lift truck for transport and handling; always maintain the system inside its own packaging until it reaches the place of installation. Remove the protective cardboard box. 05/07/11 Rev:1.0.0... - Page 16 TECNO Star Dual Power instruction manual Remove the brackets that fi x the unit to the pallet. Remove the unit from the pallet. MAX 15° If no suitable fork-lifts are available, remove manually the unit from the pallet (see picture).
-
Page 17: Positioning Of The Vacuum Cleaner
9.3 Positioning of the vacuum cleaner For a correct use and to facilitate maintenance it is advisable to keep a minimum distance of 60 cm on three sides around the appliance (excluding the side on which it is fi xed to the wall). 9.4 Transforming DX version (outlet pipes fi... - Page 18 TECNO Star Dual Power instruction manual Disassemble the intake of the “C” exhaust pipe and the “D” closing sheet by removing the screws. After exchanging their housings, reassemble the intake of the “C” exhaust pipe and the “D” closing sheet by fastening the screws.
-
Page 19: Starting The Vacuum Cleaner
10 STARTING THE VACUUM CLEANER 10.1 Control board The TECNO Star Dual Power vacuum cleaner features a control board from which the appliance fun- ctions can be programmed by means of a simple operator’s interface display with 6 function keys. -
Page 20: Electric Connection
TECNO Star Dual Power instruction manual 10.2 Electric connection WARNING: the electric connection must be carried out ONLY by qualifi ed personnel Before connecting the system to the electrical power supply check that the supply voltage corresponds to that required by the vacuum cleaner (see the identifi cation plate). -
Page 21: Auxiliary Connection Signal
10.2.1 Auxiliary connection signal Tecno Star Dual Power Unit model Produced untill 31st December 2011 Tecno Star Dual Power Unit model Produced from 1st January 2012 05/07/11 Rev:1.0.0... -
Page 22: Use Of The Vacuum Cleaner
11 USE OF THE VACUUM CLEANER Once the TECNO Star Dual Power vacuum cleaner has been connected to the power supply, it can be started every time a fl exible hose is plugged into any of the suction sockets installed in the different rooms. -
Page 23: Programming And Use Of The Computer For Controlling The Central Unit
11.3 Programming and use of the computer for controlling the central unit The TECNO Star Dual Power vacuum cleaner is provided with a practical display with membrane keybo- ard as shown below. The use of this display and of the membrane keyboard allows the operator to send the inputs to the computer of the central unit in order to select the various functions, programme the routine maintenance and upload specifi... -
Page 24: Programming The Start Up
TECNO Star Dual Power instruction manual 11.3.1 Programming the start up Here are the main Menu screens for the start up FIRST INSTALLATION Screen display which appears when Welcome and thank you fi rst switching the system. for your purchase. - Page 25 INSTALLER PHONE NO. Insert the INSTALLER phone no. --------------- +/0123456789 Press ESC SERVICE NAME Insert the SERVICE name Press the Left and Right arrows to scroll the numbers. Press ENTER to select the --------------- ABCDEFGHILMNOPQR..number. Press ESC to move onto the next screen display.
-
Page 26: Main Menu
TECNO Star Dual Power instruction manual Main screen alarms Below are the displays of the alarms Menu which can appear on the screen display. Press ESC to cancel the alarm and to return to the main screen display. 26-07-11 26-07-11... -
Page 27: Turbo Function Menu
11.3.3 Turbo function Menu TURBO FUNCTION Function Active <ON> Select ON to start motor no.2 so to incre- If active, vacuum power is at maximum ase the suction power. Use the Right (>) and Left (<) arrows to modify the parameter; Press Enter to save the parameter se- lected;... -
Page 28: Information And Alarms Menu / Alarms Coding
TECNO Star Dual Power instruction manual 11.3.5 Information and Alarms Menu - Alarms Coding INFO/ALARMS Last alarms Press ENTER to access the selected Alarm stats Submenu; Maitenance list Use the up and down arrows to scroll System Info (1.50) Service Info through the Menu;... - Page 29 Press ESC to exit the Menu. More precisely: Service: name and phone number reference of the authorized Sistem Air’s Technical Service Install: name and phone number reference of the installation technician of the suction system Here below are detailed the Coding of the Alarms:...
-
Page 30: Menu For Setting Machine Stop
TECNO Star Dual Power instruction manual 11.3.6 Menu for setting machine stop This Menu enables to set the machine stop in case of routine maintenance alarm. SET ALARMS POLICIES Press ENTER to enter the Submenu se- FILTER alarm lected; Maintenance alarm... - Page 31 DUST ALARM Set the Dust Alarm when the dust bag selection is switched off (OFF) see Instal- lation Parameters Menu (see paragraph Dust timer (h) <06> 11.3.7). Stop engine <ON> Dust timer (h): time in hours to switch on the dust alarm and related motor block. Motor block: Select ON to stop the unit with Dust Alarm switched on;...
-
Page 32: Installation Parameters Menu
TECNO Star Dual Power instruction manual 11.3.7 Installation parameters Menu This Menu allows parameters set by the system start-up procedure to be modifi ed (see paragraph 11.3.1). INSTALLATION PARAM. Press ENTER to access the Submenu SERVICE NAME selected; Service phone no. - Page 33 SERVICE PHONE NO. Insert the service phone no. +3933312345678 --------------- +/0123456789 Press Enter to save the number selected; Press ESC Press ESC to save data. SERVICE PHONE NO. Updating fl ash params INSTALLER NAME Insert the installer name Paolo ROSSI --------------- ABCDEFGHILMNOPQR Press Enter to save the number selected;...
-
Page 34: Data Transmission Menu
TECNO Star Dual Power instruction manual AUTOCLEANER SYSTEM Function active <OFF> Switching on the Autocleaner System control (optional accessory): Cicles number < 2> ACTIVE FUNCTION: Working <12h> OFF: the Autocleaner system is not con- Autoclean.Timer <015> nected to the vacuum cleaner. -
Page 35: Parameters Reset Menu
11.3.9 Parameters reset Menu This Menu allows the user to reset the default parameters set by the manufacturer. RESET PARAMETERS Press ENTER to reset all params to factory default Press ENTER to accept the cancellation of all the parameters set by the user. Press ESC to exit without saving. -
Page 36: Maintenance
Maintenance should be carried out according to the effective running time of the system so to ensure effi cient performance and avoid serious mechanical damages. The TECNO Star Dual Power vacuum cleaners are controlled by a computer which also checks the routine maintenance cycles: •... -
Page 37: Cleaning The Vacuum Cleaner Body (Cylinder)
Level 2/Maintenance 2 Alarm: • check of the wear of the suction motor carbons • replacement of the suction motor carbons • everything indicated in level 1 Also in this case the operator can decide whether to switch off the system immediately and satisfy main- tenance requirements or fi... - Page 38 TECNO Star Dual Power instruction manual Tie up the dust bag and remove it from the container. Introduce a new dust bag and the bag-stretcher. Assemble the conveyor cone. Put the dust container back in its position. Use both hands to lower the clip handle.
-
Page 39: Replacing The Fi Lter Cartridge
12.5 Replacing the fi lter cartridge Lift the release handle using both hands. Remove the dust container. Unscrew the blocking knob. Replace the fi lter cartridge. Screw the blocking knob. 05/07/11 Rev:1.0.0... - Page 40 TECNO Star Dual Power instruction manual Reassemble the dust container in its position. Use both hands to lower the clip handle. 05/07/11 Rev:1.0.0...
-
Page 41: Regeneration Of The Fi Lter Cartridge
12.6 Regeneration of the fi lter cartridge WARNING DO NOT USE THE VACUUM CLEANER WITHOUT THE FILTER CARTRIDGE. ENSURE YOU HAVE REPLACED A SPARE FILTER CARTRIDGE BEFORE CARRYING OUT THIS OPERATION. The fi lter cartridge can be rege- nerated several times by vacuum cleaning the dirt on the fi... -
Page 42: Recommended Spare Parts
TECNO Star Dual Power instruction manual 13.2 Recommended spare parts It is advisable to order in time those spare parts which need to be replaced most often. In order to guarantee the optimal and long working life of the vacuum cleaner it is recommended to use only original SISTEM-AIR spare parts, as detailed below. -
Page 43: Troubleshooting
17 - TROUBLESHOOTING PROBLEM CAUSE SOLUTION There is no suction from any of the Alarm signalled on the RESET the alarm and carry out recommended maintenance computer suction sockets The power cable is Connect the power cable unplugged The micro line cable is not Connect the activation cable connected (sensor) - Page 44 TECNO Star Dual Power instruction manual 05/07/11 Rev:1.0.0...
-
Page 45: Appendix A - Connection To The Autocleaner Appliance
APPENDIX A - CONNECTION TO THE AUTOCLEANER APPLIANCE (OPTIONAL) See Autocleaner Manual A.1 Positioning of the Autocleaner Disassemble the 4 screws on the rear side of the cylinder and use them to fi x the anchoring bracket provided with the Autocleaner system. -
Page 46: A.2 Pneumatic Connection
TECNO Star Dual Power instruction manual A.2 Pneumatic connection Approach the pipe connection of the vacuum system to the inlet on the rear side of the appliance. N.B.: check that the sealing gasket provided is correctly positioned between the suction socket and the suction plug. - Page 47 05/07/11 Rev:1.0.0...
- Page 48 TECNO Star Dual Power instruction manual 05/07/11 Rev:1.0.0...
