17.6.2 REMOTE COMMANDS

As mentioned earlier, the macro shortcut entry "net1" addresses a controllable network source connected
to the first network input on a NewTek live production system. A second NDI connected to input 7 would
be addressed using the shortcut entry "net7".
At present, 3Play 3P1 supports the commands discussed next, included in the NewTek product macro
system.
CLIP_STORE
Delay (ms) Shortcut
(time) net#
This command stores a custom local reference ID for the current clip (the one currently visible at on the
network input). The value ID can be a string. ID is global and shared across your system (it is not stored
per system output, if you have multiple).
For example:
Delay (ms)
(time)
The entry above will 'remember' the current clip with the name "AAA1". (The default for ID is an empty
string, which is a valid storage target.)
CLIP_RESTORE
Delay (ms) Shortcut
(time) net#
This command cues up content previously stored with a specified ID value on the upstream source channel
assigned to the network input designated.
For example:
Delay (ms)
(time)
Page | 160
Value Key 1
clip_store index
Shortcut Value
net# clip_store
Value Key 1
clip_restore index
Shortcut Value
net# clip_restore index
Value 1
ID
Key 1 Value 1
index AAA1
Value 1
ID
Key 1 Value 1
AAA1
