OPERATING INSTRUCTIONS
Reworking
1. Plug the power cord.
2. Turn on the upper right hand switch. Digital readout
of current temperature will appear.
temperature
3. Adjust
of component being reworked.
NOTE: If reworking plastic or larger components,
higher temperature and airflow is needed.
4. When proper adjustment of airflow and temperature
has been set, wait a few seconds for the temperature and
airflow to stabilize.
5. Maintain a 15mm distance between the component
to be soldered and the hot air gun.
6. Move the air gun in a rotating manner focusing
around the component.
7. Wait until the component bonds.
CAUTION! Do not let the air stand in
one position for more than one second.
WARNING: When turned ON, temperature of the hot air gun ranges
from 100°C - 480°C. Injury might occur if not handled properly.
airflow
and according to the type
6
TABLE OF CONTENTS
Package Inclusion ....................................... 3
Parts List ..................................................... 3
Specifications ............................................... 4
Function .....................................................
Care and Safety Precaution
Operating Instruction
Soldering ........................................
Desoldering .....................................
Air Nozzles ................................................. 8
PACKAGE INCLUSION
857A++ Main Station with hot air gun
Hot air gun holder
Air nozzles
G001 IC popper
Product manual
Power cord
PARTS LIST
Part No.
20094 Heating Element
30106S Hot Air Gun Plastic Handle
S002 Hot Air Gun Complete Handle
20962 Hot Air Gun Metal Pipe
10070 Turbine Motor
NOTE: Use only genuine replacement parts.
4
......................... 5
6
7
Description
