  • Page 1 UPServer2.0 ON-LINE DOUBLE CONVERSION UPServer2.0 On Line Double Conversion Uninterruptible Power Supplies...

  • Page 2: Table Of Contents

    UPServer2.0 ON-LINE DOUBLE CONVERSION Table of Contents INTRODUCTION ........................... 2 SAFETY WARNINGS ........................3 INSTALLATION..........................4 Inspecting the Equipment ............................4 Unpacking the Cabinet ............................4 Checking the accessories ...........................4 Rackmount Installation ............................5 Rackmount converted to Tower Installation ...................... 11 OPERATION ..........................15 Control Cover Functions...........................
  • Page 3 UPServer2.0 ON-LINE DOUBLE CONVERSION Class B EMC Statements (High Voltage Models up to 3000 VA) FCC Part 15 NOTE This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 4: Introduction

    UPServer2.0 ON-LINE DOUBLE CONVERSION Introduction This UPS protects your sensitive electronic equipment from most common power problems, including power failures, power sags, power surges, brownouts, line noise, high voltage spikes, frequency variations, switching transients, and harmonic distortion. Power outages might occur unexpectedly and power quality can be erratic. These power problems have potential to corrupt critical data, destroy unsaved work sessions, and damage hardware —...

  • Page 5: Safety Warnings

    UPServer2.0 ON-LINE DOUBLE CONVERSION SAFETY WARNINGS IMPORTANT SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS This manual contains important instructions that you should follow during installation and maintenance of the UPS and batteries. Please read all instructions before operating the equipment and save this manual for future reference.

  • Page 6: Installation

    UPServer2.0 ON-LINE DOUBLE CONVERSION INSTALLATION This section explains: Equipment inspection  Unpacking the cabinet  Checking the accessory kit  Cabinet installation  Wiring installation  Initial startup  Inspecting the Equipment If any equipment received has been damaged during shipment, keep the shipping cartons and packing materials for the carrier or place of purchase and file a claim for shipping damage.

  • Page 7: Rackmount Installation

    UPServer2.0 ON-LINE DOUBLE CONVERSION Power cord (Input and output)  RS232 cable  If you ordered an optional Extended Battery Module (EBP), verify that the following additional item is included with the EBP: ● EBP user's guide NOTE Discard the EBP user's guide if you are installing the EBP with a new UPS at the same time.
  • Page 8 UPServer2.0 ON-LINE DOUBLE CONVERSION Assemble the left and right rails to the rear rails as shown in Figure4.Do not tighten the screws. Adjust each rail size for the depth of your rack. Figure3 Securing the Rails Select the proper size in the rack for positioning the UPS (see Figure 5). The rail occupies four positions on the front and rear of the rack.
  • Page 9 UPServer2.0 ON-LINE DOUBLE CONVERSION Place the UPS on a flat, stable surface with the front of the cabinet facing to you. Align the mounting brackets with the screw holes on each side of the UPS and fix with the supplied M4×8 flat-head screws(see Figure 6) Figure5 Installing the Mounting Brackets If installing optional cabinets, repeat Step 8 and 9 for each cabinet.
  • Page 10 UPServer2.0 ON-LINE DOUBLE CONVERSION Rackmount Wiring Installation his section explains: Installing the UPS, including connecting the UPS internal batteries  Connecting any Optional EBP(S)  Installing the UPS Do not make unauthorized changes to the ups; otherwise, damage may NOTE occur to your equipment and void your warranty.
  • Page 11 UPServer2.0 ON-LINE DOUBLE CONVERSION CAUTION A small amount of arcing may occur when connecting the internal batteries. This is normal and will not harm personnel. Connect the cables quickly and firmly Figure8 Connecting the UPS Internal Batteries 3. If you are installing EBPS, see the following section, “Connecting the EBP(s),” before continuing with the UPS installation.
  • Page 12 UPServer2.0 ON-LINE DOUBLE CONVERSION connect the ground cable (not supplied) to the ground bonding screw. See “Rear Covers” for the location of the ground bonding screw for each model. 7. If an emergency power-off (disconnect) switch is required by local codes, see “Remote Emergency Power-off”...

  • Page 13: Rackmount Converted To Tower Installation

    UPServer2.0 ON-LINE DOUBLE CONVERSION CAUTION A small amount of arcing may occur when connecting an EBP to the UPS. This is normal and will not harm personnel. Insert the EBP cable into the UPS battery connector quickly and firmly. 5. Plug the EBP cable(s) into the battery connector(s) as shown in Figure 13. Up to four EBPS may be connected to the UPS.
  • Page 14 UPServer2.0 ON-LINE DOUBLE CONVERSION Figure 13 plastic base installation ③If an EBP is needed to be placed in the middle, the assembly of plastic base is similar , The difference is that two 1U plastic base extended boards are added in the middle.(as the following shows) （A）...
  • Page 15 UPServer2.0 ON-LINE DOUBLE CONVERSION Figure15 The installation for UPS and battery box 1.Install the base, then place the RT UPS on the base one by one as Fig.16 shows. 2. The cover installation and cable connection of the UPS and EBPS are the same as RT. (To install the optional EBP(s) for a UPS)

  • Page 16: Ups Initial Startup

    UPServer2.0 ON-LINE DOUBLE CONVERSION UPS initial startup To start up the UPS: NOTE Verify that the total equipment ratings do not exceed the UPS capacity to prevent Overload alarm １. If optional EBPs are installed, verify that the EBPs are connected to the UPS. ２.

  • Page 17: Operation

    UPServer2.0 ON-LINE DOUBLE CONVERSION OPERATION This chapter contains information on how to use the UPS, including front cover operation, operating modes, UPS startup and shutdown, transferring the UPS between modes, and configuring bypass settings, load segments, and battery settings. Control Cover Functions The UPS has a three-button segmental LCD with backlight.
  • Page 18 UPServer2.0 ON-LINE DOUBLE CONVERSION Table 2 . Button function Button Function description Start up combination TOWER Press and hold this key for more than half a （ ） second to turn on the UPS. Press and hold this key for more than half a second to turn on the UPS or to turn off the UPS.
  • Page 19 UPServer2.0 ON-LINE DOUBLE CONVERSION seconds Battery Voltage Once per ● ★ ★ abnormal second warning Bypass mode Main AC Once Normal Eliminate after ● ★ every two voltage in starting the UPS minutes bypass mode Main AC high Once voltage ★...
  • Page 20 UPServer2.0 ON-LINE DOUBLE CONVERSION ★ _indicator flashes ▲ _the status of indicator depends on other conditions Display Functions As the default or after 5 minutes of inactivity, the LCD displays the output parameters. The backlit LCD automatically dims after 5 minutes of inactivity. Press any button to restore the screen.

  • Page 21: Parameters Inquiring

    UPServer2.0 ON-LINE DOUBLE CONVERSION Display the status of the charger. When charger works normally, the corresponding icon will vary Charger-status dynamically and orderly. graphics when charger works abnormally, the section icon will keep flashing When UPS is in battery mode, the number icons charger-state...

  • Page 22: User Settings

    UPServer2.0 ON-LINE DOUBLE CONVERSION Display the temperature of the inverter in the UPS. As following graphics shown: Temperature temperature of the inverter is 37℃. Display the voltage and frequency of the input. As the following Input graphics shown: the input voltage is 210v, input frequency is 49.8Hz.
  • Page 23 UPServer2.0 ON-LINE DOUBLE CONVERSION interface, the letters “ECO” will flash. ② Enter setting interface. Press and hold the function setting key for more than half a second(less than 2 seconds), the letters “ECO” ECO function will stop flash. The “ON”(or setting(1) OFF) below the ECO will flash.
  • Page 24 UPServer2.0 ON-LINE DOUBLE CONVERSION than half a second(less than 2 seconds) at this time, the letters “bPS” will stop flashing. The “ON”(or OFF) below the bPS will flash. Press and hold the scroll key for more than half a second (less than 2 seconds) to determine whether the BPS function is enabled or disabled.
  • Page 25 UPServer2.0 ON-LINE DOUBLE CONVERSION then come setting interface of output voltage OPU, at this time, the letters “OPU” will light for a long time. The numerical value below the OPU will flash. Press and hold the scroll for more than half a second (less than 2 seconds), select the numerical value in accordance with “OPU”...
  • Page 26 UPServer2.0 ON-LINE DOUBLE CONVERSION ③．Confirm the battery strings setting interface。 After selecting numerical value, press and hold the function setting key for more than half a second (less than 2 seconds). Now, the battery strings setting is confirmed and the battery type value below will flash。...
  • Page 27 UPServer2.0 ON-LINE DOUBLE CONVERSION ① Enter the setting interface. Press and hold the function setting key for more than 2 seconds, then come to setting interface, Press and hold the scroll key for more than half a second(less than 2 seconds), select function setting,...
  • Page 28 UPServer2.0 ON-LINE DOUBLE CONVERSION function setting key more than half a second(less than 2 seconds) , the letters “OPF” will stop flashing. letters below “OPF” will flash. Press and hold the scroll key more than half a second (less than 2 seconds), select output frequency, “50Hz”(output...
  • Page 29 UPServer2.0 ON-LINE DOUBLE CONVERSION second (less than 2 seconds), select “ALL”(setting parameter reset factory setting) or “OFF”(not do reset and do nothing). ③ Confirm the setting. After selecting the option, press and hold function setting for more than half a second (less than 2 seconds).

  • Page 30: Ups Turn On And Turn Off

    UPServer2.0 ON-LINE DOUBLE CONVERSION and the UPS is turned off. ● BPS on set by user through LCD, and the UPS is plugged into utility but not turned on. ● Overload on line mode or ECO mode. NOTE：When in bypass mode , the load is not protected.

  • Page 31: Turn Off Operation

    UPServer2.0 ON-LINE DOUBLE CONVERSION is in. After finishing the self-test, the corresponding LED lights and the UPS is working in battery mode. Turn off operation Turn off the UPS in line mode 1. Press and hold the OFF key for more than half a second to turn off the UPS and inverter. 2.

  • Page 32: Communication Rs232, Usb, Optionals And Epo

    UPServer2.0 ON-LINE DOUBLE CONVERSION ● First, turn on the generator, after it runs stably connect output power of the generator to UPS input terminal, then turn on the UPS. After the UPS is turned on, please connect load one by one. ●...

  • Page 33: Connectivity Cards

    UPServer2.0 ON-LINE DOUBLE CONVERSION Figure 20,21 for the communication port locations. When the communication cable is installed, power management software can exchange data with the UPS. The software polls the UPS for detailed information on the status of the power environment.
  • Page 34 UPServer2.0 ON-LINE DOUBLE CONVERSION Figura 18 SNMP card RELAY card Figure 19 UPS rear view 1) Input plugin 2) UPS output outlets 3) Thermal fuse 4) EPO 5) RJ11/RJ45 6) RS-232 port 7) USB port 8) Optiona slot for communication Emergency Power-off EPO is used to shut down the UPS from a distance.
  • Page 35 UPServer2.0 ON-LINE DOUBLE CONVERSION operation, the input power must be disconnected from the UPS when the emergency power-off function is activated. NOTE For Europe, the emergency switch requirements are detailed in Harmonized document HD-384-48 S1, “Electrical Installation of the Buildings, Part 4: Protection for Safety Chapter 46: Isolation and Switching.”...

  • Page 36: Ups Maintenance

    UPServer2.0 ON-LINE DOUBLE CONVERSION UPSilon2000 Power Management Software Each UPS ships with UPSilon2000 Power Management Software. To begin installing UPSilon2000 software, see the instructions accompanying the Software Suite CD. NOTE Install UPSilon2000 power management software with the serial number attched on the cover of the CD .When running the monitor software , choose appropriate communication port.
  • Page 37 UPServer2.0 ON-LINE DOUBLE CONVERSION Replacing Tower EBPs CAUTION The EBP is heavy. Lifting the cabinet requires a minimum of two people. 1. Unplug the EBP cable from the UPS. If additional EBPs are installed, unplug the EBP cable from the battery connector on each EBP. 2.

  • Page 38: Testing New Batteries

    UPServer2.0 ON-LINE DOUBLE CONVERSION The Installation for baffle of battery pack Figura 21 4. Grasp the handle in front of the battery pack, take out of it and hold it, then remove the battery pack as fig. 27 shown. Figura 22 Rimozione pacco batterie ...

  • Page 39: Recycling The Used Battery Or Ups

    UPServer2.0 ON-LINE DOUBLE CONVERSION Recycling the Used Battery or UPS Contact your local recycling or hazardous waste center for information on proper disposal of the used battery or UPS. WARNING Do not dispose of the battery or batteries in a fire. Batteries may explode. ...
  • Page 40 UPServer2.0 ON-LINE DOUBLE CONVERSION Model Connection type Cable UPserver 2.0 IEC320 C13-10A IEC320 C14-10A Table 17. Output 200/208/220/230/240V (Configurable or auto-sensing) Nominal Value 2000 VA 1350 W Frequency 50 or 60 Hz, auto-sensing 108%±5%–150%±5%: Load transfers to Fault mode after 30 seconds. Overload 150%±5%–200%±5%: Load transfers to Fault mode after 300 ms.

  • Page 41: Troubleshooting

    UPServer2.0 ON-LINE DOUBLE CONVERSION EN 6100-4-5, Livello 4 Criterio A CE per IEC/EN 62040-2, certifications Classe B EMC (Emission) IEC 62040-2:ed2:2005 / EN 62040-2:2006 Safety IEC 62040-1-1, IEC 60950-1 Marking CE, CB 0°C to 40°C (32°F to 104°F) in Online mode, with linear derating for altitude Operating temperature NOTE Thermal protection switches load to Bypass in case of overheating.
  • Page 42 UPServer2.0 ON-LINE DOUBLE CONVERSION When replace battery, contact Battery aged franchiser to get battery and relative assembly Didn’t press the Press the two keys at the same combination keys of time “on” UPS doesn’t UPS has no battery Connect UPS battery well, if startup after connected or battery battery voltage low, please turn...
  • Page 43 EEC will repair or (at ELSIST discretion) replace the defective product or components under the terms and conditions below, without any charge for labor or spare parts costs. ELSIST reserves the right (in its sole discretion) to replace the components of defective products or low cost products with assembled parts or new or refurbished products.
