LED Accu Pad 7
7x10W RGBAWUV
battery spot light
user manual

Advertisement

Table of Contents
loading

Related Manuals for Varytec LED Accu Pad 7

Summary of Contents for Varytec LED Accu Pad 7

  • Page 1 LED Accu Pad 7 7x10W RGBAWUV battery spot light user manual...
  • Page 2 Musikhaus Thomann Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 E-mail: info@thomann.de Internet: www.thomann.de 26.07.2017, ID: 390731...

  • Page 3: Table Of Contents

    Starting up..............................20 Connections and controls........................23 Operating..............................31 7.1 Starting the device........................... 31 7.2 Main menu............................31 7.3 Menu overview..........................37 7.4 Function in 1-channel DMX mode..................... 38 7.5 Functions in 2-channel DMX mode................... 38 LED Accu Pad 7 7x10W RGBAWUV...
  • Page 4 Table of contents 7.6 Functions in 8-channel DMX mode................... 39 7.7 Functions in 11-channel DMX mode..................40 Technical specifications........................43 Plug and connection assignments....................44 Troubleshooting............................45 Cleaning............................... 48 Protecting the environment......................49 battery spot light...

  • Page 5: General Notes

    If you sell the unit please make sure that the buyer also receives this manual. Our products are subject to a process of continuous development. Thus, they are subject to change. LED Accu Pad 7 7x10W RGBAWUV...

  • Page 6: Further Information

    General notes 1.1 Further information On our website (www.thomann.de) you will find lots of further information and details on the following points: Download This manual is also available as PDF file for you to download. Use the search function in the electronic version to find the topics of Keyword search interest for you quickly.

  • Page 7: Notational Conventions

    Texts and values displayed on the device are marked by quotation marks and italics. Examples: ‘24ch’ , ‘OFF’ . 1.3 Symbols and signal words In this section you will find an overview of the meaning of symbols and signal words that are used in this manual. LED Accu Pad 7 7x10W RGBAWUV...
  • Page 8 General notes Signal word Meaning DANGER! This combination of symbol and signal word indicates an immediate dangerous situation that will result in death or serious injury if it is not avoided. WARNING! This combination of symbol and signal word indicates a pos‐ sible dangerous situation that can result in death or serious injury if it is not avoided.
  • Page 9 General notes Warning signs Type of danger Warning – danger zone. LED Accu Pad 7 7x10W RGBAWUV...

  • Page 10: Safety Instructions

    Safety instructions Safety instructions Intended use This device is intended to be used as an electronic illumination effect using LED technics. The device is designed for professional use and is not suitable for use in households. Use the device only as described in this user manual. Any other use or use under other operating con‐ ditions is considered to be improper and may result in personal injury or property damage.
  • Page 11 Never let children unattended use electrical devices. DANGER! Electric shock caused by high voltages inside Within the device there are areas where high voltages may be present. Never remove any covers. There are no user-serviceable parts inside. LED Accu Pad 7 7x10W RGBAWUV...
  • Page 12 Safety instructions DANGER! Electric shock caused by short-circuit Always use proper ready-made insulated mains cabling (power cord) with a pro‐ tective contact plug. Do not modify the mains cable or the plug. Failure to do so could result in electric shock/death or fire. If in doubt, seek advice from a regis‐ tered electrician.
  • Page 13 Keep the device away from naked flames. NOTICE! Operating conditions This device has been designed for indoor use only. To prevent damage, never expose the device to any liquid or moisture. Avoid direct sunlight, heavy dirt, and strong vibrations. LED Accu Pad 7 7x10W RGBAWUV...
  • Page 14 Safety instructions NOTICE! Power supply Before connecting the device, ensure that the input voltage (AC outlet) matches the voltage rating of the device and that the AC outlet is protected by a residual current circuit breaker. Failure to do so could result in damage to the device and possibly injure the user.
  • Page 15 Store the equipment at a tempera‐ ture between 10 °C and 32 °C in as dry an environment as possible. During extended storage periods, charge the batteries to 50 % approximately every three months. LED Accu Pad 7 7x10W RGBAWUV...

  • Page 16: Features

    Features Features The LED pad is suitable for almost all applications, for example in clubs, bars, small stages and theatres. It is characterized by small size, solid construction also for use ‘on tour’ and enormous power. Special features of the device: 7 ×...

  • Page 17: Installation

    Make sure that the installation complies with the standards and rules that apply in your country. Always secure the device with a secondary safety attachment, such as a safety cable or a safety chain. LED Accu Pad 7 7x10W RGBAWUV...
  • Page 18 Installation NOTICE! Risk of overheating Always ensure sufficient ventilation. The ambient temperature must always be below 40 °C (104 °F). NOTICE! Use of stands When mounting the device onto a stand, ensure that the stand is in a safe and stable position and that the weight of the device does not exceed the maximum permissible load capacity of the stand.
  • Page 19 Possible data transmission errors For error-free operation make use of dedicated DMX cables and do not use ordi‐ nary microphone cables. Never connect the DMX input or output to audio devices such as mixers or ampli‐ fiers. LED Accu Pad 7 7x10W RGBAWUV...

  • Page 20: Starting Up

    Starting up Starting up Establish all connections as long as the unit is switched off. Use the shortest possible high- quality cables for all connections. battery spot light...
  • Page 21 Connect the output of the first DMX device to the input of the second one, and so on to form a daisy chain. Always ensure that the output of the last DMX device in the daisy chain is terminated with a resistor (110 Ω, ¼ W). LED Accu Pad 7 7x10W RGBAWUV...
  • Page 22 Starting up Connections in master/slave When you configure a group of devices in master/slave mode, the first unit will control the mode other units for an automatic, sound-activated, synchronized show. This function is ideal when you want to start a show immediately. Connect the DMX output of the master device to the DMX input of the first slave device.

  • Page 23: Connections And Controls

    Connections and controls Connections and controls Top side LED Accu Pad 7 7x10W RGBAWUV...
  • Page 24 Connections and controls 1 Locking screws for the mounting bracket. 2 Lateral air vents. 3 LEDs. 4 Bracket for floor placement or hanging. 5 Infrared sensor for receiving signals from the remote control. battery spot light...
  • Page 25 Connections and controls Side view LED Accu Pad 7 7x10W RGBAWUV...
  • Page 26 Connections and controls 6 Antenna for wireless DMX control. 7 [SIGNAL] Indicator for successfully established wireless DMX connection. 8 [BATTERY INDICATOR] Charge status indicator for built-in battery. 9 DMX antenna holder. 10 On / off switch. 11 IEC chassis plug with fuse holder. To replace the fuse, carefully take out the fuse holder with a small screwdriver, replace the defective fuse with a new one of the same type and push the fuse holder back in until it snaps into place.
  • Page 27 : Button to increase the displayed value by one. : Button to decrease the displayed value by one. [ENTER]: Confirms a selected value. 14 Display. 15 [DMX OUT] DMX output. 16 [DMX IN] DMX input. LED Accu Pad 7 7x10W RGBAWUV...
  • Page 28 Connections and controls Remote control battery spot light...
  • Page 29 To make numeric settings. 21 [P], [W], [A], [R], [G], [B] For direct colour selection. 22 [STROBE] Turns the strobe function on / off. 23 [SOUND 1 & 2] Activates sound-controlled mode 1 or 2 LED Accu Pad 7 7x10W RGBAWUV...
  • Page 30 Connections and controls 24 [AUTO 1 & 2] Activates the ‘preprogrammed automatic show’ 1 or 2. 25 [POWER] Activates or deactivates the device. 26 [DMX] Press once to set the DMX address. After pressing twice, the DMX mode can be set. battery spot light...

  • Page 31: Operating

    Press the on / off switch to start operation. 7.2 Main menu Press [MENU] to activate the main menu. Use to change the respectively displayed value. When the display shows the desired value press [ENTER]. LED Accu Pad 7 7x10W RGBAWUV...
  • Page 32 Operating DMX address Press [MENU]. Press repeatedly until the display shows ‘AddR’ . Press [ENTER]. Now you can set the number of the first DMX channel to be used by the device (DMX address). Use to select a value between 1 and 512 (display shows ‘A001’ … ‘A512’ ). When the display shows the desired value press [ENTER] to confirm the selection and then [MENU] to return to the parent menu.
  • Page 33 This setting is only relevant if the device is not controlled via DMX. The device can operate in stand-alone mode or control connected devices of the same type, that must be configured as slaves. The auto show can only be activated on the master device. LED Accu Pad 7 7x10W RGBAWUV...
  • Page 34 Operating Operating mode ‘Slave’ Press [MENU]. Press repeatedly until the display shows ‘SLAV’ . Press [ENTER]. ‘SLA’ is flashing in the display. The device is now configured as slave and follows the settings of the master device to which it is connected. Press [MENU] to return to the parent menu. This setting is only relevant if the device is not controlled via DMX.
  • Page 35 ‘on’ , to enable the wireless module. Press [ENTER] while the display shows ‘oFF’ , to disable the wireless module. When using the wireless DMX function, unfold the antenna for wireless DMX control from the bracket and determine a proper alignment for transmission. LED Accu Pad 7 7x10W RGBAWUV...
  • Page 36 Operating Remote control Press [MENU]. Press repeatedly until the display shows ‘rEno’ . Press [ENTER]. Use to now either enable (display shows ‘On’ ) or disable (display shows ‘OFF’ ) the remote control function. When the display shows the desired value press [ENTER] to confirm the selection and then [MENU] to return to the parent menu.

  • Page 37: Menu Overview

    Operating 7.3 Menu overview LED Accu Pad 7 7x10W RGBAWUV...

  • Page 38: Function In 1-Channel Dmx Mode

    Operating 7.4 Function in 1-channel DMX mode Channel Value Function 0…255 36 different colour macros 7.5 Functions in 2-channel DMX mode Channel Value Function 0…255 Intensity (0 % to 100 %) 0…255 36 different colour macros battery spot light...

  • Page 39: Functions In 8-Channel Dmx Mode

    Intensity blue (0 % to 100 %) 0…255 Intensity white (0 % to 100 %) 0…255 Intensity amber (0 % to 100 %) 0…255 Intensity ultraviolet (0 % to 100 %) 0…8 No function 9…255 Strobe frequency slow to fast LED Accu Pad 7 7x10W RGBAWUV...

  • Page 40: Functions In 11-Channel Dmx Mode

    Operating 7.7 Functions in 11-channel DMX mode Channel Value Function 0…255 Intensity (0 % to 100 %) 0…255 Intensity red (0 % to 100 %) 0…255 Intensity green (0 % to 100 %) 0…255 Intensity blue (0 % to 100 %) 0…255 Intensity white (0 % to 100 %) 0…255...
  • Page 41 Colour-change flash (24 colours) 81…90 Colour-change fade (6 colours) 91…100 Colour-change fade (red-green; white-ultraviolet) 101…110 Colour-change fade (red-blue; white-amber) 111…120 Colour-change fade (green-blue; white) 121…255 Sound-controlled colour change 0…255 Setting the programme speed or microphone sensitivity LED Accu Pad 7 7x10W RGBAWUV...
  • Page 42 Operating Channel Value Function 0…127 Sound-controlled colour change (static) 128…255 Sound-controlled colour change (flash) battery spot light...

  • Page 43: Technical Specifications

    5 mm × 20 mm, 3.15 A, 250 V, fast acting Battery Lithium-ion, 11,1 V, 10400 mAh Protection class IP20 Housing colour White Dimensions (W × H × D) 260 × 200 × 251 mm Weight 3.4 kg LED Accu Pad 7 7x10W RGBAWUV...

  • Page 44: Plug And Connection Assignments

    Plug and connection assignments Plug and connection assignments Introduction This chapter will help you select the right cables and plugs to connect your valuable equip‐ ment so that a perfect light experience is guaranteed. Please take our tips, because especially in ‘Sound & Light’ caution is indicated: Even if a plug fits into a socket, the result of an incorrect connection may be a destroyed DMX controller, a short circuit or ‘just’...

  • Page 45: Troubleshooting

    Never connect the DMX input or output to audio devices such as mixers or ampli‐ fiers. In the following we list a few common problems that may occur during operation. We give you some suggestions for easy troubleshooting: LED Accu Pad 7 7x10W RGBAWUV...
  • Page 46 Troubleshooting Symptom Remedy The unit does not work, no light Check the mains connection. If the device is operated independently from the mains power supply, check the charge status of the built-in battery. Apparently no function despite Check if the unit is in DMX mode or in ‘slave’ mode. If so, proper power supply check the unit in another mode.
  • Page 47 DMX interface circuit. If the procedures recommended above do not succeed, please contact our Service Center. You can find the contact information at www.thomann.de. LED Accu Pad 7 7x10W RGBAWUV...

  • Page 48: Cleaning

    Cleaning Cleaning Optical lenses Clean the optical lenses, that are accessible from the outside, regularly in order to optimize the light output. The frequency of cleaning depends on the operating environment: wet, smoky or particularly dirty surroundings can cause more accumulation of dirt on the optics of the device.

  • Page 49: Protecting The Environment

    They should be returned to the manufacturer for disposal or recycled elsewhere in accordance with your local regulations. Remove lithium batteries from the device before disposal. Protect used lithium batteries against short circuit, for example by taping the poles. LED Accu Pad 7 7x10W RGBAWUV...
  • Page 50 Protecting the environment Disposal of your old device This product is subject to the European Waste Electrical and Electronic Equipment Directive (WEEE) in its currently valid version. Do not dispose with your normal household waste. Dispose of this device through an approved waste disposal firm or through your local waste facility.
