- Page 1 Manual LED Accu Pad 7 7x10 W RGBWAUV white...
-
Page 2: Table Of Contents
Table of contents Safety instructions ..........................3 1.1. FOR SAFE AND EFFICIENT OPERATION ................3 1.2. Further safety instructions ..........Fehler! Textmarke nicht definiert. 1.2.1. Safety-related red flags ..........Fehler! Textmarke nicht definiert. 1.2.2. Designated use ........................ 4 1.2.3. Overhead installation ....................... 5 Introduction ............................ -
Page 3: Safety Instructions
1. Safety instructions • This device is suitable for indoor use (not outdoors) only. • All modifications to the device will void the warranty. • Repairs are to carry out by skilled personnel only. • Use only fuses of the same type and original parts as spare parts. •... -
Page 4: Designated Use
2. Designated use This device was developed for professional use on stages, in discos, theatres etc. The device is only approved for a connection up to 230V 50/60 Hz AC voltage and only for indoor use. Regular breaks during operation increase the lifetime of your device. Avoid convulsions or any form of forceful impact during the installation or the start-up of the device. -
Page 5: Overhead Installation
2.1.1. Overhead installation Overhead installation Danger of life! Danger of life! You have to observe the regulations of BGV C1 (formerly VBG 70) and You have to observe the regulations of BGV C1 (formerly VBG 70) and You have to observe the regulations of BGV C1 (formerly VBG 70) and EN60598-2-17 17 Installations are to carry out by skilled personnel only. - Page 6 The maximum drop exceed must not exceed 20cm. A safety rope once exposed to failing load or damaged may not be used furthermore. Adjust the desired inclination angle via the mounting bracket and tighten the screw. 6 / 16...
-
Page 7: Introduction
3. Introduction Thank you for buying the LED Accu Pad 7 7x10 W RGBWAUV white. It is a powerful device. For a successful installation and operation, please read this manual carefully. 3.1. Product overview 7 / 16... -
Page 8: Battery
3.2. Battery 3.2.1. Battery charging This device has a battery indicator. There you can readout which lifetime the battery has. During the charge the battery indicators light up in sequence. You can use the device during the charge. Before you disconnect the device from the main, it should be charged completely. -
Page 9: Connections
4. Connections 4.1. Electrical connections If you wish to change the power supply settings, see the chapter Appendix. Connect the fixture to the mains with the enclosed power cable and plug. The earth has to be connected. Cable (EU) Cable (US) International Brown Black... -
Page 10: Control
5. Control 5.1. Structure of the menu To get to the main menu, press MENU. You are now in the main menu. You can select the menu items by using the UP / DOWN keys. When the function appears, you want to change, press the ENTER button. -
Page 11: Master-Slave
5.2. Master-Slave 1. Connect all devices to each other. 2. Choose for the first device an automatic program (Menu: Auto) or a color (Menu: CoLo). 3. Activate at every other device the slave mode (Menu: SLAV). 5.3. Wireless DMX 1. Choose rELE in the menu and confirm with ENTER. 2. -
Page 12: Ir Remote
5.4. IR remote 1. Choose rEno in the menu and confirm with ENTER. 2. To activate the IR remote control please choose On and confirm with ENTER. 12 / 16... -
Page 13: Dmx Chart
6. DMX chart 6.1. DMX mode 1 (1 channel) Channel Value from Value to Function 36 different color macros. 6.2. DMX mode 2 (2 channels) Channel Value from Value to Function 36 different color macros. Dimmer 0-100% 6.3. DMX mode 3 (8 channels) Channel Value from Value to... - Page 14 Color change Fade (Red-Green; White-UV) Color change Fade (Red-Blue; White-Amber) Color change Fade (Green-Blue; White) Color change music controlled Set the program speed or the sensitivity of the microphone. Color change music controlled (static) Color change music controlled (Flash) 14 / 16...
-
Page 15: Technical Dato
7. Technical dato Power supply Voltage 100-240 V AC, 50/60 Hz Power consumption max. 65 W Battery Other 8.000 mAh battery Light source LM type Color spectrum RGBWAUV Power 70 W Number / Power 7x 10 W Optics Beam angle 23°... - Page 16 Importer: B & K Braun GmbH Industriestraße 2 D-76307 Karlsbad www.bkbraun.com info@bkbraun.com 16 / 16...
