  • Page 1 Manual LED Accu Street Bar 8x8W RGBW IP65...

  • Page 2: Table Of Contents

    Table of contents Safety instructions ..........................3 1.1. For safe and efficient operation ....................3 Designated use ..........................4 2.1. Overhead installation ....................... 5 Introduction ............................7 3.1. Dimensions ..........................7 Connections ............................. 8 4.1. Electrical connections ......................8 4.2. DMX connections ........................

  • Page 3: Safety Instructions

    1. Safety instructions • This device is suitable for indoor and outdoor use This device is suitable for indoor and outdoor use. • All modifications to the device will void the warranty. All modifications to the device will void the warranty. •...

  • Page 4: Designated Use

    2. Designated use This device was developed for professional use on stages, in discos, theatres etc. The device is only approved for a connection up to 230V 50/60 Hz AC voltage and only for indoor use. Regular breaks during operation increase the lifetime of your device. Avoid convulsions or any form of forceful impact during the installation or the start-up of the device.

  • Page 5: Overhead Installation

    2.1. Overhead installation Overhead installation Danger of life! Danger of life! You have to observe the regulations of BGV C1 (formerly VBG 70) and You have to observe the regulations of BGV C1 (formerly VBG 70) and You have to observe the regulations of BGV C1 (formerly VBG 70) and EN60598-2-17 17 Installations are to carry out by skilled personnel only.
  • Page 6 The maximum drop exceed must not exceed 20cm. A safety rope once exposed to failing load or damaged may not be used furthermore. Adjust the desired inclination angle via the mounting bracket and tighten the screw. 6 / 20...

  • Page 7: Introduction

    3. Introduction Thank you for buying the LED Accu Street Bar 8x8W RGBW IP65. It is a powerful device. For a successful installation and operation, please read this manual carefully. 3.1. Dimensions 7 / 20...

  • Page 8: Connections

    4. Connections 4.1. Electrical connections If you wish to change the power supply settings, see the chapter Appendix. Connect the fixture to the mains with the enclosed power cable and plug. The earth has to be connected. Cable (EU) Cable (US) International Brown Black...

  • Page 9: Control

    5. Control Press MENU to get to the menu. With UP/DOWN you can select the required point of menu. Confirm your selection with ENTER. With UP/DOWN you can make your settings after this confirm your settings with ENTER. 5.1. Structure of the menu Menu Submenu 1 Submenu 2...
  • Page 10 VERSION Shows the current software version. With this function you can download the customer DOWNLOAD setting from another device. WIRELESS ON / OFF (De-)Activates the wireless DMX. RELEASE Release PCB TEMP Shows the current temperature. UPDATE Update RESET Reset 10 / 20...

  • Page 11: Dmx Chart

    6. DMX chart 6.1. DMX mode 1 (3 channels) Channel Value from Value to Function Saturation Dimmer 0 – 100% 6.2. DMX mode 2 (4 channels) Channel Value from Value to Function Dimmer red 0 -100% Dimmer green 0 – 100% Dimmer blue 0 –...
  • Page 12 Cool white Warm white White 3200 White 2500 Yellow 2 Straw Orange 2 Light rose Dark pink Magenta 2 Blue 2 Med blue green Dark blue Bright pink Medium blue Golden amber Deep golden amber Pale lavender Apricot Dark lavender Chocolate Just blue Sunrise pink...

  • Page 13: Dmx Mode 5 (43 Channels)

    6.5. DMX mode 5 (43 channels) Channel Value from Value to Function Dimmer 0 – 100% Dimmer red 0 – 100% Dimmer green 0 – 100% Dimmer blue 0 – 100% Dimmer white 0 – 100% No function R100% / G upwards / B0% / W0% R downwards / G100% / B0% / W0% R0% / G100% / B upwards / W0% R upwards / G downwards / B100% / W0%...
  • Page 14 White 2 White 3 White 4 White 5 White 6 White 7 White 8 White 9 White 10 White 11 Setting the speed if channel 6 is activated. No function (if channel 6 is not activated) Strobe slow – fast (if channel is not activated) No function Automatic program 1 Automatic program 2...
  • Page 15 LED 1/2/3/4 + 5/6/7/8 Control the LEDs in groups of 4 LED 1/2/5/6 + 3/4/7/8 Control the LEDs in groups of 4 LED 1/2/7/8 + 3/4/5/6 Dimmer red LED 1 0 – 100% Dimmer green LED 1 0 – 100% Dimmer blue LED 1 0 –...

  • Page 16: Wireless Dmx

    90 – 99 ID 9 ID 30 ID 53 100 – 109 ID 10 ID 31 ID 54 110 – 119 ID 11 ID 32 ID 55 120 – 129 ID 12 ID 33 ID 56 130 – 139 ID 13 ID 34 ID 57 140 –...

  • Page 17: Technical Data

    8. Technical data Power supply Voltage 100 – 240 V AC / 50-60 Hz Power consumption max. 64 W Battery Light source LM type LED 4in1 Color spectrum RGBW Power 64 W Number / Power 8x 8W Optics Beam angle 25°...
  • Page 18 18 / 20...
  • Page 19 19 / 20...
  • Page 20 Importer: B & K Braun GmbH Industriestraße 2 D-76307 Karlsbad www.bkbraun.com info@bkbraun.com 20 / 20...
