- Page 1 Long Range Repeater Installation Manual For AC-Powered and Solar-Powered Repeaters Models 7653 and 7654...
- Page 2 Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Changes or modification not expressly approved in writing by Davis Instruments may void the warranty and void the user's authority to operate this equipment. FCC ID: IRDWW765Y...
- Page 3 ). The Long Range Repeater works in much the same way as the Vantage Pro2 wireless repeaters, but extends the range and distance between a repeater and a receiver by up to 10 times that of the Vantage Pro2 wireless repeater. Long Repeater Manual Overview...
- Page 4 Long Range Repeater Components and Hardware In addition to the wireless repeater enclosure and hardware, the long range repeater comes equipped with custom-selected external antennas that can be used separately on in comibination of one another. Omni-direction Antenna Omni Antenna 48"...
- Page 5 Repeater Board Contents The board contained within the repeater enclosure has the following contents: Solar Power Tab AC Adpater Repeater Cables Battery Compartment Status Transmitter DIP Switches Repeater Test Switch Repeater DIP Switches...
- Page 6 The component unique to the Long Range Repeater board is: • Antenna Cables — Connects the repeater board to the external antennas. Mounting the Wireless Repeater The antenna configuration and wireless repeater can be mounted on a pole at designated location.
- Page 7 Omni and Yagi Antenna Combination Assembly Omni Antenna 5/16" U-Bolts Flat Washer Lock Washer 48" Antenna Yagi Antenna Cables 2" Diam. Pole...
- Page 8 Two Yagi Antenna Combination Assembly Connecting External Antennas to the Repeater Repeater Cables Cable Clamps Antenna Cables...
-
Page 9: Specifications
Specifications Complete specifications for all of the Vantage Pro2 weather products as well as the wire- less repeater are available in the Weather Support section of our website: http://www.davisnet.com/support/weather/ General Operating Temperature....-40 to 150° Fahrenheit (-40 to 65° Celsius) Non-Operating Temperature . - Page 10 Repeater Transmit Interval ....2.5625 - 3.0000 seconds depending on ID.
