PocketWizard FlexTT5 Quick Manual

340.00 – 354.00 mhz, us fcc/ic, 433.42 – 434.42 mhz, ce
Hide thumbs Also See for FlexTT5:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Manual
MAKE IT POSSIBLE
Quick Guide
FlexTT5 for Panasonic
340.00 – 354.00 MHz, US FCC/IC
433.42 – 434.42 MHz, CE
This PocketWizard radio runs on powerful software called ControlTL
It is pre-set with default settings allowing you to use it right away or it
can be configured to your specific needs using the PocketWizard Utility
which can be downloaded at:
www.PocketWizard.com/support/downloads.
• UPDATE FIRMWARE:
ControlTL radios to the latest firmware for best functionality.
• Please read Quick Guide thoroughly before operating.
• Visit wiki.PocketWizard.com for complete operating information.
™
Using the Utility, update all your PocketWizard
.
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FlexTT5 and is the answer not in the manual?

Questions and answers

Related Manuals for PocketWizard FlexTT5

Summary of Contents for PocketWizard FlexTT5

  • Page 1 This PocketWizard radio runs on powerful software called ControlTL ® It is pre-set with default settings allowing you to use it right away or it can be configured to your specific needs using the PocketWizard Utility which can be downloaded at: www.PocketWizard.com/support/downloads.

  • Page 2: Fcc Part 15.19 Warning Statement

    FCC Statements FCC Part 15.19 Warning Statement THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
  • Page 3 FCC Part 15.105(b) Warning Statement (continued) If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna.
  • Page 4 Configuration/Channel 1 Configuration/Channel 2 Power Off Hot Shoe TEST/LEARN Button Remote Flash Triggering Port (P2) Locking Ring Remote Camera Triggering Port (P1) Status LED • You need a FlexTT5 for each remote Speedlight. • Set all radios to the same channel.

  • Page 5: Basic Wireless

    1. Slide FlexTT5 Transceiver onto camera. ® 2. Slide Speedlight onto remote FlexTT5 Transceiver. Set the Zone Switch to your desired Zone. Repeat for each remote Speedlight. Note: You need a receiving FlexTT5 for each remote Speedlight 3. Make sure all your PocketWizard radios are on the same channel and take pictures ®...

  • Page 6: Manual Flash

    3. Slide Speedlight onto remote FlexTT5 Transceiver. Note: You need a receiving FlexTT5 for each remote Speedlight 4. Set Zone Switch (A, B, C) on remote FlexTT5. All remote i-TTL Speedlights on the same group/zone will be treated as one zone of light.
  • Page 7 ® Make sure all your PocketWizard radios are on the same channel and take pictures normally. Note: Manual remote flashes are not calculated as part of the TTL exposure. For proper exposure, adjust your camera’s exposure settings, or adjust the power level directly on your remote flash.

  • Page 8: Other Functions

    Power off the unit, reset all connections, and power back on. RESET RESET A / CHANNEL RESET: To reset to channels programmed in the PocketWizard Utility, hold TEST on power up. green LED blinks twice to indicate reset. Release TEST. Advanced features set via PocketWizard Utility will be retained.
  • Page 9 Compatibility Panasonic cameras and Speedlights compatible with PocketWizard ControlTL radios: The FlexTT5 is compatible with the GH4 Camera and the DMW-FL580L and DMW-FL360L Speedlights. Visit wiki.PocketWizard.com for compatibility information. Some Panasonic equipment compatibility may be implemented via future firmware updates.

  • Page 10: Specifications

    Trigger Delay: 0 seconds – “faster than a wire” when using compatible Panasonic cameras. Note: Approximately 900 microseconds delay if using Basic Trigger Mode. Batteries: FlexTT5 - 2 x AA (IEC:LR6) (60 hours) ® Operating Temperature: Above -15º C (5º F) and below 50º C (120º F) for FlexTT5 Storage Temperature (without battery): Above -30º...

  • Page 11: Warranty

    © 2011 LPA Design. All rights reserved. Product features and specifications are subject to change without notice. PocketWizard, ControlTL, MiniTT1, FlexTT5, PowerST4, AC3, AC9, HyperSync, Plus II and MultiMAX are either trademarks or registered trademarks of LPA Design. All other trademarks contained herein are the property of their respective owners.
