- Page 1 HERALD FLOOR STANDING FIRED CONDENSING BOILERS Installation, Commissioning, Maintenance and User Instructions MODELS: HCB46CE HCB61CE HCB86CE installation manual_herald 46-86_februaury 2018...
-
Page 2: Table Of Contents
Table of Contents INTRODUCTION ..............................................4 SAFETY GUIDELINES............................................. 5 GENERAL DESCRIPTION OF SAFETY SYMBOLS USED................................5 WHAT TO DO IF YOU SMELL GAS ........................................ 6 PRINCIPAL PARTS ..............................................7 TECHNICAL DATA ..............................................9 DIMENSIONS AND CLEARANCES ........................................10 DIMENSIONAL DRAWINGS .......................................... 10 CLEARANCES .............................................. - Page 3 19.4 BURNER REMOVAL ............................................66 19.5 CLEANING THE HEAT EXCHANGER ......................................66 19.6 DRAINING BOILER SYSTEM ........................................66 19.7 REFILLING THE SYSTEM ..........................................67 19.8 OTHER CHECKS ............................................67 20.0 SMART SYSTEM CONTROL SETTINGS ......................................68 20.1 DISPLAY PANEL ACCESS MENU ........................................ 68 20.2 PARAMETER SETTING ..........................................
-
Page 4: Introduction
INTRODUCTION The Lochinvar Herald range is a floor standing gas fired condensing boiler. The equipment comprises a stainless steel radial burner assembly and a heat exchanger that permits fully condensing operation. The burner is initiated by a full electronic ignition sequence control that incorporates a spark ignition and a flame rectification device for supervision of the flame. -
Page 5: Safety Guidelines
SAFETY GUIDELINES READ AND UNDERSTAND THE INSTRUCTIONS Read and fully understand all instructions before attempting to operate maintain or install the unit. Keep these instructions near the Boiler for quick reference. This equipment must be installed by a competent person, registered with the H.S.E. approved body. All installations must conform to the relevant Gas Safety and Building Regulations. -
Page 6: What To Do If You Smell Gas
Do not re-enter the building until it is safe to do so Lochinvar limited is not liable for any damage caused by inaccurately following these mounting instructions. Only original parts may be used when carrying out any repair or service work. -
Page 7: Principal Parts
PRINCIPAL PARTS ITEM DESCRIPTION FUNCTION NOTE Stainless steel heat Allows water to flow through specially designed coils for maximum heat transfer, while providing protection Not Shown in 3.1.2 exchanger against flue gas corrosion. The coils are encased in a jacket that contains the combustion process. Heat exchanger access Not Shown in 3.1.2 Allows access to the combustion side of the heat exchanger coils. - Page 8 3.1.2 3.1.1 RINCIPLE PARTS TO BE USED IN CONJUNCTION WITH TABLE...
-
Page 9: Technical Data
TECHNICAL DATA Model Number HCB46CE HCB61CE HCB86CE GENERAL DATA Product I.D. Number CE 0063 CQ3351 Classification 112H31B/P Input (gross) 61.5 83.5 Input (net) 39.6 55.4 75.2 Output (50º/30º) 41.2 58.7 79.7 Output (80º/60º) 38.5 53.2 Seasonal Efficiency 96.4 95.6 Shipping Weight @0%O mg/kWh GAS DATA –... -
Page 10: Dimensions And Clearances
DIMENSIONS AND CLEARANCES 5.1 DIMENSIONAL DRAWINGS Note full dimensional drawings showing connection sizes and positions are available from Lochinvar technical support 5.1.1 HCB46CE-HCB61CE IMENSIONAL DRAWING MODEL 5.1.2 , HCB86CE IMENSIONAL DRAWING MODELS Model Dimension Unit HCB46CE HCB61CE HCB86CE 1080... -
Page 11: Clearances
5.2 CLEARANCES 5.2.1 ENCLOSURE INSTALLATION CLEARANCES ( 5.2.2 PLANT-ROOM INSTALLATION CLEARANCES (... -
Page 12: General Requirements
GENERAL REQUIREMENTS The Lochinvar Herald condensing boiler has been designed to operate trouble free for many years. These instructions should be followed closely to obtain the maximum usage and efficiency of the equipment. READ AND UNDERSTAND THE INSTRUCTIONS Read and fully understand all instructions before attempting to operate maintain or install the unit. -
Page 13: Water Quality
WATER QUALITY The Lochinvar Herald contains a stainless steel heat exchanger; therefore, care must be exercised to ensure that the system water and any water treatment are compatible. Whenever a new boiler is connected to an existing system, the pipework must be thoroughly cleaned and flushed to remove debris, rust particles, carbonate deposits and any existing water treatment that might be incompatible with the heat exchanger. -
Page 14: Clearances
GAS SUPPLY The Lochinvar Herald range is suitable for use on second and third family gasses 2H - G20 - 20mbar and 3P - G31 - 37mbar. For details relating to Propane (3P) please refer to Section on LPG FUEL: 9.1 SERVICE PIPES... - Page 15 EQUIPMENT GAS SYSTEM LEAK CHECK An approved gas-inlet appliance isolating valve and union should be installed for each unit in a convenient and safe position and be clearly marked. Ensure that the gas-inlet appliance isolating valve is in the OFF position. Although the equipment receives a gas leak check and gas train component integrity check prior to leaving the factory, transit and installation may cause disturbance to unions, fittings and components.
-
Page 16: Flue System
Before installation of any flue system read the installation manual carefully for both the appliance and flue system to be used. Information on the flue system Supplied by Lochinvar can be found within this manual. -
Page 17: Flue System Technical Details
10.2 FLUE SYSTEM TECHNICAL DETAILS Model Number HCB46CE HCB61CE HCB86CE FLUE DATA TYPE B Nominal flue diameter 80+/-0.6 100+/-0.6 Maximum flue gas temp °C Maximum equivalent length 1000 Equivalent length 90 bend Equivalent length 45 bend Flue gas temperature °C Flue draught requirements mbar -0.03 to -0.1... - Page 18 10.4.1 FLUE TERMINAL POSITIONS Location Description HCB46CE – HCB61CE HCB86CE Directly below an opening, air brick, opening windows etc. 2000 Above an opening, air brick, opening windows etc. 1000 Horizontally to an opening, air brick, opening windows etc. 1000 Below a gutter or sanitary pipework Below the eaves Below a balcony or car port roof From a vertical drain or soil pipe...
-
Page 19: Approved Flue System
10.5 APPROVED FLUE SYSTEM For Concentric and Twin pipe flue systems only the Lochinvar supplied M&G flue system must be used The approved flue system is not suitable for use external to the building. If external routes cannot be avoided, a flue system manufacturer should be consulted to supply a suitable alternative. -
Page 20: Room Sealed (Type C) Flue Assembly
Additional wall brackets may be required to ensure the flue system is stable. For a full list of flue components supplied and optional parts to complete the system see the herald flue guide available at www.lochinvar.ltd.uk ITEM NUMBER DESCRIPTION... - Page 21 To install the flue connection to the HCB46CE – HCB61CE boilers the following procedure should be followed: Check you have all items shown in Section 10.2.1 Check the flue temperature sensor (supplied with the boiler) is securely located into the hole on the exhaust transition.
-
Page 22: Installation Of Transition Kit To Hcb86Ce Boiler
Additional wall brackets may be required to ensure the flue system is stable. For a full list of flue components supplied and optional parts to complete the system see the herald flue guide available at www.lochinvar.ltd.uk ITEM NUMBER DESCRIPTION... - Page 23 To install the flue connection to the HCB86CE boiler the following procedure should be followed: Check you have all items shown in Section 10.3.2. Check the flue temperature sensor (supplied with the boiler) is securely located into the hole on the exhaust transition.
- Page 24 10.4 C13 CONCENTRIC HORIZONTAL FLUE SYSTEMS Flue system specifications MANUFACTURER MUELINK AND GROL (M&G) TEMPERATURE CLASS T120 FLUE GAS MATERIAL PP Each concentric horizontal flue kit includes the items shown in the tables below Item No HBHF001 CONCENTRIC HORIZONTAL FLUE ASSEMBLY MODELS HCB46CE,HCB61CE COMPONENTS INCLUDED...
-
Page 25: Flue Terminal Installation
11.0 FLUE TERMINAL INSTALLATION 11.1 TYPE C (HORIZONTAL ROOM SEALED) 11.1.1 HORIZONTAL CONCENTRIC ROOM SEALED APPLICATION, MODELS HCB46CE-HCB61CE 11.1.2 HORIZONTAL CONCENTRIC ROOM SEALED APPLICATION, MODELS HCB86CE When the boiler is installed as a Type C (Horizontal concentric) appliance, the flue system should be installed as follows: Determine the location of the flue terminal, taking into account minimum distances as detailed in Section 10.4.1 and the relevant British Standards. -
Page 26: Flue Terminal Guarding
Fill the void between the terminal and wall with water resistant sealant. Fit the wall plates or rosette using appropriate fixings. Install the remainder of the flue system working progressively away from the boiler supporting the pipes as necessary. 11.1.3 HORIZONTAL TERMINAL INSTALLATION 11.2 FLUE TERMINAL GUARDING... - Page 27 11.3 CONCENTRIC VERTICAL FLUE SYSTEMS Flue system specifications MANUFACTURER MUELINK AND GROL (M&G) TEMPERATURE CLASS T120 FLUE GAS MATERIAL PP Each concentric horizontal flue kit includes the items shown in the tables below Item No HBVF001 CONCENTRIC VERTICAL FLUE ASSEMBLY MODELS HCB46CE,HCB61CE COMPONENTS INCLUDED Number...
-
Page 28: Type C 33 (Vertical Room Sealed)
11.4 TYPE C (VERTICAL ROOM SEALED) 11.4.1 VERTICAL CONCENTRIC ROOM SEALED APPLICATION, MODELS HCB46CE-HCB61CE 11.4.2 VERTICAL CONCENTRIC ROOM SEALED APPLICATION, MODELS HCB86CE When the boiler is installed as a Type C (Vertical Concentric) appliance, the flue system should be installed as follows: Confirm that the roof flashing is correct for the type of roof through which the terminal is to be installed. - Page 29 11.4.3 VERTICAL TERMINAL ROOF FLASHINGS FOR SYNTHETIC, FLAT AND TILED ROOFS 11.4.4 INSTALLING TERMINAL THROUGH ROOF FLASHING...
- Page 30 11.4.5 ENERAL CONCENTRIC FLUE SYSTEM INSTALLATION GUIDELINES The information in this section is for General guidance only and may not fully represent the installation on site Do not drill and screw into flue system...
- Page 31 Max distance between brackets...
-
Page 34: Type C 43 (U Duct)
11.5 TYPE C (U DUCT) This appliance can operate on a U-Duct common flue system. The maximum lengths for the interconnecting flue can be found in Section 10.2.1. Concrete components of the U-Duct must meet the requirements of BS EN 1858. Mass Rate @ 100% Mass Rate @ 23% Mass Rate @ 100%... - Page 35 When installing the boiler as a Type C53 appliance, it should be noted that the terminals must not be installed on opposite sides of the building. If the flue temperature sensor is not fitted, the flue gas temperature may exceed the maximum temperature rating of the flue and can lead to severe personal injury, death or substantial property damage.
- Page 36 11.6.1 GENERAL TWIN-PIPE INSTALLATION GUIDELINES The information in this section is for General guidance only and may not fully represent the installation on site...
- Page 38 To install a Type C terminal or air inlet, the procedure for either a Type C (horizontal) or a Type C (vertical) terminal should be followed noting that the annular space of the terminal should be sealed off.
-
Page 39: Type B (Conventional Flue With Fan Assistance)
11.7 TYPE B (CONVENTIONAL FLUE WITH FAN ASSISTANCE) When the boiler is installed as a Type B appliance, the flue system should be installed in accordance with the flue manufacturer’s specific instructions. Item No HBCF001 FAN ASSISTED OPEN FLUE STARTER ASSEMBLY Kit contains components to start the connection to the appliance only MODELS HCB46CE,HCB61CE... -
Page 40: C63 Certified Flue Systems
1.Insert the exhaust transition into the exhaust port of the boiler. 2..Insert the flue temperature sensor into the location hole on the exhaust transition. If the flue temperature sensor is not fitted, the flue gas may exceed the maximum temperature rating of the flue and can lead to severe personal injury, death or substantial property damage. -
Page 41: Air Supply
12.0 AIR SUPPLY The following information is based on single boiler installations only. If more than one boiler is being used, BS5440-2 or BS6644 (as appropriate) should be consulted to calculate the necessary requirements. 12.1 COMBUSTION VENTILATION When used as a Type C (room sealed) appliance, provided sufficient clearance is provided, ventilation for combustion is not necessary as the combustion air is ducted directly from outside. -
Page 42: Water Connections
OPEN VENTED SYSTEM ARRANGEMENT The Lochinvar Herald can be used in an open vented arrangement provided that a vent pipe in accordance with CP 342 or BS6644 as appropriate is fitted. The minimum static head requirement for an open vented system is 0.5 bar. - Page 43 13.3.1 TYPICAL SCHEMATIC, SINGLE BOILER WITH LOW LOSS HEADER 13.3.2 TYPICAL SCHEMATIC, SINGLE BOILER WITH PLATE SYSTEM SEPARATOR...
-
Page 44: Schematics
KEY FOR SCHEMATICS Lochinvar limited may provide technical advice and guidance to assist with best practice, optimisation and installation of Lochinvar products; however, we will not be liable for any duties as designers under construction (design and management regulations 2015). In all cases where information is provided, the customer must assess and manage risks associated with the technical information and advice provided. - Page 45 14.1.1 TYPICAL INSTALLATION SHOWING MULTIPLE HERALD BOILERS WITH CASCADE CONTROL AND ALTERNATIVE LEADER DHW WORKING AS A ZONE...
- Page 46 14.1.1 TYPICAL INSTALLATION SHOWING MULTIPLE HERALD BOILERS WITH CASCADE CONTROL AND ALTERNATIVE LEADER DHW PRIORITY...
-
Page 47: Circulating Pumps
COEFFICIENT OF EXPANSION OF WATER AT 3.8 BAR COLD FILL PRESSURE 14.2 CIRCULATING PUMPS A suitable primary pump, sized in accordance with 14.2.1 should be fitted to the inlet to the boiler. Primary pumps are available from Lochinvar Limited as ancillary items. ΔT (°C): 13.89 16.67 19.44... -
Page 48: Primary Pipework Header Sizing
If your installation is outside the scope of this guidance, please contact Lochinvar Technical support before proceeding with the installation. -
Page 49: Electrical Supply
15.0 ELECTRICAL SUPPLY Wiring external to the equipment must be installed in accordance with the I.E.E. Regulations and any local regulations that apply. Model Normal Supply Voltage External Fuse Rating Power Consumption HCB46CE 120 W 230V AC HCB61CE 50 Hz 6.0 A 144 W 1 PH... -
Page 50: High Voltage Connector Strip
15.3 HIGH VOLTAGE CONNECTOR STRIP D.H.W. PRIMARY SECONDARY BOILER SYSTEM 230V~50Hz MAINS PUMP OUTPUTS 190 WATTS MAX 15.3.1 HIGH VOLTAGE CONNECTION STRIP The output across the 3 terminals should not exceed 190W per terminal. It is highly recommended these switched outputs are only used to switch suitable starter overload relays on the pumps. - Page 51 CONNECTION OUTPUT / INPUT NOTES An internal volt free contact across pins 1 and 2 will close in the event of the heater locking out. ALARM CONTACTS Volt free – Close on alarm This connection can be used by a BMS to monitor the operation of the heater. RUNTIME Volt free –...
-
Page 52: Electrical Connections
15.5 ELECTRICAL CONNECTIONS Access to the High Voltage and Low Voltage Connection Strips can be made by removing the appropriate knockouts on the back panel of the boiler. All connections should be secured using an appropriate cord anchorage. One cord anchor is supplied with the boiler for securing the mains supply to the unit. -
Page 53: Wiring Diagram
15.8 WIRING DIAGRAM 15.8.1 WIRING DIAGRAM... -
Page 54: Ladder Diagram
15.9 LADDER DIAGRAM 15.9.1 LADDER DIAGRAM... -
Page 55: Smart System Control
16.0 SMART SYSTEM CONTROL 16.1 GENERAL The Lochinvar Herald uses the SMART SYSTEM control interface. The control panel display gives information on set- up, system status and diagnostic data in words rather than codes. 16.2 SMART SYSTEM CONTROL PANEL USB Drive... -
Page 56: Saving Parameters
16.3 SAVING PARAMETERS Please note that the brackets ([]) denote screen status. 16.3.1 TO SAVE PARAMETERS AND EXIT PROGRAMMING Press the RIGHT SELECT (SAVE) key and then press the RIGHT SELECT (HOME) KEY. 16.3.2 TO ENTER A PARAMETER AND CONTINUE PROGRAMMING Press the RIGHT SELECT (SAVE) key 1 time to return to the parameter listings, press again to return to the menu listings. - Page 57 If flame is not detected after spark ends the control will perform a post-purge, then start another pre-purge cycle and try to light the boiler again. If the flame is detected it holds the firing rate steady for a few seconds then begins to modulate the firing rate based on a set point or some other command (such as the 0-10v signal) If a space heating call for heat is active and the tank...
-
Page 58: Status Display Screens
16.4 STATUS DISPLAY SCREENS Section Display Description STANDBY The unit has not received a call for heat START The unit has received a call for heat and is checking all safety circuits PREPURGE The unit has received a call for heat and has initiated a pre-purge period IGNITION The unit has initiated the spark ignition to the main burner A (Boiler... - Page 59 Section Display Description 0-10V BMS IN 0-10V BMS OUT BMS ADDRESS BMS SCREEN BMS CONTROL? SYS PUMP SPEED BLR PUMP OUT SH RUN TIME total space heating run time SH CYCLES total space heating demand cycles DHW RUN TIME total DHW running time HISTORY DHW CYCLES total DHW demand cycles...
-
Page 60: Commissioning And Testing
17.0 COMMISSIONING AND TESTING 17.1 ELECTRICAL INSTALLATION Notes on the requirements for electrical installation are provided in Section 15.0. A schematic drawing of the control circuit is shown in Section 15.0: WIRING DIAGRAM. 17.2 GAS INSTALLATION For design see 9.0: GAS SUPPLY. See Section3.0: for details on the position of the gas connection. 17.3 WATER CONNECTIONS For design see Section 13.0: WATER CONNECTIONS... -
Page 61: Temperature Adjustment Procedure
<100 ppm 17.4.5 NATURAL GAS COMBUSTION FIGURES If the combustion figures are not within the range specified, contact Lochinvar Technical support for further guidance. Combustion figures for Propane firing can be found in Section 18.0: LPG FUEL. 17.5 TEMPERATURE ADJUSTMENT PROCEDURE 17.5.1... -
Page 62: Lpg Fuel
LPG fuel. In the event of any seal or gasket being broken it is essential that the seal or gasket be replaced. Contact Lochinvar limited for replacement seals and gaskets. Model Part No. - Page 63 If the boiler is already installed and operational, you must turn off the gas supply, turn off the power supply and allow the boiler to cool before proceeding. The conversion procedure is as follows: 18.2.2 HCB46CE – HCB86CE Remove the top and front access covers from the unit (no tools required for removal). Remove the impulse tube and wiring plug from the gas valve.
-
Page 64: Lpg Commissioning And Testing
Combustion figures should be as follows: Model No. 10.5% 0.5% HCB46CE <100 ppm 10.5% 0.5% HCB61CE <100 ppm 10.5% 0.5% HCB86CE <100 ppm 18.3.2 LPG COMBUSTION FIGURES If the combustion figures are not within the range specified, contact Lochinvar Technical support for further guidance. -
Page 65: Maintenance
The boiler has a built in function that reminds the user that routine maintenance is due. As a default, this is set to 12 months 10,000 operational hours or 10,000 ignition cycles. Lochinvar Limited recommends that this be the maximum service interval. -
Page 66: Burner Removal
19.4 BURNER REMOVAL If it has been determined that the flame picture is unacceptable, the burner can be removed and cleaned using the following procedure: Isolate the electrical and gas supplies to the heater. Allow the boiler to cool down. Disconnect the wiring connections to the ignition electrode. -
Page 67: Refilling The System
19.7 REFILLING THE SYSTEM Close the drain valve. Open the cold-water inlet valve from the header tank or pressurisation unit to boiler system. Working systematically towards the highest point in the system, open all bleed valves and allow any trapped air to escape. Follow the lighting instructions as detailed in Section 17.4.3. -
Page 68: Smart System Control Settings
20.0 SMART SYSTEM CONTROL SETTINGS 20.1 DISPLAY PANEL ACCESS MENU To access menus from the display panel use the procedure shown below: Only suitably qualified engineers should alter the settings and parameters within the herald boiler. Incorrect settings could lead to operational problems within the boiler. These problems would not be covered under the herald boiler warranty 20.1.1 DISPLAY PANEL ACCESS MENU... -
Page 69: Parameter Setting
20.2 PARAMETER SETTING Installer Menu Description User Access Section Access Vacation Mode (On/Off) 21.1 21.1 Time and Date 21.1 Software Version (read only) 21.1 Temperature Units (°C/°F) 21.1 SH Night Setback Offset 21.1 IF SH NSB > 0: 21.1 i. SH Night Setback On Times GENERAL ii. - Page 70 User Installer Menu Description Section Access Access 21.5 Tank Minimum Set Point 21.5 Tank Maximum Set Point 21.5 DHW Max Rate DHW Type (normal, zone) i. SH/DHW Switching Time ii. DHW SETTINGS DHW/SH Switching Time (CONT.) ELSE: 21.5 i. DHW FORCES SYSP (YES/NO) ii.
- Page 71 User Installer Menu Description Section Access Access Anti-cycling Time 21.7 21.7 Anti-cycling Override Differential ANTI-CYCLING 21.8 Ramp Delay (Enable/Disable) 21.8 Modulation Factor Controlling Sensor(Outlet/System 21.9 Supply/Inlet) Cascade Address IF Address = 0: Maximum Cascade Outlet Set Point Cascade Offset Cascade Differential Cascade Type (L/L, EFF) Minimum On/Off Time Minimum Next On Time Minimum Pumps On...
- Page 72 User Installer Menu Description See Section Access Access System Pump Delay 21.11 21.11 Boiler Pump Delay 21.11 DHW Pump Delay 21.11 System Pump Anti-Seize Delay CIRCULATION 21.11 Boiler Pump Anti-Seize Delay PUMPS 21.11 DHW Pump Anti-Seize Delay 21.11 System Pump Type (CFH, WWSD) 21.11 Boiler Pump Delta T Set Point 21.11...
-
Page 73: Viewable And Changeable Control Parameters
21.0 VIEWABLE AND CHANGEABLE CONTROL PARAMETERS Before changing p a r a m e t e r s , n o t e t h e settings so that the unit can be returned to its original operating parameters. 21.1 GENERAL 21.1.1 ACATION... -
Page 74: Temperature Settings
21.1.6 (SH) (DHW) N PACE EATING OMESTIC ATER IGHT ETBACK N AND IMES These are the times at which the SH Night Setback and DHW Night Setback Offsets become active and inactive. There are seven (7) stop times and seven (7) start times each for the SH and DHW night setback functions. Any start or stop time may be set to any time during the week. -
Page 75: Data Logging
21.2.3 (SH) M PACE EATING AXIMUM OINT The SH maximum set point sets the maximum water temperature set point that can be used for space heating. The user or installer will not be able to program the control with a higher SH set point. This parameter can only be changed by the installer by accessing Maximum SH Set point parameter. -
Page 76: Dhw Settings
21.5 DHW SETTINGS 21.5.1 DHW T OINT By installing a tank sensor, the SMART SYSTEM control can perform the tank thermostat function. The SMART SYSTEM control automatically detects the presence of this sensor, and generates a DHW call for heat when the tank temperature drops below the tank set point differential (Tank Set point Differential parameter), and finishes the call for heat when the tank temperature reaches tank set point. - Page 77 21.5.10 DHW T PEED IMITING FOR NDIRECT This parameter determines the maximum fan speed (and therefore the maximum kW rate) to be used when heating an indirect DHW tank. This setting may be used when the tank is unable to accept all of the kW available from the boiler.
-
Page 78: Outdoor Reset
21.6 OUTDOOR RESET The option of controlling up to three (3) different outdoor resets for low outdoor temperatures is available. 21.6.1 (1 - 3) L UTDOOR When the outdoor air temperature drops to this point, the water temperature will be at the Set point 1 at Low Outdoor Temp 1, Set point 2 at Low Outdoor Temp 2 and Set point 3 at Low Outdoor Temp 3 parameters. - Page 79 21.6.5 (1 - 3) OINT UTDOOR EMPERATURE When the outdoor air temperature rises to or above Outdoor (1 - 3) High parameters, the calculated set point will be at this setting (FIG. 1-1). These parameters can be changed by the installer by accessing the Set point 1 at High Outdoor Temp 1, Set point 2 at High Outdoor Temp 2 and Set point 3 at High Outdoor Temp 3 parameters.
-
Page 80: Anti-Cycling
21.7 ANTI-CYCLING 21.7.1 YCLING Once the burner turns off, a set amount of time must elapse before the control will respond to a new demand. The control will block the new heat demand and anti-cycling will be shown in the display until the time has elapsed or the water temperature drops below the Anti-Cycling Override Differential parameter. -
Page 81: Ramp Settings
21.8 RAMP SETTINGS Please note that the brackets ([]) denote screen status. The SMART SYSTEM control can be programmed to limit the firing rate for a fixed period of time at the start of a space heating or BMS set point demand. There are six (6) possible limits, each with their own time delay. The first limit applies as soon as the burner starts. - Page 82 21.9.5 ASCADE IFFERENTIAL This parameter determines how much the temperature must go below the turn off temperature (Set point + Offset) before the lead boiler turns on. This parameter can be adjusted by the installer by accessing the Cascade Differential parameter.
-
Page 83: Building Management System (Bms)
21.9.10 LTERNATE EADER This parameter allows the Member 1 boiler to automatically assume control of the Cascade should it lose communication with the Leader boiler. When programmed to YES, it is recommended that the Member 1 boiler have its own set of external sensors installed (such as the system supply sensor), to maintain the same level of temperature control as with the Leader boiler. - Page 84 21.10.3 ATE AT INIMUM OLTS When programmed for BMS control through the 0 - 10V BMS input or through ModBus/BACnet and the BMS Type is programmed as POWER, the modulation percentage represented by the Volts at Minimum parameter is set by the Rate at Minimum Volts parameter.
-
Page 85: Circulation Pumps
21.10.11 IFFERENTIAL OLTS When programmed for BMS control through the 0 - 10V BMS input or through ModBus/BACnet and the BMS Thermostat Input is set to INACTIVE, the Off Differential Volts parameter determines how far below the On Volts setting the 0 - 10V BMS input voltage must be in order to disable the boiler. The minimum value is 0.2V and the maximum is the On Volts setting. -
Page 86: Service Notification
21.11.7 YSTEM The system pump can be programmed to operate in response to any of the Room Thermostat inputs, or to run continuously until all three (3) SH demands go into Outdoor Shutdown. To program the system pump to operate only with a space heating call for heat, set the System Pump Type parameter to CFH. -
Page 87: Basic Setup
USB-A (rectangular) port next to the display. Once a drive is inserted, the display will search the root directory of this drive for a folder named “Lochinvar”. If it does not find it, the display will ask if you want it to create this folder. -
Page 88: Erp Data Table
22.0 ERP DATA TABLE HCB46CE HCB61CE HCB86CE HCB116CE Type Boiler: Condensing boiler: low temperature boiler: B11 boiler: Cogeneration space heater: Combination heater: Unit: Value Value Value Value Rated heat output 38.5 P-rated (P4) at 60-80C 38.1 51.1 73.1 103.4 Heat output (p1) 30% at 30-37C 17.1 25.4 37.2... -
Page 89: User Instructions
23.0 USER INSTRUCTIONS Once the installation and commissioning is complete, the equipment owner or their representative should be made aware of the operation of the appliance and its safety devices. A practical demonstration should be given describing each functional step. Incorrect use may result in injury and will also invalidate the warranty. 23.1 GENERAL REQUIREMENTS This equipment must be installed by a competent person, registered with an H.S.E. -
Page 90: Smart System Control
23.4 SMART SYSTEM CONTROL USB Drive PC Connection Left select key Navigation dial Reset switch Right select key The information on the bottom of the display shows the functions of the two SELECT keys on both corner, and the NAVIGATION dial in the centre. MENU Left SELECT key SETPOINTS... -
Page 91: Maintenance
23.6 MAINTENANCE See section 19.0 Maintenance 23.7 AIR SUPPLY When installed as a conventionally flued appliance, the room in which the appliance is installed must be ventilated. Blocking these vents may lead to severe injury, serious property damage or death. The area in which the appliance is installed should not be used to store any other materials ...
