nest Learning Installation & Configuration Manual page 28

Switch between Heating,​ ​ C ooling,
and Range modes
Heat Pump:
Setting compressor and auxiliary
lockout temperatures
Heat Pump:
Change heat pump valve
orientation
Adjust ECO Heating and
Cooling Temperatures
Adjust Safety Temperatures
Restart or reset the settings on the
thermostat
To switch to and from heating and cooling modes, follow these steps:
1. Press the ring to bring up the menu
2. Select the Heating and Cooling icon
3. Turn the ring to select HEAT, COOL, HEAT • COOL, or OFF
4. Press the ring again to select
Both auxiliary and compressor lockout temperatures can be changed in the Heat Pump
section of the Equipment Settings menu. By default, the Nest Thermostat will lock out the
auxiliary heater when the outdoor temperature is above 50°F but will not lockout the
compressor at any temperature.
The lockout temperatures are only enforced when the Nest Thermostat is connected to
Wi-Fi so it can track outdoor temperatures.
To access the Heat Pump section of Equipment settings:
1. Press the ring to bring up the menu
2. Turn the ring and select SETTINGS
3. Turn the ring and select EQUIPMENT
4. Turn the ring and select HEAT PUMP
Follow these steps:
1. Press the ring to bring up the menu
2. Turn the ring and select SETTINGS
3. Turn the ring and select EQUIPMENT
4. Turn the ring and select HEAT PUMP
These temperatures are set as the final step during the setup interview. But if the Nest
Thermostat is already configured, here are the steps:
1. Press the ring to bring up the menu
2. Turn the ring and select SETTINGS
3. Turn the ring and select ECO
Turn the ring to set the HEAT TO temperature. Press the ring to set the COOL TO
temperature. Press the ring again when done.
No matter the schedule, the Nest Thermostat will never let the home go above or below
the safety temperatures. To adjust them, follow these steps:
1. Press the ring to bring up the menu
2. Turn the ring and select SETTINGS
3. Turn the ring and select EQUIPMENT
4. Turn the ring and select SAFETY TEMP
You may need to reset the settings if:
You need to restart the thermostat
●
● Reset Nest Sense features
● To help with troubleshooting Wi-Fi issues
● The thermostat needs to be reconfigured
Follow these steps to access the RESET settings:
1. Press the ring to bring up the menu
2. Turn the ring and select SETTINGS
3. Turn the ring and select RESET
4. Select one of the following options: CANCEL, RESTART, SCHEDULE, AUTOAWAY,
NETWORK, ALL SETTINGS
27
