nest Learning Thermostat Installation Manual

REVISION HISTORY
Date Rev Description
11-05-2014 1 EVT release
02-02-2015 4 DVT Release - JC
02-05-2015 5 Removed TBA line in Warranty
02-06-2015 6 p3 cap V; sc H, C pp3, 6; add "Multi-speed...;" added ™s p5, removed "and" p9,
removed "Note" p 10, updated warranty copy.
02-11-2015 7 p3 cap V, cap RH, RC; pp3, 7: reorder "W3, Y3, G3, E, HUM or DEHUM;"
pp5, 10: removed "Amazon App Store;" p11: added FCC Compliance URL
02-12-2015 8 p3: added commas, (C); p10: replaced "pop up" w/ "appear;" p11: removed
"Recycle your old thermostat..."
02-12-2015 9 DVT Release
03-05-2015 10 Added Spanish translations
03-17-2015 11 Removed G2, G3, Y3, "or boiler," "Multi-speed...," "Getting started" page,
moved "Watch the video" to Compatibility page, replaced step 12 w step 12
from D2. LQA edits: added "aceite;" changed "del sector" to "de la industria,"
"Refrigeración" to "Enfriamiento," "en to casa no haya" to "tu casa no tenga
instalado," "Casi nunca..." to "En raras ocasiones...," "uno" to "una." Added
Spanish translations warranty pages.
03-25-2015 12 No change, updated spec.
03-31-2015 13 No BLE: POR
04-08-2015 14 Step 12: changed "Your thermostat..." to "The app will show you..."
04-09-2015 15 Added Spanish translation for Step 12, changed "viejo" to "anterior" p6
04-10-2015 16 Updated illustration p7
