nest Learning Thermostat Installation Manual
Hide thumbs
Also See for Learning Thermostat:
- Installation manual ,
- Installation and configuration manual (34 pages) ,
- Installation manual (7 pages)
Related Manuals for nest Learning Thermostat
Summary of Contents for nest Learning Thermostat
- Page 1 Learning Thermostat Installation Guide...
- Page 2 Compatibility Go to nest.com/works to make sure Nest will work in your home and find out if you’ll need Nest Concierge professional installation. Watch the video Before you install Nest, watch the installation video nest.com/support Questions? Visit support or give us a call at 855-4MY-NEST.
- Page 3 Contents Display Base Nest Screwdriver Wall Screws Optional Trim Plate Steel Plate Screws for Steel Plate...
- Page 4 If your old thermostat is labeled 110V or 220V Jumper wires are short wires between or has thick wires with wire nuts, your system two connectors. Nest doesn’t need them. is high voltage. Not sure? Contact support. An R wire can go into either Rc or Rh.
- Page 5 7. Mark where screws will go 6. Disconnect wires and remove base Use the bubble level to make sure Nest is level. Tip: Wrap the wires around a pencil to keep them from falling into the wall.
- Page 6 Insert the steel plate screws into the long slots on the steel plate. Use the other two short steel screws to attach the Nest base and trim plate to the steel plate.
- Page 7 8. Attach base 9. Connect wires After all wires are connected, make sure they’re flush with the wall. 10. Attach display 11. Switch power back on Press the display until it clicks into place. Breaker Box Switch...
- Page 8 12. Setup and Nest Account Nest will turn on and start setup. Turn the ring and press to select. Connect Nest to Wi-Fi during setup, then visit nest.com/home to create a Nest Account so you can control Nest from anywhere.
- Page 9 Federal Communications This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These Commission (FCC) limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 10 Industry Canada (IC) This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: Compliance Notice: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence.
