ESI ESRTP5 User Instructions

Programmable room thermostat
Hide thumbs Also See for ESRTP5:
Table of Contents

Advertisement

Quick Links

See also: User Manual and Installation Instructions , Instruction and Installation Manual
ESRTP5
Programmable Room
Thermostat
User Instructions

Advertisement

Table of Contents
loading

Related Manuals for ESI ESRTP5

Summary of Contents for ESI ESRTP5

  • Page 1 ESRTP5 Programmable Room Thermostat User Instructions...
  • Page 2 Thank you for choosing ESi Controls. All our products are tested in the UK so we are confident this product will reach you in perfect condition and give you many years of service. However, for additional peace of mind, we recommend you register your product online at www.esicontrols.co.uk/warranty for your...

  • Page 3: Table Of Contents

    Contents User Instructions 1. Quick Operating Guides Display and Button Functions Quick Command Guide 2. Setting the Time and Date (tInE) 3. Operation Modes Auto Manual 3.1.1 Off / Frost Protection 3.1.2 All Day Mode (AL) Holiday Mode (HOLI) 4. Main Menu Copy Function (CoPy) Backlight On/Off (LiGH) Resetting the Unit (rESE)

  • Page 5: User Instructions

    User Instructions...

  • Page 6: Quick Operating Guides

    1. Quick operating guide Display and Button Functions Temperature, time and data display Auto operation mode Off / Frost protection mode Manual operation mode Flame symbol when system calling for heat Cancels and returns to the previous menu Either confirms and saves the setting, or moves you to next option within a function Dial to adjust temperature and parameters...

  • Page 7: Quick Command Guide

    Quick Command Guide...

  • Page 8: Setting The Time And Date (Tine)

    2. Setting the time and date (tInE) N.B. Please note, when first powered or in the event of a power loss the time will be flashing and the time and date will need to be set. Follow steps 2-6 to set the time on first setup.

  • Page 9: Operation Modes

    3. Operation modes Operation Modes: AUTO, MAN, OFF. Press in homescreen to choose operation mode. AUTO • In Auto mode, choose All Day mode. See section 3.2 for details. • In Auto mode, choose Holiday mode. See section 3.3 for details. •...

  • Page 10: Manual

    Temporary set temperature range: 5°C-35°C. N.B: The temporary set temperature will not replace the original program event’s set temperature. When the program event ends, it will return to the default heating program automatically. 3.1.1 Permanent manual override of set temperature. 1.

  • Page 11: Holiday Mode (Holi)

    Heating under All Day mode will be on until 23:59 that day. At 23:59, the unit will exit All Day mode and return to Auto mode. Set temperature range: 5°C-35°C. Holiday Mode (HOLI) 1. In homescreen, press to select Auto mode 2.

  • Page 12: Main Menu

    4. Main menu In the homescreen, press and hold until the displays shows tInE then release to enter main menu. Use the dial to choose between tInE, ProG, CoPy, LiGH, tEcH and rESE. Press enter desired setting. Press to return to Homescreen. Copy Function (CoPy) The unit is provided with a copy function which allows an adjusted programme to be copied to another day.

  • Page 13: Resetting The Unit (Rese)

    return to previous menu LiGH setting range: Off/On. Default: Off. N.B. It is recommended to leave this setting in the default OFF mode as heat generated by the thermostat’s power supply and LED will affect temperature measurement. A deviation of up to 3.5°C may occur, which will be calibrated automatically by the unit within 30 minutes of first connecting the thermostat.

  • Page 14: Pre-Set Temperatures

    5. Program settings Factory Pre-Set Programme This unit has been designed to be a simple to use thermostat, requiring minimal user intervention with a pre-programmed heating profile. The pre-set heating times and temperatures will suit most people (See table below). Operation setting range: 5/2 day, 7 day, 24 Hour.

  • Page 15: Day

    Pre-Set Temperatures: 7 Day 5.1.2 In 7 day setting, the pre-set settings are the same as the 5/2 Day programme. Pre-Set Temperatures: 24 Hours 5.1.3 In 24hr setting, the pre-set settings are the same as Mon-Sun of the 5/2 Day programme. Setting the Operation Mode (5/2 day, 7 day, 24hr) (ProG) 1.

  • Page 16: 5/2 Day

    5. Turn the dial to adjust temperature (increments of 0.5°c). Then press to save and return to program choice (P1-P6). 6. Repeat steps 3-5 for all time and temperature programs. Then press to return to step 2. Repeat steps 2-6 until all desired days have been programmed then press to return to previous menu or leave for 1 minute...

  • Page 17: Hour

    24 Hour 5.3.3 1. Choose 24 hour operation (See section 5.2 for details). Then press . 2. Turn the dial to choose the program (P1-P6). Then press to enter time setting. 3. Turn the dial to adjust the time (10 minutes increments). Then press to enter temperature setting.
  • Page 18 We are continuously developing our products to bring you the very latest in energy saving technology and simplicity. However, should you have any questions setting up your controls please email us at sales@esicontrols.co.uk or for technical queries call us on our dedicated technical helpline 07539 117468.
  • Page 19 WARNING: Interference with sealed parts renders the guarantee void. In the interests of continuous product improvement we reserve the right to alter designs, specifications and materials without prior notice and cannot accept liability for errors.
  • Page 20 Version 6.10.1...
