Proper Video Termination
Improper termination of the video outputs will result in degradation (ringing, undershoot and/or
overshoot) of the test signals. The following figures show suggested methods for connecting
the video generator to displays having 50 and 75 Ohm input impedances in both differential and
single ended modes of operation.
50 Ohm Differential
75 Ohm Differential
68-00183 Rev. C
50 Ohm Single Ended
75 Ohm Single Ended
