Summary of Contents for Matsui MEH60WH
-
Page 1: Electric Hob
Electric Hob MEH60WH... -
Page 2: Table Of Contents
contents getting to know your hob ....... .3 important safety notes ........4 control panel . -
Page 3: Getting To Know Your Hob
Thank you for choosing the Matsui MEH60WH electric hob. We hope the following information will help you to quickly familiarise yourself with the features of the hob and to use it successfully and safely. Please read this user guide before using the hob and keep it for future reference. -
Page 4: Important Safety Notes
important safety notes We have included this section for your safety. Please read this information carefully before using your electric hob. WARNING: It is hazadous for anyone other than authorised service personal to carry out servicing or repairs which involves the removal of covers. To avoid the risk of an electric shock, do not attempt repairs yourself. - Page 5 important safety notes The electrical safety of this hob is guaranteed only if it is connected to a properly earthed system, which complies with the electrical safety standards in force. If you cannot verify that this fundamental safety requirement is in place, consult a qualified electrician.
-
Page 6: Control Panel
control panel Your electric hob has four hotplates. Each dial has a symbol above it, which indicates which hotplate it controls. The electric hob is designed for operating at 6 different levels. To select upper right hotplate To select upper left hotplate To select lower left rapid heat hotplate To select lower right hotplate The signal light located on the control panel shows... -
Page 7: Instructions For Use
instructions for use Using the hotplates Switch the hotplates on by turning the knob from 1-6, depending on the temperature required, 6 is the highest setting. There are two different types of hotplate. Two for larger cooking pans and two for smaller pans. -
Page 8: Hints And Tips
hints and tips Cookware Use heavy gauge, flat, smooth bottom pans that conform to the diameter of the hotplate. This will provide good contact with the hotplate and help reduce cooking times. Never use plastic or aluminium foil dishes on the hotplates. Clean the hob after every use. -
Page 9: Installation Guide
installation guide WARNING: The electric connection for this appliance should be carried out by a qualified electrician, according to the instructions in this guide and in compliance with the current regulations. In the event of any damage that occurs as a result of improper connection or installation, the warranty will not be valid. - Page 10 installation guide Fitting the hob into a work surface The hob can be fitted into any work surface provided it is heat resistant up to at least 90ºC. Create an opening with the dimensions shown in the picture below. The distance between Installation of 60cm Electric Hob with Side Knob Control Min.
-
Page 11: Making An Electrical Connection
installation guide 20 mm 30-50 mm If there is any self-adhesive seal protruding from the edge of the hob, trim it off, being careful not to scratch the worktop. If the hob is being fitted over a cupboard or drawer unit which has no top panel, a top panel must be fitted. - Page 12 installation guide An approved suitable cable must be connected from the Consumer Unit (main fuse box) and be protected by its own 30amp fuse or Micro Circuit Breaker (MCB). The electrician must provide a fused double-pole switch, which disconnects both the line (live) and neutral conductors.
-
Page 13: Specifications
Model MEH60WH Rated Voltage (V) Rated 'Frequency (Hz) Power (Kw) Current (A) Product Dimensions (cm) External Width External Depth Product Dimensions (cm) Internal Width Internal Depth... - Page 14 This symbol on the product or in the instructions means that your electrical and electronic equipment should be disposed at the end of its life separately from your household waste. There are separate collection systems for recycling in the EU. For more information, please contact the local authority or your retailer where you purchased the product.
