Understanding the Drive LEDs
6
This chapter describes the LEDs on the front panel of the DDS-4 and DAT 72 drives. These LEDs pro-
vide information about both normal and error conditions.
Topics in this chapter are:
"Front Panel LEDs" on page 46
"LED Summary" on page 47
"Clean LED" on page 47
"Media LED" on page 48
"Drive LED" on page 48

Front Panel LEDs

Figure 16 on page 46 shows an example of the LEDs on the drive front panel of the DDS-4 and DAT
72 drives. The external tape drive has the same front-panel LEDs, plus a green Power-On LED.
Front Panel LEDs on Internal Drive (external drive is similar)
FIGURE 16.
46
