Quick Start Installation
2
This chapter provides quick-start instructions for getting the internal or external tape drives up and
running in the shortest possible time.
Topics in this chapter are:
"Tape Drive Components" on page 14
•
"Installing the Internal Tape Drive" on page 15
•
"Installing the External Tape Drive" on page 16
•
NOTE:
installation instructions or Chapter 4 for external drive installation instructions.
Tape Drive Components
The following describes the major components of the tape drives.
FIGURE 2.
Front Panel Components
For more information on LEDs and their meaning, see "Front Panel LEDs" on page 46.
If you prefer more detailed instructions, see Chapter 3 for internal drive
14
