Default settings shown
Front of drive
Internal Tape Drive Switch Settings
FIGURE 4.
SCSI ID
Jumper Pins: 1–2, 3–4, 5–6, 7–8
Default Setting:
Each SCSI device on the bus must have its own unique ID. Your internal tape drive is shipped with a
default SCSI ID of 6. If another SCSI device in the SCSI chain is already using this ID, use jumper
pins 1–2, 3–4, 5–6, and 7–8 to change the drive's SCSI ID. Table 3 lists the SCSI IDs and their cor-
responding jumper settings.
TABLE 3.
SCSI IDs and Corresponding Jumper Settings
SCSI ID
0
1
2
3
4
5
6 (default)
7
8
9
10
11
O
Data compression (DC)
N
SCSI DC control
Media recognition
Self Test
Operating-system
configuration
switches
Wide/Narrow SCSI
Inquiry String support
SCSI ID 6
Jumpers
1–2
3–4
Open
Open
Shunted
Open
Open
Shunted
Shunted
Shunted
Open
Open
Shunted
Open
Open
Shunted
Shunted
Shunted
Open
Open
Shunted
Open
Open
Shunted
Shunted
Shunted
5–6
7–8
Open
Open
Open
Open
Open
Open
Open
Open
Shunted
Open
Shunted
Open
Shunted
Open
Shunted
Open
Open
Shunted
Open
Shunted
Open
Shunted
Open
Shunted
Reviewing Drive Default Settings
